Voltsure
™
Ultima LCD
Line Interactive UPS
Instruction manual
Important: This manual contains important safety instructions.
Keep this manual handy for reference.
• Before using this product please read all instructions carefully.
• Keep these instructions for future reference.
• All specifications are subject to change without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Voltsure Ultima LCD 650 and is the answer not in the manual?

Questions and answers

Related Manuals for Sollatek Voltsure Ultima LCD 650

Summary of Contents for Sollatek Voltsure Ultima LCD 650

  • Page 1 Voltsure ™ Ultima LCD Line Interactive UPS Instruction manual Important: This manual contains important safety instructions. Keep this manual handy for reference. • Before using this product please read all instructions carefully. • Keep these instructions for future reference. • All specifications are subject to change without prior notice.

  • Page 2: Package Contents

    IMPORTANT SAFETY WARNING (SAVE THESE INSTRUCTIONS) CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants. (See the specifications for the acceptable temperature and humidity range.) CAUTION! To reduce the risk of overheating the UPS, do not cover the UPS’ cooling vents and avoid exposing the unit to direct sunlight or installing the unit near heat emitting appliances such as space heaters or furnaces.
  • Page 3 3. INSTALLATION AND INITIAL STARTUP NOTE: Before installation, please inspect the unit. Ensure nothing inside the package is damaged. Placement & Storage Conditions Install the UPS in a protected area that is free of excessive dust and has adequate air flow. Place the UPS away from other units at least 20 cm to avoid interference.
  • Page 4 5. SPECIFICATION PANEL Ultima   L CD   6 50 MODEL Plug   t ype Capacity   ( VA/W) 650VA/360W Input   V oltage 220/230/240VAC Voltage   r ange 170-280Vac 162-290VAC Input   F requency 50 or 60 Hz Output   V oltage 220/230/240VAC Voltage  ...
  • Page 5 Ultima   L CD   8 50 Ultima   L CD   1 000 Ultima   L CD   1 000 850VA/480W 1000VA/600W 1000VA/600W 220/230/240VAC 220/230/240VAC 220/230/240VAC 170-280Vac 162-290VAC 170-280Vac 170-280Vac 162-290VAC 51 or 60 Hz 52 or 60 Hz Auto sensing 52 or 60 Hz Auto sensing 220/230/240VAC 220/230/240VAC...
  • Page 6 6. REAR PANELS ➌ ➌ ➋ ➋ ➍ ➍ ➎ ➏ ➊ ➊ REAR PANEL 650 EU REAR PANEL 650 UK ➌ ➌ ➋ ➋ ➍ ➍ ➎ ➏ ➊ ➊ REAR PANEL 850 UK REAR PANEL 850 EU ➌ ➌...
  • Page 7 ➌ ➌ ➋ ➍ ➍ ➎ ➊ ➋ ➊ REAR PANEL 1500EU REAR PANEL 1500UK ➌ ➌ ➋ ➍ ➍ ➎ ➋ ➊ ➊ REAR PANEL 2000EU REAR PANEL 2000UK KEY: 1. Output receptacles 2. AC input 3. USB port 4.

  • Page 8: Troubleshooting
