Summary of Contents for Magellan 2200VS

  • Page 1 Magellan 2200VS and 2300HS Enhanced Product Reference Guide...
  • Page 2 Magellan is a registered trademark of Datalogic Scanning, Inc. in many countries, including the U.S.A. and All-Weighs, FirstStrike and Surround- Scan are registered trademarks of Datalogic Scanning, Inc. in the U.S.A. OmegaTek, Produce Rail, Productivity Index Reporting and SmartSen- try are all trademarks of Datalogic Scanning, Inc.

  • Page 3: Table Of Contents

    Operational Verification ................2-16 Installation: Model 2200VS ................2-17 Installation: Model 2300HS ................2-20 Chapter 3. Operation and Maintenance ............3-23 Scanning Items: Model 2200VS ..............3-24 Scanning Items: Model 2300HS ..............3-25 Operational Controls ..................3-26 Operational Modes ..................3-26 Power-Up/Selftest &...
  • Page 4 IBM Number of Host Resets ..............5-117 IBM Transmit Labels in Code 39 Format ........... 5-118 IBM Label Slicing Control ............... 5-119 IBM Maximum Label Slice Length ............5-120 USB-OEM Scanner Device Type .............. 5-121 RS-232 Features ..................5-122 ® Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 5 RS-232 Baud Rate ................5-122 RS-232 Number of Data Bits ..............5-126 RS-232 Number of Stop Bits ..............5-127 RS-232 Parity ..................5-128 RS-232 Hardware Control ..............5-130 RS-232 Intercharacter Delay ..............5-133 RS-232 Software Flow Control ............... 5-134 RS-232 Host Echo ................5-135 RS-232 Host Echo Quiet Interval ............
  • Page 6 EAN Two Label Combined Transmission ........... 5-243 UPC/EAN Guard Insertion ..............5-244 UPC/EAN Stitch Exact Label Halves ............5-245 UPC/EAN Stitch Unlike Label Halves ............5-246 UPC/EAN Character Reconstruction ............5-247 EAN Two Label Minimum Reads .............. 5-248 ® Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 7 UPC/EAN Correlation ................5-250 UPC/EAN Minimum Segment Length ............5-251 Addons ....................5-257 Addon Timer ..................5-261 2-Digit Add-ons Minimum Reads ............5-262 5-Digit Add-ons Minimum Reads ............5-264 Code 128 Add-ons Minimum Reads ............5-266 GTIN Enable ..................... 5-268 GTIN Label ID ..................
  • Page 8 Code 93 Label ID .................. 5-356 Code 93 Length Control ................. 5-357 Code 93 Length 1 ................. 5-358 Code 93 Length 2 ................. 5-359 Code 93 Correlation ................5-360 Code 93 Stitching ................. 5-361 Code 93 Minimum Reads ............... 5-362 ® Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 9 MSI/Plessey Enable ..................5-364 MSI/Plessey Check Character Calculation ..........5-365 MSI/Plessey Number of Check Characters ..........5-366 MSI/Plessey Check Character Transmission ..........5-367 MSI/Plessey Label ID ................5-368 MSI/Plessey Length Control ..............5-369 MSI/Plessey Length 1 ................5-370 MSI/Plessey Length 2 ................5-371 MSI/Plessey Correlation ................
  • Page 10 ® Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 11: Chapter 1. Introduction

    Chapter 1 Introduction This Product Reference Guide contains comprehensive instructions on how to install the scanner, how to program it using special programming feature bar code labels, and advanced user information as described in the following overview. Manual Overview , presents the manual’s contents, describes features Chapter 1, Introduction and specifications, provides regulatory and safety information, and lists the bar code symbologies the scanner will read.

  • Page 12: How To Use This Manual

    Refer- ence the other sections as required for information about scanner installation, operation, maintenance and bar code programming. Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 13: Scanner Nomenclature

    Use of this product does not warrant the need for a DANGER block. Scanner Nomenclature Controls, indicators and other nomenclature are shown in Figure 1-1 Figure 1-1. Scanner Nomenclature Speaker Model 2200VS Scan Window Volume/Tone Indicator Push Button LED plus...

  • Page 14: Connectors

    · Application Download Programming (OSP) (where appropriate) · Application Download · RS-232 Handheld Scanner Input · Auxiliary RS-232 Label Data Output · EAS interlock Connection to this port is Optional Connection to this port is Optional Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 15: Physical Parameters

    Refer to the Operation section of this manual for more details about the topic: and Maintenance Scanning Items: Model 2200VS AC Adapter is an illustration of the AC/DC Adapter . Figure 1-3 Figure 1-3.

  • Page 16: Electrical Specifications

    If the adapter will not plug into your AC power receptacle, the model shipped is not compatible with your electrical system. Please contact your distributor immediately to receive the necessary information and compo- nents to ensure electrical compatibility. Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 17 Electrical Specifications Safe operation of your scanner or scanner requires properly grounded elec- trical outlets. Be sure to have a qualified electrician certify the earth-ground connection on circuits which will be used to power the unit. CAUTION The scanner is powered on/off by connecting/disconnecting its AC power supply.

  • Page 18: Laser And Product Safety

    (Optical instruments include binoculars, microscopes, telescopes and magni- CAUTION fying glasses. This does not include eyeglasses worn by the user). To prevent exposure to laser light, do not remove the protective housing of the scanner. There are no user-serviceable parts inside the unit. Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 19 Laser and Product Safety Safety precautions to be taken: No adjustments or alteration of the scanner housing are to be attempted by the user. The failure of the facet wheel motor while the unit is continuing to emit a laser beam causes the emission levels to exceed those for inherently safe operation.

  • Page 20: Labeling

    Introduction Labeling Regulatory, reference and safety labeling for both models is shown in Figure 1-5 Figure 1-6 Figure 1-5. Labeling: Model 2200VS PSC Inc. 959 Terry Street Eugene, OR 97402 USA XXXXXXXXXXXX This illustration shows general label Product of USA This device complies with Part 15 of the FCC Rules.
  • Page 21 Labeling Figure 1-6. Labeling: Model 2300HS IEC CLASS 1 LASER PRODUCT Class IIa Laser Product. Avoid long term viewing of direct laser light. Appareil á laser de classe IIa. Eviter toute exposition prolongée de la vue à lumière laser directe. 6-1018 Host EAS Opening...

  • Page 22: Agency Compliances

    CDRH Class IIa laser device Canada same as CDRH SGM-1 specification Australia AS 2211 Class 1 Europe IEC 60825-1 Class 1 ® Contact Datalogic Marketing or your Datalogic Scanning representative for a complete listing of approvals for other countries. 1-12 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 23: Bar Codes Supported

    Bar Codes Supported Bar Codes Supported The scanner can read/decode the following bar code types (symbologies): Retail Codes • UPC Versions A & E with full expansion E to A, plus A and E to 13 capability • UPC Supplementals and Add-ons (Bookland & Coupon code, UPC two character supplemental encodation and UPC five charac- ter supplemental encodation and supplemental C128) with support for conditional add-ons...

  • Page 24: Dual Bar Codes For Japan (2 Label Read)

    The following qualifications apply to Dual Bar Codes for Japan: NOTE • Two label combined transmission • Two label global midamble (see , for more Chapter 5, Programming details) • Two label flag is set by selecting any 4 digits as the flag 1-14 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 25 Chapter 2 Site Preparation and Installation This chapter outlines the procedures for unpacking the scanner, verifying function, preparing the countertop or wall, routing cables, and installing the scanner. Unpacking To unpack the unit: • Inspect the package for signs of damage that may have occurred dur- ing shipping.

  • Page 26: Chapter 2. Site Preparation And Installation

    Follow these steps to ensure that your unit has arrived undamaged and is fully functional before installing it in the counter and connecting it to your POS system: 1. [2200VS scanners ONLY] Remove the mounting bracket. 2. Plug the connector from the AC/DC Adapter into the scanner (see Figure 2-1 Figure 2-1.

  • Page 27: Installation: Model 2200Vs

    Installation: Model 2200VS ® The Magellan 2200VS scanner can either be used “freestanding,” or can be conveniently mounted to a countertop or wall using the mounting bracket. Provide a secure installation as described below. 1. Determine the best location for scanner installation. Some consider- ations are: •...
  • Page 28 11. Slide the scanner into its mount until it’s fully seated; taking care to guide cables so they won’t be pinched or trapped between assem- blies. Reference Figure 2-2 This completes the installation instructions. Figure 2-2. Magellan ® 2200VS Installation 2-18 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 29 Installation: Model 2200VS Route cables for countertop mount Connector Cover Route cables for wall mount 2-19 Product Reference Guide...

  • Page 30: Installation: Model 2300Hs

    4. Seat the scanner or in the countertop opening (or adapter). 5. Switch the terminal OFF. 6. Connect the interface cable to the terminal. 7. Connect the scanner’s AC Adapter to the AC outlet. 8. Switch the terminal ON. 2-20 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 31 Installation: Model 2300HS Figure 2-3. Countertop Modification Options a. Shelf installation b. Adapter w/flange above counter 6.07" (154.2mm) 6.26" (159mm) Rim of adapter 6.07" (154.2mm) Cut hole 6.26" Cut hole (159mm) Rim rests on top of counter 3.42" (86.9mm) 3.47" (88.1mm) Shelf Depth c.
  • Page 32 POS terminal. Reference Chapter 4, Problem Isolation if the scanner does not perform as expected. NOTE This completes the installation instructions for this model. 2-22 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 33: Chapter 3. Operation And Maintenance

    Chapter 3 Operation and Maintenance The information contained in this section describes how to operate and maintain the scanner. Topics include scanning tips, and scan window cleaning and replacement. 3-23 Product Reference Guide...

