CUSTOMER EXPERIENCE CENTER
1-800-331-4331
Printed in U.S.A. 7/09
08-TCS-03068
10%
Cert no. SGS-COC-005612
I n f o r ma t i o n P r o v i d e d b y :
00505-QRG10-AVA
AVALON
2 0 1 0

QUICK REFERENCE

GUIDE

Advertisement

Table of Contents
loading

Summary of Contents for Toyota Avalon 2010

  • Page 1: Quick Reference

    AVALON CUSTOMER EXPERIENCE CENTER 2 0 1 0 1-800-331-4331 QUICK REFERENCE GUIDE Printed in U.S.A. 7/09 Cert no. SGS-COC-005612 I n f o r ma t i o n P r o v i d e d b y : 00505-QRG10-AVA 08-TCS-03068...
  • Page 2: Spare Tire & Tools

    Spare tire & tools of your vehicle’s capabilities and limitations. Tool location Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your Luggage floor cover Spare tire cover new Avalon.
  • Page 3: Table Of Contents

    Spare tire & tools Tire Pressure Monitoring (warning) System 24 Trunk-Internal release Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. I n f o r ma t i o n P r o v i d e d b y : ®...
  • Page 4 OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Telephone controls Steering wheel climate controls Voice command button Distance button Driving position memory switches Headlight, turn signal and front fog light controls Ignition switch (standard key) Wiper and washer controls “ENGINE START STOP”...
  • Page 5 Trunk opener main switch Audio system Storage compartment /Navigation system switches Outside rearview mirror /Rear window defogger button Cruise control Tilt lock release lever Tire Pressure Monitoring (warning) System reset Telescopic lock release Power rearview mirror control Glass breakage sensor Rear sunshade switch Trunk opener Fuel filler door opener...
  • Page 6: Instrument Cluster

    If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 7 Malfunction/Check Engine indicator Engine oil replacement reminder Low fuel level warning Open door warning Airbag SRS warning Tire Pressure Warning Low windshield washer fluid level warning Security indicator Headlight low/high beam indicator Turn signal indicator Automatic headlight leveling system warning Slip indicator Vehicle Stability Control system warning Cruise control indicator...
  • Page 8: Keyless Entry 1

    OVERVIEW Keyless entry Locking operation Without Smart Key system With Smart Key system Push Unlocking operation Without Smart Key system With Smart Key system Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety.
  • Page 9: Smart Key System 2

    Smart Key system (if equipped) Start function Green indicator ON Depress Push brake pedal Carrying NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from: Accessories such as the radio will operate.
  • Page 10: Fuel Tank Door Release And Cap

    OVERVIEW Fuel tank door release and cap Turn Push Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Light control-Instrument panel Brightness control Trunk release Trunk opener Main switch Push I n f o r ma t i o n P r o v i d e d b y :...
  • Page 11: Engine Maintenance

    Hood release Pull Pull up latch and raise hood Engine maintenance Engine coolant reservoir Power steering fluid reservoir Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty Maintenance Guide.”...
  • Page 12: Auto Lock Functions 2

    FEATURES/OPERATIONS Auto lock functions Automatic door locks can be programmed to operate in two different modes, or turned OFF. 1. Doors lock: when shifting from Park. Doors unlock: when shifting into Park. 2. Doors lock: when the vehicle speed goes above 12 mph. Doors unlock: when the driver’s door is opened within 10 seconds after turning the “ENGINE START STOP”...
  • Page 13: Parking Brake

    Tilt and telescopic steering wheel Angle Length Lock release lever Lock release lever Hold wheel, push lever down, set angle and length, and return lever. NOTE: Do not attempt to adjust while the vehicle is in motion. Parking brake Set: Depress Release: Depress again Seats-Head restraints Lock release button...
  • Page 14: Seat Adjustments-Front

    FEATURES/OPERATIONS Seat adjustments-Front Manual seat Power seat Seatback angle Seat position (forward/backward) Leg support (if equipped) Lumbar support (if equipped) Position, cushion angle (if equipped) and height (if equipped) Seat adjustments-Rear Seatback angle lever Refer to the Owner’s Manual for more details. Windshield wipers &...
  • Page 15 Lights & turn signals Headlights Headlights Parking lights Auto DRL OFF Low beam High beam High beam flasher -Daytime Running Light system (DRL) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Automatically turns lights off after a delay of 30 seconds, or the lock switch on remote may be pushed after locking.
  • Page 16: Moonroof

    FEATURES/OPERATIONS Windows-Power Driver side Window lock switch Down Automatic operation Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction. Window lock switch Deactivates all passenger windows. Driver’s window remains operable.
  • Page 17: Telephone Controls

    Refer to “Hands-free system (for cellular phone),” Section 3-3 in the Owner’s Manual for more details, or go to Toyota.com and enter “Bluetooth” in the keyword search. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 18: Cruise Control

    FEATURES/OPERATIONS Garage door opener (HomeLink ® (if equipped) ® Garage door openers manufactured under license from HomeLink * can be programmed to operate garage doors, estate gates, security lighting, etc. Refer to “Garage door opener,” Section 3-6 in the Owner’s Manual for more details.
  • Page 19: Dynamic Laser Cruise Control

    Dynamic Laser Cruise Control (if equipped) Refer to the Owner’s Manual for more details and complete safety precautions before attempting to use “Dynamic Laser Cruise Control.” Fixed speed mode (1) To select conventional/fixed speed control Push the ON-OFF button. Push the lever forward and hold until the “NORM.” indicator appears. (2) To set, cancel and resume a speed Refer to instructions for Cruise Control on the previous page.
  • Page 20: Audio

    FEATURES/OPERATIONS Audio Preset buttons - functions in other Push to skip up/down folder modes indicated above number and radio category type Load CD(s) Eject CD Seek station/ CD track select Push to Push to turn adjust tone Station/CD Mode ON/OFF &...
  • Page 21: Center Display

    Steering wheel switches Audio control Climate control Temperature Volume control selector Auto A/C ON System OFF “ ” Use to search within the selected audio medium (radio, CD, iPod, etc.). “MODE” Push to turn audio ON and select an audio mode. Push and hold to turn audio system OFF.
  • Page 22: Controls

    FEATURES/OPERATIONS Air Conditioning/Heating Display Without navigation system With navigation system Control Temperature selector (driver side) Temperature selector (passenger side) Climate control OFF Air Conditioning ON/OFF Fresh or recirculated cabin air Automatic climate control ON Outside rearview mirror*/Rear defogger Airflow vent In “...
  • Page 23: Door Locks

    Seat ventilators/Heaters (if equipped) With ventilator Heater only Push Turn Heater Turn Push Ventilator Push knob to pop the controller out. Turn clockwise for heater, counter-clockwise for ventilator. Door locks Lock Unlock I n f o r ma t i o n P r o v i d e d b y :...
  • Page 24: Clock

    FEATURES/OPERATIONS Power outlets Auxiliary box Console box The “ENGINE START STOP” switch/engine switch must be in the “ACC” or “ON” position to be used. Cup holders Front Rear (type B) Rear (type A) Clock Without navigation system H-Hour set M-Minute set :00-Round off minutes With navigation system Refer to the “Navigation System Owner’s Manual.”...
  • Page 25: Doors-Child Safety Locks

    SAFETY AND EMERGENCY FEATURES Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seatbelts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again.
  • Page 26: Seatbelt Comfort Guide

    If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. NOTE: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light.
  • Page 27 TABLE OF CONTENTS Index 1-6. Theft deterrent system Before driving Engine immobilizer system ........ 83 Alarm ........85 1-1. Key information Theft prevention labels Keys ........22 (U.S.A.)....... 87 1-2. Opening, closing and locking 1-7. Safety information the doors and trunk Correct driving posture ..
  • Page 28 2-3. Operating the lights and 3-2. Using the audio system windshield wipers Audio system type ....210 Headlight switch....156 Audio cover ......212 Fog light switch ....159 Using the radio ....213 Windshield wipers and Using the CD player ... 220 washer ......
  • Page 29 TABLE OF CONTENTS Index 3-6. Other interior features 4-3. Do-it-yourself maintenance Sun visors ......286 Do-it-yourself service precautions ....... 324 Vanity mirrors ..... 287 Hood ........327 Clock ........288 Positioning a floor jack..328 Outside temperature display ......289 Engine compartment ..
  • Page 30 5-2. Steps to take in an emergency For owners If a warning light turns on or a warning buzzer sounds......393 Reporting safety defects If you have a flat tire.... 405 for U.S. owners ....460 If the engine will not Seat belt instructions start........
  • Page 31: For Your Information

    Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 32 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 33 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that will hurt or kill you, your occupants or others.
  • Page 34 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 35 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 36: Before Driving

    TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other features interior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
  • Page 37 Pictorial index Exterior Windshield wiper P. 160 ∗ Moon roof P. 77 Outside rear view mirror P. 72 Hood P. 327 Side marker light P. 156 Headlight (low beam) P. 156 Turn signal light P. 145 ∗ Fog light P. 159 Headlight (high beam) P.
  • Page 38 Tail/stop light P. 156 Rear window defogger P. 208 Tail lights P. 156 Fuel filler door P. 80 Trunk P. 46 Door P. 40 Tire Back-up light ●Rotation P. 345 ●Replacement P. 405 Turn signal light P. 145 ●Inflation pressure P.
  • Page 39 Pictorial index Interior Door pocket Head restraint P. 59 P. 285 Console box P. 280 Seat belt P. 61 SRS driver airbag P. 90 Power window SRS knee airbag switch P. 74 P. 90 Front passenger airbag P. 90 ∗ Storage compartment P.
  • Page 40 Inside rear view mirror P. 70 Interior light P. 277 Personal light P. 277 Personal light P. 277 SRS curtain shield airbag P. 90 ∗ Moon roof switch P. 77 Vanity mirror P. 287 Sun visor P. 286 ∗ Garage door opener switches P.
  • Page 41 Pictorial index Interior Door lock switch P. 40 Window lock switch P. 74 Power window switches P. 74 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 42 ∗ Storage compartment P. 283 Navigation system switches Cup holders P. 284 ∗ Ashtray P. 290 Shift lever P. 140 Shift lock override button P. 416 ∗ Seat heater/ventilator switch P. 293 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 43: Driving Position Memory Switches

    Pictorial index Instrument panel Gauges and meters P. 148 Headlight switch P. 156 Turn signal lever P. 145 Windshield wipers and Fog light switch P. 159 washer switch P. 160 Driving position ∗ memory switches Glove box P. 279 P. 55 Horn P.
  • Page 44 Audio remote control switches P. 239 ∗ Telephone switch P. 247 Engine (ignition) switch (vehicles with smart key system) P. 133 Engine (ignition) switch (vehicles without smart key system) P. 137 Climate remote control switches P. 206 Talk switch P. 247 ∗...
  • Page 45: Center Display 1 /Navigation System

    Pictorial index Instrument panel Clock P. 288 Center display P. 154 Navigation system Emergency flashers P. 384 Air conditioning Air conditioning system P. 198 system P. 198 Rear window and outside rear Audio system view mirror defoggers P. 208 P. 210 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 46 Outside rear view mirror switches P. 72 Fuel filler door opener P. 80 Trunk opener P. 46 ∗ Rear sunshade switch P. 296 ∗ Glass breakage sensor P. 85 ∗ : If equipped : Refer to “Navigation System Owner’s Manual”. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 47: 1-1. Key Information

