SERVICE
Samsung Color Laser Printer
CLP-350N
CLP-350N
CLP-350N/XAA
Basic Model : CLP-350N
Manual
The keynote of Product
High Performance /
High Quality Muti-path CLBP
- Model : only CLP 350N
- Speed(Color/Mono) : 5/20ppm(A4). 5/19ppm(Let)
- Printing resolution : 2,400 x 600 dpi
- Emulation : PCL6/PS3
- Memory expansion => Max.128MB
- Processor : 300MHz
- Interface : IEEE 802.3,Ethernet(10/100Mbps)
Wireless: Not Supported
- Toner Cartridge :
4K Toner(K), 2K toner(C, M, Y each)
- Printer Life : 200,000 pages
Monthly Max. Duty : 25,000 pages/month

Advertisement

Table Of Contents

Troubleshooting

   Related Manuals for Samsung CLP-350N

   Summary of Contents for Samsung CLP-350N

  • Page 1: Service Manual

    CLP-350N CLP-350N/XAA Basic Model : CLP-350N SERVICE Manual Samsung Color Laser Printer The keynote of Product High Performance / High Quality Muti-path CLBP - Model : only CLP 350N - Speed(Color/Mono) : 5/20ppm(A4). 5/19ppm(Let) - Printing resolution : 2,400 x 600 dpi - Emulation : PCL6/PS3 - Memory expansion =>...

  • Page 2: Table Of Contents

    Contents 1. Precautions 1.1 Safety Warning 1.2 Caution for safety 1.3 ESD Precautions 2. Product Specification 2.1 Product Specifications 2.1.1 Product Overview 2.1.2 Specifications 2.1.3 Model Comparison Table 2.2 System Overview 2.2.1 System Structure 2.2.2 Main PBA Description 2-14 2.2.3 CRUM 2-24 2.2.4 General Description 2-26...

  • Page 3

    Continued 3.4.2 Fuser Unit 3-12 3.4.3 LSU Unit 3-13 3.4.4 HVPS Board 3-13 3.4.5 Main Board 3-14 3.4.6 Drive Unit 3-14 3.4.7 SMPS Board 3-15 3.4.8 Transfer Unit 3-15 4. Alignment & Troubleshooting 4.1 Alignment and Adjustments 4.1.1 Control Panel 4.1.2 Function 4.1.3 Jam Removal 4.1.4 Sample Pattern...

  • Page 4

    Continued 5.1 Main 5.2 Cover Unit 5.3 Top Cover 5.4.1 Rear Cover 5.4.2 Transfer Unit 5-10 5.5 Frame 5-12 5.6 LSU Cover 5-16 5.7 Fuser Ass'y 5-18 5.8 Main Drive 5-20 5.9 Cartridge-Transfer 5-24 5.10 Cartridge-Drum 5-27 5.11 Toner BK 5-29 5.12 Toner CMY 5-31...

  • Page 5

    Continued 7.2 Acronyms and Abbreviations 7.3 Select a location for the printer 7.4 A4 ISO 19752 Standard Pattern...

  • Page 6: Precautions

    High voltages and lasers inside this product are dangerous. This printer should only be serviced by a suitably trained and qualified service engineer. (2) Use only Samsung replacement parts There are no user serviceable parts inside the printer. Do not make any unauthorized changes or additions to the printer, these could cause the printer to malfunction and create electric shock or fire hazards.

  • Page 7: Caution For Safety

    Take care not to cut or damage the power cable or plugs when moving the machine. (9) Use caution during thunder or lightening storms. Samsung recommend that this machine be disconnected from the power source when such weather conditions are expected. Do not touch the machine or the power cord if it is still connected to the wall socket in these weather conditions.

  • Page 8: Handling Precautions

    1.2.4 Assembly / Disassembly Precautions Replace parts carefully, always use Samsung parts. Take care to note the exact location of parts and also cable routing before dismantling any part of the machine. Ensure all parts and cables are replaced correctly.

  • Page 9: Disregarding This Warning May Cause Bodily Injury

    Failure to do so could cause the printer to tip or fall possibly causing personal injury or damaging the printer. (5) Do not install the printer on a sloping or unstable surface. After installation, double check that the printer is stable. Service Manual Samsung Electronics...

  • Page 10: Esd Precautions

    9. Minimize bodily motions when handling unpackaged replacement ESDs. Normal motions, such as the brushing together of clothing fabric and lifting one’s foot from a carpeted floor, can generate static electricity sufficient to damage an ESD. Service Manual Samsung Electronics...

  • Page 11: Product Specification

    2. Product specification and feature 2.1 Product Specifications 2.1.1 Product Overview Item Descriptions Basic Model CLP-350N Maket of Sales Main Target : Reseller Black only Function(Saving money) Main Specification 1.Speed Up to 20 ppm in A4 (19 ppm in Letter) Up to 5 ppm in A4 (5 ppm in Letter) 2.Printing Resolution...

  • Page 12: Specifications

    Specifications are correct at the time of printing. Product specifications are subject to change without notice. See below for product specifications. 2.1.2.1 General Specifications Item CLP-350N Engine Speed Simplex Up to 20 ppm in A4 (19 ppm in Letter) Up to 5 ppm in A4 (5 ppm in Letter)

  • Page 13

    Supporting OS Windows 2000/XP/2003/Vista/98/Me/NT 4.0 Various Linux OS including Red Hat 8.0~9.0, Mandrake 9.2~10.1, SuSE 8.2~9.2 and Fedora Core 1~4 Mac OS 10.3 ,10.4 Default Driver SPL-C (Samsung Printer Language Color), PCL6, PS3 Driver feature Watermark Overlay N-up printing Poster printing...

  • Page 14: Paper Handling

    Product specification and feature 2.1.2.3 Paper Handling Item CLP-350N Standard Capa. 150-sheet Semi Cassette Tray Max. Capa. 150 sheets @ 75g/ Printing Max. Size 216 x 356mm (8.5" x 14") Min. Size 76 x 127 mm (3" x 5") Margin(T/B/L/R)

  • Page 15

    Product specification and feature 2.1.2.4 Consumables Item CLP-350N No. of CRUs 6 (C/M/Y/K toner, Imaging Unit, Waste toner container) K toner cartridge: CLP-K350A C toner cartridge: CLP-C350A M toner cartridge: CLP-M350A Y toner cartridge: CLP-Y350A Imaging unit : CLP-R350A Waste toner container: CLP-W300A...

  • Page 16

    Product specification and feature 2.1.2.5 Environment Item CLP-350N Acoustic Noise Level Printing Less than 48.0 dBA (Color printing) (Sound Power/Pressure) Less than 49.0 dBA (B/W printing) Standby Less than 35 dBA Sleep Background noise level Input Voltages 110-120 VAC, 50/60Hz...

  • Page 17: Model Comparison Table

    Product specification and feature 2.1.3 Model Comparison Table Item Magicolor 2400W CLP-350N Print Method: Electro photographic laser Electro photographic laser Print Speed: 5 ppm colour/ 20 ppm monochrome 5 ppm colour/ 19 ppm monochrome Resolution: 2400 x 600 ; 1200 x 600 ; 600 x 600...