  • Page 34: Scanning Items: Model 2200Vs

    Operation and Maintenance Scanning Items: Model 2200VS Item bar codes are scanned by either... • sliding or pushing items through the scan volume in a right-to-left or left-to-right motion (see a). This is known as “Sweep” Figure 1 scanning, and is the best choice for high throughput super- and hypermarket installations where it is necessary to minimize the need to grip or lift items.

  • Page 35: Scanning Items: Model 2300Hs

    Scanning Items: Model 2300HS Scanning Items: Model 2300HS The scanner is mounted so its scan window is flush with the countertop. This allows for maximum working space, and also permits the user to slide items over its surface without having to grasp or pick them up. Bar codes are effortlessly scanned when swept through the zone projected from the substantial scan window as shown in Figure 1...

  • Page 36: Operational Controls

    A tone indicating Selftest is complete is a configurable fea- ture. See the topic Power-up Beep Control Chapter 5 this manual. NOTE 3-26 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 37: Operating Mode

    Operational Modes Error Reporting If a fatal error is detected during Selftest or operation, the scanner will not advance to Normal Operation Mode. Selftest diagnostics will cause the scanner to sound a long, low tone. When this occurs, error codes may be accessed by momentarily pressing the Volume/Tone Push Button.

  • Page 38: Sleep Mode

    Normal Operation. 1. “Timeout” and “Sleep Mode” time delays are programmable features that can be selected through Chapter 5 use of the programming bar codes included in 3-28 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 39: Additional Functions

    Additional Functions Additional Functions Additional scanner functions include programming, running scanner diagnostics, or initiating a reset. Programming Scanners are typically programmed at the factory to settings specified by the customer. Generally, POS system interface and bar code symbologies are pre-configured to operate in the target environment. con- Chapter 5 tains the necessary instructions, bar codes, and descriptions to program/...

  • Page 40: Scanner Reset

    Clean the exterior surface of the scan window at least twice daily with a nonabrasive, mild, water-based glass cleaner and paper towels or lint-free cleaning tissues. Textured plastic surfaces and stainless steel can also be cleaned using these cleaning agents. 3-30 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 41: Chapter 4. Problem Isolation

    Chapter 4 Problem Isolation In the event of a suspected functional problem, use the troubleshooting references provided in this section. This useful information will help you identify and resolve the cause of the problem. The scanner incorporates features that indicate when a problem occurs. The scanner may: •...

  • Page 42: Diagnostic Procedures

    However, if the problem is caused by faulty cable, or power supply, you can fix the problem by replacing the defective component and complete the installation. 4-32 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 43: Error Codes

    Error Codes Error Codes If an error is detected, the scanner will sound a long low tone (for three seconds) and flash its LED, indicating a failure. When this occurs, press the Volume/Tone Push button to hear the error code. If it is configured to do so, the scanner will sound a series of beeps corresponding to the error code and/or flash its LED simultaneous to the beeps.

  • Page 44: Flowcharts

    Go to Selftest the scanner Consult the Selftest flowchart if you're pass Selftest flowchart unsure the unit has passed Selftest. Will the Other Problems? Go to Poor/No scanner read Reading flowchart Call Tech Support bar codes reliably 4-34 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 45 Flowcharts Figure 4-2. Problem Isolation: Selftest SELFTEST START Scan the Factory Is the Is the Is the Defaults bar code in error code error code Section 6 to enable the blinking in default configuration error file. Restart the unit. No interface selected (Null Interface).

  • Page 46: Problem Isolation

    Section satisfactorily 5. Check bar code symbology options and other configurable features. Troubleshoot the host or call Tech Support. LED and beeper indications are configurable features. Behavior may vary from that described here. 4-36 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 47 Flowcharts Figure 4-4. Problem Isolation: No Transmit to POS NO TRANSMIT TO POS START Check the interface (I/F) Verify programmable cable connections. If parameters using the possible, retest the information and programming Does the system using a known- bar codes provided in Section scanner read DONE good I/F cable.
  • Page 48 Problem Isolation NOTES 4-38 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 49: Chapter 5. Programming

    Chapter 5 Programming Introduction to Label Programming The programming bar code labels contained in this manual will allow you to customize and configure features and settings for your scanner . To ensure full compatibility and proper function, use only the programming bar codes in this manual and other product-specific publications to pro- gram scanner features.

  • Page 50: Integrating The Scanner With Your Host System

    POS terminal by attempting to change to an incompati- ble interface. ALWAYS make interface selections with the host cable CAUTION DISCONNECTED. 5-40 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 51 Integrating the Scanner With Your Host System Ensure that your planned modifications are compatible with the cur- rent interface. For example, baud rate selections are only valid in the RS-232 interface. The scanner will sound an error tone when scanning programming labels for features invalid to the current interface group.

  • Page 52: Programming Overview

    6000 support this functionality. Handheld data format require- ments (baud rate, parity, etc.) are presented in of this manual. Appendix E Additionally the programmable feature, , must be set Auxiliary Port Mode to “External Handheld Input” to allow operation. 5-42 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 53: What Is Programming Mode

    Programming Overview What Is Programming Mode? Programming Mode is a state in which the scanner must be placed in order to accept commands via programming bar code labels. When pro- gramming using the bar code labels in this manual, the scanner is typically placed in Programming Mode by scanning the SWITCH label.

  • Page 54: Programming Session

    A single ‘good read’ beep is sounded when scanning these single digits in Programming Mode. Only the final required digit in the sequence will produce a tri- ple beep when scanned, indicating a successfully programmed feature. 5-44 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 55 Programming Overview It is recommended that programming sessions be limited to one fea- ture at a time. Should you make a mistake in the programming sequence, it can be difficult to discover where an error has been made if several features are programmed at once. Additionally, it can be confusing to determine which features may or may not have been suc- NOTE cessfully set following such a session.

  • Page 56: Programming Sequence

    Item Value, and exit Programming Mode (all in one step). 1. An “Item Tag” is a term used to describe an assigned number, which is encoded in a programming bar code, that toggles (selects, enables, disables, etc.) a specific programming feature. 5-46 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 57 Programming Overview Table 5-1. Programming Sequence ITEM TAG ITEM VALUE END/RESET ENABLE NEW FEATURE SWITCH SWITCH 3 4 5 ENABLE NEW FEATURE USING THE FOLLOWING SETTINGS... SWITCH SWITCH ONE BAR CODE CONTAINS SWITCH + ITEM TAG + ITEM VALUE + SWITCH 5-47 Product Reference Guide...

  • Page 58: Led And Beeper Indicators

    Mode as a part of its function. If this bar code is scanned follow- ing a SWITCH bar code, it will simply cause the scanner to exit Programming Mode without making changes. NOTE RETURN TO FACTORY SETTINGS 5-48 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 59: Test Mode

    If You Make a Mistake... Test Mode Use this feature to place the scanner into a testing, or “demo” mode. This special mode disables the scanner interface, meaning that bar code data is not sent out to the host via the scanner interface. This allows the bar code to be scanned continuously without requiring a response from the POS terminal.

  • Page 60: General Scanner Features

    3. Complete the programming sequence by scanning the SWITCH bar code. SCANNER BUTTON OPTIONS = DISABLE SCANNER BUTTON 5-50 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 61 General Scanner Features Scanner Button Options — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SCANNER BUTTON OPTIONS = ENABLE STANDARD FUNCTIONS SCANNER BUTTON OPTIONS = ENABLE RESET ONLY 5-51 Product Reference Guide...

  • Page 62: Double Read Timeout

    3. Complete the programming sequence by scanning the SWITCH bar code. If the incidence of multiple reads is not acceptable, increase the Dou- ble Read Timeout setting to a higher value. NOTE DOUBLE READ TIMEOUT = 400ms DOUBLE READ TIMEOUT = 600ms 5-52 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 63 General Scanner Features Double Read Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DOUBLE READ TIMEOUT = 800ms DOUBLE READ TIMEOUT = 1 SECOND 5-53 Product Reference Guide...

  • Page 64: Laser Timeout

    3. Complete the programming sequence by scanning the SWITCH bar code. LASER TIMEOUT = 5 MINUTES 5-54 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 65 General Scanner Features Laser Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LASER TIMEOUT = 10 MINUTES LASER TIMEOUT = 15 MINUTES 5-55 Product Reference Guide...

  • Page 66: Motor Timeout

    3. Complete the programming sequence by scanning the SWITCH bar code. MOTOR TIMEOUT = 5 MINUTES 5-56 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 67 General Scanner Features Motor Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MOTOR TIMEOUT = 10 MINUTES MOTOR TIMEOUT = 15 MINUTES 5-57 Product Reference Guide...
  • Page 68 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MOTOR TIMEOUT = 30 MINUTES MOTOR TIMEOUT = 60 MINUTES 5-58 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 69: Label Gone Timeout

    General Scanner Features Label Gone Timeout Specifies the amount of time that data segments are stored by the software before being discarded if a label has not been successfully decoded during the current “label in volume session,” which is defined as the time between when the label gone time is first started until the label gone timer expires.
  • Page 70 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL GONE TIMEOUT = 160 mS LABEL GONE TIMEOUT = 250 mS 5-60 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 71 General Scanner Features Label Gone Timeout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL GONE TIMEOUT = 500 mS LABEL GONE TIMEOUT = 1 Second 5-61 Product Reference Guide...