    1-1. Key information Keys The following keys are provided with the vehicle. Vehicles with smart key system Electronic keys • Operating the smart key system (→P. 24) • Operating wireless remote control function (→P. 36) Mechanical keys Key number plate Vehicles without smart key system Master keys Operating the wireless remote...
  • Page 48 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made at your Toyota dealer using the key number plate. (→P. 417) ■...
  • Page 49: 1-2. Opening, Closing And Locking The Doors And Trunk

    1-2. Opening, closing and locking the doors and trunk ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (→P.
  • Page 50 1-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors Grip the handle to unlock the door. Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after the door is locked.
  • Page 51 1-2. Opening, closing and locking the doors and trunk Antenna location and effective range ■ Antenna location Antennas outside cabin Antenna outside trunk Antenna inside trunk Antennas inside cabin I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 52 1-2. Opening, closing and locking the doors and trunk ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 3 ft. (1 m) of an outside door handles.
  • Page 53 1-2. Opening, closing and locking the doors and trunk ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from →...
  • Page 54 1-2. Opening, closing and locking the doors and trunk ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. STEP Turn the “ENGINE START STOP” switch off. STEP When the indicator on the key surface is turned off, push and hold , or for approximately 5 seconds while pushing the button on the key.
  • Page 55 1-2. Opening, closing and locking the doors and trunk ■ Battery-saving function In the following circumstances, the entry function is disabled in order to pre- vent the vehicle and electronic key batteries from discharging. ● When the entry function has not been used for 2 weeks or more ●...
  • Page 56 1-2. Opening, closing and locking the doors and trunk ■ Note for the smart key system ● Even when the electronic key is within the effective range (detection areas), the system may not operate properly in the following cases. • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
  • Page 57 1-2. Opening, closing and locking the doors and trunk ■ Alarms and warning indicators A combination of exterior and interior alarms are used to prevent theft of the vehicle and unforeseeable accidents resulting from erroneous operation. Take appropriate measures according to which warning light comes on. (→P.
  • Page 58 When the electronic key battery is fully depleted →P. 363 ■ Customization that can be configured at Toyota dealer Settings (e.g. smart key system) can be changed. (Customizable features →P. 454) I n f o r ma t i o n P r o v i d e d b y :...
  • Page 59 1-2. Opening, closing and locking the doors and trunk ■ Certification for the smart key system For vehicles sold in the U.S.A. FCC ID: HYQ14AAB FCC ID: HYQ13BZH FCC ID: HYQ14ABK FCC ID: HYQ13BZW NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 60 (→P. 26) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
  • Page 61: Wireless Remote Control

    1-2. Opening, closing and locking the doors and trunk Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle and the trunk from outside the vehicle. Vehicles with smart key system Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door.
  • Page 62 1-2. Opening, closing and locking the doors and trunk ■ Operation indicator Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Trunk: A buzzer sounds to indicate that the trunk has been unlocked. ■...
  • Page 63 1-2. Opening, closing and locking the doors and trunk ■ Customization that can be configured at Toyota dealer Settings (e.g. 2-step unlocking function, trunk unlocking function) can be changed. (Customizable features →P. 454) ■ Certification for wireless remote control For vehicles sold in the U.S.A.
  • Page 64 1-2. Opening, closing and locking the doors and trunk For vehicles sold in the U.S.A. NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 65: Doors

    1-2. Opening, closing and locking the doors and trunk Doors The vehicle can be locked and unlocked using the entry function, wireless remote control or door lock switch. ■ Entry system (vehicles with smart key system) →P. 25 ■ Wireless remote control →P.
  • Page 66 1-2. Opening, closing and locking the doors and trunk ■ Inside lock button Locks the door Unlocks the door The front doors can be opened by pulling the inside handles even if the lock buttons are in the lock position. Locking the front doors from the outside without a key STEP Move the inside lock button to the lock position.
  • Page 67 1-2. Opening, closing and locking the doors and trunk Rear door child-protector lock The door cannot be opened from inside the vehicle when the locks are set. These locks can be set to prevent children from opening the rear doors. Push down rear door switches to lock the rear doors.
  • Page 68 1-2. Opening, closing and locking the doors and trunk Function Operation Vehicles with smart key system All doors are unlocked when the driver’s door is opened within 10 seconds after turning the “ENGINE START STOP” switch OFF. Driver’s door linked door unlocking function Vehicles without smart key system All doors are unlocked when the driver’s door...
  • Page 69 1-2. Opening, closing and locking the doors and trunk Shift the shift lever to “P” or “N”, STEP press and hold the driver’s door lock switch ( ) for about 5 seconds then release. The shift lever and switch posi- tions corresponding desired function to be set are...
  • Page 70 1-2. Opening, closing and locking the doors and trunk ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 454) CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle.
  • Page 71: Trunk

    1-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the trunk opener, smart key system or wireless remote control. ■ Opening the trunk from inside the vehicle Push the opener switch. ■ Opening the trunk from outside the vehicle Entry system (vehicles with smart key system) →P.
  • Page 72 1-2. Opening, closing and locking the doors and trunk ■ Internal trunk release lever The trunk lid can be opened by pulling down on the glow-in-the-dark lever located on the inside of trunk lid. The lever will continue to glow for some time after the trunk lid is closed.
  • Page 73 1-2. Opening, closing and locking the doors and trunk CAUTION ■ When children are in the vehicle Observe the following precautions. Failure to do so may result in death or serious injury. ● Do not allow children to enter the trunk. If a child is accidentally locked in the trunk, they could overheat or suffo- cate.
  • Page 74 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to fall closed again after it is opened.
  • Page 75: Adjustable Components (Seats, Steering Wheel, Mirrors)

    1-3. Adjustable components (seats, steering wheel, mirrors) Front seats Manual seat Seatback angle lever Seat position lever I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 76 1-3. Adjustable components (seats, steering wheel, mirrors) Power seat Seat leg support switch Seat position fore/aft switch Seat cushion (front) angle switch Vertical height switch Seatback angle switch Lumbar support switch : if equipped Active head restraint When a front seatback receives a strong impact during a rear- end collision, the head restraint moves...
  • Page 77 1-3. Adjustable components (seats, steering wheel, mirrors) ■ Active head restraint Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may cause the head restraint inner structure to appear. This does not indicate a problem. During Inner rear-end...
  • Page 78: Rear Seats

    1-3. Adjustable components (seats, steering wheel, mirrors) Rear seats To adjust the seat back angle, pull the lock release lever. ■ Keep the flap area clear Do not place objects on the flap area. If Flap area objects are left in the gap, the reclining seatback will not lock properly, and may move unexpectedly.
  • Page 79 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION ■ Reclining adjustment Do not recline the seat more than necessary when the vehicle is in motion, to reduce the risk of sliding under the lap belt. If the seat is too reclined, during an accident the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoulder belt, increasing the risk of death or serious injury.
  • Page 80: Driving Position Memory System

    1-3. Adjustable components (seats, steering wheel, mirrors) ∗ Driving position memory system Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be entered into the computer’s mem- ory and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
  • Page 81 1-3. Adjustable components (seats, steering wheel, mirrors) ■ Recalling the memorized position STEP Vehicles with smart key system: Turn the “ENGINE START STOP” switch to IGNITION ON mode. Vehicles without smart key system: Turn the engine switch to the “ON” position. Push button “1”...
  • Page 82 1-3. Adjustable components (seats, steering wheel, mirrors) Push the “1” or “2” button on the STEP driver’s side and the button on the wireless remote control at the same time for about 1 sec- ond until you hear a beep. STEP Open one of the doors.
  • Page 83 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION ■ Seat adjustment caution Take care during seat adjustment that the seat does not strike the rear pas- senger. If this happens, you can stop the movement by pressing another seat posi- tion memory button.
  • Page 84: Head Restraints

    1-3. Adjustable components (seats, steering wheel, mirrors) Head restraints Head restraints are provided for all seats. Down Push and hold the lock release button when lowering the head restraint. Lock release button ■ Removing the head restraints Pull the head restraint up while pushing the lock release button.
  • Page 85 1-3. Adjustable components (seats, steering wheel, mirrors) ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■ Adjusting the center rear seat head restraint Always raise the head restraint one level from the stowed position when using.
  • Page 86: Seat Belts

    1-3. Adjustable components (seats, steering wheel, mirrors) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 87 1-3. Adjustable components (seats, steering wheel, mirrors) ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Seat belt comfort guide (outside rear seats) If the shoulder belt sits close to a person’s neck, use the seat belt comfort guide.
  • Page 88 1-3. Adjustable components (seats, steering wheel, mirrors) Buckle, position and release the STEP seat belt. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
  • Page 89 1-3. Adjustable components (seats, steering wheel, mirrors) ■ Pregnant women Obtain medical advice and wear the seat belt in the proper way. (→P. 61) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants.
  • Page 90 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at the same time, including children. ● Toyota recommends that children should be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 91 ● Do not attempt to install, remove, modify, disassemble or dispose of a seat belt. Have any necessary repairs carried out by your Toyota dealer. Inap- propriate handling of the pretensioner may cause it to activate or operate improperly and may cause death or serious injury.
  • Page 92 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION ■ Using a seat belt comfort guide ● Make sure the belt is not twisted and that it lies flat. The elastic cord must be behind the belt and the guide must be on the front. ●...
  • Page 93: Steering Wheel

    1-3. Adjustable components (seats, steering wheel, mirrors) Steering wheel The steering wheel can be adjusted to a comfortable position. ■ To change the angle Hold the steering wheel, press the tilt lock release lever, and adjust to the ideal position by moving the steering wheel vertically.
  • Page 94 1-3. Adjustable components (seats, steering wheel, mirrors) CAUTION ■ After adjusting the steering wheel Make sure that the steering wheel is locked. Otherwise, the steering wheel may move suddenly, possibly causing an accident and resulting in death or serious injury. ■...
  • Page 95: Inside Rear View Mirror

    1-3. Adjustable components (seats, steering wheel, mirrors) Inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In auto mode, sensors are used to detect the headlights of vehi- cles behind and automatically reduces the reflected light.
  • Page 96 1-3. Adjustable components (seats, steering wheel, mirrors) ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure correct functioning of the sen- sors, do not touch or cover the sensors. CAUTION ■ While driving Do not adjust the position of the mirror. Doing so may lead to mishandling of the vehicle and an accident, or result- ing in death or serious injury.
  • Page 97: Outside Rear View Mirrors

    1-3. Adjustable components (seats, steering wheel, mirrors) Outside rear view mirrors Mirror angle can be adjusted using the switch. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down Left ■ The outside rear view mirrors can be operated when Vehicles with smart key system The “ENGINE START STOP”...
  • Page 98 1-3. Adjustable components (seats, steering wheel, mirrors) ■ Auto anti-glare function (vehicles with auto anti-glare inside rear view mirror) When the anti-glare inside rear view mirror is set to auto mode, the outside rear view mirrors will activate in conjunction with the anti-glare inside rear view mirror to reduce reflected light.
  • Page 99: Opening And Closing The Windows And Moon Roof Power Windows

