- Page 1 FloorMaster™ 200-C Cleat Nailer IMPORTANT! OPERATING MANUAL AND DO NOT DESTROY SCHEMATIC It is the customer’s responsibility to have all operators and service personnel read and understand this manual.
-
Page 2: Safety Instructions
What DUO-FAST will do: DUO-FAST will, within the applicable warranty period, replace or repair at DUO-FAST's option, the tool without any cost for parts or labor. All tools must be accompanied by their original dated sales receipt. -
Page 3: Tool Specifications
TOOL AND FASTENER SPECIFICATIONS TOOL SPECIFICATIONS MODEL NO. 502190 HEIGHT 23.23” WIDTH 3.15” LENGTH 17.72 “ WEIGHT 10lbs. 5.3oz. OPERATING PRESSURE 60 to 100 p.s.i. CLEAT NAIL SIZES CLEAT NAIL SIZES LENGTH 1-1/2” - 2” GAUGE/HEAD 16ga. L cleat TOOL AIR FITTINGS This tool uses a 1/4”... - Page 4 DO NOT DISABLE OR REMOVE THE WORK CON- Use only parts and fas ten ers spe cifi cal ly designed and TACT ING ELEMENT rec om mend ed by Duo-Fast for use in the tool and This tool is equipped with a safety mechanism, called a ®...
-
Page 5: Operating The Tool
UNPACKING When unpacking, check and make sure that all accessories are included. If anyone is missing or broken, please contact your distributor. Refer to the following lists, 1 each: Hammer S3 Hex key S5 Hex key Operating instructions Nailer S4 Hex key Air tool oil CONNECTING THE TOOL WITH THE AIR SUPPLY 1. - Page 6 EXPLODED VIEW L Cleat Nailer #502190 WARNING All parts must be periodically inspected and replaced if worn or broken. Failure to do this can affect the tool’s operation and present a safety hazard.
- Page 7 L Cleat Nailer - 502190 PARTS LEGEND Key# Part# Description Key# Part# Description 501783 Plunger 501809 Screw 501784 O-Ring 501810 Spring Washer 501785 O-Ring 502114 Screw 501786 Poppet 502208 Rail 501787 O-Ring 502209 Magazine 501788 O-Ring 502211 Spring 501789 O-Ring 502212 502202 Piston Assembly...
-
Page 8: Troubleshooting
TROUBLESHOOTING STOP USING THE TOOL IMMEDIATELY IF ANY OF THE FOLLOWING PROBLEMS OCCUR. SERIOUS PERSONAL INJURY COULD OCCUR. REPAIRS OR REPLACEMENTS MUST BE DONE BY A QUALIFIED PERSON OR AN AUTHORIZED SERVICE CENTER. A. Tighten and recheck. Air leaking in cylinder cap A.
