MODEL XLT2 BIKE TRAILER
Owner's Manual should be kept for future reference
1. Completely read and understand Owner's Manual before assembling or operating this product.
2. This product should be assembled by an adult
IMPORTANT SAFETY INFORMATION
•
Failure to follow these warnings and assembly instructions could result in serious injury or death!
•
Immediately discard all plastic bags and plastic wrapping materials!
•
Maximum weight capacity for this trailer is two (2) children at 100 pounds, max payload!
•
Never use this trailer/stroller if it becomes damaged!
•
To avoid serious injury, children should always wear the seat belt and the shoulder straps!
•
Do not install a car seat or any other seating device not approved by the manufacturer inside the trailer!
•
A reflector that complies with CPSC regulations must be visible on the rear of trailer.
•
Never leave children unattended in or around this product!
•
Never allow children to assemble, fold, or disassemble this unit!
•
Accessories or parcels placed in trailer/stroller may cause it to become unstable!
•
Not for use with children under 12 months old! Children must be able to support their own heads!
•
Before riding, check that all parts are assembled according to the manufacturer instructions!
Also, ensure that the trailer does not interfere with braking, pedaling, or steering of the bicycle!
•
Do not allow any of the child's body, clothing, shoe laces, or toys to come into contact with moving parts!
•
Make no modifications to the trailer!
•
Tires should be inflated to 25-35 PSI for maximum comfort! Check tire pressure before each use!
•
Use a foot pump or hand pump to inflate tires! Pressurized air hoses can cause over inflation!
•
Periodically re-check all fasteners to make sure they are tight!
•
Clean trailer only with soap and water. Do not use solvents!
TOWING TIPS:
•
Make sure your bike brakes work properly! Braking distance is increased when pulling a trailer!
•
This trailer is wide! Allow extra clearance near curbs, signs, parked cars, and other obstacles!
•
A bicycle with trailer attached requires a wide turning radius! Do not turn sharply!
•
Children must wear an approved safety helmet when using this product in trailer mode!
•
Never remove protective canopy when pulling children in the trailer!
•
Always use the safety flag when pulling this trailer!
•
Do not ride over curbs! Avoid bumps and holes! Always signal your turns!
•
Use extra caution when turning on uneven pavement, and going downhill!
•
Not for use at high speeds! Do not exceed 10 MPH!
•
NEVER use this trailer at night!
•
Install a rearview mirror on your bike to check on children in trailer!
•
Dress children appropriately to prevent them from getting chilled or overheated while riding!
Protect against wind-chill in cold temperatures, and provide adequate ventilation and hydration
during warmer temperatures.
INSTRUCTIONAL OWNER'S MANUAL
PRODUCT REGISTRATION:
MAKE SURE TO REGISTER YOUR PURCHASE AT
http://allensportsusa.com/about/product-registration
TO QUALIFY FOR PRODUCT WARRANTY AND TO RECEIVE
IMPORTANT PRODUCT NOTIFICATIONS
SAFETY TOWING TIPS
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allen Sports XLT2
Summary of Contents for Allen Sports XLT2
- Page 1 TO QUALIFY FOR PRODUCT WARRANTY AND TO RECEIVE IMPORTANT PRODUCT NOTIFICATIONS MODEL XLT2 BIKE TRAILER Owner’s Manual should be kept for future reference 1. Completely read and understand Owner’s Manual before assembling or operating this product. 2. This product should be assembled by an adult IMPORTANT SAFETY INFORMATION •...
-
Page 2: Parts List
INSTRUCTIONAL OWNER’S MANUAL FULLY ASSEMBLED TRAILER PARTS LIST QUANTITY DESCRIPTION Frame w/ Canopy, Sling Seat with 5 point safety harness, tow bar, tow bar coupler and rear wheel bracket attached 20” Rear wheels Safety flag... -
Page 3: Wheel Installation
You must make certain the frame is locked before using the trailer. Failure to do so could result in serious injury to you or your child. WHEEL INSTALLATION Your xlt2 trailer uses simple and convenient push button quick-release wheels. STEP 1: Push the button on the outside of the wheel hub. - Page 4 INSTRUCTIONAL OWNER’S MANUAL TOW ARM STEP 1: Locate the hitch arm, and position on the left side of the trailer, as shown (fig 4a). The hitch arm is held in place by a spring pin and a quick release pin. STEP 2: Depress the spring pin and insert the hitch arm in the bracket on the frame as shown (fig 4b).