    1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. One-touch closing Closing One-touch opening Opening : Pressing the switch in the opposite direction will stop win- dow travel partway.
  • Page 100 1-4. Opening and closing the windows and moon roof ■ The power windows can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
  • Page 101 1-4. Opening and closing the windows and moon roof CAUTION ■ When closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
  • Page 102: Moon Roof

    1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open Stops just before it is opened fully. Press the switch again to fully open.
  • Page 103 1-4. Opening and closing the windows and moon roof ■ The moon roof can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
  • Page 104 1-4. Opening and closing the windows and moon roof ■ When the battery is disconnected The moon roof must be initialized in order to ensure proper operation. STEP Open the window halfway. STEP Hold down “TILT UP” switch during the following moon roof sequence: Tilt up →...
  • Page 105: 1-5. Refueling

    1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the “ENGINE START STOP” switch or the engine switch OFF and ensure that all the doors and windows are closed. ■...
  • Page 106 1-5. Refueling Closing the fuel tank cap After refueling, turn the fuel tank cap clockwise until you hear a click. The cap will revolve slightly in the opposite direction once released. ■ Fuel types Use unleaded gasoline. (Octane Rating 87 [Research Octane Number 91] or higher) ■...
  • Page 107 ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Failure to do so may cause a fire or other incident which may result in death or serious injury.
  • Page 108: Theft Deterrent System Engine Immobilizer System

    1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with a smart key system The indicator light flashes after...
  • Page 109 1-6. Theft deterrent system ■ Certifications for the engine immobilizer system For vehicles sold in the U.S.A. FCC ID: MOZRI-21BTY FCC ID: NI4TMIMB-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 110: Alarm

    1-6. Theft deterrent system ∗ Alarm The system sounds the alarm and flashes lights when forcible entry is detected. ■ Triggering the alarm The alarm is triggered in the following situations. ● A locked door or trunk is unlocked or opened in any way other than using the entry function, wireless remote door lock func- tion or using the mechanical key.
  • Page 111 1-6. Theft deterrent system ■ Items to check before locking the vehicle To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following: ● Nobody is in the vehicle. ● The windows and moon roof are closed before the alarm is set. ●...
  • Page 112: Theft Prevention Labels (U.s.a.)

    1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 113: Safety Information Correct Driving Posture

    1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 114 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 115: Srs Airbags

    1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 116 1-7. Safety information Airbag system components Front airbag sensor Driver’s seat position sensor Front passenger airbag Knee airbag “AIR BAG ON” and “AIR BAG Airbag sensor assembly OFF” indicator lights Occupant detection system Side airbag (ECU and sensors) Curtain shield airbag Front passenger’s seat belt buckle switch Side and curtain shield airbag...
  • Page 117 1-7. Safety information Your vehicle is equipped with “ADVANCED AIRBAGS” designed based on US motor vehicle safety standards (FMVSS208). The air- bag system controls airbag deployment power for the driver and front passenger. The driver airbag system consists of the driver seat’s position sensor etc.
  • Page 118 1-7. Safety information ■ Operating conditions (front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to a 12-19 mph (20-30 km/h) frontal collision with a fixed wall that does not move or deform).
  • Page 119 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
  • Page 120 1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
  • Page 121 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. ● Any of the SRS airbags have been inflated.
  • Page 122 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 123 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 124 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
  • Page 125 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board, steering wheel pad or lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
  • Page 126 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnish, are damaged or cracked, have them replaced by your Toyota dealer. ● Do not place anything, such as a cushion, on the front passenger’s seat.
  • Page 127 Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbag may malfunction or deploy (inflate) accidentally, causing death or serious injury.
  • Page 128: Front Passenger Occupant Classification System

    1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger’s seat belt reminder light “AIR BAG OFF”...
  • Page 129 1-7. Safety information Condition and operation in the front passenger occupant classi- fication system ■ Adult “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat...
  • Page 130 1-7. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front Activated...
  • Page 131 1-7. Safety information : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may recognize him/her as a child depending on his/her physique and posture. : In the event the front passenger does not wear a seat belt. : When a large child who has outgrown a child restraint system sits in the front passenger seat, the system may recognize him/ her as an adult depending on his/her physique or posture.
  • Page 132 1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
  • Page 133 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction on the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
  • Page 134: Child Restraint Systems

    1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
  • Page 135 1-7. Safety information Forward-facing ⎯ Convertible seat Booster seat ■ Selecting an appropriate child restraint system ● Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belt. ● If a child is too large for a child restraint system, sit the child on a rear seat and use the vehicle’s seat belt.
  • Page 136 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 137 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not allow the child to lean his/her head or any part of his/her body against the door or the area of the seat, front pillar or roof side rail from which the side airbags or curtain shield airbags deploy even if the child is seated in the child restraint system.
  • Page 138: Installing Child Restraints

    1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the outboard rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
  • Page 139 1-7. Safety information Installation with LATCH system Adjust the seatback as leaned as STEP As leaned possible. as possible STEP Widen the gap between the seat cushion and seatback slightly. Type A Latch the hooks of the lower STEP straps onto the LATCH anchors. Canada only I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 140 1-7. Safety information STEP If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether anchors. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
  • Page 141 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing ⎯ Infant seat/convertible seat ■ Place the child restraint system STEP on the rear seat facing the rear of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
  • Page 142 1-7. Safety information While pushing the child restraint STEP system down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 143 1-7. Safety information Fully extend the shoulder strap STEP and then allow it to retract slightly into the ALR lock mode. Lock mode allows the seat belt to retract only. While pushing the child restraint STEP system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
  • Page 144 1-7. Safety information ■ Booster seat Place the booster seat on the STEP seat facing the front of the vehi- cle. Sit the child in the booster seat. STEP Fit the seat belt to the booster seat according to the manufac- turer’s instructions and insert the plate into the buckle.
  • Page 145 1-7. Safety information Child restraint systems with a top tether strap Secure the child restraint using a STEP seat belt or LATCH anchors, and lock the head restraint in place at the lowest position. Open the anchor bracket cover, STEP latch the hook onto the anchor bracket and tighten the top tether strap.
  • Page 146 1-7. Safety information CAUTION ■ When installing a child restraint system Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be injured or even killed in the event of sudden braking, sudden swerving or an accident.
  • Page 147 1-7. Safety information CAUTION ■ When installing a child restraint system ● Push and pull the child restraint system from side to side and forward to be sure it is secure. ● After securing a child restraint system, never adjust the seat. ●...
  • Page 148: 2-1. Driving Procedures

    2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 133, 137 ■ Driving STEP With the brake pedal depressed, shift the shift lever to “D”. (→P. 140) STEP Release the parking brake.
  • Page 149 ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ●...
  • Page 150 2-1. Driving procedures CAUTION ■ When starting the vehicle Always keep your foot on the brake pedal while stopped with the engine run- ning. This prevents the vehicle from creeping. ■ When driving the vehicle ● Do not drive if you are unfamiliar with the location of the brake and accel- erator pedals to avoid depressing the wrong pedal.
  • Page 151 2-1. Driving procedures CAUTION ■ When driving the vehicle ● Do not shift the shift lever to "P" while the vehicle is moving. Doing so can damage the transmission and may result in a loss of vehicle control. ● Do not shift the shift lever to "R" while the vehicle is moving forward. Doing so can damage the transmission and may result in a loss of vehicle control.
  • Page 152 2-1. Driving procedures CAUTION ● Do not drive in excess of the speed limit. Even if the legal speed limit per- mits it, do not drive over 85 mph (140 km/h) unless your vehicle has high speed capability tires. Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible injury.
  • Page 153 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 154 2-1. Driving procedures CAUTION ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or press the accelera- tor pedal, which could cause an accident or fire due to abnormal engine overheating.
  • Page 155 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have your Toyota dealer check and replace the brake pads as soon as pos- sible. The rotor damage can result if the pads are not replaced when needed.
  • Page 156 Short in electrical components ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following. ● Brake function ●...
  • Page 157: Engine (Ignition) Switch (With Smart Key System)

    2-1. Driving procedures Engine (ignition) switch (with smart key system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in “P”.
  • Page 158 2-1. Driving procedures ■ Changing engine (ignition) switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) Emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used.
  • Page 159 2-1. Driving procedures ■ When the steering lock cannot be released The green indicator light on the “ENGINE START STOP” switch will flash. Press the “ENGINE START STOP” switch again while turning the steering wheel slightly in either direction. ■ If the engine does not start The engine immobilizer system may not have been deactivated.
  • Page 160 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver’s seat. Do not press the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
  • Page 161: Engine (Ignition) Switch (Without Smart Key System)

    2-1. Driving procedures Engine (ignition) switch (without smart key system) ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in “P”. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
  • Page 162 2-1. Driving procedures ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK” position. To free it, turn the key while turn- ing the steering wheel slightly in either direction.
  • Page 163 2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for long periods without the engine running. ■ When starting the engine ● Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.
  • Page 164: Automatic Transmission

    2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever S mode driving position Vehicles with smart key system: While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever.
  • Page 165 2-1. Driving procedures ■ Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing Neutral Normal driving S mode driving : Shifting to the D position allows the system to select a gear suitable for the driving conditions. Setting the shift lever to the D position is recommended for normal driv- ing.
  • Page 166 2-1. Driving procedures Changing shift ranges in S mode Shift the shift lever to the S mode driving position and operate the shift lever. Upshifting Downshifting The initial shift range in S mode is automatically set to “5” or “4” according to vehicle speed.
  • Page 167 2-1. Driving procedures ■ Shift ranges and their functions ● You can choose from 6 levels of engine braking force. ● A lower shift range will provide greater engine braking force than a higher shift range, and the engine speed will also increase. ■...
  • Page 168 S mode driving position This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.) ■...
  • Page 169: Turn Signal Lever

    2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change The left hand signal will flash until you release the lever.
  • Page 170: Parking Brake

    2-1. Driving procedures Parking brake Sets the parking brake (Depressing the pedal again releases the parking brake.) U.S.A. Canada : Fully depress the parking brake pedal with your left foot while depressing the brake pedal with your right foot. NOTICE ■...
  • Page 171: Horn

    2-1. Driving procedures Horn To sound the horn, press on or close to the mark. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 172: 2-2. Instrument Cluster

    2-2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the target region. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Low fuel level warning light →P.
  • Page 173 2-2. Instrument cluster Odometer/Trip meter display Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and dis- play different distances independently.
  • Page 174 2-2. Instrument cluster Instrument panel light control The brightness of the instrument panel lights can be adjusted. Darker Brighter NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed.
  • Page 175: Indicators And Warning Lights

    2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster The units used on the speedometer and some indicators may differ depending on the target region.
  • Page 176 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Cruise control indicator (→P. 145) (→P. 165) Headlight high beam Cruise control indicator indicator (→P. 157) (→P. 165, 168) Headlight indicator Ready mode indicator (→P.
  • Page 177 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
  • Page 178: Center Display