  • Page 72: Auxiliary Port Mode

    3. Complete the programming sequence by scanning the SWITCH bar code. AUXILIARY PORT MODE = DISABLE 5-62 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 73 General Scanner Features Auxiliary Port Mode — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. AUXILIARY PORT MODE = EXTERNAL HANDHELD INPUT AUXILIARY PORT MODE = PIR/CT 5-63 Product Reference Guide...

  • Page 74: Auxiliary Port Baud Rate

    3. Complete the programming sequence by scanning the SWITCH bar code. AUXILIARY PORT BAUD RATE = 1200 AUXILIARY PORT BAUD RATE = 2400 5-64 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 75 General Scanner Features Auxiliary Port Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 4800 RS-232 BAUD RATE = 9600 5-65 Product Reference Guide...
  • Page 76 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 19200 RS-232 BAUD RATE = 38400 5-66 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 77 General Scanner Features Auxiliary Port Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 57600 RS-232 BAUD RATE = 115200 5-67 Product Reference Guide...

  • Page 78: Productivity Index Reporting (Pir)/Cashier Training (Ct)

    3. Complete the programming sequence by scanning the SWITCH bar code. PIR/CT = DISABLE PIR/CT = ENABLE 5-68 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 79: Indication Features

    Indication Features Indication Features Green LED Idle State This feature specifies the state of the green scanner LED when the scanner is idle and ready to read a label. Options are: • • On dim To set the LED Idle State: 1.

  • Page 80: Power-Up Beep Control

    3. Complete the programming sequence by scanning the SWITCH bar code. POWER-UP BEEP = OFF POWER-UP BEEP = ONE BEEP 5-70 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 81: Good Read Beep Control

    Indication Features Good Read Beep Control This feature enables/disables scanner beep upon successfully decoding of a label. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the two bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 82: Good Read Beep Frequency

    3. Complete the programming sequence by scanning the SWITCH bar code. GOOD READ BEEP FREQUENCY = LOW 5-72 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 83 Indication Features Good Read Beep Frequency — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP FREQUENCY = MEDIUM GOOD READ BEEP FREQUENCY = HIGH 5-73 Product Reference Guide...

  • Page 84: Good Read Beep Length

    001 = 10ms 005 = 50ms 040 = 400ms 250 = 2,500ms (2.5 seconds) 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned SET GOOD READ BEEP LENGTH 5-74 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 85: Good Read Beep Volume

    Indication Features Good Read Beep Volume Selects the beeper volume upon a good read beep. There are five selectable volumes, with each volume increment adding approximately five decibels to the previous level: • 0 = Lowest Volume • 1 = Medium-Low Volume •...
  • Page 86 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP VOLUME = MEDIUM LOW GOOD READ BEEP VOLUME = MEDIUM 5-76 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 87 Indication Features Good Read Beep Volume — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ BEEP VOLUME = HIGHEST 5-77 Product Reference Guide...

  • Page 88: Good Read When To Indicate

    3. Complete the programming sequence by scanning the SWITCH bar code. GOOD READ = INDICATE AFTER DECODE 5-78 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 89 Indication Features Good Read When to Indicate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GOOD READ = INDICATE AFTER TRANSMIT GOOD READ = INDICATE AFTER CTS GOES INACTIVE, THEN ACTIVE (RS-232 ONLY) 5-79...

  • Page 90: Eas Features

    3. Complete the programming sequence by scanning the SWITCH bar code. EAS ACTIVE STATE = ACTIVE LOW EAS ACTIVE STATE = ACTIVE HIGH 5-80 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 91: Eas Timeout

    EAS Features EAS Timeout Specifies the amount of time that an EAS (Electronic Article Survellance) signal is held in its active state for a good read indication. To set the EAS Timeout: Scan the SWITCH bar code. 2.Scan the bar code, below.

  • Page 92: Interface Related Features

    Keyboard Wedge C USB-OEM Keyboard Wedge D Port 17 Keyboard Wedge E Port 5B Keyboard Wedge F Port 9B Keyboard Wedge G USB Keyboard Keyboard Wedge H Keyboard Wedge I NOT USER-SELECTABLE Keyboard Wedge J Null Interface 5-82 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 93 Interface Related Features Interface Type — continued A new scanner may have been shipped from the factory with a Null Interface (no interface type selected) to ensure system compatibility at installation. In this case, the correct Interface Type programming bar code must be scanned first before the scanner can be used with a POS NOTE system.
  • Page 94 For example, if RS-232 is selected, turn to the pages in this manual headed as features specific to the RS-232 interface. NOTE 5. Connect new interface cable(s). 5-84 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 95 Interface Related Features RS-232 Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 96 Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = RS-232 WINCOR-NIXDORF 5-86 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 97 Interface Related Features RS-232 Single Cable Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 98 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION Single cable installations require connection at the POS Terminal (host) port. NOTE INTERFACE TYPE = USB-OEM 5-88 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 99: Ibm Port 17 Interface Selection

    Interface Related Features IBM Port 17 Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 100 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = IBM PORT 5B 5-90 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 101 Interface Related Features IBM Port 9B Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 102 Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = USB KEYBOARD 5-92 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 103 Interface Related Features Keyboard Wedge A Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 104 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = KEYBOARD WEDGE B 5-94 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 105 Interface Related Features Keyboard Wedge C Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 106 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = KEYBOARD WEDGE D 5-96 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 107 Interface Related Features Keyboard Wedge E Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 108 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = KEYBOARD WEDGE F 5-98 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 109 Interface Related Features Keyboard Wedge G Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 110 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = KEYBOARD WEDGE H 5-100 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 111 Interface Related Features Keyboard Wedge I Interface Selection Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS terminal by attempt- ing to change to an incompatible interface.
  • Page 112 POS terminal by attempt- ing to change to an incompatible interface. ALWAYS make interface selections with the host cable DISCONNECTED. CAUTION INTERFACE TYPE = KEYBOARD WEDGE J 5-102 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 113: Maximum Host-Transmitted Message Length

    Interface Related Features Maximum Host-Transmitted Message Length Specifies the maximum number of data characters allowed in messages transmitted to the host. To set the Maximum Host-Transmitted Message Length: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET MAXIMUM HOST-TRANSMITTED MES- below.

  • Page 114: Number Of Host Transmission Buffers

    3. Complete the programming sequence by scanning the SWITCH bar code. NUMBER OF HOST TRANSMISSION BUFFERS = 1 NUMBER OF HOST TRANSMISSION BUFFERS = 2 5-104 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 115: Aim Id

    Interface Related Features AIM ID AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with scanned bar code data. AIM label identifiers consist of three characters as follows: • A close brace character (ASCII ‘]’), followed by... •...
  • Page 116 AIM ID — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. AIM ID: DISABLE AIM ID: ENABLE 5-106 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 117: Label Id Control

    Interface Related Features Label ID Control A Label ID is a customizable code of up to two ASCII characters (00-FF), used to identify a bar code (symbology) type, available for all except IBM interfaces. It can be appended previous to or following the transmitted bar code data depending upon how this option is enabled.
  • Page 118 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL ID TRANSMISSION: DISABLE LABEL ID TRANSMISSION: BEFORE BAR CODE DATA 5-108 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 119 Interface Related Features Label ID Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. LABEL ID TRANSMISSION: AFTER BAR CODE DATA 5-109 Product Reference Guide...

  • Page 120: Global Prefix

    If designating less than 20 hex pairs, you can end the programming sequence early by scanning the TERMINATE bar code. SEQUENCE 5. Complete the programming sequence by scanning the SWITCH bar code. 5-110 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 121 Interface Related Features Global Prefix — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. SET GLOBAL PREFIX TERMINATE SEQUENCE 5-111 Product Reference Guide...

  • Page 122: Global Suffix

    To set the Global Suffix: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. 3. Complete the programming sequence by scanning the SWITCH bar code. GLOBAL SUFFIX = NO GLOBAL SUFFIX 5-112 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 123 Interface Related Features Global Suffix — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. GLOBAL SUFFIX = CR GLOBAL SUFFIX = CR LF 5-113 Product Reference Guide...

  • Page 124: Case Conversion

    3. Complete the programming sequence by scanning the SWITCH bar code. CASE CONVERSION = NO CASE CONVERSION 5-114 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 125 Interface Related Features Case Conversion — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CASE CONVERSION = UPPER CASE CASE CONVERSION = LOWER CASE 5-115 Product Reference Guide...

  • Page 126: Ibm Features

    3. Complete the programming sequence by scanning the SWITCH bar code. IBM INTERFACE OPTION = FULL HOST INTERFACE SUPPORT IBM INTERFACE OPTION = IGNORE HOST I/F CONFIG OF SCANNER 5-116 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 127: Ibm Number Of Host Resets

    IBM Features IBM Number of Host Resets Specifies how many consecutive resets are processed before the scanner starts a five-second period during which a user is allowed to enter label- programming mode and configure the scanner. To set the number of host resets: 1.