  • Page 18: System Overview

    Product specification and feature 2.2 System Overview This chapter describes the functions and operating principles of the main components. 2.2.1 System Structure 2.2.1.1 Main Parts of System Service Manual Samsung Electronics...

  • Page 19

    It is a power delivery unit by gearing By driving the motor, it supplies the power to the feeding unit, the fusing unit, and the distributing unit. The Main Motor is similar to CLP-300 Series Main Motor. Service Manual Samsung Electronics...

  • Page 20

    Blade on OPC on OPC ITB Unit ITB Unit P2: Image P2: Image on Media on Media Media Path Media Path Blade Blade Developer Developer Eraser Eraser Charger Charger Laser Scanning Unit Laser Scanning Unit Service Manual 2-10 Samsung Electronics...

  • Page 21

    2. No ozone is produced because corona is not used 3. Charger roll is cleaned with cleaning roll 4. Toner remained on OPC after T1 process is cleaned by cleaning blade and retrieved into waste toner box by auger and belt driving mechanism Service Manual 2-11 Samsung Electronics...

  • Page 22

    3. 4 times of T1 process is required to make a color image on ITB, which means multi-pass process 4. ITB has a hole as a fiducial mark for timing. Engine control for color image is synchronous with it, ITB Home Sensing Signal Service Manual 2-12 Samsung Electronics...

  • Page 23

    T2 Roll engagement and disengagement Fusing 3 Roll system -> short warm-up time (38sec) Post Pressure Roll 1. Color Image on media is melted down and fixed into media by fusing process Service Manual 2-13 Samsung Electronics...

  • Page 24: Main Pba Description

    Product specification and feature 2.2.2 Main PBA Description 2.2.2.1 Main Controller PBA Service Manual 2-14 Samsung Electronics...

  • Page 25

    Product specification and feature 2.2.2.2 Main PBA Service Manual 2-15 Samsung Electronics...

  • Page 26

    5 Banks, Up to 128MB Address space per Bank Programmable Timing to Control SDRAM A.C Characteristics Support Self Refresh for Data Retention ROM Controller 32-bit width, 4 Banks, Up to 16MB Address space per Bank Burst Capability Programmable Timing per Bank Service Manual 2-16 Samsung Electronics...

  • Page 27

    1 Channel, Operated at max frequency 400kHz RTC Controller Engine Controller LSU Control and Interface Unit 2 Channels STEP Motor Control Unit 8 Channels PWM Control Unit 8 Channels ADC Control Unit 2 Channels DAC Control Unit Service Manual 2-17 Samsung Electronics...

  • Page 28

    Product specification and feature CHORUSm (Internal Block Diagram) Service Manual 2-18 Samsung Electronics...

  • Page 29

    GPIO controller built in CHORUSm collects the status of all sensors. According to this status of sensors, it controls printer mechanism to help normal printing. There are sensors such as Paper Empty Sensor, Registration Sensor and Developer Home Sensor, etc. Service Manual 2-19 Samsung Electronics...

  • Page 30

    1st and 2nd transfer voltage and current, fusing temperature, used-up toner and toner amount, and interior temperature, etc. 14) DAC Control It is controlled by DAC Controller built in CHORUSm and used to set standard level of light amount of LSU Laser Diode. Service Manual 2-20 Samsung Electronics...

  • Page 31

    2) AC Output Fuser Unit(Heat Lamp, Thermostat) 3) Output Voltage CHANNEL +5.0V +24V +24VF V_out +5.0V +/-5% +24.0V +15%/-10% +24.0V +15%/-10% Load MicroController, MOTOR, CLUTCH, CMOS, LOGIC HVPS CON3 To Main PBA CON1 AC Input Service Manual 2-21 Samsung Electronics...

  • Page 32

    HVPS PBA generates high voltage of charger, supply, T1 and T2 which is supplied to Developer, ensuring optimum condition for image formation. HVPS receives input of 24V and generates high voltage, supplying it to Toner, OPC, Cartridge, ITB Unit and Transfer Roller. Service Manual 2-22 Samsung Electronics...

  • Page 33

    1.5% (supply voltage is connected to ZENER Diode 350V) DC -50V ~ -600V DC ERROR type: 1. if Deve is GND, density will be extremely down. 2. if Deve is floating (for insecure terminal contact), density will be extremely down. Service Manual 2-23 Samsung Electronics...

  • Page 34: Crum

    2) Copy the information of Operating Area into Back up Area. 3) Write-Protect Back up Area. 4) Clear some information of Operation Area. -> Supplier/Model Name/MFC date/Serial Number (Manufacture Information) -> Let cartridge refiller initialize manufacture information and life span information. Service Manual 2-24 Samsung Electronics...

  • Page 35

    Product specification and feature CRUM Position Agitator Washer Bottle Cap- CRUM Agitator Seal CRUM Coupling Service Manual 2-25 Samsung Electronics...

  • Page 36: General Description

    Product specification and feature 2.2.4 General Description This chapter is the product specification for the CLP-350N. The CLP-350N is a Color Laser Printer. CLP-350N is developed for two target users. Those are small office users who sometimes need color printouts, and medium business users who mainly use B/W printouts.

  • Page 37

    No LCD, 1 keys and 5LEDs 2.2.4.7 Periodic Replacing Parts Samsung shall specify parts requiring replacement and the frequency of replacement. The parts identified may be deemed customer replaceable parts. Periodic replacement parts shall be recommended as follows * Average A4-/letter-sized page count based on Std. ISO 19752 of individual colors on each page. Usage conditions and print patterns may cause results to vary.

  • Page 38: Power Switch

    - Deve-Home 2.2.4.11 CRUMS The CLP-350N engine will be equipped with electronics that can read and write data into NVRAMs otherwise known as CRUMs that reside within 1) C, M, Y, K Toner cartridges and 2) Imaging kit(Developer, OPC, ITB). The CRUM has a company ID, and Samsunga electronics logo.

  • Page 39: Printer Driver

    F/W. Hence the Status Monitor can stop polling because the Printer F/W informs the Status Monitor that printing job is complete. 2.3.3 Status Monitor Status Monitor has no user interface. It shows only HTML help when any error occurs during printing jobs. Service Manual 2-29 Samsung Electronics...

  • Page 40: Network Interface

    Help to the user although the error has occurred while printing. Set option value enable/disable Set last error status polling interval System Status Monitor Printer Driver Registry Get option value Get last error status enable/disable polling interval Service Manual 2-30 Samsung Electronics...

  • Page 41

    Color Registration measure Auto Color Registration pattern printing Video data Color Registration adjustment P Sync. Page Sync. modify Video signal L Sync. Line Sync. modify generator clock Video Clock Freq. modify temperat temperature control sensor Service Manual 2-31 Samsung Electronics...

  • Page 42: Alarm Shortage

    SCF Cove Open 4. Service Call : Unrecoverable Error Engine LSU Error Main Motor Error Engine Fuser Over(Low) Heat Error + Open Heat Error Transfer Belt Error 5. Others Memory Overflow Error Ready IP Conflict Service Manual 2-32 Samsung Electronics...