    2-2. Instrument cluster Center display The center display provides information including your vehicle’s driving condition, outside temperature. Vehicles with navigation system Refer to “Navigation System Owner’s Manual”. Vehicles without navigation system Audio display (→P. 210) Air conditioning display (→P. 198) Outside temperature display (→P.
  • Page 179 2-2. Instrument cluster Trip information ■ Driving range Displays the estimated maximum distance that can be driven with the quantity of fuel remaining. ● This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that displayed.
  • Page 180: 2-3. Operating The Lights And Windshield Wipers

    2-3. Operating the lights and windshield wipers Headlight switch The headlights can be operated manually or automatically. U.S.A. The side marker, park- ing, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn The headlights and all the lights listed above turn on and off auto-...
  • Page 181 2-3. Operating the lights and windshield wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off.
  • Page 182 To turn the lights on again, turn the engine switch to the “ON” position, or turn the light switch OFF once and then back to the position. ■ Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be changed. (Customizable features →P. 454) NOTICE ■...
  • Page 183: Fog Light Switch

    2-3. Operating the lights and windshield wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 184: Windshield Wipers And Washer

    2-3. Operating the lights and windshield wipers Windshield wipers and washer ■ Intermittent wiper with interval adjuster (if equipped) Wiper intervals can be adjusted for intermittent operation (when is selected). Intermittent wiper operation Low speed wiper operation High speed wiper operation Temporary operation Increases the intermittent windshield wiper frequency...
  • Page 185 2-3. Operating the lights and windshield wipers Wash/wipe operation Wipers will automatically oper- ate a couple of times after the washer squirts. ■ Raindrop detection windshield wipers (if equipped) With “AUTO” selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume and vehicle speed.
  • Page 186 2-3. Operating the lights and windshield wipers Sensor sensitivity (high) Sensor sensitivity (low) Wash/wipe operation Wipers will automatically oper- ate a couple of times after the washer squirts. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 187 2-3. Operating the lights and windshield wipers ■ The windshield wiper and washer can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
  • Page 188 [90°C]) or extremely cold (at less than 14°F [-10°C]), the wipers do not oper- ate even if the wiper lever is in “AUTO” mode. ■ Customization that can be configured at Toyota dealer Settings (e.g. drip prevention function) can be changed. (Customizable features →P. 457) CAUTION ■...
  • Page 189: Using Other Driving Systems Cruise Control

    2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without using the accelerator. Indicator Cruise control switch ■ Set the vehicle speed STEP Press the “ON-OFF” button to operate the cruise control. Push the button once more to deactivate the cruise control.
  • Page 190 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pressing the lever up or down and releasing it.
  • Page 191 Turn the “ON-OFF” button off once, and then reactivate the system. If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION ■...
  • Page 192: Dynamic Laser Cruise Control

    2-4. Using other driving systems ∗ Dynamic laser cruise control Dynamic laser cruise control supplements conventional cruise con- trol with a vehicle-to-vehicle distance control. In the vehicle-to-vehi- cle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehi- cles ahead.
  • Page 193 2-4. Using other driving systems ■ Set the vehicle speed STEP Press the “ON-OFF” button to operate the cruise control. Push the button once more to deactivate. Accelerate or decelerate to STEP the desired speed and press the lever down to set. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 194 2-4. Using other driving systems ■ Selecting conventional constant speed control mode Press the “ON-OFF” button to operate the cruise con- trol. Switch to constant speed control mode. (Push and hold for approxi- mately 1 second.) Push the button once more to deactivate.
  • Page 195 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is displayed. In the constant speed control mode, fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pressing the lever up or down and releasing it.
  • Page 196 2-4. Using other driving systems ■ Changing the vehicle-to-vehicle distance Each push of the switch changes the vehicle-to-vehicle distance Long Medium Short Vehicles with smart key sys- tem: vehicle-to-vehicle distance is automatically set to the long mode when “ENGINE START STOP”...
  • Page 197 2-4. Using other driving systems Cruising in vehicle-to-vehicle distance control mode This mode employs a laser radar sensor to detect the presence of vehicles within 400 ft. (120 m) ahead and to judge the distance between your vehicle and those vehicles. Note that vehicle-to-vehicle distance will close when traveling on long downhill slopes.
  • Page 198 2-4. Using other driving systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
  • Page 199 If the same code appears again after implementing the correction procedure, or if the cruise control cannot be set, contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 200 Vehicle-to-vehicle distance control driving must be reset by turning the “ON- OFF” button on again. If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. ■...
  • Page 201 2-4. Using other driving systems ■ Vehicle-to-vehicle distance settings Select a distance from the table below. Note that the distances shown corre- spond to a vehicle speed of 55 mph (90 km/h). Vehicle-to-vehicle distance increases/decreases in accordance with vehicle speed. Distance options Vehicle-to-vehicle distance Long...
  • Page 202 2-4. Using other driving systems CAUTION ■ Before using dynamic laser cruise control Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set vehicle speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes, etc.
  • Page 203 2-4. Using other driving systems CAUTION ■ When the laser radar sensor may not be correctly detecting the vehicle ahead Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the proximity alarm (→P.
  • Page 204 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by a Toyota dealer. ● Do not disassemble the sensor.
  • Page 205: Driving Assist Systems

    2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 206 2-4. Using other driving systems ■ Sounds and vibrations caused by the ABS, brake assist, VSC and TRAC ● A sound may be heard from the engine compartment when the engine is started or just after the vehicle begins to move. This sound does not indi- cate that a malfunction has occurred in any of these systems.
  • Page 207 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
  • Page 208: 2-5. Driving Information

    2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the trunk whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far forward as possible helps maintain vehicle balance.
  • Page 209 Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 188) Toyota does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing. Example on your vehicle...
  • Page 210 2-5. Driving information CAUTION ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk. ● Receptacles containing gasoline ● Aerosol cans ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury.
  • Page 211 2-5. Driving information CAUTION ■ Weight of the load ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant’s weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury.
  • Page 212: Vehicle Load Limits

    Even if the number of occupants are within the seating capacity, do not exceed the total load capacity. ■ Towing capacity Toyota does not recommend towing a trailer with your vehicle. ■ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
  • Page 213: Winter Driving Tips

    2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 214 2-5. Driving information ■ Before driving the vehicle Perform the following according to the driving conditions. ● Do not try to forcibly open a window or move a wiper that is frozen. Pour warm water over the frozen area to melt the ice. Wipe away the water immediately to prevent it from freezing.
  • Page 215 2-5. Driving information Selecting snow chains Use the correct snow chain size when mounting the snow chains. Chain size is regulated for each tire size. Side chain: 0.12 in. (3.0 mm) 1.18 in. (30.0 mm) 0.39 in. (10.0 mm) Cross chain: 0.16 in.
  • Page 216 2-5. Driving information CAUTION ■ Driving with snow tires Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury. ● Use tires of the size specified for your vehicle. ●...
  • Page 217 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
  • Page 218: Trailer Towing

    Your Toyota is not designed for trailer towing or for the use of tow hitch mounted carriers.
  • Page 219: Dinghy Towing

    2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 220 2-5. Driving information I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 221: Using The Air Conditioning System And Defogger Automatic Air Conditioning System

    3-1. Using the air conditioning system and defogger Automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Without navigation system With navigation system Passenger’s side Driver’s side temperature control Windshield temperature control Automatic mode defogger Dual Air conditioning...
  • Page 222 3-1. Using the air conditioning system and defogger Using the automatic mode STEP Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the temperature set- ting. STEP Press “∧” to increase the temperature and “∨” to decrease the temperature on The temperature for the driver and passenger seats can be set sep- arately.
  • Page 223 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press The air outlets switch each time the button is pressed. The air flow shown on the display indicate the following. Air flows to the upper body. Air flows to the upper body and feet.
  • Page 224 3-1. Using the air conditioning system and defogger Air flows to the feet. Air flows to the feet and the windshield defogger operates. ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) modes each time the button is pressed.
  • Page 225 3-1. Using the air conditioning system and defogger Defogging the windshield Press The air conditioning system con- trol operates automatically. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 226 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Turn the knob to open or close the vent Direct air flow to the left or right Side outlets Turn the knob to open or close the vent Direct air flow to the left or...
  • Page 227 There may be a problem in the air conditioning system if the indi- cator light continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Air conditioning odors ●...
  • Page 228 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 229: Using The Steering Wheel Climate Control Switches

    3-1. Using the air conditioning system and defogger Using the steering wheel climate control switches Some air conditioning feature can be controlled using the switches on the steering wheel. Temperature control Automatic mode Using the automatic mode STEP Press The air conditioning system will begin to operate. Air outlets and fan speed are automatically adjusted according to the tempera- ture setting.
  • Page 230 3-1. Using the air conditioning system and defogger Adjust the temperature settings ∧ ∨ Press “ ” to increase the temperature and “ ” to decrease the tem- perature on Press “∧” (increase) or “∨” (decrease) on to separately adjust the temperature for the passenger and driver sides (dual mode).
  • Page 231: Rear Window And Outside Rear View Mirror Defoggers

    3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers These features are used to defog the rear window, and to remove raindrops, dew and frost from the outside rear view mirrors. With outside rear view mir- ror defoggers Without outside rear view mirror defoggers...
  • Page 232 3-1. Using the air conditioning system and defogger CAUTION ■ When the outside rear view mirror defoggers are on (if equipped) Do not touch the rear view mirror surfaces, as they can become very hot and burn you. NOTICE ■ To prevent battery discharge Turn the defoggers off when the engine is not running.
  • Page 233: 3-2. Using The Audio System

    3-2. Using the audio system Audio system type CD player with changer and AM/FM radio The audio system appearance may differ slightly for vehicles not equipped with JBL brand audio system. Title Page Using the radio P. 213 Using the CD player P.
  • Page 234 3-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION ■ For vehicles sold in the U.S.A. and Canada ●...
  • Page 235: Audio Cover

    3-2. Using the audio system Audio cover Press to open. CAUTION ■ When opening or closing the audio cover Do not jam your hands in the cover. NOTICE ■ To avoid damaging the audio cover or CD ● Do not hold the cover while it is opening. ●...
  • Page 236: Using The Radio

    3-2. Using the audio system Using the radio Press to choose an AM or FM band. Seek frequency Change the program type Station selector Adjust the frequency Power Volume AM⋅SAT/FM mode buttons (AM, FM mode) or channel (SAT mode) Scan for receivable stations ®...
  • Page 237 3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) ■ Scanning the preset radio stations STEP Press and hold until you hear a beep. Preset stations will be played for 5 seconds each. STEP When the desired station is reached, press the button again. ■...
  • Page 238 3-2. Using the audio system ® Satellite Radio (if equipped) ® ■ Receiving XM Satellite Radio STEP Press until “SAT” shows in the display. The display changes as follows each time the button is pressed. “AM” → “SAT1” → “SAT2” → “SAT3” STEP Turn to select a desired channel from all the categories...
  • Page 239 3-2. Using the audio system ® ■ Presetting XM Satellite Radio channels Select the desired channel. Press and hold the button (1 - 6) until you hear a beep. ■ Changing the channel category Press “∧” or “∨” on ® ■...
  • Page 240 3-2. Using the audio system ■ When the battery is disconnected All preset stations are erased. ■ Reception sensitivity ● Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
  • Page 241 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
  • Page 242 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 438-9677 (Canada).
  • Page 243: Using The Cd Player

