Notice Please read this manual thoroughly and save it for future use before attempting to connect or operate this unit. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without notice. Copyright Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form, in whole or in part, without...
Table of Contents Important Safeguard and Warning ......................4 Front Panel .............................. 6 Rear Panel .............................. 7 Local Login .............................. 8 Web ................................. 9 Appendix Toxic or Hazardous Materials or Elements ................10...
Important Safeguard and Warning All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. We are not liable for any problems caused by unauthorized modifications or attempted repair. Improper battery use may result in fire, explosion, or personal injury! When replace the battery, please make sure you are using the same model! Note...
Page 5
4. Turn the device upside down 6. Connect the HDD cable and Fix the HDD firmly. and then turn the screws in power cable. firmly. in the chassis. 7. Put the cover in accordance 8. Secure the screws in the with the clip and then place the rear panel and the side panel.
Front Panel The front panel is shown as in Figure 1. Figure 1 Please refer to the following sheet for detailed information. Name Function HDD status indictor light The red light becomes on when HDD is abnormal. The red light becomes on when the power connection Power indicator light is OK.
Rear Panel For detailed operation instruction of other series product, please refer to the User’s Manual included in the resources CD. The product rear panel is shown as below. See Figure 2. Figure 2 Please refer to the following sheet for detailed information. Port Name Connection Function...
Local Login After system booted up, default video display is in multiple-window mode. Click Enter or left click mouse, you can see the login interface. See Figure 3. System consists of one account: Username: admin. Password: admin. (administrator, local and network) Note For security reason, please modify password after you first login.
Open IE and input NVR address in the address column. For example, if your NVR IP is 10.10.3.16, then please input http:// 10.10.3.16 in IE address column. System pops up warning information to ask you whether install control or not. Please click Install button.
Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ (Panel) ○ ○ ○ ○ ○ ○...
