Summary of Contents for apivio Liberty1
-
Page 2: User Precautions
User Precautions Please read the instructions carefully to protect yourself and others Precautions when using from personal injury or damage to property. · Please do not touch the phone with wet hands. · Please do not use the phone for other than its intended purpose. Precautions when installing ·... - Page 3 User Precautions Precautions when using battery FCC SAR Compliance Statement · Please don’t use this phone with a battery from another Your wireless phone is a radio transmitter and receiver. manufacturer, as this could damage the device. It is designed and manufactured not to exceed the emission limits ·...
- Page 4 User Precautions Warnings · This device is for indoor use, only in the 5150~5250Mhz frequency range. · This device was tested for typical body-worn operations. · To comply with RF exposure requirements, keep at least 1.5cm (0.5 inches) between the user's body and the headset, including the antenna.
-
Page 5: Table Of Contents
Contents User Precautions ....02 Extra Functions Useful Functions ....18 Basic Instructions Text Input ......20 Components ..... 06 Display ......21 HD Voice Features ..... 06 Setting ......22 About the Phone ....07 System info ....... 23 LCD Status ....... -
Page 6: Components
Components HD Voice Features Please check to ensure the components pictured below · This device uses high-end speakers and receivers to are in the box after purchase. Please contact the retail support HD Voice capability. store where you purchased the device, if there are any ·... -
Page 7: About The Phone
About the Phone Volume : Adjust the sound volume. Menu : Access the phone menu. Search : Search your registered Wi-Fi networks. Wireless line : Search Wi-Fi networks. Phone book : Access the phone book. System info : Access system information. Message : SMS(Texting is not supported at this time). -
Page 8: Lcd Status
LCD Status Indicates Wi-Fi signal strength. Status Icon Strong signal Weak signal Indicates phone status. Please refer to the icon Indicates the phone call function is unavailable. legend on the right, for details. Indicates the phone call function is available. Indicates the alarm has been set. -
Page 9: Insert The Battery
Insert the battery Install the adaptor Please use the included battery. If you need to exchange or purchase another battery, please contact Connect the adaptor an authorized service centre. to the rear connector. Push (1) Push down on the battery cover, as shown at left, and pull down (2) to separate. -
Page 10: Wi-Fi Connection
Wi-Fi Connection Press and hold the [End] Select the desired You will be connected button for 3 seconds to power network, Press [OK], and can begin using on the phone. and enter applicable your device. password. Press to search for available Wi-Fi connections While connecting to an AP, Web browser will open automatically if Web Authentication is required. -
Page 11: To Access Web Ui
To Access Web UI You can check the phone status or set up the phone via Home Web browser. Please follow the steps below. You can check the current phone status. 1. To check IP address [Menu] → 8.System info → 3.Network info 2. - Page 12 To Access Web UI Call Setup Phone Setup Account : check the account information. Phone Password : change the user password. Network : setup roaming feature. QoS : setup QoS related setting. Time : select Time zone and setup NTP server.
- Page 13 To Access Web UI Function Setup Maintenance Functions : setup the phone functions. Reboot : reboot the phone. WiFi Scan Channel : select WiFi channels. Factory Default : restore to factory default setting. - Please make sure before restore to factory default. All the setting will be completed deleted.
-
Page 14: Make A Call / Hang Up
Make a Call / Hang Up Input the call Press the phone To set the answer type: [Menu] → 2.Call Manage → number number . 2.Answer type. Using phone Select the number history in history. Answer a call with Out of Office function Using Search and select If the Out of Office function is activated, the phone will... -
Page 15: Transfer
Transfer Adjust Volume You can transfer a call to another number or to another In standby mode, press [Volume] and click the phone in the same group. button. You can adjust Volume, Ring, Call, Power On/Off, Alarm. Adjust the volume (8 steps) by pressing [Volume] or On the call Input the... -
Page 16: Cfa
Phone Book · Manage groups at → 3.Manage groups. · In the phone book list, press the [Menu] button to delete Press the [Menu] button to Add, Edit, Delete groups and or edit entries. members. Register up to 30 per Group. ·... -
Page 17: Message
Message Send and receive messages with your phone. Please inquire with your service provider if this function is available in your area. Write the message Spam Message → 1.Write → → Input the number → → Select → 3.Spam Message save mode →... -
Page 18: Useful Functions
Useful Functions Out of Office Alarm [Menu] → 4.Useful Functions → 1.Out of Office Set and clear multiple alarm functions. • How to set : [Menu] → 4.Useful Functions → 3.Alarm • Auto attendant : Set and clear the Out of Office auto answer while away from your desk/work. - Page 19 Useful Functions • How to set : [Menu] → 4.Useful Functions → 6.Web Calculator Browser → use Navi button to go to Input Box → Use the Direction buttons or [OK] button to cycle through the on screen options. Press the [Back] button →...
-
Page 20: Text Input
Text Input To use TEXT INPUT Mode To Use Keypad on the phone - To input text, press any number or Search button then - Use keypad on the phone and press ‘Menu’ button to Text input keyboard will pop up. complete. -
Page 21: Display
Display Wallpaper Brightness Select from 10 kinds of wallpaper for on-screen display. Adjust display brightness(10 levels). • How to set : [Menu] → 6. Display → 3. Brightness → • How to set : [Menu] → 6.Display → 1.Wallpaper → Select brightness →... -
Page 22: Setting
Display Setting Menu style Wifi setting Select a menu style (Rotate or Grid) To search for available WiFi connections. • How to set : [Menu] → 6.Display → 5.Menu style → • How to set : [Menu] → 7.Setting → 1.Wifi setting → →... -
Page 23: System Info
• How to set : [Menu] → 7.Setting → 4.Time zone → select the zone → • This manual is for software version 2.00.022 and browser version 1.0.0. • If your device's software version is different than the version above, you may download the most current version from "www.apivio.com". -
Page 24: Trouble Shooting
Trouble shooting Solutions to common issues (may occur even when the phone is functioning normally) Symptoms Solutions The battery must be sufficiently charged for the phone to operate. Please charge the phone on the cradle, 1. The phone does not work. and ensure it is positioned correctly and securely. -
Page 25: Disposal
Warranty If your product does not work properly because of a defect in materials or workmanship, Apivio Systems Inc. (referred to as “the warrantor”) will, for the length of the period indicated on the chart on p. 20, which starts with the date of original purchase (“12 month Warranty... -
Page 26: Damage Compensation
Damage Compensation Free of charge Compensation services are free of charge for manufacturer’s defects or spontaneous failure within the 12 month warranty period. Compensation Types of damage Within warranty After warranty Exchange or refund Major repair within 10 days from the purchase Exchange or free repair Major repair within 1 month from the purchase Exchange... -
Page 27: Specifications
Specifications Section Description IEEE 802.11 a/b/g/n (CSMA/CA) RF Protocol RF Channel / 2.400~2.4835GHz / 13 Channel Frequency 5.15~5.25, 5.25~5.35, 5.47~5.65, 5.725~5.825GHz / 19 Channel Talk Time : Up to 4 Hours Standby Time : Up to 78 Hours Battery Charging Time : Under 6 Hours Input AC 100~200V, 50~60Hz, 0.5A Output... - Page 28 MWP-1100NAP-01(20150123) ·Usual manual can be changed as IP Phone software version without any notice.