    3-2. Using the audio system Using the CD player Insert a CD or press with a CD inserted. Random playback Fast-reverse Fast-forward Repeat play Select track CD slot CD insert CD eject Search playback Power Volume Select CD Playback Display text message I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 244 3-2. Using the audio system Loading a CD ■ Loading a CD STEP Press STEP Insert a CD when the indicator on the slot turns from amber to green. ■ Loading multiple CDs STEP Press and hold until you hear a beep. STEP Insert a CD when the indicator on the slot turns from amber to green.
  • Page 245 3-2. Using the audio system Selecting a track Press “∧” to move up and “∨” to move down using until the desired track number is displayed. Fast-forwarding and reversing tracks To fast-reverse, press and hold To fast-forward, press and hold Scanning tracks STEP Press...
  • Page 246 3-2. Using the audio system Random playback ■ Current CD Press Tracks are played in random order until the button is pressed again. ■ All CDs Press and hold until you hear a beep. Tracks on all loaded CDs are played in random order until the button is pressed again.
  • Page 247 Depending on the contents recorded, the characters may not be displayed properly or may not be displayed at all. ■ Error messages Refer to the following table and take the appropriate measures. If the prob- lem is not rectified, take the vehicle to your Toyota dealer. Correction Message Cause Procedures...
  • Page 248 3-2. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may be possible depending on recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protect features may not be used. ■...
  • Page 249 3-2. Using the audio system NOTICE ■ Discs and adapters that cannot be used Do not use the following types of discs, 3 in. (8 cm) disc adapters or Dual Disc. Doing so may damage the player and render the disc insert/eject function unusable.
  • Page 250 3-2. Using the audio system NOTICE ■ Player precautions Failure to follow the precautions below may result in damage to the discs or the player itself. ● Do not insert anything other than discs into the disc slot. ● Do not apply oil to the player. ●...
  • Page 251: Playing Mp3 And Wma Discs

    3-2. Using the audio system Playing MP3 and WMA discs Insert an MP3 or WMA disc or press with a disc inserted. Random playback Fast-reverse Fast-forward Repeat play CD slot CD insert CD eject Select file Select folder Select file Search Power Volume...
  • Page 252 3-2. Using the audio system Loading, ejecting and selecting MP3 and WMA discs Refer to the section titled “Using the CD player” for details. (→P. 220) Selecting a folder ■ Selecting a folder Press “∧” or “∨” on ■ Selecting the desired folder by cueing the first file of each folder Press and hold until you hear a beep.
  • Page 253 3-2. Using the audio system Random playback ■ To play files from a particular folder in random order Press ■ To play all the files on a disc in random order Press and hold until you hear a beep. Repeat play ■...
  • Page 254 3-2. Using the audio system ■ Canceling random, repeat and scan playback Press again. ■ Display →P. 224 ■ Error messages →P. 224 ■ CD player protection feature To protect the internal components, playback is automatically stopped when a problem is detected while the CD player is being used. ■...
  • Page 255 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 256 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 level 1, level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
  • Page 257 3-2. Using the audio system ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
  • Page 258 3-2. Using the audio system ■ CD-R and CD-RW discs ● CD-R/CD-RW discs that have not been subject to the “finalizing process” (a process that allows discs to be played on a conventional CD player) cannot be played. ● It may not be possible to play CD-R/CD-RW discs recorded on a music CD recorder or a personal computer because of disc characteristics, scratches or dirt on the disc, or dirt, condensation, etc.
  • Page 259: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- ting • Sound quality and vol- ume balance (→P. 237) The sound quality and bal- ance setting can be changed to produce the best sound. •...
  • Page 260 3-2. Using the audio system ■ Adjusting sound quality Turning adjust the level. Mode Sound quality Level Turn to the left Turn to the right displayed mode “BAS” Bass -5 to 5 “MID” Mid-range -5 to 5 High equipped) “TRE” Treble -5 to 5 Front/rear...
  • Page 261: Using The Aux Adapter

    3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Connect the portable audio STEP device. STEP Press ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls.
  • Page 262: Using The Steering Wheel Audio Switches

    3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations CD: Select tracks, files (MP3 and WMA) and discs Power on, select audio source Turning on the power...
  • Page 263 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Press and hold the button to continue increasing or decreasing the vol- ume. Selecting a radio station STEP Press to select the radio mode.
  • Page 264 3-2. Using the audio system ■ Canceling automatic selection of a radio station Push the same switch. CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 265: Using The Hands-Free System (For Cellular Phone)

    Hands-free System Additional Information For additional information pairing and connecting cellular phone or for phone ® compatibility with vehicle’s Bluetooth system, please visit the following website: http://www.toyota.letstalk.com ■ Conditions under which the system will not operate ® ● If using a cellular phone that does not support Bluetooth ●...
  • Page 266 3-3. Using the hands-free system (for cellular phone) ■ ® About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models Compatible with HFP (Hands Free Profile) Ver. 1.0 and OPP (Object Push Profile) Ver. 1.1. ® If your cellular phone does not support HFP, you cannot enter the Bluetooth phone, and take OPP service individually.
  • Page 267 3-3. Using the hands-free system (for cellular phone) NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 268 3-3. Using the hands-free system (for cellular phone) CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth, for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive expo- sure evaluation (MPE).
  • Page 269: Using The Hands-Free System

    3-3. Using the hands-free system (for cellular phone) Using the hands-free system ■ Audio unit Displays such items as message, name, and phone number Lower-case characters and special characters, such as an umlaut, cannot be dis- played. ® Displays Bluetooth con- nection condition If “BT”...
  • Page 270 3-3. Using the hands-free system (for cellular phone) ■ Steering wheel Volume End call Sending/Receiving Press: Voice command sys- tem on Press and hold: Voice com- mand system off ■ Microphone I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 271 3-3. Using the hands-free system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free system without checking the display or operating ■...
  • Page 272 3-3. Using the hands-free system (for cellular phone) Using the hands-free system for the first time Before using the hands-free system, it is necessary to register a cel- lular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
  • Page 273 3-3. Using the hands-free system (for cellular phone) Menu list of the hands-free system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in ⎯ ⎯ Callback the incoming history memory Dialing a number stored in ⎯...
  • Page 274 3-3. Using the hands-free system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock Locking the phone book Security Phonebook Unlocking the phone book Unlock Registering a cellular phone Pair Phone to be used Changing a registered name Change Name...
  • Page 275 3-3. Using the hands-free system (for cellular phone) ■ Using a short cut key Second First menu Operation detail menu Dialing a number registered ⎯ Dial “XXX (name)” in the phone book Phone book add ⎯ Adding a new number entry Phone book change Changing a name of a phone...
  • Page 276 3-3. Using the hands-free system (for cellular phone) ■ Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
  • Page 277: Making A Phone Call

    3-3. Using the hands-free system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number 1. “Dial by number” ● Dialing by inputting a name 1. “Dial by name” ● Speed dialing ●...
  • Page 278 3-3. Using the hands-free system (for cellular phone) STEP Dial by one of the following methods: a. Press b. Press and say “Dial”. c. Select “Dial” by using Dialing by inputting a name STEP Press and say “Dial by name”. STEP Select a registered name to be input by either of the following methods:...
  • Page 279 3-3. Using the hands-free system (for cellular phone) Speed dialing STEP Press STEP Press the preset button in which the desired number is regis- tered. STEP Press When receiving a phone call ■ Answering the phone Press ■ Refusing the call Press I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 280 3-3. Using the hands-free system (for cellular phone) Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: Operate the cellular phone. Refer to the manual that comes with the cellular phone for the oper- ation of the phone.
  • Page 281 3-3. Using the hands-free system (for cellular phone) The following operations can be performed: Dialing: Press or select “Dial” by using a voice command Storing the number in the phone book: Select “Store” by using a voice command or Deleting: Select “Delete” by using a voice command or ■...
  • Page 282: Setting A Cellular Phone

    3-3. Using the hands-free system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free system allows the system to function. The following function can be used for regis- tered cellular phones: ■ Functions and operation procedures To enter menu for each function, follow the steps below by using a voice command or ●...
  • Page 283 3-3. Using the hands-free system (for cellular phone) Selecting a cellular phone to be used STEP Select “Select Phone” by using a voice command or Pattern A STEP Select a cellular phone to be used by either of the following methods, and select “Confirm”...
  • Page 284 3-3. Using the hands-free system (for cellular phone) Changing a registered name STEP Select “Change Name” by using a voice command or STEP Select a name of cellular phone to be changed by either of the following methods: a. Press and say the desired phone name, and select “Confirm”...
  • Page 285 3-3. Using the hands-free system (for cellular phone) Pressing while a name of cellular phone is being read selects the cellular phone, and the following functions will be available: ● Selecting a cellular phone: “Select Phone” ● Changing a registered name: “Change Name” ●...
  • Page 286 3-3. Using the hands-free system (for cellular phone) Changing the passkey STEP Select “Set Passkey” by using a voice command or Pattern A STEP Press , say a four to eight-digit number, and select “Confirm” by using a voice command or Pattern B STEP Select a four to eight-digit number by using...
  • Page 287: Security And System Setup

    3-3. Using the hands-free system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1. “Setup” → 2. “Security” → 3. “Set PIN” ●...
  • Page 288 3-3. Using the hands-free system (for cellular phone) ■ Changing the PIN STEP Select “Set PIN” by using a voice command or STEP Enter the registered PIN by using a voice command or STEP Enter a new PIN by using a voice command or When using , input the code one digit at a time.
  • Page 289 3-3. Using the hands-free system (for cellular phone) Setting voice guidance volume STEP Select “Guidance Vol” by using STEP Change the voice guidance volume. To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Initialization STEP Select “Initialize” and then “Confirm” by using STEP Select “Confirm”...
  • Page 290: Using The Phone Book

    3-3. Using the hands-free system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dial 1. “Phonebook” → 2. “Set Speed Dial (Speed Dial)” ●...
  • Page 291 3-3. Using the hands-free system (for cellular phone) ■ Adding procedure STEP Select “Add Entry” by using a voice command or STEP Use one of the following methods to input a telephone num- ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice”...
  • Page 292 3-3. Using the hands-free system (for cellular phone) Inputting a phone number by using STEP2-1 Select “Manual Input” by using STEP2-2 Input a phone number by using , and press again. Input the phone number one digit at a time. Selecting a phone number from outgoing or incoming history STEP2-1 Select “Call History”...
  • Page 293 3-3. Using the hands-free system (for cellular phone) STEP Select the name to be registered by either of the following methods, and select “Confirm” by using a voice command or a. Press and say the desired name. b. Select “Record Name” by using , and say the desired name.
  • Page 294 3-3. Using the hands-free system (for cellular phone) Setting speed dial STEP Select “Set Speed Dial (Speed Dial)” by using a voice com- mand or STEP Select the data to be registered as speed dial by either of the following methods: a.
  • Page 295 3-3. Using the hands-free system (for cellular phone) Changing a registered name STEP Select “Change Name” by using a voice command or STEP Select a name to be changed by either of the following meth- ods. a. Press , say desired name, and select “Confirm” by using a voice command or b.
  • Page 296 3-3. Using the hands-free system (for cellular phone) Deleting registered data STEP Select “Delete Entry” by using a voice command or Pattern A STEP Select data to be deleted by either of the following methods, and select “Confirm” by using a voice command or a.
  • Page 297 3-3. Using the hands-free system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command begins reading the list of the registered data. When listing is complete, the system returns to “Phonebook”. Pressing while a data is being read aloud selects the data, and the following function will be available.
  • Page 298: 3-4. Using The Interior Lights

