USER'S MANUAL
for the
Model CFP24W2
24 INCH AMLCD FLAT PANEL COLOR
MONITOR
Document # 150-CF24-101
Nov 2009
1 Riga Lane, Birdsboro, PA 19508 USA
Telephone: 610-404-7400 * Fax: 610-404-8190 *
www.aydindisplays.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFP24W2 and is the answer not in the manual?

Questions and answers

Sassan Purirani
May 8, 2025

where do I download driver for CFP24W2 touch screen display?

0

Related Manuals for Aydin Displays CFP24W2

Summary of Contents for Aydin Displays CFP24W2

  • Page 1 USER’S MANUAL for the Model CFP24W2 24 INCH AMLCD FLAT PANEL COLOR MONITOR Document # 150-CF24-101 Nov 2009 1 Riga Lane, Birdsboro, PA 19508 USA Telephone: 610-404-7400 * Fax: 610-404-8190 * www.aydindisplays.com...

  • Page 2: Table Of Contents

    Table of Contents Introduction.......................3 Specifications ....................3 Front Panel Buttons/On-Screen Display............4 3.1. Front Panel Buttons...................4 3.2. Power Management ..................4 On-Screen Control Function Items ..............6 4.1. OSD (ON SCREEN DISPLAY) – PRE ADJUSTMENT NOTICE ....6 4.1.1. OSD Timeout Period ................6 4.1.2. OSD Activation...................6 4.1.3.

  • Page 3: Introduction

    Introduction The Model CFP24W2 AMLCD Monitor is a 24” diagonal display with a native resolution of 1600 x 1200 (WUXGA). The display is designed to operate from 115/220 VAC, 60Hz, single phase. Inputs are provided for DVI-D, VGA and Video.

  • Page 4: Front Panel Buttons/On-Screen Display

    3. Front Panel Buttons/On-Screen Display 3.1. Front Panel Buttons Press MENU to display the On-Screen-Display (OSD). Use the ▲ and ▼ to move the cursor to the desired menu selection and press MENU to access the adjustment or function. With the √ button you can exit the current function and go back to the previous menu point.
  • Page 5 To extinguish the No Sync symbol and display an image, do one of the following: Supply a format with Horizontal or Vertical Synchronization frequencies that are compatible with the display. Connect a video source to the selected video input on the display Enable the correct video input source by pushing the ‘√’...

  • Page 6: On-Screen Control Function Items

    On-Screen Control Function Items 4.1. OSD (ON SCREEN DISPLAY) – PRE ADJUSTMENT NOTICE 4.1.1. OSD Timeout Period The OSD (On Screen Display) has a user-selectable Timeout Period. If the OSD is activated and no front panel keys are depressed for a period of 5 to 60 seconds, the OSD will automatically deactivate.

  • Page 7: Osd (On Screen Display) - Stored Values

    4.2. OSD (ON SCREEN DISPLAY) – STORED VALUES Values chosen during OSD interaction are stored in memory under the following conditions: √ The “ ” is pressed • Timeout period expires • Values chosen during OSD interaction are not stored in memory under the following conditions: √...

  • Page 8: Osd Menu Navigation - Image Menu (Main Vga Mode)

    1) Choose the desired Sub-Function. The currently selected Sub-Function will be distinguished by the white font color displayed on the Selection Button. Example: Source After the desired Sub-Function is highlighted, press the “MENU” key to activate the highlighted Sub-Function √ Press the “...
  • Page 9 When the IMAGE menu is highlighted, press the “MENU” key to access the IMAGE menu. The OSD will auto-index to the first selection (Auto Adjust) on the menu list. The selection will be highlighted with a raised background and a blue indicator dot as per the example below.

  • Page 10: Osd Menu Navigation - Pip Menu

    4.5. OSD MENU NAVIGATION – PIP MENU If the OSD is not visible, press the “MENU” key once to activate the OSD. Press ▼ ▲ the [ ] or [ ] keys to navigate to the PIP menu Observe the following choices in the PIP Menu Selection List: Source - (Multiple Sub-Function Selection Buttons) •...

  • Page 11: Osd Menu Navigation - Color Menu

    2) Adjust the desired Level. Example: Adjustment Indicator Brightness ▼ ▲ After the desired selection is activated, press the [ ] or [ ] keys to set the desired level. √ Press the “ ” key one time to accept the desired level and resume navigation in the PIP Menu Selection List.

  • Page 12: Osd Menu Navigation - Controls Menu

    1) Choose the desired Sub-Function. The currently selected Sub-Function will be distinguished by the white font color displayed on the Selection Button. Example: sRGB After the desired Sub-Function is highlighted, press the “MENU” key to activate the highlighted Sub-Function. √ Press the “...
  • Page 13 1). Adjust the desired Level. Example: Adjustment Indicator Back Light ▼ ▲ After the desired selection is activated, press the [ ] or [ ] keys to set the desired level. √ Press the “ ” key one time to accept the desired level and resume navigation in the CONTROLS Menu Selection List.
  • Page 14 ▼ ▲ When the Factory Reset OSD is displayed, press the [ ] or [ ] keys to select the following: No (Default Selection) – Do Not Perform Factory Reset • Yes – Perform Factory Reset • √ If “No” is highlighted, press the “MENU” or “ ”...

  • Page 15: Osd Menu Navigation - Osd/Reset Menu - Factory Reset13

    4.9. OSD MENU NAVIGATION – OSD/RESET MENU – STANDARD FUNCTIONS If the OSD is not visible, press the “MENU” key once to activate the OSD. Press ▼ ▲ the [ ] or [ ] keys to navigate to the OSD/RESET menu Observe the following choices in the OSD/RESET Menu Selection List: Factory Reset - (Single Sub-Function Selection Button) •...

  • Page 16: Osd Menu - Sample Images

    4.10. OSD MENU – SAMPLE IMAGES MAIN - VGA MAIN - DVI IMAGE COLOR CONTROLS 150-CF24-101 16 of 19...
  • Page 17 OSD/RESET 150-CF24-101 17 of 19...

  • Page 18: Touch Screen Drivers

    5. Touch Screens 5.1 Drivers Your newly purchased AMLCD display may have a Resistive Touch Option. If it does, please install the following Touch Driver. If you require further assistance, please contact Aydin Displays’ Customer Service at 610-404-7400 x 5322. http://home.eeti.com.tw/web20/eg/drivers.htm 150-CF24-101...

  • Page 19: Maintenance

    6. Maintenance 6.1 Preventive Maintenance The only periodic maintenance recommended is exterior surface cleaning when necessary. The window and exterior surfaces may be cleaned with standard non-abrasive glass cleaners applied with a soft cloth to avoid scratching the anti-reflective coating on the glass panel. 6.2 Corrective Maintenance The only field corrective maintenance recommended is fuse replacement .