  • Page 128: Ibm Transmit Labels In Code 39 Format

    3. Complete the programming sequence by scanning the SWITCH bar code. IBM TRANSMIT LABELS IN CODE 39 FORMAT = DISABLE IBM TRANSMIT LABELS IN CODE 39 FORMAT = ENABLE 5-118 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 129: Ibm Label Slicing Control

    IBM Features IBM Label Slicing Control Enables/disables the slicing of IBM-46XX host transmission data into multiple pieces when a label is longer than the length specified by Maximum Label Slice Length Options are: • Disable Label Slicing — Send data to host in one piece. •...

  • Page 130: Ibm Maximum Label Slice Length

    14 to 246. Pad all single and double digit numbers with leading zeroes to yield a three-digit entry (014-100). 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned. SET IBM MAXIMUM LABEL SLICE LENGTH 5-120 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 131: Usb-Oem Scanner Device Type

    IBM Features USB-OEM Scanner Device Type The IBM-USB protocol allows for the scanner to be identified as one of two different types of barcode scanners. Depending on what other scan- ners you may already have connected to a USB POS, you may need to change this setting to enable all scanners to communicate.

  • Page 132: Features

    3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 BAUD RATE = 1200 RS-232 BAUD RATE = 2400 5-122 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 133 RS-232 Features RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 4800 RS-232 BAUD RATE = 9600 5-123 Product Reference Guide...
  • Page 134 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 19200 RS-232 BAUD RATE = 38400 5-124 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 135 RS-232 Features RS-232 Baud Rate — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 BAUD RATE = 57600 RS-232 BAUD RATE = 115200 5-125 Product Reference Guide...

  • Page 136: Number Of Data Bits

    3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 NUMBER OF DATA BITS = 7 RS-232 NUMBER OF DATA BITS = 8 5-126 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 137: Rs-232 Number Of Stop Bits

    RS-232 Features RS-232 Number of Stop Bits Specifies number of stop bits required for sending and receiving data. 8 data bits with 2 stop bits and parity enabled is not a valid configura- tion. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 138: Parity

    Parity setting. You’ll need to cover any unused bar codes, as well as facing pages to ensure that the scanner reads only the bar code you intend to scan. 3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 PARITY = NONE 5-128 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 139 RS-232 Features RS-232 Parity — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 PARITY = EVEN RS-232 PARITY = ODD 5-129 Product Reference Guide...

  • Page 140: Hardware Control

    CTS signal must transition to inactive and then to active to enable scanning for the next label. • Enable Magellan SL CTS scan control — Emulates default Magel- lan SL setting for this feature. To set this feature: 1.
  • Page 141 RS-232 Features RS-232 Hardware Control — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 HARDWARE CONTROL = ENABLE CTS FLOW CONTROL RS-232 HARDWARE CONTROL = ENABLE CTS SCAN CONTROL 5-131 Product Reference Guide...
  • Page 142 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 HARDWARE CONTROL = ENABLE MGL SL CTS SCAN CONTROL 5-132 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 143: Intercharacter Delay

    RS-232 Features RS-232 Intercharacter Delay Specifies delay between the end of one character and the beginning of the next in 10-millisecond increments. To set the RS-232 Intercharacter Delay: 1. Scan the SWITCH bar code. 2. Scan the bar code below, SET RS-232 INTERCHARACTER .

  • Page 144: Software Flow Control

    3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 SOFTWARE FLOW CONTROL = DISABLE RS-232 SOFTWARE FLOW CONTROL = ENABLE 5-134 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 145: Host Echo

    RS-232 Features RS-232 Host Echo When enabled, this feature passes all data through the scanner to the host as it comes in. This feature is used for applications where “daisy chaining” of RS-232 devices onto the same cable is necessary. If, for example, one of the devices in the chain is a terminal where someone is entering data while another person is simultaneously scanning a bar code requiring transmis- sion to the host, the scanner will wait for the RS-232 channel to be quiet...

  • Page 146: Host Echo Quiet Interval

    001 = 10ms 005 = 50ms 040 = 400ms 100 = 1,000ms (1 second) 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned. SET RS-232 HOST ECHO QUIET INTERVAL 5-136 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 147: Ignore Host Commands

    RS-232 Features RS-232 Ignore Host Commands When set to ignore host commands, the scanner will ignore all host com- mands except for the minimum set necessary to keep the interface active, and transmit labels. For normal operation of the interface, disable this feature.

  • Page 148: Ttl

    3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 LEVELS = NORMAL RS-232 RS-232 LEVELS = TTL 5-138 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 149: Ttl Invert

    RS-232 Features RS-232 TTL Invert Enables/disables inversion of TTL. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code below which represents the desired setting for this feature. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 150: Icl Dc1 Character Delay Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 ICL DC1 CHARACTER DELAY = DISABLE RS-232 ICL DC1 CHARACTER DELAY = ENABLE 5-140 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 151: Beep On Ascii Bel

    RS-232 Features RS-232 Beep on ASCII BEL Enables/disables ability of scanner to beep (sound a good read tone) on receiving an ASCII BEL (07 hex). • Disable • Enable To enable/disable this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 152: Beep On Not On File

    Select for the host to beep (or not) when a not-on-file condition is detected by the host. This feature is also applicable to single cable RS-232. RS-232 BEEP ON NOT ON FILE = DISABLE RS-232 BEEP ON NOT ON FILE = ENABLE 5-142 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 153: Ack Nak Enable

    RS-232 Features RS-232 ACK NAK Enable This enables/disables the ability of the scanner to support the RS-232 ACK/NAK protocol. When configured, the scanner and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error.
  • Page 154 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 ACK/NAK = HOST ACKNOWLEDGEMENT RS-232 ACK/NAK = LABEL & HOST 5-144 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 155: Ack Character

    RS-232 Features RS-232 ACK Character This feature specifies which ASCII character will be used as an ACK char- acter. DO NOT set this feature to use previously defined characters such as XON, XOFF or host commands as this will conflict with normal opera- tion of these characters.

  • Page 156: Nak Character

    “4”, then “1” (the ASCII corre- sponding hex value). 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits/characters have been scanned. SET RS-232 NAK CHARACTER 5-146 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 157: Retry On Ack Nak Timeout

    RS-232 Features RS-232 Retry on ACK NAK Timeout This option specifies the action scanner performs on expiration of the 232 ACK NAK Timeout Value To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 158: Ack Nak Timeout Value

    005 = 1,000ms (1 second) 040 = 8,000ms (8 seconds) 075 = 15,000ms (15 seconds) 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned. SET RS-232 ACK NAK TIMEOUT VALUE 5-148 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 159: Ack Nak Retry Count

    RS-232 Features RS-232 ACK NAK Retry Count This feature sets the number of times for the scanner to retry a label trans- mission under a retry condition. To set the RS-232 ACK NAK Retry Count: 1. Scan the SWITCH bar code. 2.

  • Page 160: Ack Nak Error Handling

    3. Complete the programming sequence by scanning the SWITCH bar code. RS-232 ACK NAK ERROR HANDLING = IGNORE ERRORS 5-150 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 161 RS-232 Features RS-232 ACK NAK Error Handling — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RS-232 ACK NAK ERROR HANDLING = ASSUME ACK RS-232 ACK NAK ERROR HANDLING = ASSUME NAK 5-151 Product Reference Guide...

  • Page 162: Indicate Transmission Failure

    RS-232 Indicate Transmission Failure Enables/disables an audible error indication upon a transmission failure. RS-232 INDICATE TRANSMISSION FAILURE = DISABLE RS-232 INDICATE TRANSMISSION FAILURE = ENABLE 5-152 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 163: Single Cable Rs-232 Options

    Single Cable RS-232 Options Single Cable RS-232 Options The RS-232 Single Cable interface shares some configuration options with other RS-232 interfaces. Rather than repeat them in this chapter as Single Cable options, please find them referenced as follows: • RS-232 Baud Rate on page 122 •...

  • Page 164: Single Cable Pacesetter Plus Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. SINGLE CABLE PACESETTER PLUS = DISABLE SINGLE CABLE PACESETTER PLUS = ENABLE 5-154 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 165: Single Cable Rs-232 Rts Cts Selection

    Single Cable RS-232 Options Single Cable RS-232 RTS CTS Selection Specifies how RTS and CTS are used to control the data flow. RTS is con- trolled by the Scanner and can be continuously held high/low, or can be asserted during label transmission. The scanner looks at CTS, as the con- figuration values state, to determine when to send label data.
  • Page 166 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RTS CTS SELECTION = OPTION 2 RTS CTS SELECTION = OPTION 3 5-156 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 167 Single Cable RS-232 Options Single Cable RS-232 RTS CTS Selection — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. RTS CTS SELECTION = OPTION 4 RTS CTS SELECTION = OPTION 5 5-157 Product Reference Guide...

  • Page 168: Single Cable Rs-232 Use Bcc

    3. Complete the programming sequence by scanning the SWITCH bar code. SINGLE CABLE RS-232 USE BCC = DISABLE SINGLE CABLE RS-232 USE BCC = ENABLE 5-158 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 169: Single Cable Rs-232 Use Ack/Nak

    Single Cable RS-232 Options Single Cable RS-232 Use ACK/NAK Enables/disables the ability of the scanner to use ACK/NAK. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 170: Single Cable Rs-232 Use Stx

    3. Complete the programming sequence by scanning the SWITCH bar code. SINGLE CABLE RS-232 USE STX = DISABLE SINGLE CABLE RS-232 USE STX = ENABLE 5-160 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 171: Set Single Cable Rs-232 Stx Character

    Single Cable RS-232 Options Set Single Cable RS-232 STX Character This feature selects the STX character. To specify the STX Character: 1. Scan the SWITCH bar code. 2. Scan the bar code, SET SINGLE CABLE RS-232 STX CHARAC- below. You’ll need to cover any unused bar codes on this and the facing page to ensure the scanner reads only the bar code you intend to scan.