    3-4. Using the interior lights Interior lights list Illuminated entry system: The various lights automatically turn on/ off according to the presence of the key, whether the doors are locked/unlocked, whether the doors are open/closed, and the “ENGINE START STOP” switch mode (vehicles with smart key sys- tem) or the engine switch position (vehicles without smart key sys- tem).
  • Page 299 “DOOR” position, the lights will go off automatically after 20 minutes. ■ Customization that can be configured at Toyota dealer Setting (e.g. The time elapsed before lights turn off) can be changed. → P. 457)
  • Page 300 3-4. Using the interior lights Interior lights “ON” “OFF” “DOOR” The interior lights are turned on/ off by the illuminated entry sys- tem. Personal lights Front ON/OFF Rear ON/OFF I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 301: 3-5. Using The Storage Features

    3-5. Using the storage features List of storage features Overhead console Glove box Door pocket Cup holders Console boxes Coin tray Storage compartment I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 302 3-5. Using the storage features Glove box Open Lock with the mechanical key or the master key Unlock with the mechanical key or the master key ■ Glove box light The glove box light turns on when the instrument panel light switch is on. ■...
  • Page 303 3-5. Using the storage features Console boxes Front Lift the lid while pulling the lever. Rear Lift the lid while pulling the lever. ■ When using the front console box lid as an armrest If necessary, the console box lid can slide forward.
  • Page 304 3-5. Using the storage features ■ Tray in the front console box The tray slides forward/backward and can be removed. CAUTION ■ While driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking. Overhead console The overhead console is useful temporarily...
  • Page 305 3-5. Using the storage features CAUTION ■ Items that should not be left in the overhead console Do not leave glasses or lighters in the console. If the interior of the vehicle becomes hot, lighters may explode and glasses may warp or become cracked. ■...
  • Page 306 3-5. Using the storage features Storage compartment Front console (if equipped) Center console CAUTION ■ While driving Do not leave the storage compartment open. The opened compartment may hit your body or items may be thrown out of the compartment in the event of an accident or sudden braking and cause injury.
  • Page 307 3-5. Using the storage features Cup holders Front open, press down release the cup holder lid. Rear (type A) Pull down the armrest. Rear (type B) Pull down the armrest and open the lid. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 308 3-5. Using the storage features CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 309: 3-6. Other Interior Features

    3-6. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position, then slide back- wards. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 310: Vanity Mirrors

    3-6. Other interior features Vanity mirrors The light turns on when the cover is opened. To adjust the brightness of the lights, slide the switch. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 311: Clock

    3-6. Other interior features Clock Without navigation system Adjust the hour Adjust the minutes Rounds to the nearest hour With navigation system Refer to “Navigation System Owner’s Manual”. ■ The clock is displayed when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
  • Page 312: Outside Temperature Display

    The engine switch is in the “ON” position. ■ When “--”, “F” or “E” is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
  • Page 313: Ashtrays

    3-6. Other interior features ∗ Ashtrays CAUTION ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. ■ To prevent fire ● Fully extinguish matches and cigarettes before putting them in the ashtray, then make sure the ashtray is fully closed.
  • Page 314: Power Outlets

    3-6. Other interior features Power outlets The power outlets can be used for 12V accessories that run on less than 10A. Front console box Center console box ■ The power outlets can be used when Vehicles with smart key system The “ENGINE START STOP”...
  • Page 315 3-6. Other interior features NOTICE ■ To avoid damaging the power outlets Close the power outlets lid when not in use. Foreign objects or liquids that enter the power outlets may cause a short cir- cuit. ■ To prevent the fuse from being blown Do not use an accessory that uses more than 12V/10A.
  • Page 316: Seat Heaters/Ventilators

    3-6. Other interior features ∗ Seat heaters/ventilators The seat heaters and ventilators heat the seats and maintain good airflow by blowing air from the seats. Vehicles with ventilator Press the knob to release it, and turn the knob to the desired temperature setting.
  • Page 317 3-6. Other interior features ■ The seat heaters and ventilators can be used when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. CAUTION ■...
  • Page 318: Armrest

    3-6. Other interior features Armrest Pull the armrest down for use. NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 319: Rear Sunshade

    3-6. Other interior features ∗ Rear sunshade The rear sunshade can be raised and lowered by pressing the switch shown below. Raise/lower ■ The rear sunshade can be used when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON”...
  • Page 320 Operating the rear sunshade after turning the “ENGINE START STOP” switch or the engine switch off The rear sunshade can be raised and lowered for approximately 1 minute. ■ Customization that can be configured at Toyota dealer Contact your Toyota dealer for further details. CAUTION ■...
  • Page 321: Floor Mats

    3-6. Other interior features Floor mats Securely place a mat that matches the size of the space on the car- pet. Secure the floor mat using the hooks provided. CAUTION ■ When inserting the floor mat Observe the following precautions. Failure to do so may result in the floor mat slipping and interfering with the movement of the pedals during driving, resulting in an accident.
  • Page 322: Trunk Features

    3-6. Other interior features Trunk features ■ Cargo net The cargo net is provided for securing loose items. ■ Shopping bag hooks ■ Storage box I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 323 3-6. Other interior features Trunk storage extension Pull down the rear seat center armrest. Open (push down the handle) Lock with the mechanical key or the master key Unlock with the mechanical key or the master key CAUTION ■ While driving ●...
  • Page 324: Garage Door Opener

    3-6. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
  • Page 325 3-6. Other interior features Press and hold down one of the STEP ® buttons on the HomeLink the button on the transmitter. Continue holding down both but- ® tons until the HomeLink indica- tor light changes from a slow blink to a rapid flash. This will take approximately 30 seconds.
  • Page 326 3-6. Other interior features ■ Programming a Rolling Code system (for U.S.A. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. STEP Locate the learn button on the ceiling mounted garage door opener motor.
  • Page 327 ® the remaining HomeLink buttons. ■ Programming other devices To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. ■ Reprogramming a button ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
  • Page 328 3-6. Other interior features ■ Before programming ● Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the ® HomeLink ■ Certification for the garage door opener This device complies with Part 15 of the FCC Rules and with RSS-210 of the IC Rules.
  • Page 329: Compass

    3-6. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on or off, press the switch. ■ Displays and directions Display Direction North Northeast...
  • Page 330 3-6. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
  • Page 331 3-6. Other interior features STEP Wait a few seconds until the compass direction is displayed. The calibration is complete. ■ Circling calibration If “CAL” appears on the display, drive the vehicle at 5 mph (8 km/ h) or less in a circle until a direc- tion is displayed.
  • Page 332 3-6. Other interior features CAUTION ■ While driving Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood.
  • Page 333 3-6. Other interior features I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 334: 4-1. Maintenance And Care

    4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 335 4-1. Maintenance and care ■ Automatic car washes ● Fold the mirrors back before washing the vehicle. ● Brushes used in automatic car washes may scratch the vehicle surface and harm your vehicle’s paint. ■ High pressure car washes Do not allow the nozzles of the car wash to come within close proximity of the windows.
  • Page 336 4-1. Maintenance and care CAUTION ■ Caution about the exhaust pipe Exhaust gasses cause the exhaust pipe to become quite hot. When washing the vehicle, be careful not to touch the pipe until it has cooled sufficiently, as touching a hot exhaust pipe can cause burns. NOTICE ■...
  • Page 337: Cleaning And Protecting The Vehicle Interior

    4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 338 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 339 4-1. Maintenance and care NOTICE ■ Cleaning detergents Do not use the following types of detergent, as they may discolor the vehicle interior or cause streaks or damage to painted surfaces. ● Non-seat portions: Organic substances such as benzine or gasoline, alka- line or acidic solutions, dye, or bleach.
  • Page 340: Maintenance Maintenance Requirements

    It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 341 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
  • Page 342: General Maintenance

    “Scheduled Maintenance Guide” or “Owner’s” Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
  • Page 343 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven pedal Accelerator pedal effort or catching)? • Can the vehicle be hold securely on an Automatic transmission “Park” mechanism incline with the shift lever in “P”? • Moves smoothly? Brake pedal •...
  • Page 344 4-2. Maintenance Vehicle exterior Items Check points Doors/trunk • Operate smoothly? Engine hood • The lock system works properly? Fluid leaks • Is there any leakage after parking? • Inflation pressure is correct? • Tire surfaces not worn or damaged? Tire •...
  • Page 345: Emission Inspection And Maintenance (I/M) Programs

    If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
  • Page 346: Do-It-Yourself Maintenance Do-It-Yourself Service Precautions

    Brake fluid level (→P. 338) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
  • Page 347 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 367) as original Headlight aim (→P. 376) • Phillips-head screwdriver • Automatic transmission fluid ® DEXRON II or III Power steering fluid level (→P. 339) •...
  • Page 348 4-3. Do-it-yourself maintenance CAUTION ■ When working near the electric cooling fan or radiator grille Vehicles with smart key system Be sure the “ENGINE START STOP” switch is turned OFF. With the “ENGINE START STOP” switch in IGNITION ON mode, the electric cooling fan may automatically start to run if the air conditioning is on and/or the cool- ant temperature is high.
  • Page 349: Hood

    4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release STEP lever. The hood will pop up slightly. Lift the hood catch and lift the STEP hood. CAUTION ■...
  • Page 350: Positioning A Floor Jack

    4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front Rear I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 351 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
  • Page 352: Engine Compartment

    4-3. Do-it-yourself maintenance Engine compartment Engine coolant reservoir Fuse box (→P. 367) (→P. 336) Battery (→P. 341) Power steering fluid Radiator (→P. 337) reservoir (→P. 339) Electric cooling fans Engine oil filler cap Condenser (→P. 337) (→P. 333) Washer fluid tank Engine oil level dipstick (→P.
  • Page 353 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the cover ■ Installing the clips Open Insert Press I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 354 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After turning off the engine, wait more than five minutes for the oil to drain back into the bottom of the engine.
  • Page 355 4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 356 ● Oil consumption: Max. 1.1 qt./600 miles, 0.9 lmp.qt./600 miles (1.0 L per 1000 km). If the vehicle consumes more than this amount, contact your Toyota dealer. ■ After changing the engine oil (U.S.A.only) The oil change system should be reset. Perform the following procedures: STEP Switch the display to the odometer.
  • Page 357 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. ●...
  • Page 358 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
  • Page 359 Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
  • Page 360 4-3. Do-it-yourself maintenance Brake fluid ■ Checking fluid level The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Make sure to check the fluid type and prepare the necessary items. ■ Adding fluid Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel...
  • Page 361 4-3. Do-it-yourself maintenance NOTICE ■ If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high. If the reservoir needs frequent refilling, it may indicate a serious problem.
  • Page 362 4-3. Do-it-yourself maintenance ■ Checking the fluid level Make sure to check the fluid type and prepare the necessary items. ® Fluid type Automatic transmission fluid DEXRON II or III Items Rag or paper, clean funnel (only for adding fluid) STEP Clean all dirt off the reservoir.
  • Page 363 Check the battery condition by the indicator color. Good condition Type A Type B Charging necessary. Green Blue Have the battery checked by your Toyota dealer. Not working properly, have the Dark White battery checked your Toyota dealer. Clear or light yellow...
  • Page 364 4-3. Do-it-yourself maintenance ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive. Therefore, before recharging: ● If recharging with the battery installed on the vehicle, be sure to discon- nect the ground cable. ● Make sure the power switch on the charger is off when connecting and disconnecting the charger cables to the battery.
  • Page 365 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: ●...
  • Page 366 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid If any washer does not work or the low washer fluid warning light comes on, the washer tank may be empty.
  • Page 367: Tires