  • Page 43: Crum Overview

    Product specification and feature 2.3.9 CRUM Overview - Stands for “Customer Replaceable Unit Monitor” - EEPROM, SAMSUNG CRUM is used for CRUM Memory. - CRUM stores various information on consumables (including consumables’ life). - In CLP350N, total five CRUM’s are used...

  • Page 44: Initailize Flow

    Product specification and feature 2.3.11 Initailize Flow Service Manual 2-34 Samsung Electronics...

  • Page 45

    Product specification and feature Service Manual 2-35 Samsung Electronics...

  • Page 46: Disassembly And Reassembly

    3.4 Disassembly Procedure page(3-10) 3.4.1 Cover Unit page(3-10) 3.4.2 Fuser Unit page(3-12) 3.4.3 LSU Unit page(3-13) 3.4.4 HVPS Board page(3-13) 3.4.5 Main Board page(3-14) 3.4.6 Drive Unit page(3-14) 3.4.7 SMPS Board page(3-15) 3.4.8 Transfer Unit page(3-15) Service Manual Samsung Electronics...

  • Page 47: Precautions When Replacing Parts

    3.1.1 Precautions when assembling and disassembling * Use only approved Samsung spare parts. Ensure that part number, product name, any voltage, current or temperature rating are correct. Failure to do so could result in damage to the machine, circuit overload, fire or electric shock.

  • Page 48: Parts For Maintenance And Repair

    ** Image counts based on one color on each page. If you print documents in full color (Cyan, Magenta, Yellow, Black), the life of this item will be reduced by 25%. Service Manual Samsung Electronics...

  • Page 49: Printer Cleaning

    * Do not touch transfer roller when cleaning inside of machine. If transfer roller gets dirty, printing quality could be low. * Please refer to the User Manual for cleaning instructions. Service Manual Samsung Electronics...

  • Page 50: Information Related To Disassembly And Assembly

    (hot water sets the toner). Do not ing the fuser. touch the developer roller surface as cont- amination will reduce print quality. Take care not to damage the roller's surface when installing or removing a toner car- tridge. Service Manual Samsung Electronics...

  • Page 51: Screws Used In The Printer

    UNIT MPF + BRACKET-MPF MEA-ASSY-MPF + GUIDE-PAPER-MP MEA-UNIT FRAME BASE + MEA-ASSY-MPF 6003-000261 SCREW-TAPTITE;BH,+,B,M3,L6, HOUSING-OPC ZPC(YEL),SWRCH18A 6003-000282 SCREW-TAPTITE;BH,+,B,M3,L8, F/M_Upper-Fuser + C/M_Carbon-Brush ZPC(BLK),SWCH10 FRAME ASSY FRAME-PTB ASS'Y COVER-M-OP FRAME LED + Cover DECO COVER-M-OP FRAME LED + LED PBA Service Manual Samsung Electronics...

  • Page 52

    SUB MAIN FRAME + DRIVE unit SUB MAIN FRAME + HOUSING MIDDLE PART SUB MAIN FRAME + HVPS PBA SUB MAIN FRAME + LINK FRONT(COVER RIGHT) UNIT DUCT LEFT+ HOUSING MIDDLE PART COVER_FRAME-FUSER + BRACKET_GUIDE-FRAME COVER_M_EXIT-ROLLER + COVER_M_SIDE-L/R Service Manual Samsung Electronics...

  • Page 53

    SUB MAIN FRAME + COVER EXIT GUIDE Sub Main Frame + Link Rear 1 MEA FRAME BASE + MPF unit(right) MEA-UNIT FRAME BASE + CAM-CATCH MEA-UNIT FRAME BASE + IPR-BRKT BASE BAR BRKT-GEAR-TRAY + BRKT-HOLDER-PICKUP FRAME-BASE-MP + BRACKET-GEAR-TRAY FRAME-BASE-MP + PLATE-GROUND BRACKET Service Manual Samsung Electronics...

  • Page 54

    Disassembly and Reassembly SEC CODE DESCRIPTION & SPECIFICATION LOCATION QT'Y MPF UNIT ASS'Y + SOLENOID FRAME-P-REGI + COVER-M-REGI-FRAME FRAME-P-REGI + FRAME-PICK-UP FRAME-PICK-UP + GUIDE-GEAR-BRACKET SOLENOID-MAIN + GUIDE-GEAR-BRACKET HOLDER SENSOR + FRAME-P-REGI 6003-000264 SCREW-TAPTITE;PWH,+,B,M3, COVER-INNER-MP + GEAR-PINION L6,ZPC(YEL),SWRCH18 Service Manual Samsung Electronics...

  • Page 55: Disassembly Procedure

    3.4.1 Cover Unit 1.Take out the Cassette. 3. Remove the Imagine Unit. 2. Open the Front-Cover. 4. Remove the ITB Unit. When reassembling, reassemble ITB Unit to the direction of arrow ( from down to up ) Service Manual 3-10 Samsung Electronics...

  • Page 56

    8. Release the Right-Cover from the SET. 6. Remove the one screw from the Right-Cover. 9. In the same way, release the Left-Cover from the SET. 7. Remove the one screw from the rear of the Right- Cover. Service Manual 3-11 Samsung Electronics...

  • Page 57: Fuser Unit

    Disassembly and Reassembly 3.4.2 Fuser Unit 1. Remove the 4 screws on the Fuser. 3. Take out the Fuser Ass’y. 2. Push the Holder shaft Fuser as shown below . Service Manual 3-12 Samsung Electronics...

  • Page 58: Lsu Unit

    2. Unplug the Harness (2 EA), remove the 3 screws and release the LSU from the SET. 3.4.4 HVPS Board 1. Unplug the Harness (2 EA), remove the 6 screws, and 2. Unplug the Harness from the HVPS. take out the HVPS. Service Manual 3-13 Samsung Electronics...

  • Page 59: Main Board

    1. Unplug all the Harness from the Main board, remove the 5 screws and release the Main board from the SET. 3.4.6 Drive Unit 1. Remove the 10 screws and release the Drive Ass’y from the SET. Service Manual 3-14 Samsung Electronics...

  • Page 60: Smps Board

    Disassembly and Reassembly 3.4.7 SMPS Board 1. Unplug the Harness (2 EA), remove the 4 screws and release the SMPS board from the SET. 3.4.8 Transfer Unit 1. Take out the Transfer Unit. Service Manual 3-15 Samsung Electronics...

  • Page 61: Alignment And Adjustments

    4.1.1.1 Overview - The CLP-350N printers do not have LCD panel which is used in other color model printers. On the con- trary to other models of color printers, they show the status of the printer only with their LEDs.

  • Page 62: Function

    - Start manual feeding function When you select manual feed for paper source, press this button each time you feed a sheet of paper manually. The application of manual feeding function in CLP-300 will be determined Service Manual Samsung Electronics...

