Samsung SCX-483xFD Service Manual page 213

CASSETTE Parts List
Drawer# Part Code Description
0 JC90-01036A CASSETTE
1 JC61-04127A FRAME-CASSETTE
2 JC64-00611A LOCKER-PLATE
3 JG61-70531A SPRING ETC-LOCKER,PLATE
4 JG66-40003A GEAR-PINION
5 JC90-01033A CASSETTE-GUIDE RIGHT
6 JC61-04128A GUIDE-SIDE RIGHT
7 JC66-02826A LEVER-SIDE RIGHT
8 JC61-04131A STOPPER-SIDE RIGHT
9 6107-002777 SPRING-CS
10 JC64-00426A KNOB-GUIDE_REAR
11 JC61-00013A SPRING ETC-PAD
12 JC70-20901A IEX-SHAFT IDLE,F/UP
13 JC90-01034A CASSETTE-GUIDE LEFT
14 JC61-04129A GUIDE-SIDE LEFT
15 JC70-20901A IEX-SHAFT IDLE,F/UP
16 JC64-00609A INDICATOR-PAPER
17 JC64-00610A LOCKER-CASSETTE
18 6107-001287 SPRING-CS
19 JC63-02932A GROUND-CASSETTE
20 JC61-04126A PLATE-P-KNOCK_UP
21 JC73-00141A RPR-PAD CASSETTE
22 6107-002779 SPRING-CS
23 JC90-01032A CASSETTE-ROLLER RETARD
Qty Service Remark Drawer#
1 SA 24 JC67-00465A
1 SA 25 JC73-00328A
1 SNA 26 JC61-04101A
1 SA 27 6107-002778
1 SA 28 JC63-02917A
1 SA 29 JC63-02933A
1 SA 30 JC63-02984A
1 SA 31 JC90-01035A
1 SA 32 JC61-04130A
1 SA 33 JC64-00612A
1 SNA 34 JC64-00613A
1 SNA 35 JC64-00614A
1 SA 36 JC66-02827A
1 SA 37 JC70-00594A
1 SA 38 JC70-00595A
1 SA 39 JC64-00615A
1 SA 40 JC61-04132A
2 SNA 41 JC64-00426A
2 SNA 42 6107-002777
1 SNA 43 JC61-00013A
1 SA 44 JC64-00608A
1 SA 45 JC63-03025A
2 SA 46 JC68-00780A
1 SA
55
SA : SERVICE AVAILABLE, SNA : SERVICE not AVAILABLE
Part Code Description
COUPLER-TORQUE_LIMITER
RUBBER-TL
HOLDER-RETARD_SHAFT
SPRING-CS
COVER-CASSETTE
SHEET-RETARD
SHEET-CASSETTE
CASSETTE-GUIDE REAR
GUIDE-REAR PAPER
LOCKER-RIGHT GUIDE
LOCKER-LEFT GUIDE
LOCKER-SLIDE GUIDE
LEVER-GUIDE REAR
ADJUST-REAR UPPER
ADJUST-REAR LOWER
LOCKER-ADJUST REAR
SUPPORT-GUIDE LOCK
KNOB-GUIDE_REAR
SPRING-CS
SPRING ETC-PAD
HANDLE-CASSETTE
ABSORBER-CST BOTTOM
LABEL(P)-CAUTION PRINTING
Qty Service Remark
1 SA
1 SA
1 SA
2 SA
1 SA
1 SNA
1 SA
1 SA
1 SA
1 SNA
1 SNA
1 SNA
1 SA
1 SA
1 SA
1 SNA
1 SA
1 SNA
2 SA
2 SNA
1 SA
1 SNA
1 SNA