    ■ Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection. Do not fail to initialize the tire...
  • Page 368 4-3. Do-it-yourself maintenance ■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 396) Installing tire pressure warning valves and transmitters When replacing tires or wheels, tire pressure warning valves and transmitters must also be installed.
  • Page 369 4-3. Do-it-yourself maintenance ■ How to initialize the tire pressure warning system STEP Park the vehicle in safe place and turn the “ENGINE START STOP” switch or the engine switch OFF. While the vehicle is moving, initialization is not performed. STEP Adjust the tire inflation pressure to the specified cold tire infla- tion pressure level.
  • Page 370 When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer. ■ When to replace your vehicle’s tires Tires should be replaced if: ●...
  • Page 371 4-3. Do-it-yourself maintenance ■ Maximum load of tire Check that the maximum load of the replacement tire is greater than 1/2 of the Gross Axle Weight Ratings (GAWR) of either the front axle or the rear axle, whichever is greater. For the GAWR, see the Certification Label.
  • Page 372 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
  • Page 373 4-3. Do-it-yourself maintenance ■ Tire pressure warning system certification FCC ID: PAXPMV107J FCC ID: HYQ13BCX IC ID: 3729A-PMV107J IC ID: 1551A-13BCX For vehicles sold in the U.S.A. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 374 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 375 4-3. Do-it-yourself maintenance NOTICE ■ Driving on rough roads Take particular care when driving on roads with loose surfaces or pot- holes. These conditions may cause losses in tire inflation pressure, reducing the cushioning ability of the tires. In addition driving on rough roads may cause damage to the tires themselves, as well as the vehicle’s wheels and body.
  • Page 376: Tire Inflation Pressure

    4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 437) Type A Type B I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 377 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended levels, adjust tire pressure.
  • Page 378 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 379 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
  • Page 380: Wheels

    ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 381 Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
  • Page 382: Air Conditioning Filter

    4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Set the air conditioning system to recirculated mode. The air conditioning filter case cannot be removed with the sys- tem in the outside air mode.
  • Page 383 (500 kPa, 5.0 kgf/cm bar). If it is not available, have the filter cleaned by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 384 4-3. Do-it-yourself maintenance ■ Replacement method Remove the air conditioning filter from the filter case and replace it with a new one. ↑UP” marks shown on “ the filter and the filter case should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
  • Page 385: Key Battery

    4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with rag.) ●...
  • Page 386 4-3. Do-it-yourself maintenance Remove the depleted battery. STEP Insert a new battery with the “+” terminal facing up. ■ Replacing the battery (vehicles without smart key system) Remove the cover. STEP Remove the module. STEP I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 387 Use a CR1632 (vehicles with smart key system), or CR2016 (vehicles without smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by a Toy- ota dealer.
  • Page 388 4-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the remote control. ●...
  • Page 389: Checking And Replacing Fuses

    4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Turn the “ENGINE START STOP” switch or the engine switch OFF.
  • Page 390 4-3. Do-it-yourself maintenance Remove the fuse with the pull- STEP out tool. STEP Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse...
  • Page 391 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit Rear window defogger, outside RR DEF 50 A rear view mirror defogger Anti-lock brake system, vehicle ABS/VSC No.2 30 A stability control system RDI FAN 50 A Electric cooling fan Anti-lock brake system, vehicle ABS/VSC No.1...
  • Page 392 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 140 A (Limited Charging system, RR DEF, ABS/ grade) VSC No.2, HEATER, ABS/VSC 120 A No.1, RDI FAN, WASHER, S-HORN (XL, XLS grade) Electronic controlled transmission system, multiport fuel injection STOP No.3 7.5 A system/sequential multiport fuel injection system Multiport fuel injection system/...
  • Page 393 4-3. Do-it-yourself maintenance Fuse Ampere Circuit STR LOCK 25 A Steering lock system STOP No.1 15 A Multiplex communication system Multiport fuel injection system/ EFI No.1 25 A sequential multiport fuel injection system, fuel pump HORN 10 A Horn HEAD LH UPR 15 A Left-hand headlight (high beam) HEAD RH UPR...
  • Page 394 4-3. Do-it-yourself maintenance ■ Driver’s side instrument panel Fuse Ampere Circuit RR DOOR 20 A Power window RL DOOR 20 A Power window Power window, driving position FR DOOR 20 A memory system 15 A Front fog lights 7.5 A On-board diagnosis system MPX-B 7.5 A...
  • Page 395 4-3. Do-it-yourself maintenance Fuse Ampere Circuit S-HTR 20 A Air conditioning system DOOR No.2 25 A Multiplex communication system S/ROOF 30 A Moon roof Parking lights, license plate lights, TAIL 10 A tail lights, front and rear side marker lights Seat heaters, navigation system, emergency flashers, electronically controlled...
  • Page 396 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, SRS airbag system, front 10 A passenger occupant classification system, smart key system, starting system, electronic controlled transmission system Gauges and meters, center GAUGE No.2 7.5 A display Power rear view mirrors, center...
  • Page 397 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
  • Page 398: Headlight Aim (With Discharge Headlights)

    4-3. Do-it-yourself maintenance Headlight aim (with discharge headlights) ■ Vertical movement bolts Adjustment bolt A Adjustment bolt B ■ Before checking the headlight aim STEP Make sure the vehicle has a full tank of gas and the area around the headlight is not deformed. STEP Park the vehicle on level ground.
  • Page 399 If you feel that there is a large deviation, have the headlight aim adjusted at a Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 400: Light Bulbs

    4-3. Do-it-yourself maintenance Light bulbs You may replace the following bulbs yourself. For more information about replacing other light bulbs, contact your Toyota dealer. ■ Prepare a replacement light bulb. Check the wattage of the light bulb being replaced. (→P. 438) ■...
  • Page 401 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Rear turn signal lights, stop/tail and rear side marker lights Open the trunk, remove the STEP cover as follows. Turn the bulb bases counter- STEP clockwise and remove (upper and lower), or squeeze bulb base and remove (center).
  • Page 402 4-3. Do-it-yourself maintenance ■ License plate lights Use a flathead screwdriver to STEP disengage the side of the lamp. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 403 The high mounted stoplights consist of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. If two or more LEDs in a stoplight burn out, your vehicle may not conform to local laws (SAE).
  • Page 404 Doing so could result in electric shock and death or serious injury. ■ High-intensity discharge (HID) headlights (if equipped) ● Contact your Toyota dealer before replacing high-intensity discharge headlights (including light bulbs). ● Do not touch the high-intensity discharge headlight’s high voltage socket when the headlights are turned on.
  • Page 405: Essential Information Emergency Flashers

    5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
  • Page 406: If Your Vehicle Needs To Be Towed

    If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 407 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 408 5-1. Essential information Towing with a wheel lift-type truck From front Release the parking brake. From rear Use a towing dolly under the front wheel. NOTICE ■ To prevent causing damage to the transmission Never tow this vehicle from the rear with the front wheel on the ground. ■...
  • Page 409 5-1. Essential information Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 410: If You Think Something Is Wrong

    5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
  • Page 411: Fuel Pump Shut Off System

    5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
  • Page 412: Event Data Recorder

    5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is a system to record data in a crash or a near car crash event.
  • Page 413 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle’s owner (or the leasing company for a leased vehicle) is obtained ●...
  • Page 414: Steps To Take In An Emergency If A Warning Light Turns On Or A Warning Buzzer Sounds

    Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer) •...
  • Page 415 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Malfunction in: (U.S.A.)
  • Page 416 5-2. Steps to take in an emergency Warning light Warning light/Details ABS warning light (U.S.A.) Malfunction in: • The ABS; or • The brake assist system. (Canada) Automatic headlight leveling system warning light Malfunction in the automatic headlight leveling system. (if equipped) Vehicle stability control system warning light Malfunction in the VSC system or TRAC system.
  • Page 417 Low tire inflation pressure. pressure. When the light stays on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. Low washer fluid warning light Fill the tank. Low level of washer fluid...
  • Page 418 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Engine oil replacement reminder light Illuminates for about 3 sec- onds and then flasher for Check and the engine oil, about 15 seconds: and change if necessary. Engine oil is scheduled to (U.S.A.) be changed.
  • Page 419 5-2. Steps to take in an emergency Have the malfunction repaired immediately. (vehicles with smart key system) After taking the specified steps to correct the suspected problem, check that the warning light turn off. Interior Exterior Correction Warning light Details buzzer buzzer procedure...
  • Page 420 5-2. Steps to take in an emergency Interior Exterior Correction Warning light Details buzzer buzzer procedure An open door other than the driver’s door is closed while the Turn the electronic key is “ENGINE outside the detec- START STOP” Once 3 times tion range and the switch OFF or...
  • Page 421 Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
  • Page 422 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
  • Page 423 If the tire pressure warning light comes on after blinking for 1 minute when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it checked by your Toyota dealer. Vehicles without smart key system If the tire pressure warning light comes on after blinking for 1 minute when the engine switch is turned to the “ON”...
  • Page 424 Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. ● Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
  • Page 425 5-2. Steps to take in an emergency CAUTION Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light).
  • Page 426: If You Have A Flat Tire

    5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
  • Page 427 5-2. Steps to take in an emergency Take out the jack Remove the cover. STEP To remove the jack, turn the jack STEP joint by hand until the jack becomes free. Taking out the spare tire Remove the luggage floor cover. STEP I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 428 5-2. Steps to take in an emergency Loosen the center fastener that STEP secures the spare tire. Remove the spare tire cover. STEP I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 429 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
  • Page 430 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire.
  • Page 431 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
  • Page 432 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Reinstall the wheel ornament. STEP STEP Stow the flat tire, tire jack and all tools. ■...
  • Page 433 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
  • Page 434 ■ When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
  • Page 435: If The Engine Will Not Start

    5-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting procedures → are being followed ( P. 133, P. 137), consider each of the following points. ■ The engine will not start even when the starter motor oper- ates normally One of the following may be the cause of the problem.
  • Page 436 ● There may be a malfunction in the steering lock system (vehi- cles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart key system) When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
  • Page 437: If The Shift Lever Cannot Be Shifted From P