  • Page 63: Led Function

    LED control order 1) Control LED according to current printer state : After the panel task is received each event, the LED operation is controlled by current printer status. 2) Write LED value to GOP (General Output Port) Service Manual Samsung Electronics...

  • Page 64

    Scanner Error P Motor Error All LEDs (Toner low LEDs, Status (Green) LED) blink a time interval of 1 second. H Sync Error All LEDs (Toner low LEDs, Status(Green) LED) blink a time interval of 4 seconds. Service Manual Samsung Electronics...

  • Page 65

    After Status (Red) LED blinks seven times, Toner low LEDs blink one time. After Status (Red) LED blinks eight times, Toner low LEDs blink one time. After Status (Red) LED blinks nine times, Toner low LEDs blink one time. Service Manual Samsung Electronics...

  • Page 66: Jam Removal

    Most of the jammed paper can be removed in this step. If you cannot find the jammed paper, or if there is any resistance removing the paper, stop pulling and go to the next step. Service Manual Samsung Electronics...

  • Page 67

    6. Open and then close the rear cover or front 4. Holding the inner cover open, carefully take the cover to resume printing. jammed paper out of the printer. The inner cover will then close automatically. Service Manual Samsung Electronics...

  • Page 68: Tips For Avoiding Paper Jams

    • Do not use creased, damp, or highly curled paper. • Do not mix paper types in a tray. • Use only recommended print materials. • Ensure that the recommended print side of print materials is facing up in the paper tray. Service Manual Samsung Electronics...

  • Page 69: Sample Pattern

    You can print a configuration page from the printer’s control panel. Use the configuration page to view the current settings, to help troubleshoot problems. To print a configuration page: In ready mode, press and hold the Stop button on the control panel for 5 seconds. A configuration page prints out. Service Manual Samsung Electronics...

  • Page 70: Periodic Defective Image

    White Spot, Horizontal black band Transfer Roller 32.7mm Ghost, Damaged Image by abnormal tranfer Transfer Roller 57.5mm Ghost, Damaged Image by abnormal tranfer Pressure Roller 50.3mm Background Heat Roller 86.4mm Black Spots or Vertical Black Band Service Manual 4-10 Samsung Electronics...

  • Page 71: How To Use Edc (engine Diagnostic Control) Mode

    LSU. 4.1.6.1 Enterence When trying to check the CLP-350N EDC Mode, additional EDC execution program needed. [ Procedure of EDC Mode operation ] a) First, turn on the Power of Printer, wait until Ready state...

  • Page 72

    If paper exists in the tray, "With Paper" will be displayed. If not, "Without Paper" message will be. Tray2 Empty If paper exists in the tray, "With Paper" will be displayed. If not, "Without Paper" message will be. Service Manual 4-12 Samsung Electronics...

  • Page 73

    When select key is pushed, Eraser On message will be displayed . If not, Eraser Off message will be. Fuser When select key is pushed, Fuser On message will be displayed. If not, Fuser Off message will be. Service Manual 4-13 Samsung Electronics...

  • Page 74

    Duty : 50% -> 2552V , Range : 264V ~ 4730V Supply DC Duty : 50% -> -269V , Range : -1V ~ -591V AC, Vpp Duty : 50%-> 1210V , Range : 800V ~ 2160V Service Manual 4-14 Samsung Electronics...

  • Page 75

    Paper is not picked up Cover Open /Close, When you still want to continue printing - Paper Jam inside printer There is a paper inside printer After cover Open , Paper must be removed, and then close the cover Service Manual 4-15 Samsung Electronics...

  • Page 76

    Home of Development is not checked or checked at the abnormal time Clutch of Development or Main board must be checked - ADC not Confirm Error Signal of confirmation for ADC is not detected Main board must be checked Service Manual 4-16 Samsung Electronics...

  • Page 77: Error Message

    The blinking toner cartridge is totally exhausted. Remove the old toner cartridge and install a new one. The blinking toner cartridge is wrong. Only install a Samsung toner cartridge, designed for your printer. A paper jam has occurred. To solve the problem.

  • Page 78: Itb Unit Reset

    1. If your printer become special condition, the Reset Count button will display on the Smart panel. At that time, click the button. 2. And then the pop-up below appears. . If you enter the ITB S/N and click Apply , the count will be clear. ( Max 2 times ) Service Manual 4-18 Samsung Electronics...

  • Page 79

    Adjustment and Troubleshooting 3. After reboot the your computer, you can check the cleared count as shown the picture below. Service Manual 4-19 Samsung Electronics...

  • Page 80: Troubleshooting

    - No Power LED Panel - Power Module error - Main PBA Indicate Status LED Refer to "Red Lamp ON" Green OK? "4.1.2.2 LED Function" Print(test pattern) printing Refer to "Solution Quality is of Image Problem" Nomal? Service Manual 4-20 Samsung Electronics...

  • Page 81: Troubleshooting Checklist

    If completing the checklist does not See "Solving General Printing Problems" resolve the printer problem, check See "Solving Print Quality Problems" the following troubleshooting See "Common Windows Problems" sections. See "Common Macintosh Problems" See "Common Linux Problems" Service Manual 4-21 Samsung Electronics...

  • Page 82: Solving General Printing Problems

    The printer is not Check the power switch and the receiving power. power source. The printer is not Select Samsung CLP-300 Series selected as the default printer. as your default printer. Check the printer for the following: ・Close the printer cover.

  • Page 83

    The printer driver Software Section. Try printing a may be incorrectly installed. test page. Check the LEDs on the control The printer is malfunctioning. panel to determine if the printer is indicating a system error. Service Manual 4-23 Samsung Electronics...

  • Page 84

    Paper has been loaded incorrectly. Check that the paper guides are set correctly. Remove excess paper from the There is too much paper in the tray. tray. Use only paper that meets printer The paper is too thick. specifications. Service Manual 4-24 Samsung Electronics...

  • Page 85

    5 ppm in color mode. From the Start menu, choose If using Windows 98/Me, the Settings and Printers. Right-click Spooling Setting may be set the Samsung CLP-350N Series incorrectly. printer icon, choose Properties, click the Details tab, and then choose the Spool Settings button.

  • Page 86

    Or, ensure that the paper size in the printer driver settings matches the paper selection in the software application settings you use. Service Manual 4-26 Samsung Electronics...

  • Page 87

    An incorrect type of Use only paper that meets printer paper is being used. specifications. After opening the front cover, There may be debris remove the imaging unit and then inside the printer. clear the debris. Service Manual 4-27 Samsung Electronics...

  • Page 88

    The software Try printing a job from another application is malfunctioning. application. Exit Windows and reboot the The operating system computer. Turn the printer off and is malfunctioning. then back on again. Service Manual 4-28 Samsung Electronics...

  • Page 89

    Check the file to ensure that it does The file may have blank pages. not contain blank pages. Some parts in the Contact a service representative. printer may be defective. Service Manual 4-29 Samsung Electronics...

  • Page 90

    1200dpi [Normal] or 600dpi [Draft]. [Best] and then try printing again. If you increase the photo size in the The resolution of the software application, the resolution photo is very low. will be reduced. Reduce the photo size. Service Manual 4-30 Samsung Electronics...

