- Page 1 Network Video Recorder HOLNVR08xxx HOLNVR08xxx8P Quick Start Guide 8200-1104-02 B0...
- Page 2 Notice Please read this manual thoroughly and save it for future use before attempting to connect or operate this unit. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without notice. Copyright Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form, in whole or in part, without...
-
Page 3: Table Of Contents
Table of Contents Important Safeguards and Warnings ......................iii Hardware Installation and Connection ....................1 Check Unpacked NVR ........................1 About Front Panel and Rear Panel ....................1 After Remove the Chassis ......................1 HDD Installation ..........................1 Front Panel ............................. 3 Rear Panel ............................ -
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation. - Page 5 Do not put other devices on the top of the NVR； Be installed in well ventilated place; do not block the vent. Accessories Check the accessories after opening the box： Please refer to the packing list in the box *...
-
Page 6: Hardware Installation And Connection
Hardware Installation and Connection Note All the installation and operations should conform to your local electric safety rules. Check Unpacked NVR When you receive the NVR from the forwarding agent, please check whether there is any visible damage. The protective materials used for the package of the NVR can protect most accidental clashes during transportation. - Page 7 1. Use the screwdriver to loose the screws of the rear panel and then remove the front cover. 2. Put the HDD to the HDD bracket in the chassis and then line up the four screws to the four holes in the HDD.
-
Page 8: Front Panel
Front Panel For detailed operation instruction, please refer to the User’s Manual included in the resources CD. The front panel is shown as in Figure . Figure 1 Please refer to the following sheet for front panel button information. Name Icon Function Power button, press this button for three seconds to boot up or... - Page 9 Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous character before the cursor. In motion detection setup, working with Fn and direction keys to realize setup. In text mode, click it to switch between numeral, English character(small/capitalized) and etc.
-
Page 10: Rear Panel
Rear Panel For detailed operation instruction, please refer to the User Manual included in the resources CD. The rear panel is shown as below. See Figure 2. Figure 2 Please refer to the following sheet for detailed information. Name Function Power Power on/off button. - Page 11 Name Function RS485_A port. It is the cable A. You can connect to the RS-485 control devices such as speed dome PTZ. communication RS485_B.It is the cable B. You can connect to the control port devices such as speed dome PTZ. 10M/100M/1000Mbps self-adaptive Ethernet...
-
Page 12: Connection Sample
Connection Sample For detailed operation instruction, please refer to the User’s Manual included in the resources CD. See Figure . Figure 3... -
Page 13: Gui Operation
GUI Operation Connect the device to the monitor and then connect a mouse and power cable. Click the power button at the rear panel and then boot up the device to view the video output. You can use the mouse to implement some GUI operation. -
Page 14: Remote Device
Figure 5 Note For security reason, please modify password after you first login. Within 30 minutes, three times login failure will result in system alarm and five times login failure will result in account lock! Remote Device From Main menu->Setting->Camera->Remote device or right click mouse on the preview interface and then select remote device item, you can see the following interface. - Page 15 Click Manual Add button, you can add a device directly. See Figure . Note Please note the manual add function is for Holis, Dahua, Panasonic, Sony, Dynacolor, Samsung, AXIS, Arecont, ONVIF and custom. When the type is the custom, you can just input URL address, user name and password connect to the network camera without considering network camera manufacture.
-
Page 16: Schedule
Schedule Note You need to have proper rights to implement the following operations. Please make sure the HDDs have been properly installed. After the system booted up, it is in default 24-hour regular mode. You can set record type and time in schedule interface. - Page 17 Select a channel you want to set. See Figure . Figure 9 Set record type. See Figure . Figure 10 Please draw manually to set record period. There are six periods in one day. See Figure . Figure 11 Please check the box to select the corresponding function.
-
Page 18: Real Time Playback
Figure 12 Figure 13 Real time Playback Preview control interface Move you mouse to the top centre of the video of current channel, you can see system pops up the preview control interface. See Figure . If your mouse stays in this area for more than 6 seconds and has no operation, the control bar automatically hides. - Page 19 Figure 14 Name Name Name Realtime Digital zoom Manual record playback Manual Bidirectional Remote device Snapshot talk Realtime playback button is to playback the previous 5-60 minutes record of current channel. Please go to the Main Menu->Setting->System->General to set real-time playback time. System may pop up a dialogue box if there is no such record in current channel.
-
Page 20: Web Operation
Web Operation Note Slightly difference may be found in the interface due to different series. The following operation is based 32-channel series product. This series NVR product support the Web access and management via PC. Web includes several modules: Monitor channel preview, record search, alarm setup, system configuration, PTZ control, monitor window and etc. -
Page 21: Login
After you insert PoE, system follows the principles listed below to map channel. a) If it is your first time to insert PoE, system can map it to the first idle channel. After map, the channel can memorize the MAC address of the IPC. It is a <Channel>---<IPC mac> map. If current channel does not connect to other device, system can memorize current MAC address, otherwise it can refresh to the newly added device and memorize the <PoE port>---<Channel>. -
Page 22: Main Window
Figure 15 Main Window LAN Login For the LAN mode, after you logged in, you can see the main window. See Figure . Click the channel name on the left side; you can view the real-time video. Figure 16 WAN Login In WAN mode, after you logged in, the interface is shown as below. -
Page 23: Appendix Toxic Or Hazardous Materials Or Elements
Figure 17 For detailed operation information, please refer to the User Manual included in the resources CD. Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○... - Page 24 not leak or mutate so that the use of these (substances or elements) will not result in any severe environmental pollution, any bodily injury or damage to any assets. The consumer is not authorized to process such kind of substances or elements, please return to the corresponding local authorities to process according to your local government statutes.
