Congratulations! We welcome you to the exciting world of motor home travel and camping. You will
find it convenient and enjoyable to have all the comforts of home and still enjoy the great outdoors
wherever you choose to go.
Your motor home has been carefully designed, engineered and manufactured to provide dependability
as well as safety. Before sliding into the driver's seat, take a few minutes to become familiar with opera-
tions and features. This manual was prepared to aid you in the proper care and operation of the vehicle and
equipment. We urge you to read it completely. In addition, spend some time with the dealer when you take
delivery, you will want to learn all you can about your new motor home.
Your new motor home is covered by a factory warranty against defects in material and workmanship.
This warranty should be validated at once and returned to the factory by your dealer.
Read and understand all instructions and precautions in this manual before operating your new motor
home.
Throughout this manual, certain items are labeled NOTE, CAUTION and WARNING. These terms
alert you to precautions that can involve risk to your vehicle or to your personal safety. Read and follow
them carefully.
NOTE: Indicates a special point of information.
CAUTION
Indicates that a failure to observe can
cause damage to vehicle or equip-
ment
.
WARNING
This symbol is used to alert you to
precautions that involve your per-
sonal safety as well as vehicle dam-
age. Read and follow them carefully.
