Installation Manual
F36 HARLEquiN
F54 NuOvO
Ceiling Fans for indoor use
TABLE OF CONTENTS
1. Important Safety Instructions
2. Unpacking Your Fan
3. Installing Your Fan
4. Light Kit Option
5. Operating Your Fan
6. Care of Your Fan
7. Troubleshooting
8. Warranty Terms & Conditions
For Warranty in Australia call 1300 469 326
p.1
p.1-2
p.3-7
p. 8
p. 9
p. 9
p. 9
p. 10
