Astivita ASTCER60TOP Instruction Manual

Ceramic
Hide thumbs Also See for ASTCER60TOP:
Table of Contents

Advertisement

Quick Links

Ceramic Hob

Instruction Manual / Installation Manual
MODEL: ASTCER60TOP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASTCER60TOP and is the answer not in the manual?

Questions and answers

Related Manuals for Astivita ASTCER60TOP

Summary of Contents for Astivita ASTCER60TOP

  • Page 1: Ceramic Hob

    Ceramic Hob Instruction Manual / Installation Manual MODEL: ASTCER60TOP...

  • Page 2: Safety Warnings

    Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory.
  • Page 3 • Please make this information available to the person responsible for installing the appliance as it could reduce your installation costs. • In order to avoid a hazard, this appliance must be installed according to these instructions for installation. • This appliance is to be properly installed and earthed only by a suitably qualified person.
  • Page 4 Hot Surface Hazard • During use, accessible parts of this appliance will become hot enough to cause burns. • Do not let your body, clothing or any item other than suitable cookware contact the Induction glass until the surface is cool. •...
  • Page 5 • Never use your appliance for warming or heating the room. • After use, always turn off the cooking zones and the cooktop as described in this manual (i.e. by using the touch controls). • Do not allow children to play with the appliance or sit, stand, or climb on it.
  • Page 6 • Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can scratch the Induction glass. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 7 •WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket. •WARNING: Danger of fire: do not store items on the cooking surfaces.

  • Page 8: Product Overview

    Congratulations on the purchase of your new Ceramic Hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.

  • Page 9: Product Information

    Product Information The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The ceramic cooker hob centers on customers and adopts personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life.

  • Page 10: Choosing The Right Cookware

    Choosing the right Cookware Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob –...

  • Page 11: Using Your Ceramic Hob

    Using your Ceramic Hob To start cooking • After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the state of standby mode. 1. Touch the ON/OFF control，all indictors show “-“.

  • Page 12: When You Have Finished Cooking

    When you have finished cooking 1a. Turn the cooking zone off by scrolling down to “-“ or touching control together. 1b. Turn the whole cooktop off by touching the ON/OFF control. 2. Beware of hot surfaces will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature.
  • Page 13 Using the Dual zone function • The function only work in 4# cooking zone • The dual cooking zone has two cooking areas that you can use a central section and an outer section. You can use the central section (A) independently or both sections (B) at once.
  • Page 14 4. Touching the dual zone control “◎” , you can activate the outer section as well. 5. A neon above the dual cooking zone control will light. 6. The cooking zone indicator show “ P “ and “ 6 ” alternately Deactive the Dual zone 1.

  • Page 15: Locking The Controls

    Locking the Controls • You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). • When the controls are locked, all the controls except the ON/OFF control are disabled. To lock the controls Touch the keylock control.

  • Page 16: Using The Timer As A Minute Minder

    Using the Timer You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. • You can set it to turn one cooking zone off after the set time is up. •...
  • Page 17 5. When the time is set, it will begin to count down immediately. The display w ill show the remaining time and the timer indicator will flash for 5 seconds. 6. Buzzer will bips for 30 seconds and the timer indicator shows “- - “...

  • Page 18: Cooking Guidelines

    4. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds. NOTE: The red dot next to power level indicator will illuminate indicating that zone is selected. 5.

  • Page 19: Heat Settings

    setting higher than the lowest setting to ensure the food is cooked properly in the time recommended. Searing steak To cook juicy flavoursome steaks: 1. Stand the meat at room temperature for about 20 minutes before cooking. 2. Heat up a heavy-based frying pan. 3.

  • Page 20: Care And Cleaning

    • sautéing 7 - 8 • cooking pasta • stir-frying • searing • bringing soup to the boil • boiling water Care and Cleaning What? How? Important! Everyday soiling on 1. Switch the power to the • When the power to the cooktop is glass (fingerprints, cooktop off.

  • Page 21: Hints And Tips

    Spillovers on the 1. Switch the power to the • The cooktop may beep and turn touch controls cooktop off. itself off, and the touch controls 2. Soak up the spill may not function while there is 3. Wipe the touch control area liquid on them.

  • Page 22: Technical Specification

    Technical Specification Cooking Hob ASTCER60TOP Cooking Zones 4 Zones Supply Voltage 220-240V~ 50/60Hz Installed Electric Power 6000-7000W Product Size L×W×H(mm) 590X520X50 Building-in Dimensions A×B (mm) 560X490 Weight and Dimensions are approximate. Because we continually strive to improve our products we may change specifications and designs without prior notice.

  • Page 23: Before Locating The Fixing Brackets

    Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. A(mm) B(mm) C(mm) 50 mini 20 mini Air intake Air exit 5mm Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob.

  • Page 24: Connecting The Hob To The Mains Power Supply

    Cautions 1. The ceramic cooker hob must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The ceramic cooker hob shall not be mounted to cooling equipment, dishwashers and rotary dryers. 3.
  • Page 25 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
  • Page 26 This appliance is labeled in compliance with European directive 2002/96/EC for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