  • Page 172: Set Single Cable Rs-232 Etx Character

    001 to 127. 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned. SET SINGLE CABLE RS-232 ETX CHARACTER 5-162 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 173: Keyboard Wedge/Usb Keyboard Features

    Keyboard Wedge/USB Keyboard Features Keyboard Wedge/USB Keyboard Features Features listed in this section apply to both the Keyboard Wedge and USB Keyboard interfaces unless otherwise noted. Keyboard Interface — Keyboard Layout This feature specifies the country/language to be supported by the key- board.
  • Page 174 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. ³ 0 3 0 2 0 2 KEYBOARD LAYOUT = BRITAIN KEYBOARD LAYOUT = DENMARK 5-164 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 175 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = FRANCE KEYBOARD LAYOUT = GERMANY 5-165 Product Reference Guide...
  • Page 176 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = ITALY KEYBOARD LAYOUT = NORWAY 5-166 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 177 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = PORTUGAL KEYBOARD LAYOUT = SPAIN 5-167 Product Reference Guide...
  • Page 178 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = SWEDEN KEYBOARD LAYOUT = SWITZERLAND 5-168 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 179 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = JAPANESE 106 KEY KEYBOARD LAYOUT = HUNGARY 5-169 Product Reference Guide...
  • Page 180 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = CZECH KEYBOARD LAYOUT = SLOVAKIA 5-170 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 181 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Layout — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. KEYBOARD LAYOUT = ROMANIA KEYBOARD LAYOUT = CROATIA 5-171 Product Reference Guide...

  • Page 182: Keyboard Interface Quiet Interval

    001 = 10ms 005 = 50ms 040 = 400ms 100 = 1,000ms (1 second) 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned. SET KEYBOARD INTERFACE QUIET INTERVAL 5-172 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 183: Keyboard Interface Caps Lock State

    Keyboard Wedge/USB Keyboard Features Keyboard Interface Caps Lock State Specifies the format in which the scanner sends character data.. Choices are: • CAPS LOCK OFF — send character data in normal format. • CAPS LOCK ON — send character data in reverse case. •...
  • Page 184 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CAPS LOCK STATE = SHIFT LOCK ON CAPS LOCK STATE = CAPS LOCK COMPENSATION MODE 5-174 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 185: Keyboard Interface - Keyboard Simulation

    Keyboard Wedge/USB Keyboard Features Keyboard Interface — Keyboard Simulation Enables/disables ability of scanner to perform host communications nor- mally performed by attached keyboard. This feature does not apply to the USB Keyboard interface. NOTE All PCs check the keyboard status during the power-on Selftest. It is rec- ommended that you enable this function if you are working without a keyboard installation.

  • Page 186: Keyboard Interface - Control Characters

    You’ll need to cover any unused bar codes on this and the fac- ing page to ensure that the scanner reads only the bar code you intend to scan. 3. Complete the programming sequence by scanning the SWITCH bar code. CONTROL CHARACTERS = DISABLE 5-176 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 187 Keyboard Wedge/USB Keyboard Features Keyboard Interface — Control Characters — contin- Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CONTROL CHARACTERS = ENABLE TRANSMISSION OF CTL CHARACTERS CONTROL CHARACTERS = ENABLE FUNCTION KEY MAPPING 5-177 Product Reference Guide...

  • Page 188: Keyboard Interface - Intercharacter Delay

    001 = 10ms 005 = 50ms 040 = 400ms 100 = 1,000ms (1 second) 4. The scanner will automatically exit Programming Mode when the appropriate amount of digits have been scanned. SET KEYBOARD WEDGE INTERCHARACTER DELAY 5-178 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 189: Symbology Programming

    Symbology Programming Symbology Programming If the scanner’s interface type must be changed, always be sure that interface configuration is the FIRST item scanned during a pro- gramming session. (Selecting an interface type resets ALL other configuration items — including symbology programming — to the NOTE factory default for that interface type.) Coupon Control...
  • Page 190 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. COUPON CONTROL = ENABLE UPC/EAN COUPON DECODING COUPON CONTROL = ENABLE DATABAR COUPON DECODING 5-180 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 191: Upc-A Enable

    UPC-A Enable UPC-A Enable Enables/disables the ability of the scanner to decode UPC-A labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 192: Upc-A Number System Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. UPC-A NUMBER SYSTEM CHARACTER TRANSMISSION = DISABLE UPC-A NUMBER SYSTEM CHARACTER TRANSMISSION = ENABLE 5-182 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 193: Upc-A Check Character Transmission

    UPC-A Enable UPC-A Check Character Transmission Enables/disables transmission of a UPC-A check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 194: Expand Upc-A To Ean-13

    3. Complete the programming sequence by scanning the SWITCH bar code. EXPAND UPC-A TO EAN/JAN-13 = DISABLE EXPAND UPC-A TO EAN/JAN-13 = ENABLE 5-184 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 195: Upc-A Label Id

    UPC-A Enable UPC-A Label ID This feature specifies a UPC-A label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 196: Upc-A 2-Digit Supplemental Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET UPC-A 2-DIGIT SUPPLEMENTAL LABEL ID 5-186 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 197: Upc-A 5-Digit Supplemental Label Id

    UPC-A Enable UPC-A 5-Digit Supplemental Label ID This feature specifies a UPC-A 5-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 198: Upc-A 128 Supplemental Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET UPC-A 128 SUPPLEMENTAL LABEL ID 5-188 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 199: Upc-A Minimum Reads

    UPC-A Enable UPC-A Minimum Reads Specifies the minimum number of consecutive times a UPC-A label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
  • Page 200 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC-A MINIMUM READS = 3 UPC-A MINIMUM READS = 4 5-190 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 201: Upc-E Enable

    UPC-E Enable UPC-E Enable Enables/disables the ability of the scanner to decode UPC-E labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 202: Upc-E Number System Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. UPC-E NUMBER SYSTEM CHARACTER TRANSMISSION = DISABLE UPC-E NUMBER SYSTEM CHARACTER TRANSMISSION = ENABLE 5-192 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 203: Upc-E Check Character Transmission

    UPC-E Enable UPC-E Check Character Transmission Enables/disables transmission of a UPC-E check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 204: Expand Upc-E To Upc-A

    3. Complete the programming sequence by scanning the SWITCH bar code. EXPAND UPC-E TO UPC-A = DISABLE EXPAND UPC-E TO UPC-A = ENABLE 5-194 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 205: Expand Upc-E To Ean-13

    UPC-E Enable Expand UPC-E to EAN-13 Enables/disables expansion of UPC-E labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 206: Upc-E Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET UPC-E LABEL ID 5-196 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 207: Upc-E 2-Digit Supplemental Label Id

    UPC-E Enable UPC-E 2-Digit Supplemental Label ID This feature specifies a UPC-E 2-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 208: Upc-E 5-Digit Supplemental Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET UPC-E 5-DIGIT SUPPLEMENTAL LABEL ID 5-198 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 209: Upc-E 128 Supplemental Label Id

    UPC-E Enable UPC-E 128 Supplemental Label ID This feature specifies a UPC-E 128 Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 210: Upc-E Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. UPC-E MINIMUM READS = 1 UPC-E MINIMUM READS = 2 5-200 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 211 UPC-E Enable UPC-E Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC-E MINIMUM READS = 3 UPC-E MINIMUM READS = 4 5-201 Product Reference Guide...

  • Page 212: Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. EAN-13 = DISABLE EAN-13 = ENABLE 5-202 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 213: First Character Transmission

    EAN-13 Enable EAN-13 First Character Transmission Enables/disables transmission of EAN/JAN-13 first character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 214: Check Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. EAN-13 CHECK CHARACTER TRANSMISSION = DISABLE EAN-13 CHECK CHARACTER TRANSMISSION = ENABLE 5-204 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 215: Isbn Conversion Enable

    EAN-13 Enable EAN-13 ISBN Conversion Enable Enables/disables conversion of EAN/JAN-13 labels starting with 978 to Bookland ISBN labels. If any add-on information is present on the label prior to the conver- sion to ISBN, the add-on data will be discarded. Only the base label will be converted.

  • Page 216: Ean 13 Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET EAN 13 LABEL ID 5-206 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 217: 2-Digit Supplemental Label Id

    EAN-13 Enable EAN-13 2-Digit Supplemental Label ID This feature specifies an EAN-13 2-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 218: 5-Digit Supplemental Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET EAN-13 5-DIGIT SUPPLEMENTAL LABEL ID 5-208 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 219: 128 Supplemental Label Id

    EAN-13 Enable EAN-13 128 Supplemental Label ID This feature specifies an EAN-13 128 Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 220: Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. EAN-13 MINIMUM READS = 1 EAN-13 MINIMUM READS = 2 5-210 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 221 EAN-13 Enable EAN-13 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-13 MINIMUM READS = 3 EAN-13 MINIMUM READS = 4 5-211 Product Reference Guide...

