MODEL XLT-X2 BIKE TRAILER
Owner's Manual should be kept for future reference
1. Completely read and understand Owner's Manual before assembling or operating this product.
2. This product should be assembled by an adult
IMPORTANT SAFETY INFORMATION
•
Failure to follow these warnings and assembly instructions could result in serious injury or death!
•
Immediately discard all plastic bags and plastic wrapping materials!
•
Maximum total weight capacity for one child is 50 pounds, and for two children is 100 pounds!
•
Never use this trailer/stroller if it becomes damaged!
•
To avoid serious injury, children should always wear the seat belt and the shoulder straps!
•
Never leave children unattended in or around this product!
•
Never allow children to assemble, fold, or disassemble this unit!
•
Accessories or parcels placed in trailer/stroller may cause it to become unstable!
•
Not for use with children under 12 months old! Children must be able to support their own heads!
•
Before riding, check that all parts are assembled according to the manufacturer instructions!
•
Tires should be inflated to 25-35 PSI for maximum comfort! Check tire pressure before each use!
•
Use a foot pump or hand pump to inflate tires! Pressurized air hoses can cause over inflation!
•
Periodically re-check all fasteners to make sure they are tight!
•
Clean trailer only with soap and water. Do not use solvents!
•
Make sure your bike brakes work properly! Braking distance is increased when pulling a trailer!
•
This trailer is wide! Allow extra clearance near curbs, signs, parked cars, and other obstacles!
•
A bicycle with trailer attached requires a wide turning radius! Do not turn sharply!
•
Children must wear an approved safety helmet when using this product in trailer mode!
•
Never remove protective canopy when pulling children in the trailer!
•
Always use the safety flag when pulling this trailer!
•
When pulling one child in the trailer, seat him/her in the enter!
•
Do not ride over curbs! Avoid bumps and holes! Always signal your turns!
•
Use extra caution when turning on uneven pavement, and going downhill!
•
Not for use at high speeds! Do not exceed 10 MPH!
•
NEVER use this trailer at night!
•
Install a rearview mirror on your bike to check on children in trailer!
•
Dress children appropriately to prevent them from getting chilled or overheated while riding!
Protect against wind-chill in cold temperatures, and provide adequate ventilation and hydration
during warmer temperatures.
INSTRUCTIONAL
OWNER'S MANUAL
SAFETY TOWING TIPS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XLT-X2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allen Sports XLT-X2

Summary of Contents for Allen Sports XLT-X2

  • Page 1 INSTRUCTIONAL OWNER’S MANUAL MODEL XLT-X2 BIKE TRAILER Owner’s Manual should be kept for future reference 1. Completely read and understand Owner’s Manual before assembling or operating this product. 2. This product should be assembled by an adult IMPORTANT SAFETY INFORMATION •...

  • Page 2: Parts List

    INSTRUCTIONAL OWNER’S MANUAL FULLY ASSEMBLED TRAILER PARTS LIST QUANTITY DESCRIPTION Frame w/ Canopy, Sling Seat with 5 point safety harness, tow bar, tow bar coupler and rear wheel bracket attached 20” Rear wheels Safety flag...
  • Page 3 INSTRUCTIONAL OWNER’S MANUAL MAIN CABIN FRAME AND ASSEMBLY STEP 1: Remove the trailer, wheels, hitch arm and walking kit from the box. NOTE: 1. Set the walking kit small swivel wheel aside, as you will install this later. 2. Lay the trailer on the ground with the black fabric side down.

  • Page 4: Wheel Installation

    INSTRUCTIONAL OWNER’S MANUAL WHEEL INSTALLATION Your Allen Sports trailer uses simple and convenient push button quick-release wheels. STEP 1: Push the button on the outside of the wheel hub. STEP 2: Insert the axle through the hanger bracket on the frame as shown (Fig. 7).

  • Page 5: Safety Flag Installation

    INSTRUCTIONAL OWNER’S MANUAL TOP COVER/WINDSCREEN NOTE: The clear vinyl windscreen and the protective mesh barrier zip open for loading. In inclement weather, the clear windscreen protects your passengers from the elements. Weather permitting, you can roll up the clear window and affix with Velcro straps provided.

  • Page 6: Five-Point Harness

    OWNER’S MANUAL SAFETY WRIST STRAP NOTE: The model XLT-X2 includes a safety wrist strap that should be installed and used whenever the XLT-X2 in the jogger/ stroller mode. Always use the wrist strap when a passenger is in the stroller.
  • Page 7 INSTRUCTIONAL OWNER’S MANUAL FOLDING STEP 1: To fold your trailer, simply open the rear compartment flap and locate the release latches on the vertical frame tubes. STEP 4: To operate the latches, first depress the locking button, and then lift to open the frame. STEP 5: Push forward to fold.
  • Page 8 INSTRUCTIONAL OWNER’S MANUAL ATTACHING TRAILER TO BICYCLE Your Allen Strailer is designed to attach easily to just about any full-size bicycle. The hitch fitting must be attached to the rear axle of the bike. Do not attach to any cycle where it cannot attach to the axle. It is recommended that the bicycle(s) to which the trailer will be attached undergo a safety check by a qualified bicycle mechanic before attaching the trailer to it.

  • Page 9: Trailer Maintenance

    INSTRUCTIONAL OWNER’S MANUAL TRAILER MAINTENANCE Your trailer will give you many years of service with minimal care. To ensure safe and dependable operation, we recommend the fol- lowing regular maintenance: BEFORE EACH RIDE: STEP 1: a. Check all fasteners to make sure they are tight. Tighten or replace if needed b.
  • Page 10 INSTRUCTIONAL OWNER’S MANUAL PARKING BRAKE (CONT.) STEP 4: Place the Wheel Guard/Brake Assembly against the frame, and use the hex key wrench provided to tighten the screws until snug. The nut is secured inside the plastic housing so you will not need a wrench or plier to hold the nut NOTE: while tightening the fixing screw.
  • Page 11 INSTRUCTIONAL OWNER’S MANUAL JOGGER KIT Your XLTX2 trailer can accept an optional jogger kit. If not included with your trailer at time of purchase, please contact your retailer for more information on how to purchase this accessory. INCLUDES: The kit consists of 2 fork tubes, and a quick release 16 inch wheel...
  • Page 12 INSTRUCTIONAL OWNER’S MANUAL INSTALLING THE JOGGER KIT To install the jogger kit, first remove the hitch arm by releasing opening and releasing the QR pin, then STEP 1: press the spring pin and pull out the arm. Also remove the pin on the opposite side clamp. Next, take one arm, ( Right and left arms are not the same, note the screw thread faces up), insert into STEP 2: the aluminum bracket, align with the fixing hole and insert and lock the spring pin.

  • Page 13: Warranty

    IF YOUR PRODUCT REQUIRES WARRANTY SERVICE, PLEASE DO NOT RETURN IT TO RETAIL STORE. PLEASE CONTACT: ALLEN SPORTS USA (800) 722-5536 ~ CUSTOMERSERVICE@ALLENRACKS.COM Please note that all returns and exchanges are subject to the return policy of the retailer where the product was originally purchased R.
