Summary of Contents for Fujitsu Siemens Computers STYLISTIC ST50XX

  • Page 1 EasyGuide STYLISTIC ST50XX English...
  • Page 2 Are there ..any technical problems or other questions which you would like to be clarified? Please contact: ● your sales partner ● your sales outlet Further information can be found in the "Safety" and "Warranty" manuals. The latest information on our products, tips, updates, etc., can be found on the internet under: http://www.fujitsu-siemens.com...
  • Page 4 Distributed by Fujitsu Siemens Computers GmbH Order No.: A26391-K145-Z120-1-7619 Edition 3 AG 1004 10/04...

  • Page 5: User Guide

    Getting Started Using the Tablet PC STYLISTIC ST50XX Security functions Care and maintenance Troubleshooting and tips User Guide Technical data Regulatory information Index October 2004 edition...
  • Page 6 All other trademarks referenced are trademarks or registered trademarks of their respective owners, whose protected rights are acknowledged. Copyright © Fujitsu Siemens Computers GmbH 2004. All rights, including rights of translation, reproduction by printing, copying or similar methods, in part or in whole, are reserved.

  • Page 7: Table Of Contents

    Contents Getting Started..........................1 Tablet PC features and controls ......................1 Top side view..........................1 Under side ..........................2 Rear side view ...........................2 Left side view..........................3 Right side view...........................3 Status display ............................4 Application buttons / security panel buttons..................6 Navigation buttons ..........................9 Additional functions of application and navigation buttons ...............10 Interfaces, ports and other hardware components ................12 Using the Tablet PC........................15 System modes..........................15...
  • Page 8 Contents Security functions ......................... 37 Overview of all security functions ....................37 Kensington Lock........................37 Security Panel (only under Windows)..................37 BIOS password protection....................... 37 SmartCard reader ........................38 Using Trusted Platform Module (optional) ................38 Brief overview of the security functions ................... 39 Configuring and using Security Panel (only under Windows)............

  • Page 9: Getting Started

    Getting Started The STYLISTIC ST50XX Tablet PC is a powerful pen-based computer that has been designed to support Microsoft Windows XP Tablet PC Edition. This chapter provides an overview of the Tablet PC and its features and controls. Tablet PC features and controls Features and controls that you use to operate the Tablet PC are outlined below and illustrated in the figures.

  • Page 10: Under Side

    Getting Started Under side 1 = On/Off switch for wireless LAN/ Bluetooth 4 = Memory module cover 2 = Hard disk drive cover 5 = Battery release latch 3 = Tablet Dock port 6 = Removable battery Rear side view 1 = Pen / pen garage 5 = PC card eject button 2 = Anchorage for pen retention cord...

  • Page 11: Left Side View

    Getting Started Left side view 1 = USB ports 6 = LAN port 2 = Headphones port 7 = Modem port 3 = Microphone jack 8 = Kensington Lock slot 4 = FireWire port 9 = Port for power adapter 5 = Monitor port (with port cover) Right side view...

  • Page 12: Status Display

    Getting Started Status display Icons appear in the status display indicating the status of system functions such as system mode and battery charge level. 1 = Power-on indicator 2 = Power source indicator 3 = Battery charge level indicator 4 = Hard disk indicator 5 = Security Panel indicator The following table lists the different display states: The specification "blinking"...
  • Page 13 Getting Started Icon Mode Indicator state Remarks ON mode Green Battery charge is between 50%-100%. Idle mode Amber Battery charge is between 13%-49%. Battery charge is between 0%-12%. Red, blinking There is a battery error. Suspend-to-RAM Green, blinking slow Battery charge is between 50%-100%. mode Amber, blinking slow Battery charge is between 13%-49%.

