be holding charge as well as expected, it may be worn out and should be replaced by a new one.
Please consult the factory for further details and recommended battery treatment.
During battery charging, the printer may become quite warm. This can crease the paper within the
mechanism. The system designer may wish to feed out some paper before printing begins, either
controlled from the host, or by the user pressing the paper feed button.
4.7
VEHICLE ADAPTOR POWER PACK
The Direct Vehicle Adaptor Power Pack is designed to be operated from a standard +12V ( Negative
Earth) vehicle power source. It must be connected on a cable loom which is capable of supplying
10A and have a 10A in-line fuse in the positive connection.
Electrical Specification
Input Voltage Range:
Supply Current Requirement:
( typical )
N.B. The average and peak current requirements can be adjusted by firmware control codes.
See the Programmer Guide or contact Able Systems for details.
Printer Side Connector:
User Side Connector:
4.8
OEM 5-7.5V DC ADAPTOR PACK
The Direct 'Raw DC' Input Power Pack is designed to be operated from a 5V to 7.5V voltage source
which is capable of supplying the primary power for the printer. It must be connected on a cable loom
which is capable of supplying 10A and have a 10A in-line fuse in the positive connection.
Electrical Specification
Input Voltage Range:
Supply Current Requirement:
( typical )
N.B. The average and peak current requirements can be adjusted by firmware control codes.
See the Programmer Guide or contact Able Systems for details.
Printer Side Connector:
+11v to +18v
(with over-voltage spike protection)
2mA
( Printer in Sleep Mode )
100mA
( Printer in Idle Mode
3A average
( Printer Printing
10A peak
( Printer Printing
Molex Mini-Fit Junior Series 2 way
Part Number:
39-01-2021
Fitted with Molex Crimp Terminal
Part Number
39-00-0041
Molex Mini-Fit Junior Series 2way
Part Number:
39-01-2020
Recommended Molex Crimp Terminal (for the above connector)
Part Number:
39-00-0039 (2 off required)
+5.0V to +7.5V (without any over-voltage or reversal protection)
2mA
( Printer in Sleep Mode )
100mA
( Printer in Idle Mode
3A average
( Printer Printing
10A peak
( Printer Printing
This product has a cable with pre-stripped and tinned ends ready for
connection to the host PSU.
Ap863 Users' Guide Page 9 of 18
)
)
)
)
)
)