-
Page 5: Safety Flag Installation
INSTRUCTIONAL OWNER’S MANUAL SAFETY FLAG INSTALLATION STEP 1: Assemble the flag and insert the end into the small sleeve on the side of the trailer skin. WARNING!: This flag is meant for use only with the trailer. This flag is not a toy. Do not let your child play with this flag at any time. - Page 6 INSTRUCTIONAL OWNER’S MANUAL FOLDING STEP 1: To fold your trailer, first, release safety harnesses and allow passengers to exit the trailer STEP 2: Make sure to remove any items stored inside the trailer or in the cargo area behind the seat. STEP 3: Open the rear compartment flap and locate the release latches on the side frame tubes.
- Page 7 INSTRUCTIONAL OWNER’S MANUAL HITCH Attaching trailer to bicycle Your iGO trailer is designed to attach easily to just about any full-size bicycle. The hitch fitting must be attached to the rear axle of the bike. Do not attach to any cycle where it cannot attach to the axle. It is recommended that the bicycle(s) to which the trailer will be attached undergo a safety check by a qualified bicycle mechanic before attaching the trailer to it.
-
Page 8: Trailer Maintenance
INSTRUCTIONAL OWNER’S MANUAL TRAILER MAINTENANCE Your trailer will give you many years of service with minimal care. To ensure safe and dependable operation, we recommend the following regular maintenance: STEP 1: Before each ride: a. Check all fasteners to make sure they are tight. Tighten or replace if needed b. -
Page 9: Warranty
IF YOUR PRODUCT REQUIRES WARRANTY SERVICE, PLEASE DO NOT RETURN IT TO RETAIL STORE. PLEASE CONTACT: ALLEN SPORTS USA (800) 722-5536 ~ CUSTOMERSERVICE@ALLENRACKS.COM Please note that all returns and exchanges are subject to the return policy of the retailer where the product was originally purchased R. - Page 10 INSTRUCTIONAL OWNER’S MANUAL MODEL XLT2 JOGGER KIT Owner’s Manual should be kept for future reference 1. Completely read and understand Owner’s Manual before assembling or operating this product. 2. This product should be assembled by an adult IMPORTANT SAFETY INFORMATION WARNING #1: •...
- Page 11 FULLY ASSEMBLED TRAILER + JOGGER PARTS LIST QUANTITY DESCRIPTION quick release 16 inch wheel, handlebar, Your XLT2 trailer can accept mounting hardware an optional jogger kit. If not included with your trailer at time of purchase, please contact your retailer for fork tubes more information on how to purchase this accessory.
- Page 12 INSTRUCTIONAL OWNER’S MANUAL JOGGER ASSEMBLY STEP 1: To install the jogger kit, first remove the hitch arm by releasing opening and releasing the QR pin, then press the spring pin and pull out the arm. Also remove the pin on the opposite side clamp. STEP 2: Next, take one arm, ( Right and left arms are not the same, note the screw thread faces up), insert into the aluminum bracket, align with the fixing hole and insert and lock the spring pin.
- Page 13 INSTRUCTIONAL OWNER’S MANUAL INSTALL WHEEL STEP 1: Open the quick release axle skewer to allow the axle to fit inside the plastic fork tips. Align the flats on the axle with the flats on the fork tips, and slide into the slots.T STEP 2: Close the QR lever, making sure it is tight.
- Page 14 IF YOUR PRODUCT REQUIRES WARRANTY SERVICE, PLEASE DO NOT RETURN IT TO RETAIL STORE. PLEASE CONTACT: ALLEN SPORTS USA (800) 722-5536 ~ CUSTOMERSERVICE@ALLENRACKS.COM Please note that all returns and exchanges are subject to the return policy of the retailer where the product was originally purchased R.