  • Page 14: Application Buttons / Security Panel Buttons

    Getting Started Application buttons / security panel buttons Allow you to quickly launch pre-defined applications and utilities by pressing a button. Certain buttons have additional functions. You can activate this additional functions by pressing the Fn button while pressing the Application button. The Application buttons also have separate additional functions that can be used while the system is booting up.
  • Page 15 Getting Started Button name and Tablet PC icon Function description icon (Fn + button) The Alt button performs two functions: Alt button If you hold the Alt button down for two seconds, you can log onto the system again: – after system startup –...
  • Page 16 Getting Started Button name and Tablet PC icon Function description icon (Fn + button) The ESC button has the same function as the ESC button Application A Esc key on a keyboard. button Pressing the Fn + ESC buttons at the same time, acts to invoke a pre-determined application or keystroke combination, as assigned the Tablet Button Settings utility.

  • Page 17: Navigation Buttons

    Getting Started Navigation buttons Each of the buttons can be toggled by pressing either end of the button. The navigation buttons have dual functions. The additional functions are activated by pressing the Fn button while pressing the Navigation button. The buttons also have separate additional functions that can be used while the system is booting up.

  • Page 18: Additional Functions Of Application And Navigation Buttons

    BIOS Setup. Any changes you make take effect as soon as you save and quit the BIOS Setup. The system is booting up while the Fujitsu Siemens Computers logo is displayed immediately after turning on the system. The following table shows which additional functions the application and navigation buttons offer when booting the system and in the BIOS Setup.
  • Page 19 Getting Started Buttons and icons Purpose (when pressed while the system is booting up) Pressing the Fn button while the system is displaying the operating Fn key system boot menu opens the Windows Advanced Options Menu. This menu allows you to set different operating system modes (such as safe mode).

  • Page 20: Interfaces, Ports And Other Hardware Components

    Getting Started Interfaces, ports and other hardware components Ports and peripheral interfaces on the Tablet PC allow connection of a variety of devices. Each of the illustrated icons is either moulded into or printed on the Tablet PC casing. Port / Peripheral Tablet PC icon Meaning Slot for a Type I or Type II PC card...
  • Page 21 Getting Started Port / Peripheral Tablet PC icon Meaning An infrared transceiver built into the Tablet Infrared port (IrDA/FIR) PC allows you to communicate with other devices that are compliant with the IrDA Standard Rev. 1.1. Effective range for infrared communication is about 3 feet, and within 15 degrees of centre;...
  • Page 22 Getting Started Port / Peripheral Tablet PC icon Meaning With the Kensington MicroSaver you can Kensington Lock protect your Tablet PC from theft. The Kensington MicroSaver is available as an accessory. The FireWire jack allows you to connect FireWire port between your Tablet PC and peripherals such as a digital video camera.

  • Page 23: Using The Tablet Pc

    Using the Tablet PC This chapter covers the fundamental concepts, basic system operation and use, and system functions of the Tablet PC. The casing of your Tablet PC can become very warm during prolonged operation with the power supply unit. Therefore, touch the device carefully and only in the areas coated with a thermal suede if possible.

  • Page 24: Suspend Mode

    Using the Tablet PC Suspend mode There are two different Suspend modes: Your system may be configured to use either Suspend-to-RAM mode or Hibernate mode. Suspend-to-RAM mode All system functions are turned off to conserve power. Power to memory is on, maintaining data in programs that were running before system operation was suspended.

  • Page 25: Powering Up The Tablet Pc

    Using the Tablet PC Powering up the Tablet PC Follow the procedure below to start the Tablet PC. However, you must first make sure that the system is switched off (OFF mode, hibernate mode). To do so, observe the Status display: ●...

  • Page 26: Enabling Suspend Mode

    Using the Tablet PC Enabling Suspend mode The Tablet PC allows you to suspend the system operation without closing programs or exiting the operating system. Use this feature to conserve battery power when a system shutdown is not practical or when the battery needs to be changed. If you have set your system to turn Shut down from the Power Options utility in the Control Panel, the following procedure will not be possible, since pressing the button shuts the system down rather than suspending it.
  • Page 27 Using the Tablet PC Refer to the "Resuming operation" section in this chapter to resume system operation. Also, note the following with regard to suspending system operation: ● You can remove the battery while the system is in Suspend-to-RAM or Hibernate mode in order to install a charged battery.