    (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
  • Page 438: If You Lose Your Keys

    5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the other master keys and the key number stamped on your key number plate.
  • Page 439: If The Electronic Key Does Not Operate Properly (With Smart Key System)

    Changing “ENGINE START STOP” switch modes and starting the engine STEP Put the shift lever in “P” and apply the brakes. Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate...
  • Page 440 5 seconds after the buzzer sounds, keeping the brake pedal depressed. If the “ENGINE START STOP” switch still cannot be operated, con- tact your Toyota dealer. ■ Stopping the engine Shift the shift lever to “P” and press the “ENGINE START STOP” switch as you normally do when stopping the engine.
  • Page 441: If The Vehicle Battery Is Discharged

    You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12 volt battery, you can jump start your Toyota following the steps below.
  • Page 442 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
  • Page 443 5-2. Steps to take in an emergency ■ When the battery is removed or discharged The following systems must be initialized. → ● Power windows ( P. 74) → ● Moon roof ( P. 79) CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery.
  • Page 444 5-2. Steps to take in an emergency CAUTION ■ Battery precautions The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: ● When working with the battery, always wear safety glasses and take care not to allow any battery fluids (acid) to come into contact with skin, clothing or the vehicle body.
  • Page 445: If Your Vehicle Overheats

    If the fan is operating: Wait until the engine coolant temperature gauge begins to fall and then stop the engine. If the fan is not operating: Stop the engine immediately and call your local Toyota dealer. After the engine has cooled STEP...
  • Page 446 STEP Water can be used in an emer- gency measure if coolant is unavailable. (→P. 435) Have the vehicle checked at your nearest Toyota dealer as soon as possible. ■ Overheating In the following situations, your vehicle may be overheating.
  • Page 447 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 448: If The Vehicle Becomes Stuck

    5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the engine. Set the parking brake and shift the shift lever in “P”.
  • Page 449 5-2. Steps to take in an emergency I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 450: 6-1. Specifications

    6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 197.6 in. (5020 mm) Overall width 72.8 in. (1850 mm) Overall height 58.5 in. (1485 mm) Wheelbase 111.0 in. (2820 mm) Front 62.2 in. (1580 mm) Tread Rear 61.6 in.
  • Page 451 6-1. Specifications Vehicle identification The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 452 6-1. Specifications Engine Model 2GR-FE Type 6-cylinder V type, 4-cycle, gasoline 3.70 × 3.27 in. (94.0 × 83.0 mm) Bore and stroke Displacement 210.9 cu.in. (3456 cm Drive belt tension Automatic adjustment Fuel Fuel type Unleaded gasoline only Octane Rating 87 (Research Octane Number 91) or higher Fuel tank capacity 18.5 gal.
  • Page 453 6.0 qt. (5.7 L, 5.0 lmp.qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
  • Page 454 6-1. Specifications How to read oil container label: The ILSAC (International Lubricant Standardization and Approval Committee) Certification Mark is added to some oil containers to help you select the oil you should use. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 455 Cooling system Capacity 8.8 qt. (8.3 L, 7.3 lmp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
  • Page 456 NOTICE ■ Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmis- sion of your vehicle.
  • Page 457 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Tire size P215/55R17 93V Vehicle speed (kPa, kgf/cm or bar) Front and rear tire inflation pressure More than 99 mph 38 (260, 2.6) (Recommended cold tire (160 km/h) inflation pressure) 99 mph...
  • Page 458 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Low beam (discharge bulbs) Low beam (halogen bulbs) High beam HIR1 Fog lights Front turn signal/parking 3457A 28/8 lights Front side marker lights Exterior Rear turn signal lights 7440A Stop/tail lights 7443 21/5 Rear side marker lights...
  • Page 459: Fuel Information

    ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
  • Page 460 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ●...
  • Page 461 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s three-way catalytic converters causing the emission control system to malfunction.
  • Page 462: Tire Information

    6-1. Specifications Tire information Typical tire symbols Tire size (→P. 444) DOT and Tire Identification Number (TIN) (→P. 443) Location of treadwear indicators (→P. 345) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Tire ply composition and materials Plies are layers of rubber-coated parallel cords.
  • Page 463 6-1. Specifications Maximum cold tire inflation pressure (→P. 447) This means the pressure to which a tire may be inflated. Load limit at maximum cold tire inflation pressure (→P. 447) Summer tire or all season tire (→P. 349) An all season tire has “M+S” on the sidewall. A tire not marked “M+S”...
  • Page 464 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
  • Page 465 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 466 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
  • Page 467 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 468 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
  • Page 469 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu- on the tire pant weight (distributed in accordance with Table 1 below), and dividing it by two The surface area of the rim not covered by the...
  • Page 470 6-1. Specifications Tire related term Meaning A tire designed to operate at higher loads and Extra load tire at higher inflation pressures than the corre- sponding standard tire Groove The space between two adjacent tread ribs The layer(s) forming the inside surface of a Innerliner tubeless tire that contains the inflating medium within the tire...
  • Page 471 6-1. Specifications Tire related term Meaning Outer diameter The overall diameter of an inflated new tire The linear distance between the exteriors of the sidewalls of an inflated tire, including eleva- Overall width tions due to labeling, decorations, or protective bands or ribs A tire intended for use on passenger cars, mul- tipurpose passenger vehicles, and trucks, that...
  • Page 472 6-1. Specifications Tire related term Meaning That portion of a tire between the tread and Sidewall bead The parting of the rubber compound from the Sidewall separation cord material in the sidewall A tire that attains a traction index equal to or greater than 110, compared to the ASTM E- 1136 Standard Reference Test Tire, when using the snow traction test as described in...
  • Page 473 6-1. Specifications Designated seating Occupant distribution in Vehicle normal load, capacity, Number of a normally loaded Number of occupants occupants vehicle 2 through 4 2 in front 2 in front, 1 in second 5 through 10 seat 2 in front, 1 in second 11 through 15 seat, 1 in third seat, 1 in fourth seat...
  • Page 474: Customization Customizable Features

    Programming these preferences requires specialized equipment and may be performed by your Toy- ota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
  • Page 475 6-2. Customization Customized Item Function Default setting setting Operation indicator (Emergency flashers) Operation indicator (Buzzer) Trunk unlocking func- Wireless tion remote control Push twice Trunk unlocking opera- Push and hold (→P. 36) tion One short push Panic function Buzzer sounds when pushing with any door not closed...
  • Page 476 6-2. Customization Customized Item Function Default setting setting Driver’s door unlocked in 1- All doors Unlocking using a key step, all doors unlocked unlocked in 1-step in 2-step Speed-detecting auto- matic door lock function Door lock → P. 40) Opening driver’s door unlocks all doors Shift the shift lever to “P”...
  • Page 477 6-2. Customization Customized Item Function Default setting setting Switching operation when the vehicle is sta- tionary Windshield Drip prevention function wipers and washer Variable (→P. 160) Time elapsed before depending on the drip prevention 3 seconds the vehicle function operates speed 7.5 seconds Time elapsed before...
  • Page 478: Initialization Items To Initialize

    6-3. Initialization Items to initialize After reconnecting or performing maintenance on the battery, the fol- lowing items must be initialized for normal system operation. Item When to initialize Reference • After reconnecting or changing the Power window P. 75 battery Moon roof P.
  • Page 479: Reporting Safety Defects For U.s. Owners

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 480: Seat Belt Instructions For Canadian Owners (In French)

    Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 481 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 482 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 483 I n f o r ma t i o n P r o v i d e d b y : AVALON_U (OM41437U)
  • Page 484: Abbreviation List

    Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor GAWR Gross Axle Weight Ratings Emission inspection and maintenance LATCH Lower Anchors and Tethers for Children Light Emitting Diode Methylcy clopentadienyl Manganese Tricarbonyl M + S...
  • Page 485: Alphabetical Index

    Alphabetical index Alphabetical index A/C ..........198 Automatic light control ABS........... 181 system ........156 Air conditioning system Automatic transmission Air conditioning filter ..... 360 Automatic transmission ..140 Automatic air conditioning If the shift lever cannot be system........ 198 shifted from P......416 Steering switches ....
  • Page 486 Alphabetical index Child safety Display Airbag precautions ....97 Trip information .....155 Child-protectors.......42 Do-it-yourself maintenance ..324 Child restraint system....109 Door pocket......285 How your child should wear Doors the seatbelt ......64 Door lock......24, 36 Installing child restraints..113 Rear door child-protector ..42 Moon roof ........79 Driver’s seat belt reminder Power window lock switch..74...
  • Page 487 Alphabetical index Engine Fuel Compartment......330 Capacity ........432 Engine switch ....133, 137 Fuel gauge ......148 Hood........327 Fuel pump shut off system ..390 How to start the Gas station information ..476 engine ......133, 137 Information ......439 Identification number .... 431 Refueling .........80 If the engine will not start..
  • Page 488 Alphabetical index I/M test........323 Lights Ignition switch....133, 137 Emergency flasher switch ..384 Identification Fog light switch .....159 Engine ........431 Hazard light switch....384 Vehicle ........431 Headlights switch ....156 Illuminated entry system..275 Interior lights list ....275 Indicator lights ......151 Outer foot light ......275 Initialization Personal light switch .....277 Items to initialize....458...
  • Page 489 Alphabetical index Outside temperature Seat belts display........289 Adjusting the seat belt.....62 Overhead console ....281 Automatic locking Overheating, Engine ....424 retractor ........63 Child restraint system installation......113 Parking brake ......146 Cleaning and maintaining Parking lights the seat belts ......316 Replacing light bulbs ....
  • Page 490 Alphabetical index Shift lock system .....416 Tail lights Shopping bag hooks ....299 Replacing light bulbs.....379 Side airbags........90 Switch ........156 Side marker lights Wattage......... 438 Switch........156 Theft deterrent system Side mirror Alarm........85 Adjustment ......72 Engine immobilizer system ..83 Mirror position memory ...55 Theft prevention labels .....87 Smart key system Tire inflation pressure .....437...
  • Page 491 Alphabetical index Valet key........22 Wheels ........358 Vanity lights Window glasses ......74 Vanity lights ......287 Window lock switch....74 Wattage ........ 438 Windows Vanity mirrors......287 Power windows .......74 Vehicle identification Rear window defogger ..208 number........431 Washer........160 Vehicle load limits....188 Windshield wipers ....160 VSC...........
  • Page 492: What To Do If

    What to do if... What to do if... A tire punctures If you have a flat tire P. 405 P. 83 Engine immobilizer system The engine does not start P. 414 If the engine will not start P. 420 If the battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
  • Page 493: Warning Lights

    What to do if... The warning light or indicator If the warning light turns on P. 393 light comes on ■Warning lights Brake system warning Malfunction indicator light lamp P. 393 P. 394 Driver’s seat belt reminder ABS warning light light P.
  • Page 494: Gas Station Information

    6.4 (6.1, 5.4) (Drain and refill) Without filter 6.0 (5.7, 5.0) “Toyota Genuine Motor Oil” or equivalent Engine oil type Oil grade: ILSAC multigrade engine oil P. 433 I n f o r ma t i o n P r o v i d e d b y :...

Table of Contents
