- Page 1 P1C-gm11 INST ALLATION MANUAL Prodigy REVERSE CAMERA INTEGRA TION MODULE This manual shows the install into a gmc terrain. Other vehicle disassembly will vary. wiring remains the same with all vehicles. See application guide for applicable vehicles...
- Page 2 Cont acts www.INTRAPHEX.com SUPPORT@INTRAPHEX.COM SUPPORT: 810.355.2266 EXT 4 Fax: 866.431.0676 SCAN THE IMAGE ABOVE WITH YOUR MOBILE PHONE TO GET MORE INFORMATION ABOUT INTRAPHEX PRODUCTS...
- Page 3 THREE (3) years from date of purchase. A sales receipt, showing the installation date and INTRAPHEX product details are required to verify proof of purchase.
- Page 5 INTERFACE DIP SWITCH SETTINGS DIP 1 DIP 2 DIP 3 DIP 4 AFTERMARKET CAMERA OEM CAMERA DIP SWITCH SETTINGS MUST BE PERFORMED WITH UNIT POWERED OFF. IT WILL NOT CAUSE DAMAGE, BUT THE FUNCTION WILL NOT BE RECOGNIZED UNTIL POWER CYCLES. ...
- Page 6 REMOVE MONITOR HOOD BY PULLNG UP ON FRONT. SET ASIDE. REMOVE RADIO CONTROL PANEL. GENTLY PULL PN LOWER PART OF PANEL TO RELEASE, THERE ARE NO SCREWS. UNPLUG HVAC/RADIO CONNECTOR. SET ASIDE. REMOVE FOUR 7MM SCREWS SECURING FACTORY MONITOR IN PLACE.
-
Page 7: Power Connections
POWER CONNECTIONS POWER CONNECTIONS CAN BE MADE AT THE OBDII DATA LINK CONNECTOR OR AT THE 44 PIN RADIO HARNESS. PIN LOCATIONS ARE PROVIDED FOR REFERENCE ONLY AND SHOULD BE TESTED WITH A DIGITAL MULTI-METER. INTERFACE WIRE OBDII CONNECTOR GMLAN PIN 1 BATTERY POWER...