  • Page 28: Resuming Operation

    Using the Tablet PC Resuming operation To resume system operation (from either Suspend-to-RAM or Hibernate mode), press the On/Resume/Suspend button. ● From Suspend-to-RAM mode Status indicators indicate that the system mode is changing. It may take approximately one minute before the system returns to the ON mode and system operation resumes. Note that the display turns on shortly before the pen becomes active due to the power-up sequences observed by the system.

  • Page 29: Setting The Display Brightness

    Using the Tablet PC Setting the display brightness Depending upon whether you are running your system on battery or power adapter, the default screen brightness settings will be different. The screen brightness default for running on battery is lower than that on power adapter in order to optimise battery life. If you do not use the Tablet PC for a short time, you can minimise or switch off the screen lighting to save energy.

  • Page 30: Using The Pen

    Using the Tablet PC Using the pen You can use the pen of the Tablet PC to generate and create electronic "ink", to select items, and to navigate through programs on the Tablet PC. Programs that support handwriting recognition also allow you to write characters directly on the screen with the pen.

  • Page 31: Calibrating The Pen

    Using the Tablet PC The screen reacts when the pen tip is approximately 1/8 inch (3-5mm) from the screen. With the pen you can run all functions for which you otherwise use a mouse. In addition, you can very conveniently delete hand-written pen entries using the pen. Select menu entries (click with the left mouse button) ►...

  • Page 32: Installing A Pen Tether

    Using the Tablet PC Installing a pen tether To prevent dropping or losing your pen, you should attach it to your system using the pen tether that is available as an accessory. 1 = Anchorage for pen retention cord 2 = Larger loop 3 = Smaller loop To attach the pen to your Tablet PC, perform the following steps: ►...

  • Page 33: Replacing The Pen Tip

    Using the Tablet PC Replacing the pen tip With use, the pen tip may become worn or may pick up foreign particles that can scratch the screen. A damaged or worn tip may not move freely, causing unpredictable results when using the pen. If your pen exhibits these problems, you should replace the pen tip.

  • Page 34: Charging The Battery

    Using the Tablet PC Charging the battery ► Install the battery (see the "Removing and installing the battery" section). ► Connect the power adapter to the Tablet PC. The DC Input icon appears in the Status display. Look at the Battery Gauge icon in the Status display to determine the percent of charge in the battery.

  • Page 35: Removing Battery

    Using the Tablet PC Removing battery ► Push the battery lock (1) in the direction of the arrow. ► Pull the battery out of the Tablet-PC in the direction of the arrow (2). Inserting battery ► Orient the battery with the slides in the empty battery tray. ►...

  • Page 36: Tips For Conserving Battery Power

    Using the Tablet PC Tips for conserving battery power Battery life is dependent upon the operating system, power settings, and applications in use. You can extend the charge life of your battery by conserving battery power: ● Use an external power source such as the power adapter whenever the system is docked to a Tablet Dock.

  • Page 37: Modem Port

    Using the Tablet PC Modem port The internal LAN/56-Kbps modem module of the Tablet PC supports transmission rates of up to 56 Kbps (receive), 33.6 Kbps (send) and 14.4 Kbps (fax). (Download rates are limited to 53 Kbps in the United States due to FCC restrictions.) The Tablet PC is designed to accept a standard RJ-11 telephone plug.

  • Page 38: Removing A Pc Card

    Using the Tablet PC Removing a PC card ► First click the Safely Remove Hardware icon in the task bar in the bottom right-hand corner of the display. Select the device that is to be removed and click on Shut down. ►...

  • Page 39: Storage Card Slot

    Using the Tablet PC Storage card slot The slot is suitable for storage cards of the type "Secure Digital I/O", "Memory Stick" and "Memory Stick PRO". Inserting the storage card ► Gently push the storage card into the slot until you feel it click into place. Removing the storage card ►...