  • Page 91

    Your printer has an odd smell during initial use. After printing about 100 color pages, The oil used to there will be no more smell. It is a protect the fuser is evaporating. temporary issue. Service Manual 4-31 Samsung Electronics...

  • Page 92: Solving Print Quality Problems

    2. The paper may not meet Check the paper type and quality. paper specifications 3. A combination of faded or smeared defects may Check the inside for the printer. indicate that the printer needs cleaning Service Manual 4-32 Samsung Electronics...

  • Page 93

    Adjustment and Troubleshooting 2) Toner specks AaBbCc AaBbCc AaBbCc AaBbCc AaBbCc The paper may not meet specifications Check the paper type and quality. Service Manual 4-33 Samsung Electronics...

  • Page 94

    3. The paper lot is bad. Try a different kind or brand of paper. See "Vertical repetitive defects" on 4. The toner cartridge may be defective. the next page. Service Manual 4-34 Samsung Electronics...

  • Page 95

    Remove the imaging unit and install a new one. Clean the inside of the printer. If you still have the same problems, 2. If white vertical replace the imaging unit with a new lines appear on the page one. Service Manual 4-35 Samsung Electronics...

  • Page 96

    1. very dry (low humidity) or high humidity (higher than 80% RH) conditions can increase the 2. heck the printer's environment amount of background shading. 2. Remove one of the old toner cartridges and install a new one. Service Manual 4-36 Samsung Electronics...

  • Page 97

    Adjustment and Troubleshooting 6) Toner smear 1. Clean the inside of the printer. 2. Check the paper type and quality. 1. Toner smear 3. Remove the imaging unit and install a new one. Service Manual 4-37 Samsung Electronics...

  • Page 98

    If the defects occur on the back of 2. Parts of the printer the page, the problem will likely may have toner on them. correct itself after a few more pages. 3. The fusing assembly Contact a service representative. may be damaged. Service Manual 4-38 Samsung Electronics...

  • Page 99

    Printing on seams can cause problems. 3. If background Adjust the print resolution through scatter covers the entire surface your software application or via the area of a printed page printer properties window. Service Manual 4-39 Samsung Electronics...

  • Page 100

    Try a different paper. hollowed images The printer may need service. 2. If characters are Verify that it also occurs on a demo improperly formed and producing page. a wavy effect. Service Manual 4-40 Samsung Electronics...

  • Page 101

    Check the paper type and quality. 2. The paper may not meed specifications 3. Ensure that the paper The guides are not too tight or too or other material is loaded correctly loose against the paper stack. Service Manual 4-41 Samsung Electronics...

  • Page 102

    Both high temperature and high 2. Check the paper type and quality. humidity can cause paper curl. Also try rotating the paper 180° in 3. Turn the stack of the tray. paper over in the tray. Service Manual 4-42 Samsung Electronics...

  • Page 103

    1. Wrinkles or creases properly. Check the paper type and quality. 2. The paper may not meed specifications Also try rotating the paper 180° in 3. Turn the stack of paper the tray. over in the paper tray. Service Manual 4-43 Samsung Electronics...

  • Page 104

    Adjustment and Troubleshooting 13) Back of printouts aredirty Clean the inside of the printer. Check for leaking toner. Service Manual 4-44 Samsung Electronics...

  • Page 105

    Remove the toner cartridge and 1. The toner cartridge may reinsert. not be installed properly. 2. The toner cartridge may Install a new toner cartridge. be defective and need replacing. Change HVPS. 3. The printer may require repair. Service Manual 4-45 Samsung Electronics...

  • Page 106

    2. The paper may not meed specifications 3. The Toner Cartridge Install a new toner cartridge. may be defective and need replacing. 4. If the problem persists, Contact a service representative. the printer may require repair. Service Manual 4-46 Samsung Electronics...

  • Page 107

    1. You may be printing on the wrong 1. Character voids are surface of the paper. Remove the white areas within characters that should paper and turn it over. be solid black 2. The paper may not meet paper specifications. Service Manual 4-47 Samsung Electronics...

  • Page 108

    A toner cartridge may be installed AaBbCc 1. If horizontally improperly. aligned color or black streaks or Remove the toner cartridge and smears appear reinsert. Install a new toner cartridge. 2. A toner cartridge may be defective. Service Manual 4-48 Samsung Electronics...

  • Page 109

    18) Curl Turn the stack of paper over in the 1. If the printed paper is paper tray. Also try rotating the curled or paper does not feed into paper 180° in the tray. the printer Service Manual 4-49 Samsung Electronics...

  • Page 110: Common Windows Problems

    NOTE: Refer to the Microsoft Windows 98/Me/NT 4.0/2000/2003/XP User's Guide that came with your PC for further information on Windows error messages. Service Manual 4-50 Samsung Electronics...

  • Page 111: Common Macintosh Problems

    Print as Image when you print from document from Acrobat Reader. Acrobat Reader. The document has printed, but the print job has not Update your Mac OS to OS 10.3.3 or higher. disappeared from the spooler in Mac OS 10.3.2. Service Manual 4-51 Samsung Electronics...

  • Page 112: Common Linux Problems

    "No Choice" value. editing the printer You have to choose an option that does not conflict settings. before being able to submit the changes. Continue.. Service Manual 4-52 Samsung Electronics...

  • Page 113

    In that case, you need to make sure Landscape mode, but it prints that you leave the LLPR option set to its default rotated and cropped. Portrait setting, to avoid unwanted rotations of the page that would result in cropped output. Continue.. Service Manual 4-53 Samsung Electronics...

  • Page 114

    Some documents come out latest version of CUPS (at least 1.1.14). Some RPM as white pages when printing. packages for the most popular distributions are provided as a convenience with this Linux Printing Package. Continue.. Service Manual 4-54 Samsung Electronics...

  • Page 115

    Postscript uses CIE color space for Color Matching Some color images come out all black. System, you should upgrade Ghostscript on your system to at least GNU Ghostscript version 7.06 or later. You can find recent Ghostscript versions at www.ghostscript.com. Service Manual 4-55 Samsung Electronics...

  • Page 116: Major Problems Trouble Shooting

    Deformed Doctor-blade or cleaningblade. 2. Scratched surface Replace the transfer roller if occurred as No. 3. of the discharge roller in the developer. 3. Partly depression or deformation on the surface of the transfer roller. Service Manual 4-56 Samsung Electronics...

  • Page 117

    4. If the fuser is that corresponds to the position of the voids. defective, voids occur Remove if found. periodically at the top of 2. If the problems are not solved, replace the a black image. developer cartridge. Service Manual 4-57 Samsung Electronics...

  • Page 118

    Clean up the contaminated area by the toner. high voltage terminal in the HVPS and the one in the set. Replace the HVPS if the problems are not 4. Abnormal output from the HVPS. solved by the above four directions. Service Manual 4-58 Samsung Electronics...

