- Page 1 Owner’s Manual ESPRIT Handle Bars Saddle Stem Battery Saddle Post Fork Motor Crank Derailleur Spoke Pedal Chain Kickstand Mudguard This manual contains important safety, assembly, operational and maintenance advice. THIS MANUAL SHOULD BE READ BEFORE OPERATING THE BICYCLE www.bicycles4u.com...
-
Page 2: User Security
User Security Regular check’s for safety before riding 1) Check if the handlebar stem and saddle post are safely inserted. Take note of the maximum height markings (MIN. INSERTION) on the tube. 2) Check the brake shoes for excess wear. If there is wear, you should replace them before riding. 3) Check if the nuts on the front and rear axis are securely fixed. -
Page 3: Battery And Charging
Battery and charging Instructions on the bike operation 2) Press down the power button. 1) To turn the power ON and OFF use the Throttle indicators lights come on. power button which is located on the battery. 3)To unlock the battery turn the key 4)To lock the battery turn the key towards the position shown below. -
Page 4: Safe Charging
Steps to charge the battery 1) Confirm that the local power supply corresponds with the requirement of the charger. The input voltage is between 100V-240V. 2) The battery can be charged on the e-bike or removed from the e-bike and charged separately. -
Page 5: How To Remove The Battery
How to Ride the Electric Bike Turn the power ON Use the key to turn on the power switch. Turn the throttle slowly to drive the bike forward. The remaining battery power is displayed on the panel after turning the power on. Power cut during braking To ensure the rider’s safety, the motor will stop working when braking and restart after the brake lever is released. -
Page 6: Troubleshooting
Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION Battery gauge Power switch is open Close the switch on the battery LEDs with no case display. Battery case with no power Charge the battery Circuited Replace fuse Battery case not positioned in the right Remove battery case, put it in place right place and then lock it... -
Page 7: General Maintenance Remarks
General Maintenance Remarks Cleaning and Maintenance Regular maintenance guarantees you a longer durability and road worthy state of your bike. Maintenance includes cleaning, lubricating and ride setting adjustments. Regular maintenance work is required to sustain a warranty claim. This applies to special corrosion (surface rust) and other damages, which by non-observance, would not be undertaken by us. - Page 8 Adjust the derailleur Adjust the Fine-tuning nut or screw when the derailleur makes some abnormal sound. The way to adjust the brake of the bike is the same as adjusting the gears. The most important thing is effective braking, releasing of the brake pads and the power brake function work well together.