  • Page 40: Removing And Installing Memory Modules

    Using the Tablet PC Removing and installing memory modules Your Tablet PC has two DIMM slots. 256-Mbyte, 512-Mbyte and 1-Gbyte modules are available so that you can install up to 2 Gbytes of memory in your system. A DIMM replacement should only be carried out at a suitable workplace. You must statically discharge yourself (e.g.

  • Page 41: Installing A Memory Module

    Using the Tablet PC ► Carefully push the two mounting clips outwards (1). The memory module will flap upward (2). ► Pull the memory module out of its slot in the direction of the arrow (3). Installing a memory module ►...
  • Page 42 Using the Tablet PC ► Insert the memory module, contacts first, into the slot (1). ► Carefully push the memory module downwards until it engages noticeably (2). The memory module is coded to prevent it from being inserted backwards. ► Position the cover on its slot in the direction of the arrow (1).

  • Page 43: Wireless Lan/ Bluetooth (Optional)

    Using the Tablet PC Wireless LAN/ Bluetooth (optional) As an option, your Tablet PC can be equipped with an integrated wireless LAN and/or Bluetooth module. The wireless LAN/ Bluetooth module is switched off in the delivered state. The configuration program of the network card for Wireless LAN is provided for configuring the Wireless LAN and indicating the status of the network card.

  • Page 44: Switching Wireless Lan/ Bluetooth Module Off

    Using the Tablet PC Switching wireless LAN/ Bluetooth module off ► Slide the ON/OFF switch into the "OFF" position to deactivate the wireless LAN/ Bluetooth module. A26391-K145-Z120-1-7619, edition 3...

  • Page 45: Security Functions

    Security functions Your Tablet PC enables you to protect your system and personal data against unauthorised access in a number of ways. By combining these options, you can achieve maximum protection for your system. If you lose both the user and the admin passwords, you must contact our help desk. The telephone numbers are contained in the "Help Desk"...

  • Page 46: Smartcard Reader

    Security functions Password protection for the operating system With corresponding settings in the BIOS Setup you can block starting of the operating system. Only those who know the supervisor or user password can access the system. Password protection for your hard disk By activating the hard disk protection in the BIOS Setup you prevent unauthorised access to the hard disk drive.

  • Page 47: Brief Overview Of The Security Functions

    Security functions Brief overview of the security functions Security function Type of protection Preparation Kensington Lock Mechanical Mount and lock Kensington MicroSaver (accessory) Security Panel (activation Hardware password Install the programs provided only possible under protection with Supervisor and specify the numeric Windows) and User password.

  • Page 48: Configuring And Using Security Panel (Only Under Windows)

    Security functions Configuring and using Security Panel (only under Windows) Security panel Configuring Security Panel When you put your Tablet PC into operation for the first time, the Security Panel is not activated yet. Assign the necessary passwords with the programs FJSECS.EXE (Supervisor password) and FJSECU.EXE (User password).

  • Page 49: Setting A Supervisor Password

    Security functions To set the passwords, proceed in the following order: Setting a supervisor password The setup programme can be found under Start - AddOn. ► Double-click on the symbol to start the setup programme for FJSECS.EXE. The programme starts. ►...

  • Page 50: Using Security Panel

    Security functions Assigning the user password The setup programme can be found under Start - AddOn. ► Double-click on the symbol to start the setup programme for FJSECU.EXE. The programme starts. ► Enter the programme name FJSECU.EXE under Start - Run. ►...

  • Page 51: Configuring Password Protection In Bios Setup

    Security functions Configuring password protection in BIOS Setup Before using the various options of password protection for your data security in the BIOS Setup, please note the following hint: Please keep in mind your passwords in any case, as you will not be able to access your BIOS Setup and/or your system any longer, if you forget both the user password and the supervisor password.