  • Page 119

    HVPS. contacts between power supply in the 2. Replace the HVPS if not solved by the above side of the Developer and charge direction 1 and 2. terminal of HVPS. Service Manual 4-59 Samsung Electronics...

  • Page 120

    4. Is the movement Clean the bushing part of the transfer roller. (Up and Down) of the transfer roller smooth? If the problem is still not solved, replace the 5. Is the HVPS normal? developer. Service Manual 4-60 Samsung Electronics...

  • Page 121

    (Isopropyl Alcohol) or water. roller-pickup for foreign matter. 4. If the paper feeds into the printer rand Replace the Main B'D and/or Sensor. Jam 0 occurs, perform EDC to check feed-sensor of the engine board. Service Manual 4-61 Samsung Electronics...

  • Page 122

    2. If the recording paper is stuck in the discharge Reassemble the Actuator-Feed and Spring- roller and the fuser just after passing Actuator if the returning is bad. through the Actuator-Feed, Feed Actuator may be defective. Service Manual 4-62 Samsung Electronics...

  • Page 123

    (the solenoid does not work properly) 2. Pad-Friction is Clean the pad friction with soft clothe contaminated with foreign matter.(oil...) dampened with IPA(Isopropyl Alcohol). Use the smooth paper. 3. The face of paper is blended. Service Manual 4-63 Samsung Electronics...

  • Page 124

    Fuser Erasing Lamp 10) Paper Empty • Description 1. Bending or deformation Replace the defective actuator. of the actuator of the paper sensor. 2. The function of the engine Replace the engine board. board is defective Perform Service Manual 4-64 Samsung Electronics...

  • Page 125

    1. Check the motor harness, replace it, if 1. Motor harness or sub defective. PCB may be defective. 2. Check 24V in the SMPS 3. Check Front Cover or Jam cover are opened. 4. Replace the Main PBA, if necessary. Service Manual 4-65 Samsung Electronics...

  • Page 126

    LED of Panel does not appear after normal warmingup. 14) Vertical Line Getting Curved • Description 1. If the supply of +24v is 1. Replace LSU. unstable in the Main Control board 2. Replace the Main Control board. linking with LSU Service Manual 4-66 Samsung Electronics...

  • Page 127

    1. Foreign matter stuck Cleaning foreign matter in LSU mirror onto the window of internal lenses of LSU mirror 2. Main Controller LSU Part defect Replace Main Controller Replace Micro Switch Harness 3. Micro Switch Harness Service Manual 4-67 Samsung Electronics...

  • Page 128: Exploded Views & Parts List

    5.14 SCF-Frame 5-35 5.7 Fuser Ass'y 5-18 5.15 SCF Cassette 5-39 Samsung Color Laser Printer The keynote of Product High Performance / High Quality Muti-path CLBP - Model : only CLP 350N - Speed(Color/Mono) : 5/20ppm(A4). 5/19ppm(Let) - Printing resolution : 2,400 x 600 dpi - Emulation : PCL6/PS3 - Memory expansion =>...

  • Page 129: Main

    Exploded Views & Parts List 5.1 Main Service Manual Samsung Electronics...

  • Page 130

    Exploded Views & Parts List Main Parts List SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.1-0 CLP-350N COLOR LBP 20 B / COLOR 5 PPM 5.1-1 JC97-02994A MEA UNIT-FRAME 5.1-2 JC97-03002A MEA UNIT-COVER 5.1-3...

  • Page 131: Cover Unit

    Exploded Views & Parts List 5.2 Cover Unit Service Manual Samsung Electronics...

  • Page 132

    MEA-UNIT COVER RIGHT 5.2-3-1 JC63-01477A COVER-SIDE R 5.2-3-2 JC63-01489A COVER-DUMMY SIDE 5.2-3-3 JC67-00160A CAP-NETWORK 5.2-3-4 JC72-01410A SPONGE-COVER_SIDE R 5.2-4 JC97-03009A MEA-UNIT COVER LEFT 5.2-4-1 JC63-01476A COVER-SIDE L 5.2-4-2 JC72-01409A SPONGE-COVER-SIDE L 5.2-5 JC97-02993A MEA UNIT-COVER REAR Service Manual Samsung Electronics...

  • Page 133: Top Cover

    Exploded Views & Parts List 5.3 Top Cover Service Manual Samsung Electronics...

  • Page 134

    5.3-4 JC66-01296A LEVER-BLOCKING 5.3-5 JC66-01297A LEVER-MID BLOCKING 5.3-6 JC61-01761A HOLDER-LEVER BLOCKING 5.3-7 6044-000001 RING-CS 5.3-8 JC72-01343A PMO-SUB_M_STACKER 5.3-9 JC61-02166A BRACKET-AIR CURTAIN 5.3-10 JC63-01481A COVER-OPE 5.3-11 JC64-00337A BUTTON-STOP 5.3-12 6107-001169 SPRING-CS 5.3-13 JC63-01480A COVER-LED 5.3-14 6002-000440 SCREW-TAPPING Service Manual Samsung Electronics...

  • Page 135: Rear Cover

    Exploded Views & Parts List 5.4.1 Rear Cover Service Manual Samsung Electronics...

  • Page 136

    5.4.1-2 JC64-00336A BUTTON-REAR OPEN 5.4.1-3 JC66-01089A SHAFT-P-LOCKBAR REAR 5.4.1-4 JC61-01461A HOLDER-M-HOOK REAR R 5.4.1-5 JC61-01456A HOLDER-M-HOOK REAR L 5.4.1-6 JC61-01462A HOLDER-M-HOOK REAR C 5.4.1-7 JC66-01587A LEVER-REAR 5.4.1-8 6107-001268 SPRING-TS 5.4.1-9 6003-000196 SCREW-TAPTITE 5.4.1-10 JC96-03990A ELA UNIT-TRANSFER Service Manual Samsung Electronics...

  • Page 137: Transfer Unit

    Exploded Views & Parts List 5.4.2 Transfer Unit Service Manual 5-10 Samsung Electronics...

  • Page 138

    5.4.2-14 6107-001278 SPRING-CS 5.4.2-15 6003-000282 SCREW-TAPTITE 5.4.2-16 JC39-00036A CBF HARNESS-OPE GND 5.4.2-17 JC70-10232A IPR-PLATE SAW 5.4.2-18 JC66-01104A ROLLER-TRANSFER 5.4.2-19 JC61-01471A HOLDER-M-T2 ROLLER R 5.4.2-20 JC66-01073A GEAR-T2 ROLLER 5.4.2-21 6107-001246 SPRING-CS 5.4.2-A JC97-02628A MEA UNIT-T2 ROLLER Service Manual 5-11 Samsung Electronics...

  • Page 139: Frame

    Exploded Views & Parts List 5.5 Frame 1 Service Manual 5-12 Samsung Electronics...

  • Page 140

    Exploded Views & Parts List Frame 2 Service Manual 5-13 Samsung Electronics...

