Page 1: User Manual
User Manual HD+ Smart TV Satelliten Receiver HIGH DEFINITION MULTIMEDIA INTERFACE... - Page 2 HD+ Smart TV Satellite Receiver User Manual...
-
Page 3: Table Of Contents
Table of contents notices Before using the product Remote control Setup The Installation Wizard Basic Operation The Main Menu HbbTV Applications connecting external USB devices Program Guide (EPG) control Panel channel Lists Editing Video, photos and music streaming over your home network Frequently Asked Questions Technical Specifications... -
Page 4: Notices
notices cOPyRIGHT© 2013 TELESTAR Digital GmbH; not to be copied, used or translated in part or whole without TELESTAR prior consent in writing except approval of ownership of copyright and copyright law. Television programs, movies, video tapes, discs, and other materials may be copyrighted. - Page 5 cAUTIOn: PREVEnTIOn OF ScREEn BURn-In continuous display of still images and graphics, such as on-screen displays, stock market tickers, and other fixed (non-moving) patterns can cause permanent damage to the television. Plasma screen displays, projection televisions, and cRT televisions are especially susceptible to this. ABOUT THIS MAnUAL Instructions in this manual describe the operation using the controls on the remote.
- Page 6 VEnTILATIOn • Do not expose the product to high temperatures, such as placing it on top of other product that produce heat or in places exposed to direct sunlight or spot lights. • The ventilation slots on top of the product must be left uncovered to allow proper airflow into the unit. Do not stand the product on soft furnishings or carpets.
-
Page 7: Before Using The Product
Before using the product This chapter provides detailed description of the product and its accessories. PAcKAGE cOnTEnT Remote control User manual WLAn-Antenna 2 Batteries HDMI cable HD+ Smart card FROnT PAnEL 1. VFD Display 2. Standby indication LED 3. Standby key - Switches between operation and standby modes. 4. - Page 8 Scena 6x (IDL6650n) Rear Panel Graphics REAR PAnEL SPDIF Audio R AC 230V WiFi 50-60Hz LNB In 30W Max. Electrical shock hazard! Do not open! 950-2150Mhz Elektroschock-Gefahr! Nicht öffnen! Made in China 13/18V Max. 400mA 22Khz SPDIF Optical eSATA Video Audio L 10 11 1.
-
Page 9: Remote Control
Remote control FIRST TIME USE: Two 3V Lithium cR2032 batteries come pre-installed in your remote control. When using the remote for the first time, pull out the plastic tab from the remote to activate the batteries. REPLAcInG THE BATTERIES: With screwdriver, remove the battery tray. Insert the batteries with the “+” marking facing up into the battery tray. - Page 10 18 Unlock keyboard / backlit key press indication led 19 ALTGr function key Delete / Escape 20 ALT function key Zoom In Zoom Out 21 Tab forward backward Home-page shortcut 22 cAPS function key 30 navigation color keys Back Favorites Menu –...
-
Page 11: Setup
Setup This section explains the most important functions to ensure that you can directly watch television with your new digital receiver. Please note, additional adjustments may be required. Note: Do not connect the digital receiver to the main power yet. Connecting the Antenna and LNB (Low Noise Block) to the digital satellite receiver input connect the LnB on the satellite dish antenna directly to the digital receiver using the “LnB in”... -
Page 12: The Installation Wizard
cOnnEcTIOn DIAGRAM Home Network Analogue Audio Digital Audio SPDIF Audio R AC 230V WiFi 50-60Hz LNB In 30W Max. Electrical shock hazard! Do not open! 950-2150Mhz Elektroschock-Gefahr! Nicht öffnen! 13/18V Made in China Max. 400mA 22Khz SPDIF Optical eSATA Video Audio L Video output only eSATA devices... - Page 13 AnTEnnA SETTInGS Satellites To set up the receiver for the type of antenna connected, follow the instructions below. Select the satellites you wish to receive with the receiver. Each of the satellites in the built-in satellite list is configured with predefined default parameters. you may press the Blue button - Advanced settings - to edit these values.
- Page 14 Transponder number Use this option to select a transponder from the built-in transponder list. Once selected from the list, the Frequency, Polarity and Symbol rate fields will be updated accordingly. Alternatively you can set these fields manually. Frequency Set the frequency of the reference transponder. Polarity Set the polarity of the reference transponder.
- Page 15 cHAnnEL SEARcH In order to view video programs, you must first do a channel search. Select the search scheme you wish the wizard to follow: • Select Automatic (HD+) to search for channels on HD+’s bouquets. • Select Satellite search to search for channels on all transponders for the selected satellite •...
-
Page 16: Basic Operation
Basic Operation PROGRAM nAVIGATIOn • you can use the numeric keys on your remote control. • you can use the directional keys “Up” and “Down” on your remote control or on the front panel of the receiver. • you can use the P+ and P- keys on your remote control •... - Page 17 6. Parental rating information (displayed if available with the program broadcast) 7. Satellite signal quality bar 8. Program encryption information 9. Teletext information (displayed if available with the program broadcast) 10. Program timeline information 11. Active recording notification 12. Volume 13.
- Page 18 ASPEcT RATIO When the info-banner is displayed, scroll left with the Left arrow key until the Aspect ratio title is displayed. Press the Down arrow key and use the arrow keys to set the picture aspect ratio. RESOLUTIOn Resolution allows you to set the video resolution of the picture. 1.