  • Page 52: Password Protection For Starting The Operating System

    Security functions Change supervisor or user password ► Recall BIOS Setup and select the Security menu. When changing the password, proceed exactly as for password assignment. You can only change the supervisor password when you have logged into the BIOS Setup with the supervisor password.

  • Page 53: Password Protection For Hard Disk

    Security functions Deactivating system protection ► Call BIOS Setup and select the Security menu. ► Mark the Password on Boot field and press the Enter key. ► Select Disabled and press the Enter key. If you do not want to make any other settings, you can exit BIOS Setup. ►...

  • Page 54: Using The Smartcard Reader

    Security functions Using the SmartCard reader 1 = SmartCard reader SmartCards SmartCards are not supplied as standard equipment. You can use all SmartCards that comply with the ISO standard 7816-1, -2, -3 and -4. These SmartCards are available from various manufacturers.

  • Page 55: Inserting The Smartcard

    Security functions Inserting the SmartCard Do not use force when inserting and removing the SmartCard. Make sure that foreign objects do not fall into the SmartCard reader. ► Slide the SmartCard into the SmartCard reader with the chip facing upward and at the front. When the SmartCard is properly inserted, it protrudes by approximately 2 cm.

  • Page 56: Troubleshooting

    Security functions Troubleshooting Security panel You have forgotten your password or passwords. If you have forgotten the user password, you can reset the forgotten user password and specify a new user password with the supervisor password. If the Security panel is active and you have forgotten both the user password and the supervisor password, then contact our help desk.

  • Page 57: Care And Maintenance

    Care and maintenance This chapter gives you pointers on how to care for and maintain your Tablet PC. Protecting the display screen The Tablet PC is designed to provide you with years of service. Using a screen protector will help ensure that the screen remains as clear as possible.
  • Page 58 Care and maintenance ► Remove the protective coating from the adhesive side of the screen protector. ► Align the screen protector on the edges of the screen and lay it on the screen surface with the adhesive side downward (see illustration). ►...
  • Page 59 Care and maintenance To ensure a good seal between the screen protector and the display, do not lift the screen protector from the display once it has been applied. A plastic protective coating is provided on the screen protector that must be pulled off before touching the screen with the pen.

  • Page 60: On The Road With Your Tablet Pc

    ● To protect against damaging jolts and bumps, use a Tablet PC carrying case to transport your Convertible PC. Fujitsu Siemens Computers offers a number of solutions for transporting your Tablet PC. Contact your sales outlet. ● Protect the Tablet PC from severe shocks and extreme temperatures (e.g., direct sunlight in a car).

  • Page 61: Cleaning The Display Screen

    Care and maintenance Cleaning the display screen Clean the display by wiping the screen surface gently using a soft cotton cloth dampened with isopropyl alcohol. The Tablet PC is not waterproof. Do not pour liquids on the system or wash it with a heavily soaked cloth.

  • Page 63: Troubleshooting And Tips

    Troubleshooting and tips In the following sections possible solutions to problems that may occur are described. If you are experiencing a problem with your Tablet PC that you cannot solve by taking the actions described, contact your sales partner or hotline/help desk for further assistance. System will not resume operation If the system will not resume operation after system operation has been suspended, check the following possible causes:...

  • Page 64: Infrared Data Transfer Is Not Working

    Troubleshooting and tips Infrared data transfer is not working If you are experiencing problems transferring data over the infrared receiver of the device, note the following: ● Can the infrared receiver on the Tablet PC "see" the infrared interface on the other device? A direct line-of-sight path must exist between the infrared receiver on the Tablet PC and the infrared interface on the other device.

  • Page 65: Technical Data

    Technical data Tablet PC The following table provides general hardware specifications of the Tablet PC. Dimensions and weight Width/depth/height: 220 mm x 324.4 mm x 20.9 - 22.3 mm Weight: approx. 1.59 kg Processor CPU: Ultra low voltage processor Mobile Intel Pentium M with Enhanced SpeedStep technology Chipset: Intel 855 GME...
  • Page 66 Technical data Operation controls: ● Application buttons with additional functions ● On/Resume/Suspend button ● 2 navigation buttons Battery Main battery: ● 6 cell ● removable, Lithium ion ● 10.8 V; 4400 mAh ● Replaceable in Suspend mode ● Recharge Time: Suspend/Off: approx.

