- Page 1 SY-P4I845PE Motherboard Quick Start Guide...
- Page 2 All of our customers should ensure that their use of our products does not infringe upon any patents. It is the policy of SOYO Computer Inc. to respect the valid patent rights of third parties and not to infringe upon or to cause others to infringe upon such rights.
- Page 3 Motherboard. This guide provides all users with the basic steps of Motherboard setting and operation. For further information, please refer to the SY-P4I845PE Motherboard User' s Manual that came with your Motherboard.
-
Page 4: Sy-P4I845Pe Motherboard Layout
SY-P4I845PE Quick Start Guide SY-P4I845PE Motherboard Layout PS/2 Mouse PS/2 Mouse PS/2 KB Connector Connector COM A +12V Power COM B ATX Power USB 1_2 LAN Connector AOUT IDE 2 DDR1 DDR2 DDR3 AGP Slot AMIC DAVICOM DM9102AE AGAME PCI Slot #1... -
Page 5: Key Features
Hardware Doctor™ utility Support Serial ATA 1 channel Supports AC97 4 channel Codec On-board 10/100 mbps NIC Easy CPU settings in BIOS with the “SOYO COMBO Setup” - CPU voltage adjust - CPU ratio adjust - CPU FSB adjust... -
Page 6: Installation
Follow the directions in this section which is designed to guide you through a quick and correct method to install your new SY-P4I845PE Motherboard. For detailed information, please refer to the SY-P4I845PE Motherboard User' s Manual and T echnical Reference online manual on the CD-ROM that came with your Motherboard. -
Page 7: Install The Motherboard
SY-P4I845PE Quick Start Guide Install the Motherboard We will now begin the installation process. Please follow the systematic procedure designed to lead you to a complete and correct installation. Step 1- Install the Central Processing Unit (CPU) Step 2- Install memory modules... -
Page 8: Memory Configuration Table
Panel Devices (ACPI LED, Internal Speaker, Reset Button, IDE LED, and KeyLock Switch.), Wake-On-LAN card, VGA card, Sound Card, and other devices. For more details on connecting internal and external peripherals to your new SY-P4I845PE Motherboard, please refer to SY-P4I845PE Motherboard User' s Manual and T echnical Reference... - Page 9 SY-P4I845PE Quick Start Guide Connectors and Plug-ins CPU Cooling Fan: CPUFAN1 CPU Cooling Fan: CPUFAN2 Pi n 1 Pi n 2 Pi n 3 Pi n 1 Pi n 2 Pi n 3 +12V Sensor +12V Sensor Chassis Fan: CHAFAN1...
-
Page 10: Install Expansion Cards
SYP4I845PE Quick Start Guide ATX 12V Power Supply: ATX PW Attach the ATX 12V Power cable to three connector. (Thi s motherboard requi r es an ATX 12V power suppl y , an AT and ATX power suppl y can NOT be used.) When usi n g the Power-On by PS/2 Keyboard functi o n, pl e ase make sure the ATX power supply i s abl e to provide at l e ast 720mA on the 5V Standby l e ad (5VSB). - Page 11 SY-P4I845PE Quick Start Guide CMOS Clear (JP5) In some cases the CMOS memory may contain wrong data, follow the steps below to clear the CMOS memory. Clear the CMOS memory by momentarily shorting pin 2-3 on jumper JP5. This jumper can be easily identified by its white colored cap.
-
Page 12: Quick Bios Setup
This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS [SOYO COMBO FEATURE]. The [SOYO COMBO FEATURE] combines the main parameters that you need to configure, all in one menu, for a quick setup in BIOS. - Page 13 Insert the SOYO CD into the CD-ROM drive Step 1. If you use Windows NT or 2000, the SOYO-CD will not detect your motherboard type. In that case the following dialog will pop up, please choose your motherboard and press OK. Now the SOYO-CD Start Up Menu will be shown.
- Page 14 SY-P4I845PE Quick Start Guide The user' s manual files included on the SOYO CD are in PDF (Postscript Document) format. In order to read a PDF file, the appropriate Acrobat Reader software must be installed in your system. Note: The Start Up program automatically detects if the Acrobat Reader utility is already present in your system, and otherwise prompts you on whether or not you want to install it.
- Page 15 SY-P4I845PE Quick Start Guide driver revision: Intel Chipset Software Installation Utility for Win 98/98SE/ME/2000/XP Intel Application Accelerator for Win 98/98SE/ME/NT/2000/XP C-MEDIA Audio Driver/Application for Win 9x/ME/2000/NT/XP P4I845PE hardware monitor for Win 9x/ME/2000/NT/XP Davicom Onboard Lan Driver Installation (click here for installation procedure) HighPoint371 Raid &...
