NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affi xed on the machine to their customers/users.
2. Equipment to be installed by TFI Authorized Dealer or a service
company approved by TFI.
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by TFI Authorized Dealer or a service company approved by TFI.
5. Must use only genuine TFI replacement parts.
6.
Machine must be anchored to a solid and level surface.
TUFFSTUFF FITNESS INTERNATIONAL
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
CLM-855WS
Lat/Low Row Combo Machine
w/200 Lbs. Weight Stack
CLM-855WS_Rev0
Revision Date 4-22-2014
Advertisement
Table of Contents
Related Manuals for TFI CLM-855WS
Summary of Contents for TFI CLM-855WS
- Page 1 Lbs. Weight Stack 2. Equipment to be installed by TFI Authorized Dealer or a service company approved by TFI. 3. Provide trained personnel, supervision and correct usage of the equipment.
-
Page 2: Table Of Contents
Should additional information be required, or should situations arise that are not covered by this owner’s manual, the matter should be directed to Customer Service at Tuff Stuff Fitness International Inc. in Chino, California. www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... -
Page 3: Overhead Specifi Cations
Overhead Specifi cations L 77” X W 46” X H 83” PRODUCT WEIGHT 345 lbs MAX-LOAD WEIGHT LIMIT - 200 lbs CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com... -
Page 4: Danger, Warning, & Caution Labels Information
Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... - Page 5 Carefully read ALL Danger, Warning & Caution labels posted on the machine CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com...
- Page 6 Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack...
- Page 7 Alert Sign for home with your order, you can obtain one at no cost to you from Tuff Stuff Fitness by contacting our service department at: 1 (888) 884-8275 service@tuff stuff .net service1@tuff stuff .net CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com...
-
Page 8: Anchoring
Anchoring Holes on frame are provided for anchoring the unit to the fl oor. (See anchoring hole locations below) www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... -
Page 9: Important Safety Instructions
14. Maintain a service contract with a TFI Authorized Dealer or a Do not use accessories or accessory attachments that are not Professional Service Company approved by TFI. Keep a service recommended by TFI. -
Page 10: Registration, Service & Aassembly
Registration, Service & Assembly Thank you for purchasing the CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly. -
Page 11: Inspection/Maintenance
Perform regular maintenance (see Inspection Label). Pay special attention to areas most susceptible to wear and tear, including but not limited to cables, pulleys and rubber grip. TFI recommends you maintain a service contract with a TFI Authorized Dealer or a Professional Service Company approved by TFI. -
Page 12: Cable Inspection
IMPORTANT NOTE: DAMAGED OR WORNED CABLE (AS SHOWN ABOVE) MAY DAMAGE THE PULLEY(S). YOU MUST INSPECT THE PULLEYS AT THIS TIME FOR WEAR AND TEAR. REPLACE IF NEEDED. www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... -
Page 13: Step 1
NYLON INSERT JAM LOCK NUT Z/P 3/8-16 FLAT WASHER SAE Z/P 3/8” PLASTIC INSERT CAP 1” RD 10-12 GA Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com... -
Page 14: Step
SPLIT LOCK WASHER Z/P 3/8” FLAT WASHER SAE Z/P 3/8” 10 LB STEEL WEIGHT PLATE BLACK Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... -
Page 15: Step 3
FLAT WASHER SAE Z/P 3/8” FOOT ROLL TUBE 1 X 18 1/4 SOCKET SET SCREW Z/P 1/4-20 X 1/4 Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com... -
Page 16: Step 4
8. Open the lube package provided and apply a thin fi lm of lubricant around the fi rst 3 inches of the guide rods above the top plate. 9. After the cables are installed, do a set of reps to spread the lubricant thoroughly. www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... -
Page 17: Step 5 Cable Routing
7/8 RD X 1 5/8 LINK (3/16 CABLE) SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 FINISHED HEX NUT B/O 1/2-13 Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com... -
Page 18: Step 6
BUTTON HEAD SOCKET CAP SCREW Z/P 3/8-16 X 1 SPLIT LOCK WASHER Z/P 3/8” FLAT WASHER SAE Z/P 3/8” Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... -
Page 19: Parts List
HEX HEAD CAP SCREW GR 5 Z/P 3/8 16 X 5 LABEL WARRANTY LIGHT COMMERCIAL BNH2051 BNH3136 TFI EMBLEM 1.88 HIGH X 1.98 WIDE BLUE AND CHROME BUTTON HEAD SOCKET CAP SCREW Z/P 3/8 16 X 1 BNH2033 BNH4304 SPLIT BOLT GR 8 Z/P 1/2 13 X 1 (RND CUT) FACILITY SIGN BE ALERT! THE FITNESS EQUIPMENT... -
Page 20: Pre-Assembled Components
Pre-Assembled Components *1 UP8340X1 *4 UP8343X1 *2 UP8341X1 www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack... - Page 21 Pre-Assembled Components *3 UP8342X1 *5 UP8344X1 *6 UP8345X1 CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com...
- Page 22 Pre-Assembled Components *7 UP8305X1 *8 UP8346X1 *10 BNH0295 *11 BNH0294 www.tuff stuffi tness.com CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack...
-
Page 23: Pre-Assembled Components
Pre-Assembled Components *12 UP8348X1 *13 UP8349X1 *18 UP0092X1 *21 BNH2020 *56 BNH1650 CLM-855WS Lat/Low Row Combo Machine w/200 Lbs. Weight Stack www.tuff stuffi tness.com... -
Page 24: Warranty
TuffStuff. The obligation of TFI under this warranty is limited to repairing or replacing warranted defective parts as TFI may elect, at TFI’s facility in Chino, California, without charge to the purchaser. Purchaser is responsible for installation of repaired or replaced parts, and all transportation and insurance costs on returned or replaced equipment to and from TFI’s facility in Chino.