  • Page 67: Regulatory Information

    Regulatory information Changes or modifications not expressly approved by Fujitsu Siemens Computers could void this user’s authority to operate the equipment. CE marking CE marking for devices without radio component The shipped version of this device complies with the requirements of the EEC directives 89/336/EEC "Electromagnetic compatibility"...

  • Page 68: Declaration Of Conformity

    Fax No.: (408) 746-8299 We, Fujitsu Siemens Computers Inc., hereby declare that the equipment bearing the respective trade name and model number specified above was tested conforming to the applicable FCC rules under the most accurate measurement standards possible, and that all the necessary steps have been taken and are in force to assure that production units of the same equipment will continue to comply with the Commissions requirements.

  • Page 69: Regulatory Notices

    US trading area. Regulatory information for Tablet PC's without radio device NOTICE: Changes or modifications not expressly approved by Fujitsu Siemens Computers could void this user’s authority to operate the equipment. Notice to Users of Radios and Television These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 70 Regulatory information Notice to Users of the US Telephone Network Your Tablet PC may be supplied with an internal modem which complies with Part 68 of the FCC rules. On this Tablet PC is a label that contains the FCC Registration Number and the Ringer Equivalence Number (REN) for this equipment among other information.
  • Page 71 Regulatory information FCC rules prohibit the use of non-hearing aid compatible telephones in the following locations or applications: ● All public or semipublic coin-operated or credit card telephones. ● Elevators, highways, tunnels (automobile, subway, railroad or pedestrian) where a person with impaired hearing might be isolated in an emergency.
  • Page 72 Regulatory information NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is 0.0. The REN assigned to each terminal equipment provides an indication of the maximum number of terminals allowed to be connected to a telephone interface. The termination on an interface may consist of any combination of devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of all the devices does not exceed five.

  • Page 73: Fcc Regulatory Information For Tablet Pc's With Radio Device

    Regulatory information UL Notice This unit requires an AC adapter to operate. Use only UL Listed Class 2 adapter, output rating 19 V DC, 4.22 A. Refer to the illustration below for the correct AC Adapter output polarity: CAUTION: To reduce the risk of fire, use only 26AWG or larger telecommunications line cord. For Authorized Repair Technicians Only CAUTION: For continued protection against risk of fire, replace only with the same type and rating...
  • Page 74 Regulatory information If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: ●...
  • Page 75 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Modifications not expressly authorized by Fujitsu Siemens Computers may invalidate the user's right to operate this equipment. A26391-K145-Z120-1-7619, edition 3...

  • Page 77: Index

    Index Display 57 Agency approval specifications 58 Display Mode button 7 Application buttons 1, 6 Display screen blank or difficult to read 55 Display screen, protecting 49 additional functions 10 DOC (INDUSTRY CANADA) NOTICES 63 Alt 7 ENT 8 E-Mail button 7 ESC 8 Energy saving, battery 28 Fn 8...
  • Page 78 Index Power adapter, port 3, 12 Memory 57 Power draw, system modes 15 Memory module Power On/Resume/Suspend button 1, 14 cover 2 Power supply, indicator 4 installing 33 Power-on indicator 4 removing 32 Processor 57 Microphone 1 Microphone (optional) 1 Microphone jack 3, 12 Regulatory information 59 Mobile operation 52...
  • Page 79 Index Tablet Dock, port 2 Universal Serial Bus 3 Tablet PC USB port 3, 12 switching off 17 User Password, setting 42 switching on 17 will not resume operation 55 Tablet-PC Ventilation slots 2 storing 53 Volume, too low 56 Technical data, Tablet PC 57 Tips 55 TPM 38...