- Page 16 Check the Latest Releases Step 3. Click the ' C onnect to SOYO website' button to go the SOYO Website to find the latest BIOS, manual and driver releases for your motherboard. This button will only work if your computer is connected to the internet through a network or modem connection.
- Page 17 Sel e ct the fol l o wi n g di r ectory. The di r ectory i s i n SOYO CD “d:\LAN\Davi c om” (where D: i s your CD-ROM) then cli c k ok and you wi l l need wi n dows 98 second Edi t i o n CD to compl e te the i n stal l a ti o n, put i t i n your CD-ROM.
- Page 18 Sel e ct “Instal l from a l i s t or speci f i c locati o ns”, cl i c k it. Cl i c k on “Next”. Cli c k “Browse”. The LAN dri v er directory i s i n SOYO CD “d:\LAN\Davi c om” (where D: i s your CD-ROM), then press “ok”.
- Page 19 Driver item, then click button. 3. In the follow-on window, select Have Disk..4. Insert the Soyo cd of driver, input the path of driver D:\Raid\Hpt371\121\WinNT, then click 5. In the follow-on window, select HPT371 UDMA/ATA133 Controller item, then click 6.
- Page 20 3. Double click “! RAID controller” 4. Re-install driver 5. Choose “search for a suitable driver….” 6. Insert SOYO Driver CD, click next 7. During installation, Win 2K will prompt you to insert the RAID driver diskette 8. Browse to the directory that contains the missing file (D:\raid\hpt371\121\Win2000).
- Page 21 SY-P4I845PE Quick Start Guide Installing Driver During OS Installation Install driver during Windows NT4.0 installation 1. Go to “d:\raid\hpt371\121\” directory, (assuming that your CD-ROM is drive d) copy all the files and directory to a floppy disk. 2. Press key when the system prompts Setup is inspecting your computer’s hardware configuration.
- Page 22 SY-P4I845PE Quick Start Guide Enter to continue. 7. The follow-on interface will list the devices to be installed, in which HPT371 UDMA/ATA133 Controller item should be included (If users want to install other devices, please operate at this time. If all devices have been successfully installed, please go to next.)
- Page 23 SY-P4I845PE Quick Start Guide Serial-ATA Driver Installation Win 98SE/2000/XP installation 1. Seri a l - ATA chip will be automati c al l y detected after instal l ing Hi g hpoi n t371 dri v er.
-
Page 24: Boot-Up Issues
SY-P4I845PE Quick Start Guide Quick Trouble shoot tips Boot-up Issues The system do not power-up, no beeping sound heard and the CPU fan does not turn Check if the power cord is plug to the power source. Check if the power is connected to the M/B. - Page 25 SY-P4I845PE Quick Start Guide CMOS). Make sure the power supply you have on your system support the M/B specification. Example. If you have a P4 M/B, you need to use a P4 power supply. If you already checked the power supply specification, change the power supply it might be defective.
- Page 26 The BIOS chip is defected due to unsuccessful flash, contact your nearest SOYO branch for re-flashing. Is there a way to reprogram my BIOS after an unsuccessful flash? No other way, you need to send back the BIOS ROM to your nearest SOYO branch for re-flashing.
-
Page 27: Audio Issue
Audio Issue How can I disable the on-board Audio? Go to the SOYO Combo Feature in the BIOS setup, then set the “onboard audio” to disable. I cannot get the sound working on my system. Check if the speaker wire is connected to the line out connector in the M/B. - Page 28 SY-P4I845PE Quick Start Guide Please go to sound properties and check if the recorder and microphone in the are enabled. Check if Microphone is ok. Hard disk/FDD/ CD-ROM issue My Western digital HDD is not detected during boot-up Change the jumper settings to cable select or single.
-
Page 29: Lan Issues
SY-P4I845PE Quick Start Guide LAN Issues During LAN driver installation, the system hangs on 75%, why? Enable the onboard LAN in the BIOS setup. I have problem installing Novell NetWare v.50 Disable the APIC option in the BIOS. For updated FAQs, please check http://www.soyo.com.tw/faq.htm... - Page 30 SY-P4I845PE Quick Start Guide How to contact us: If you are interested in our products, please contact the SOYO sales department in the region you live. If you require Technical Assistance, please contact our T echnical Support in the region you live.
- Page 31 Edition : October 2002 Version P1.0 SY-P4I845PE SERIAL...