  • Page 222: Bookland Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET BOOKLAND LABEL ID 5-212 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 223: Enable

    EAN-8 Enable EAN-8 Enable Enables/disables the ability of the scanner to decode EAN/JAN-8 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 224: Check Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. EAN-8 CHECK CHARACTER TRANSMISSION = DISABLE EAN-8 CHECK CHARACTER TRANSMISSION = ENABLE 5-214 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 225: Expand Ean-8 To Ean-13

    EAN-8 Enable Expand EAN-8 to EAN-13 Enables/disables expansion of EAN/JAN-8 labels to EAN/JAN-13. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 226: Ean-8/Jan-8 Guard Insertion

    3. Complete the programming sequence by scanning the SWITCH bar code. EAN-8/JAN-8 GUARD INSERTION = DISABLE EAN-8/JAN-8 GUARD INSERTION = ENABLE 5-216 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 227: Ean-8/Jan-8 Guard Substitution

    EAN-8 Enable EAN-8/JAN-8 Guard Substitution Enables/disables the ability of the scanner to substitute a guard pattern for even-parity 6 when an EAN-8/JAN-8 label is presented. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 228: Ean-8/Jan-8 Both Guards Substitution

    3. Complete the programming sequence by scanning the SWITCH bar code. EAN-8/JAN-8 BOTH GUARDS SUBSTITUTION = DISABLE EAN-8/JAN-8 BOTH GUARDS SUBSTITUTION = ENABLE 5-218 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 229: Stitch Exact Label Halves

    EAN-8 Enable EAN-8 Stitch Exact Label Halves When enabled, this allows the scanner the ability to stitch exact EAN-8 label haves with no overlapping characters. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 230: Stitch Unlike Label Halves

    3. Complete the programming sequence by scanning the SWITCH bar code. EAN-8 STITCH UNLIKE LABEL HALVES = DISABLE EAN-8 STITCH UNLIKE LABEL HALVES = ENABLE 5-220 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 231: Ean 8 Label Id

    EAN-8 Enable EAN 8 Label ID This feature specifies an EAN 8 label ID to be added to bar code data. To set this feature: The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 232: 2-Digit Supplemental Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET EAN-8 2-DIGIT SUPPLEMENTAL LABEL ID 5-222 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 233: 5-Digit Supplemental Label Id

    EAN-8 Enable EAN-8 5-Digit Supplemental Label ID This feature specifies an EAN-8 5-Digit Supplemental label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 234: 128 Supplemental Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET EAN-8 128 SUPPLEMENTAL LABEL ID 5-224 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 235: Decoding Levels

    EAN-8 Enable EAN-8 Decoding Levels Decoding levels allow the decoder to be set to perform at one of four selectable levels: • Very Conservative — Slower scan time, virtually eleminates mis- reads. The most secure setting. • Slightly More Aggressive — Faster scanning, more aggressive, yet minimizes misreads.
  • Page 236 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 DECODING LEVELS = VERY CONSERVATIVE EAN-8 DECODING LEVELS = SLIGHTLY MORE AGGRESSIVE 5-226 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 237 EAN-8 Enable EAN-8 Decoding Levels — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 DECODING LEVELS = MODERATELY AGGRESSIVE EAN-8 DECODING LEVELS = VERY AGGRESSIVE 5-227 Product Reference Guide...

  • Page 238: Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. EAN-8 MINIMUM READS = 1 EAN-8 MINIMUM READS = 2 5-228 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 239 EAN-8 Enable EAN-8 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM READS = 3 EAN-8 MINIMUM READS = 4 5-229 Product Reference Guide...

  • Page 240: Minimum Segment Length

    Complete the programming sequence by scanning the SWITCH bar code. EAN-8 MINIMUM SEGMENT LENGTH = 5 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 6 CHARACTERS 5-230 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 241 EAN-8 Enable EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 7 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 8 CHARACTERS 5-231 Product Reference Guide...
  • Page 242 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 9 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 10 CHARACTERS 5-232 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 243 EAN-8 Enable EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 11 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 12 CHARACTERS 5-233 Product Reference Guide...
  • Page 244 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 13 CHARACTERS EAN-8 MINIMUM SEGMENT LENGTH = 14 CHARACTERS 5-234 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 245 EAN-8 Enable EAN-8 Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN-8 MINIMUM SEGMENT LENGTH = 15 CHARACTERS 5-235 Product Reference Guide...

  • Page 246: Other Upc/Ean Options

    Other UPC/EAN Options The following pages contain other selectable features for UPC/EAN sym- bologies: • Price Weight Check • In-Store Label Minimum Reads • Enable EAN Two Label • EAN Two Label Minimum Reads • Addons 5-236 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 247: Price Weight Check

    Other UPC/EAN Options Price Weight Check Enables/disables calculation and verification of price/weight check digits. Applies to all UPC-A and EAN/JAN-13 labels with eligible Number Sys- tem/First Character digits. Options are: • Disable • 4-digit price/weight • 5-digit price/weight • 4-digit European price/weight •...
  • Page 248 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. PRICE WEIGHT CHECK = 4-DIGIT PRICE/WEIGHT PRICE WEIGHT CHECK = 5-DIGIT PRICE/WEIGHT 5-238 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 249 Other UPC/EAN Options Price Weight Check — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. PRICE WEIGHT CHECK = 4-DIGIT EUROPEAN PRICE/WEIGHT PRICE WEIGHT CHECK = 5-DIGIT EUROPEAN PRICE/WEIGHT 5-239 Product Reference Guide...

  • Page 250: In-Store Label Minimum Reads

    1. Instore labels are defined as UPC-A labels with a number-system character of 2 or 4 as well as EAN-8 and EAN-13 labels with a Flag1 character of 2 or an EAN-13 label starting with the three characters '980'. 5-240 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 251 Other UPC/EAN Options In-Store Label Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. IN-STORE MINIMUM READS = 3 IN-STORE MINIMUM READS = 4 5-241 Product Reference Guide...

  • Page 252: Enable Ean Two Label

    3. Complete the programming sequence by scanning the SWITCH bar code. Contact Customer Support for details about advanced programming for this feature. EAN TWO LABEL = DISABLE EAN TWO LABEL = ENABLE 5-242 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 253: Ean Two Label Combined Transmission

    Other UPC/EAN Options EAN Two Label Combined Transmission Enables/disables the transmitting of an EAN two label pair as one label. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 254: Upc/Ean Guard Insertion

    3. Complete the programming sequence by scanning the SWITCH bar code. UPC/EAN GUARD INSERTION = DISABLE UPC/EAN GUARD INSERTION = ENABLE 5-244 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 255: Upc/Ean Stitch Exact Label Halves

    Other UPC/EAN Options UPC/EAN Stitch Exact Label Halves When enabled, this allows the scanner the ability to stitch exact UPC-A / EAN-13 label haves with no overlapping characters. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 256: Upc/Ean Stitch Unlike Label Halves

    3. Complete the programming sequence by scanning the SWITCH bar code. UPC/EAN STITCH UNLIKE LABEL HALVES = DISABLE UPC/EAN STITCH UNLIKE LABEL HALVES = ENABLE 5-246 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 257: Upc/Ean Character Reconstruction

    Other UPC/EAN Options UPC/EAN Character Reconstruction Enables/Disables character reconstruction on UPC/EAN labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 258: Ean Two Label Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. EAN TWO LABEL MINIMUM READS = 1 EAN TWO LABEL MINIMUM READS = 2 5-248 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 259 Other UPC/EAN Options EAN Two Label Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. EAN TWO LABEL MINIMUM READS = 3 EAN TWO LABEL MINIMUM READS = 4 5-249 Product Reference Guide...

  • Page 260: Upc/Ean Correlation

    Complete the programming sequence by scanning the SWITCH bar code. UPC/EAN CORRELATION = DISABLE UPC/EAN CORRELATION = ENABLE 5-250 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 261: Upc/Ean Minimum Segment Length

    Other UPC/EAN Options UPC/EAN Minimum Segment Length Specifies the minimum number of characters necessary in a UPC/EAN/ JAN label segment in order for the scanner to accept a label for decoding. Selectable from 5 to 15 characters. To set this feature: 1.
  • Page 262 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 7 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 8 CHARACTERS 5-252 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 263 Other UPC/EAN Options UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 9 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 10 CHARACTERS 5-253 Product Reference Guide...
  • Page 264 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 11 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 12 CHARACTERS 5-254 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 265 Other UPC/EAN Options UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 13 CHARACTERS UPC/EAN MINIMUM SEGMENT LENGTH = 14 CHARACTERS 5-255 Product Reference Guide...
  • Page 266 UPC/EAN Minimum Segment Length — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. UPC/EAN MINIMUM SEGMENT LENGTH = 15 CHARACTERS 5-256 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 267: Addons

    Other UPC/EAN Options Addons Add-ons (or supplemental characters) are commonly added to the end of UPC/EAN bar codes. The scanner will read the add-ons if they are enabled and in the field of view. Three add-on types are supported: 2- digit, 5-digit and Code 128 add-ons.
  • Page 268 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. OPTIONAL 2-DIGIT ADD-ONS = DISABLE OPTIONAL 2-DIGIT ADD-ONS = ENABLE 5-258 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 269 Other UPC/EAN Options Addons — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. OPTIONAL 5-DIGIT ADD-ONS = DISABLE OPTIONAL 5-DIGIT ADD-ONS = ENABLE 5-259 Product Reference Guide...
  • Page 270 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. OPTIONAL CODE 128 ADD-ONS = DISABLE OPTIONAL CODE 128 ADD-ONS = ENABLE 5-260 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 271: Addon Timer

    Other UPC/EAN Options Addon Timer When addons have been selected as optional, this feature sets the duration of time that the scanner can unsuccessfully look for an addon before pro- ceeding to read a bar code. Timer duration is specified in 10ms incre- ments.