  • Page 141: Frame Parts List

    CBF HARNESS-THER 5.5-34 JC97-02639A MEA UNIT-FU TERMINAL 5.5-34-1 JC72-41010A PMO-HOUSING TERMINAL 5.5-34-2 JC70-10961A IPR-TERMINAL FU 5.5-34-3 6021-000222 NUT-HEXAGON 5.5-34-4 JC39-00581A CBF HARNESS-FUSER_AC 5.5-34-S3 6006-000127 SCREW-MACHINE 5.5-37 JC61-01477A FRAME-M-EXIT 5.5-38 6107-001163 SPRING-CS 5.5-39 JC61-01568A HOLDER-M-EXIT F DOWN Service Manual 5-14 Samsung Electronics...

  • Page 142

    JC61-01548A HOLDER-M-CAM 5.5-59 JC66-01056A GEAR-REGI DRIVE 5.5-60 6044-000001 RING-CS 5.5-61 JC66-00346A GEAR-MP/DUP DRV 5.5-62 JC47-00009C CLUTCH-REGI 5.5-63 6031-001255 WASHER-PLAIN 5.5-64 JC66-01207A SHAFT-M-CLUTCH FUSER 5.5-65 JC47-00014A MEP-CLUTCH CAM 5.5-66 JC61-01566A HOLDER-M-CLUTCH FUSER 5.5-67 JC39-00497A CBF HARNESS-INLET Service Manual 5-15 Samsung Electronics...

  • Page 143: Lsu Cover

    Exploded Views & Parts List 5.6 LSU Cover Service Manual 5-16 Samsung Electronics...

  • Page 144

    SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.6-0 JC97-02656A MEA UNIT-COVER LSU 5.6-1 JC67-00168A BRUSH-LSU 5.6-2 JC64-00267A SHUTTER-LSU 5.6-3 JC63-00839A COVER-M-LSU 5.6-4 6107-001295 SPRING-CS 5.6-5 JC63-01093A SHEET-LSU FRONT 5.6-6 JC62-00338A SEAL-COVER LSU Service Manual 5-17 Samsung Electronics...

  • Page 145: Fuser Ass'y

    Exploded Views & Parts List 5.7 Fuser Ass'y Service Manual 5-18 Samsung Electronics...

  • Page 146

    PMO-BUSHING TX 5.7-33 JC66-01206A SHAFT-M-CAM FUSER 5.7-34 JC61-01647A HOLDER-M-SHAFT FUSER 5.7-35 JC66-01147A LEVER-M-RELEASE 5.7-36 JC66-01148A LEVER-M-LINK FUSER 5.7-37 JC66-01309A ROLLER-DUMMY 5.7-39 JC61-01679A SPRING ETC-GROUND 5.7-40 6107-001267 SPRING-CS 5.7-41 6107-001290 SPRING-CS 5.7-42 JC97-02778A MEA UNIT-GUIDE PR Service Manual 5-19 Samsung Electronics...

  • Page 147: Main Drive

    Exploded Views & Parts List 5.8 Main Drive 1 Service Manual 5-20 Samsung Electronics...

  • Page 148

    Exploded Views & Parts List Main Drive 2 Service Manual 5-21 Samsung Electronics...

  • Page 149

    5.8-38 JC31-00041A MOTOR DC-DEVE DRIVE 5.8-40 6003-000301 SCREW-TAPTITE 5.8-41 JC61-02173A BRACKET-DEVE CAM 5.8-42 6003-000269 SCREW-TAPTITE 5.8-43 JC67-00130A CAP-M-PUSH COUPLING 5.8-44 JC47-00018A CLUTCH-DEVE CAM 5.8-45 JC66-01590A SHAFT-DEVE CAM 5.8-46 JC92-01720A PBA SUB-DEVE_HOME 5.8-47 JC61-01453A HOLDER-M-LINK BLACK Service Manual 5-22 Samsung Electronics...

  • Page 150

    Main Drive Parts List SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE Drawer# SEC_Code Description QT'y Service Remark 5.8-48 JC66-01097A LINK-M-PUSH BLACK CAP 5.8-49 JC61-00699A BUSH-D6/L4 5.8-50 6502-001093 CABLE CLAMP 5.8-52 JF68-10532B LABEL(P)-BAR CODE Service Manual 5-23 Samsung Electronics...

  • Page 151: Cartridge-transfer

    Exploded Views & Parts List 5.9 Cartridge-Transfer Service Manual 5-24 Samsung Electronics...

  • Page 152

    SEAL-SIDE ITB RIGHT 5.9-39 JC62-00229A SEAL-BLADE ITB LEFT 5.9-40 JC62-00232A SEAL-TOP ITB 5.9-41 JC62-00257A SEAL-FRAME WASTE ITB 5.9-42 JC62-00258A SEAL-WASTE OPC 5.9-43 JC62-00281A SEAL-HOUSING ITB L 5.9-44 JC62-00282A SEAL-HOUSING ITB R 5.9-45 JC62-00326A SEAL-WASTE SIDE Service Manual 5-25 Samsung Electronics...

  • Page 153

    ROLLER-DRIVE ITB 5.9-70 JC66-01137A GEAR-DRIVE ITB 5.9-71 JC97-03003A MEA UNIT-ROLLER IDLE 5.9-73 JC61-01526A GUIDE-M-BUSH IDL ITB R 5.9-74 JC66-01130A ROLLER-IDLE ITB 5.9-75 JC97-03004A MEA-GUIDE IDLE ITB 5.9-76 JC61-02185A GUIDE-BUSH IDLE L 5.9-77 JC71-10322B NPR-EARTH OPC Service Manual 5-26 Samsung Electronics...

  • Page 154: Cartridge-drum

    Exploded Views & Parts List 5.10 Cartridge-Drum Service Manual 5-27 Samsung Electronics...

  • Page 155

    MEA UNIT-W_TONER_TANK 5.10-5 JC97-02615D MEA UNIT-DEV C 5.10-6 JC97-02614D MEA UNIT-DEV M 5.10-7 JC97-02613D MEA UNIT-DEV Y 5.10-8 JC97-02616D MEA UNIT-DEV K 5.10-9 JC97-03076A MEA UNIT-OPC SET 5.10-10 6107-001292 SPRING-CS 5.10-11 6003-000282 SCREW-TAPTITE 5.10-12 6006-001078 SCREW-TAPTITE Service Manual 5-28 Samsung Electronics...

  • Page 156: Toner Bk

    Exploded Views & Parts List 5.11 Toner BK Service Manual 5-29 Samsung Electronics...

  • Page 157

    JC66-01591A SHAFT-SPRING 5.11-15 JC61-01676A SPRING ETC-AUGER K 5.11-17 JC66-01589A SHAFT-AUGER 5.11-21 JC63-01492A COVER-INNER BK 5.11-22 JG72-40960A PMO-CAP TONER 5.11-23 JC66-01139A GEAR-AUGER A 5.11-24 JC66-01141A GEAR-AUGER Z15 5.11-25 JC67-00260A CAP-TONER BOTTLE BK 5.11-26 JC64-00339A HANDLE-BOTTLE BK Service Manual 5-30 Samsung Electronics...

  • Page 158: Toner Cmy

    Exploded Views & Parts List 5.12 Toner CMY Service Manual 5-31 Samsung Electronics...

