Thank you for purchasing a Panasonic product.
Please read this document and save it for future reference.
To use this unit in your country, first change the unit's region setting to match
your country (page 45).
Please access our online customer survey:
http://panasonic.net/pcc/tel/q
Premium Design Phone with Touchscreen
Operating Instructions
KX-PRX150AZ
Model No.
Advertisement
Table of Contents
Related Manuals for Panasonic KX-PRX150AZ
Summary of Contents for Panasonic KX-PRX150AZ
-
Page 1: Operating Instructions
Premium Design Phone with Touchscreen KX-PRX150AZ Model No. Thank you for purchasing a Panasonic product. Please read this document and save it for future reference. To use this unit in your country, first change the unit’s region setting to match your country (page 45). -