  • Page 272: 2-Digit Add-Ons Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. 2-DIGIT ADD-ONS MINIMUM READS = 1 2-DIGIT ADD-ONS MINIMUM READS = 2 5-262 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 273 Other UPC/EAN Options 2-Digit Add-ons Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. 2-DIGIT ADD-ONS MINIMUM READS = 3 2-DIGIT ADD-ONS MINIMUM READS = 4 5-263 Product Reference Guide...

  • Page 274: 5-Digit Add-Ons Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. 5-DIGIT ADD-ONS MINIMUM READS = 1 5-DIGIT ADD-ONS MINIMUM READS = 2 5-264 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 275 Other UPC/EAN Options 5-Digit Add-ons Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. 5-DIGIT ADD-ONS MINIMUM READS = 3 5-DIGIT ADD-ONS MINIMUM READS = 4 5-265 Product Reference Guide...

  • Page 276: Code 128 Add-Ons Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. CODE 128 ADD-ONS MINIMUM READS = 1 CODE 128 ADD-ONS MINIMUM READS = 2 5-266 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 277 Other UPC/EAN Options Code 128 Add-ons Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 128 ADD-ONS MINIMUM READS = 3 CODE 128 ADD-ONS MINIMUM READS = 4 5-267 Product Reference Guide...

  • Page 278: Gtin Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. GTIN = DISABLE GTIN = ENABLE 5-268 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 279: Gtin Label Id

    GTIN Enable GTIN Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 280: Gtin 2-Digit Supplemental Label Id

    The selectable range for this option is any hex value from 00 to FF (for each of the two characters). 4. Complete the programming sequence by scanning the SWITCH bar code. SET GTIN 2-DIGIT SUPPLEMENTAL LABEL ID 5-270 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 281: Gtin 5-Digit Supplemental Label Id

    GTIN Enable GTIN 5-Digit Supplemental Label ID This feature specifies a GTIN label ID to be added to bar code data when GTIN conversion is enabled and 5-digit supplemental addon bar code labels are converted. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.

  • Page 282: Gtin Code 128 Supplemental Label Id

    The selectable range for this option is any hex value from 00 to FF (for each of the two characters). 4. Complete the programming sequence by scanning the SWITCH bar code. SET GTIN CODE 128 SUPPLEMENTAL LABEL ID 5-272 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 283: Databar Omnidirectional Enable

    DataBar Omnidirectional Enable DataBar Omnidirectional Enable Enables/disables the ability of the scanner to decode DataBar Omnidirec- tional labels. This value-added feature is a factory-programmed option. Contact your dealer for information about upgrading your system to include this advanced capability. NOTE To set this feature: 1.

  • Page 284: Databar Omnidirectional/Ean-128 Emulation

    3. Complete the programming sequence by scanning the SWITCH bar code. DataBar Omnidirectional/EAN-128 EMULATION = DISABLE DataBar Omnidirectional/EAN-128 EMULATION = ENABLE 5-274 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 285: Databar Omnidirectional Label Id

    DataBar Omnidirectional Enable DataBar Omnidirectional Label ID This feature specifies an DataBar Omnidirectional label ID to be added to bar code data. To set this feature: The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 286: Databar Omnidirectional Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. DataBar Omnidirectional MINIMUM READS = 1 DataBar Omnidirectional MINIMUM READS = 2 5-276 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 287 DataBar Omnidirectional Enable DataBar Omnidirectional Minimum Reads — contin- Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DataBar Omnidirectional MINIMUM READS = 3 DataBar Omnidirectional MINIMUM READS = 4 5-277 Product Reference Guide...

  • Page 288: Databar Expanded Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. DataBar Expanded = DISABLE DataBar Expanded = ENABLE 5-278 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 289: Databar Expanded Ean-128 Emulation

    DataBar Expanded Enable DataBar Expanded EAN-128 Emulation Enables/disables EAN-128 emulation for DataBar Expanded. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 290: Databar Expanded Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET DataBar Expanded LABEL ID 5-280 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 291: Databar Expanded Length Control

    DataBar Expanded Enable DataBar Expanded Length Control This feature specifies either variable-length or fixed-length decoding for DataBar Expanded. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 292: Databar Expanded Length 1

    The selectable range for this option is 01 to 74. Pad all single digit numbers with a leading zero to yield a two-digit entry (01-74). 4. Complete the programming sequence by scanning the SWITCH bar code. SET DataBar Expanded LENGTH 1 5-282 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 293: Databar Expanded Length 2

    DataBar Expanded Enable DataBar Expanded Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see DataBar Expanded . Length includes the barcode’s check and data characters. Length Control) To set this feature:...

  • Page 294: Databar Expanded Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. DataBar Expanded MINIMUM READS = 1 DataBar Expanded MINIMUM READS = 2 5-284 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 295 DataBar Expanded Enable DataBar Expanded Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. DataBar Expanded MINIMUM READS = 3 DataBar Expanded MINIMUM READS = 4 5-285 Product Reference Guide...

  • Page 296: Code 39 Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. CODE 39 = DISABLE CODE 39 = ENABLE 5-286 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 297: Code 39 Start Stop Character Transmission

    Code 39 Enable Code 39 Start Stop Character Transmission Enables/disables transmission of Code 39 start and stop characters. This feature applies only when Code 39 Check Character Calcula- tion is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 298: Code 39 Check Character Calculation

    3. Complete the programming sequence by scanning the SWITCH bar code. CODE 39 CHECK CHARACTER CALCULATION = DISABLE CODE 39 CHECK CHARACTER CALCULATION = ENABLE 5-288 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 299: Code 39 Check Character Transmission

    Code 39 Enable Code 39 Check Character Transmission Enables/disables transmission of optional Code 39 check character. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 300: Code 39 Full Ascii

    3. Complete the programming sequence by scanning the SWITCH bar code. CODE 39 FULL ASCII = DISABLE CODE 39 FULL ASCII = ENABLE 5-290 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 301: Code 39 Label Id

    Code 39 Enable Code 39 Label ID This feature specifies a Code 39 label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 302: Code 39 Require Quiet Zones

    3. Complete the programming sequence by scanning the SWITCH bar code. CODE 39 REQUIRE QUIET ZONES = DISABLE CODE 39 REQUIRE QUIET ZONES = ENABLE 5-292 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 303: Code 39 Length Control

    Code 39 Enable Code 39 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 39. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 304: Code 39 Length 1

    The selectable range for this option is 01 to 50. Pad all single digit numbers with a leading zero to yield a two-digit entry (01-50). 4. Complete the programming sequence by scanning the SWITCH bar code. SET CODE 39 LENGTH 1 5-294 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 305: Code 39 Length 2

    Code 39 Enable Code 39 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 39 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.

  • Page 306: Code 39 Correlation

    Complete the programming sequence by scanning the SWITCH bar code. CODE 39 CORRELATION = DISABLE CODE 39 CORRELATION = ENABLE 5-296 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 307: Code 39 Stitching

    Code 39 Enable Code 39 Stitching Enables/disables stitching for Code 39 labels. When parts of a Code 39 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 308: Code 39 Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. CODE 39 MINIMUM READS = 1 CODE 39 MINIMUM READS = 2 5-298 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 309 Code 39 Enable Code 39 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 39 MINIMUM READS = 3 CODE 39 MINIMUM READS = 4 5-299 Product Reference Guide...

  • Page 310: Pharmacode 39 Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. PHARMACODE 39 = DISABLE PHARMACODE 39 = ENABLE 5-300 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 311: Pharmacode 39 Start Stop Character Transmission

    Pharmacode 39 Enable Pharmacode 39 Start Stop Character Transmission Enables/ disables transmission of start and stop characters for Pharmacode To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 312: Pharmacode 39 Check Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. PHARMACODE 39 CHECK CHARACTER TRANSMISSION = DISABLE PHARMACODE 39 CHECK CHARACTER TRANSMISSION = ENABLE 5-302 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 313: Pharmacode 39 Label Id

    Pharmacode 39 Enable Pharmacode 39 Label ID This feature specifies a Pharmacode 39 label ID to be added to bar code data. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 314: Code 128 Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. CODE 128 = DISABLE CODE 128 = ENABLE 1. Exception: The Code 128 symbology is always enabled with regard to scanning/reading the spe- cial C128 programming bar codes provided in this manual. 5-304 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 315: Code 128 Transmit Function Characters

    Code 128 Enable Code 128 Transmit Function Characters Enables/disables transmission of Code 128 function characters 1, 2, 3, and 4. Disabled is the recommended setting for all interfaces. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 316: Convert Code 128 To Code 39

    3. Complete the programming sequence by scanning the SWITCH bar code. CONVERT CODE 128 TO CODE 39 = DISABLE CONVERT CODE 128 TO CODE 39 = ENABLE 5-306 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 317: Code 128 Label Id

    Code 128 Enable Code 128 Label ID This feature specifies a Code 128 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled. NOTE To set this feature: 1.