  • Page 159

    JC63-01491A SHEET-AGITATOR 5.12-14 JC66-01591A SHAFT-SPRING 5.12-15 JC61-02391A SPRING ETC-AUGER RU 5.12-17 JC66-01589A SHAFT-AUGER 5.12-21 JC63-00894A COVER-INNER 5.12-22 JG72-40960A PMO-CAP TONER 5.12-23 JC66-01139A GEAR-AUGER A 5.12-24 JC66-01141A GEAR-AUGER Z15 5.12-25 JC67-00263A CAP-TONER BOTTLE 5.12-26 JC64-00340A HANDLE-BOTTLE Service Manual 5-32 Samsung Electronics...

  • Page 160: Cassette

    Exploded Views & Parts List 5.13 Cassette Service Manual 5-33 Samsung Electronics...

  • Page 161

    ADJUST-M-CASSETTE R 5.13-10 JC70-00517A ADJUST-M-CASSETTE L 5.13-11 JG66-40003A GEAR-PINION 5.13-12 JC68-01680A LABEL-INSTRUCTION 5.13-13 JF68-10532B LABEL(P)-BAR CODE 5.13-14 6107-001240 SPRING-CS 5.13-15 JC64-00223A LOCKER-M-KNOCK UP L 5.13-16 JC64-00222A LOCKER-M-KNOCK UP R 5.13-17 JG61-70531A SPRING ETC-LOCKER,PLATE 5.13-18 JC61-01158A PLATE-M-KNOCK_UP Service Manual 5-34 Samsung Electronics...

  • Page 162: Scf-frame

    Exploded Views & Parts List 5.14 SCF-Frame 1 Service Manual 5-35 Samsung Electronics...

  • Page 163

    Exploded Views & Parts List SCF-Frame 2 Service Manual 5-36 Samsung Electronics...

  • Page 164

    RING-CS 5.14-32 6107-001170 SPRING-TS 5.14-33 JC66-00377A CAM-M-PICK_UP 5.14-34 JC66-01214A SHAFT-M-FEED 5.14-35 JC66-00394A GEAR-FEED 2 5.14-36 JC33-00010C SOLENOID-SCF 5.14-37 JC63-01039A GROUND-P-PBA 5.14-38 JC63-01040A GROUND-P-FEED_ROLL 5.14-39 JC63-01041A GROUND-P-DRIVE 5.14-40 6003-000196 SCREW-TAPTITE 5.14-41 6006-001078 SCREW-TAPTITE 5.14-42 JC63-01031A COVER-M-JAM Service Manual 5-37 Samsung Electronics...

  • Page 165

    GUIDE-M-PICK UP 5.14-46 JC61-00580A HOLDER-M-PAD 5.14-47 JC63-00290A SHEET-HOLDER PAD 5.14-48 JC73-00140A RPR-FRICTION PAD 5.14-49 JC70-00314A IPR-PLATE PAD 5.14-50 JC61-70911A SPRING ETC-EXIT ROLL FD 5.14-51 JC63-01033A COVER-M-LEFT SCF 5.14-52 JC63-01034A COVER-M-RIGHT SCF 5.14-53 JC63-01035A COVER-M-REAR SCF Service Manual 5-38 Samsung Electronics...

  • Page 166: Scf Cassette

    Exploded Views & Parts List 5.15 SCF Cassette Service Manual 5-39 Samsung Electronics...

  • Page 167

    CAM-M-KNOCK UP 5.15-7 6003-000264 SCREW-TAPTITE 5.15-8 JC70-00523A ADJUST-M-SCF R 5.15-9 JC70-00524A ADJUST-M-SCF L 5.15-10 JC63-00855A COVER-M-CASSETTE 5.15-11 JC61-01664A GUIDE-M REAR SCF 5.15-12 JC72-00972A PMO-PLATE_LOCKER 5.15-13 JC73-00141A RPR-PAD CASSETTE 5.15-14 JG61-70531A SPRING ETC-LOCKER,PLATE 5.15-15 JG66-40003A GEAR-PINION Service Manual 5-40 Samsung Electronics...

  • Page 168: System Diagram

    System Diagram 6. System Diagram 6.1 Block Diagram SYSTEM BUS SFR BUS LOCAL BUS Service Manual Samsung Electronics...

  • Page 169: Connection Diagram

    System Diagram 6.2 Connection Diagram 6.2.1 Main Layout Service Manual Samsung Electronics...

  • Page 170: Power

    System Diagram 6.2.2 Power Service Manual Samsung Electronics...

  • Page 171: Imaging, Itb Unit

    System Diagram 6.2.3 Imaging, ITB Unit Service Manual Samsung Electronics...

  • Page 172: Hvps, Lsu

    System Diagram 6.2.4 HVPS, LSU Service Manual Samsung Electronics...

  • Page 173: Scf, Ope, Bldc

    System Diagram 6.2.5 SCF, OPE, BLDC Service Manual Samsung Electronics...

  • Page 174: Sensor, Clutch, Solenoid

    System Diagram 6.2.6 Sensor, Clutch, Solenoid Service Manual Samsung Electronics...

  • Page 175: Reference Information

    • Brush • Tweezers Standard : For general home use, small type. • Cotton Swab Standard : For general home use, for medical service. • Software (Driver) installation CD ROM Install Driver CD Network S/W CD Service Manual Samsung Electronics...

  • Page 176: Acronyms And Abbreviations

    Enhanced Capability Port Inter Process CommunicationEPP Enhanced parallel Port Engine Control Unit Images Per Minute EEPROM Electronically Erasable Programmable Read Only Memory Image Transfer Belt Electro Magnetic Interference local area network Electro photographic Laser Beam Printer Service Manual Samsung Electronics...

  • Page 177

    SCF/SCT Second Cassette Feeder/Second Purpose Tray Cassette Tray Network Interface Card SMPS Switching Mode Power Supply Network Printer Card SPGP Samsung Printer Graphic Processor NVRAM Nonvolatile Random Access Memory Samsung Printer Language Organic Photo Conductor SPL-C Samsung Printer Language-Color Printed Board Assembly...

  • Page 178: Select A Location For The Printer

    • Provide the proper environment : - A firm, level surface - Away from the direct airflow of air conditioners, heaters, or ventilators - Free of extreme fluctuations of temperature, sunlight, or humidity - Clean, dry, and free of dust Service Manual Samsung Electronics...

  • Page 179: A4 Iso 19752 Standard Pattern

    Reference Information 7.4 A4 ISO 19752 Standard Pattern This test page is reproduced at 70% of the normal A4 size Service Manual Samsung Electronics...

  • Page 180

    GSPN (Global Service Partner Network) North America : service.samsungportal.com Latin America : latin.samsungportal.com CIS : cis.samsungportal.com Europe : europe.samsungportal.com Samsung Electronics Co.,Ltd. Sep. 2007 China : china.samsungportal.com Printed in Korea. Asia : asia.samsungportal.com CODE : 0350-C0XAA VERSION NO. : 1.00...