-
Page 19: The Main Menu
TELETEXT If teletext information is available on the current channel, the symbol will be shown in the channel information banner. you can press the on the remote control to display this information. you can use the numeric keys 0-9, on the remote control, to enter a three-digit page number. STAnDBy MODE you can put the receiver in standby mode to reduce the power consumption while the unit is not in use. -
Page 20: Hbbtv Applications
See detailed description on the Full and mini Guides in the Program Guide chapter. Note: In order for the EPG to function properly, the time and date must be set correctly. MEDIA This entry provides various filters allowing direct access to pre-defined media folders: •... -
Page 21: Connecting External Usb Devices
connecting external USB & eSATA devices your digital receiver is equipped with a USB and eSATA connections at the back panel. When you connect a mass storage class device, the receiver will automatically initialize the device and will display an indication that the device is connected. Notes: - Supported file systems - nTFS, Fat16, Fat32, Ext2 - Format Device requires entering the PIn code (default ‘0000’). -
Page 22: Control Panel
SInGLE cHAnnEL VIEW Press the “Green” function key on your remote control to toggle between the Full Guide grid view and the Single channel view. The Single channel view makes it easier to see an overview of programs or an individual channel, e.g. - Page 23 Energy mode you can switch the receiver into three different stand-by modes: • Rapid start-up : If you prefer to get picture and sound immediately after pressing the “On” button, use this option. • Light stand-by: Power consumption is reduced while the unit is not in use. This mode turns off some parts of the receiver, allowing it to start-up again quickly when the unit is turned on.
- Page 24 Note: If daylight savings is enabled then the receiver is changing automatically the time on the following condition (valid for Europe with no time limit). • summer times begins and ends at 1:00 am universal time (Greenwich mean time) • it begins the last Sunday in March •...
- Page 25 Status check the status of your network connection. Network Storage See page 28 on “video, photo and music streaming via your home network”. Network player Set the quality of online video accessed through HLS streaming. WEB BROWSER Set the parameters associated with browsing web pages and online media using the built-in web browser. Virtual on-screen keyboard Set whether the virtual keyboard should automatically appear on screen when the web page includes an input box.
- Page 26 Symbol rate Use this option to set the symbol rate for the signal. Use this option to set the FEc (Forward Error correction). PIDs Use this option to set the PIDs between automatic and manual. If you choose manual, you can set the individual Audio and Video PIDs and the PcR.
- Page 27 SySTEM UPDATE This option supports three ways to update the software of the digital receiver: Over The Antenna (OTA), through the USB port or over the internet. When this option is executed, the receiver will automatically search for new software version at three sources in the following order - (a) on a USB disk, (b) over the internet and (c) over the satellite.
-
Page 28: Channel Lists Editing
TV supports Dolby Digital and DTS over HDMI. HDMI Video output Use this option to specify the video output format on the HDMI connector. TV SCART Use this option to specify the video output format on the TV ScART connector. HDCP Use this option to set HDcP protocol over the HDMI connection ‘On’... -
Page 29: Video, Photos And Music Streaming Over Your
Video, photos and music streaming over your home network The Receiver will seamlessly and securely connect to your Pc over your home network, stream video, music and photos from shared folders and allow you to use your Pc as a remote storage for recording and playback of your favorite TV programs. - Page 30 Set a shared folder to be your default storage for recorded TV:...
-
Page 31: Frequently Asked Questions
Frequently Asked Questions MOVInG cHAnnELS AnD EDITInG yOUR FAVORITE LISTS Under TV/Radio entry of the Main Menu, select ‘List Manager’. Select the Favorite list you would like to edit (eg My Favorite). The next screen will display the Main list on the left side and the Favorite list on the right side. Use the Up/Down keys to navigate to the channel you want to move from the Main list to the Favorite list, Mark the channel by pressing the Green button (if you wish to move a block of channels, Press OK to move the channel to the Favorite list. -
Page 32: Technical Specifications
Technical Specifications GEnERAL InFORMATIOn - Full HD+ compliant Full HD+ compliant, supporting HD+ SmartTV and HD+ Replay - WiFi and Ethernet connection - Media library, TV recording and playback over shared folders, network and USB storage devices* - Microsoft PlayReady DRM - HbbTV 1.5, HTML5 support - HLS smooth streaming and HTTP streaming - nagravision cAS and PRM embedded... - Page 33 REAR PAnEL InTERFAcES - Front-End: Input connector: Input connector: IEc169-2, Socket (F-connector for Satellite front end) Loop Through Output connector: IEc169-2, Plug - TV ScART connector: cVBS/RGB(output) L&R Audio (output) Fast Blanking (output)/Slow Blanking (output) - Digital Audio SPDIF: 1 * coaxial (RcA), 1 * Optical - cIncH (RcA): Audio L/R and cVBS (RcA) - Ethernet 10/100Mbps, RJ45 - HDMI...
-
Page 34: Troubleshooting
Troubleshooting ERROR POSSIBLE cAUSES POSSIBLE SOLUTIOnS no power supply check connection cables Disconnect device from mains power supply, eliminate the short circuit Short circuit in coaxial cable in the coaxial cable or connections, reconnect, and no image, no sound, no display activate device Defective or missing cables check connecting cables... -
Page 35: Warranty, Service And Support
Warranty, service and support This Limited Warranty applies only to the Product sold by TELESTAR Digital GmbH (hereby, the “company”) the customer purchase for his own use and not for resale. The term “Product” in this Limited Warranty does not include any software programs, whether pre-loaded with the Product, installed subsequently or otherwise. - Page 36 this Warranty; (viii) Loss of any, or damage to, programs, data, or storage media. The company may opt to replace the Product submitted for warranty services and, thus, any data stored on the original Product may become permanently inaccessible. This Limited Warranty is voided by removal or alteration of identification labels on the Product or its parts. Any technical or other support provided for a Product under warranty, such as, “How to”...
- Page 37 notes / notizen...
