Summary of Contents for Accurate Locators Pinpointer Pro
-
Page 2: Table Of Contents
Depth and type of target govern the type of tool (detector) needed. At ACCURATE LOCATORS we offer a wide variety of Imagers. Thank you for purchasing the PINPOINTER PRO Table of Contents Introduction and Packing Contents Getting Started PC Set Up... -
Page 3: Introduction And Packing Contents
This unit can be used with all USA IMAGER SYSTEMS. The PINPOINTER PRO is a stand alone unit. The control unit is in the antenna, just plug the USB cable into the computer, plug the other end into the antenna, open the program and you are ready to go. -
Page 4: Getting Started
Training is available with the purchase of a unit, and one hour of technical assistance is offered after purchase. Software The software included with the PINPOINTER PRO is installed and ready to go to work for you. Quick Start Procedure 1. -
Page 5: Pc Set Up
PC Set Up Green - Background Blue - Weak Target Red - Strong Targets Targets (common ground) (void, cave or tunnel) (metal chest, metal pipes) Scans / Second Scans per second is default set at 5, for normal walking speed of scan (how fast you travel). The highest setting of 10 would be for running or vehicle speed scanning. -
Page 6: Ground Balancing And Scan Methods
Ground Balancing and Scan Method Ground Balancing Pause and without turning the antenna (clockwise or counter clockwise) set PC at "0" (click on start) over ground that is known not to have a target, this is referred to as ground balancing. -
Page 7: Scan Methods And Samples
Scan Method and Samples When detecting hallow objects or objects with disturbed ground you can read both negative and positive numbers as it can detect the metal or the void, also the direction (north, south) the antenna is facing can influence the numbers. The indicating numbers may not be large, it is the difference in numbers that is the indicator. -
Page 8: Scan Samples
Scan Samples Using the Pinpointer Pro Scans Performed in the Dry Desert Climate at Walking Speed South to North Travel -1 / 1 Tire Rim Buried 6 ft. Deep North to South Travel -1 / +1 PVC Buried 2 ft. Deep... -
Page 9: Scan Samples
Scan Samples Using the Pinpointer Pro Scans Performed in the Dry Desert Climate at Walking Speed South to North Travel Copper, Aluminum and Other Metals Buried 5 ft. Deep North to South Travel +1 / -1 Copper, Aluminum and Other Metals Buried 5 ft. Deep... -
Page 10: Scan Sample And Pinpointer Pro Options
In mining, GPS positioning data can be critical to mission planning, safety and legal claim. Accurate Locators offers a number of GPS survey systems, optimized for mining surveys to acquire and stake out features with precision accuracy. GPS systems can also be used to lay out shaft connections from the surface to guide tunneling. -
Page 11: Trouble Shooting
Erroneous readings may be a result of the antenna being turned clockwise or counterclockwise. Low battery can be a factor in eronious readings although your computer will warn you with a low battery notice. Accurate Locators Inc. 1383 2nd Ave. Gold Hill, Oregon 97525 866-369-1975 775-751-6931 Sales Phone No. -
Page 12: Warranty
Puerto Rico or from Province to Province or Territory in Canada. Accurate Locators Inc.'s warranty is for repair or replacement of products that proves to be defective in workmanship or material subject to the warranty period and any other condition set forth on the package.