  • Page 318: Code 128 Length Control

    3. Complete the programming sequence by scanning the SWITCH bar code. You must now set the features Code 128 Length 1 Code 128 Length NOTE CODE 128 LENGTH CONTROL = VARIABLE-LENGTH CODE 128 LENGTH CONTROL = FIXED-LENGTH 5-308 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 319: Code 128 Length 1

    Code 128 Enable Code 128 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Code 128 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.

  • Page 320: Code 128 Length 2

    01 to 80. Pad all single digit numbers with a leading zero to yield a two-digit entry (01-80). 4. Complete the programming sequence by scanning the SWITCH bar code. SET CODE 128 LENGTH 2 5-310 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 321: Code 128 Correlation

    Code 128 Enable Code 128 Correlation This feature enables/disables character correlation for Code 128. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 322: Code 128 Stitching

    Complete the programming sequence by scanning the SWITCH bar code. CODE 128 STITCHING = DISABLE CODE 128 STITCHING = ENABLE 5-312 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 323: Code 128 Minimum Reads

    Code 128 Enable Code 128 Minimum Reads Specifies the minimum number of consecutive times a Code 128 label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
  • Page 324 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 128 MINIMUM READS = 3 CODE 128 MINIMUM READS = 4 5-314 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 325: Enable

    EAN-128 Enable EAN-128 Enable Enables/disables the ability of the scanner to decode EAN-128 labels. When disabled, EAN128 labels are transmitted in Code128 data format. When enabled, EAN128 labels are transmitted in EAN128 data format To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 326: Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET EAN-128 LABEL ID 5-316 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 327: Interleaved 2 Of 5 (I 2 Of 5) Enable

    Interleaved 2 of 5 (I 2 of 5) Enable Interleaved 2 of 5 (I 2 of 5) Enable Enables/disables the ability of the scanner to decode Interleaved 2 of 5 labels. To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 328: I 2 Of 5 Check Character Calculation

    3. Complete the programming sequence by scanning the SWITCH bar code. I 2 of 5 CHECK CHARACTER CALCULATION = DISABLE I 2 of 5 CHECK CHARACTER CALCULATION = ENABLE 5-318 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 329: I 2 Of 5 Check Character Transmission

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Check Character Transmission Enables/disables transmission of an optional Interleaved 2 of 5 check char- acter. This feature applies only when I 2 of 5 Check Character Calcula- tion is enabled.

  • Page 330: I 2 Of 5 Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET I 2 of 5 LABEL ID 5-320 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 331: I 2 Of 5 Length Control

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for I 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2.

  • Page 332: I 2 Of 5 Length 1

    02 to 50, even numbers only. Pad all single digit numbers with a leading zero to yield a two-digit entry (02-50). 4. Complete the programming sequence by scanning the SWITCH bar code. SET I 2 of 5 LENGTH 1 5-322 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 333: I 2 Of 5 Length 2

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see I 2 of 5 Length Control) Length includes the barcode’s check and data characters.

  • Page 334: I 2 Of 5 Correlation

    Complete the programming sequence by scanning the SWITCH bar code. I 2 of 5 CORRELATION = DISABLE I 2 of 5 CORRELATION = ENABLE 5-324 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 335: I 2 Of 5 Stitching

    Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Stitching Enables/disables stitching for I 2 of 5 labels. When parts of an I 2 of 5 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 336: I 2 Of 5 Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. I 2 of 5 MINIMUM READS = 1 I 2 of 5 MINIMUM READS = 2 5-326 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 337 Interleaved 2 of 5 (I 2 of 5) Enable I 2 of 5 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. I 2 of 5 MINIMUM READS = 3 I 2 of 5 MINIMUM READS = 4 5-327...

  • Page 338: Standard 2 Of 5 (Std 2 Of 5) Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. STANDARD 2 OF 5 = DISABLE STANDARD 2 OF 5 = ENABLE 5-328 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 339: Standard 2 Of 5 Check Character Calculation

    Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Standard 2 of 5 check character. If check character calculation is disabled, the risk is increased that a misread can occur.

  • Page 340: Standard 2 Of 5 Check Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. STANDARD 2 of 5 CHECK CHARACTER TRANSMISSION = DISABLE STANDARD 2 of 5 CHECK CHARACTER TRANSMISSION = ENABLE 5-330 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 341: Standard 2 Of 5 Label Id

    Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Label ID This feature specifies a Standard 2 of 5 label ID to be added to bar code data.. The programming feature, Label ID Control, designates whether the Label ID is transmitted as a prefix or suffix or if Label ID is disabled.

  • Page 342: Standard 2 Of 5 Length Control

    3. Complete the programming sequence by scanning the SWITCH bar code. You must now set Standard 2 of 5 Length 1 Standard 2 of 5 Length NOTE STANDARD 2 OF 5 LENGTH CONTROL = VARIABLE-LENGTH STANDARD 2 OF 5 LENGTH CONTROL = FIXED-LENGTH 5-332 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 343: Standard 2 Of 5 Length 1

    Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Standard 2 of 5 Length Con- .

  • Page 344: Standard 2 Of 5 Length 2

    01 to 50. Pad all single digit numbers with aleading zero to yield a two-digit entry (01-50). 4. Complete the programming sequence by scanning the SWITCH bar code. SET STANDARD 2 OF 5 LENGTH 2 5-334 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 345: Standard 2 Of 5 Correlation

    Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Correlation This feature enables/disables character correlation for Standard 2 of 5. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 346: Standard 2 Of 5 Stitching

    2 of 5 Length 1 and/or Standard 2 of 5 Length 2 must be properly con- figured for stitching to work. NOTE I 2 OF 5 STITCHING = DISABLE I 2 OF 5 STITCHING = ENABLE 5-336 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 347: Standard 2 Of 5 Minimum Reads

    Standard 2 of 5 (Std 2 of 5) Enable Standard 2 of 5 Minimum Reads Specifies the minimum number of consecutive times a Standard 2 of 5 label must be decoded before it is accepted as a good read. To set this feature: 1.
  • Page 348 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. STANDARD 2 of 5 MINIMUM READS = 3 STANDARD 2 of 5 MINIMUM READS = 4 5-338 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 349: Codabar Enable

    Codabar Enable Codabar Enable Enables/disables the ability of the scanner to decode Codabar labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 350: Codabar Start Stop Character Transmission

    3. Complete the programming sequence by scanning the SWITCH bar code. CODABAR START STOP CHARACTER TRANSMISSION = DISABLE CODABAR START STOP CHARACTER TRANSMISSION = ENABLE 5-340 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 351: Codabar Start Stop Character Set

    Codabar Enable Codabar Start Stop Character Set This feature selects the format of transmitted Codabar start/stop charac- ters. Options are: • ABCD/TN* E • ABCD/ABCD • abcd/tn* e • abcd/abcd To set this feature: 1. Scan the SWITCH bar code. 2.
  • Page 352 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODABAR START STOP CHARACTER = abcd/tn* e CODABAR START STOP CHARACTER = abcd/abcd 5-342 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 353: Codabar Start Stop Character Match

    Codabar Enable Codabar Start Stop Character Match Enables/disables the requirement that start and stop characters match. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 354: Codabar Check Character Calculation

    3. Complete the programming sequence by scanning the SWITCH bar code. CODABAR CHECK CHARACTER CALCULATION = DISABLE CODABAR CHECK CHARACTER CALCULATION = ENABLE 5-344 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 355: Codabar Check Character Transmission

    Codabar Enable Codabar Check Character Transmission Enables/disables transmission of an optional Codabar check character. Applies only when Codabar Check Character Calculation enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 356: Codabar Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET CODABAR LABEL ID 5-346 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 357: Codabar Require Quiet Zones

    Codabar Enable Codabar Require Quiet Zones When enabled, this feature requires that quiet zones (margins) be present for Codabar labels. When disabled, quiet zones are optional. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 358: Codabar Length Control

    3. Complete the programming sequence by scanning the SWITCH bar code. You must now set the features Codabar Length 1 Codabar Length NOTE CODABAR LENGTH CONTROL = VARIABLE-LENGTH CODABAR LENGTH CONTROL = FIXED-LENGTH 5-348 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 359: Codabar Length 1

    Codabar Enable Codabar Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode (see Codabar Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.

  • Page 360: Codabar Length 2

    03 to 50. Pad all single digit numbers with a leading zero to yield a two-digit entry (03-50). 4. Complete the programming sequence by scanning the SWITCH bar code. SET CODABAR LENGTH 2 5-350 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 361: Codabar Correlation

    Codabar Enable Codabar Correlation This feature enables/disables character correlation for Codabar. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 362: Codabar Stitching

    Complete the programming sequence by scanning the SWITCH bar code. Codabar Stitching operates using fixed lengths ONLY. Codabar Length 1 and/or Codabar Length 2 must be properly configured for stitching to work. NOTE CODABAR STITCHING = DISABLE CODABAR STITCHING = ENABLE 5-352 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 363: Codabar Minimum Reads

    Codabar Enable Codabar Minimum Reads Specifies the minimum number of consecutive times a Codabar label must be decoded before it is accepted as a good read. To set this feature: 1. Scan the SWITCH bar code. 2. Scan the bar code representing the desired option below or on the following pages.
  • Page 364 Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODABAR MINIMUM READS = 3 CODABAR MINIMUM READS = 4 5-354 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 365: Code 93 Enable

    Code 93 Enable Code 93 Enable Enables/disables the ability of the scanner to decode Code 93 labels. To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 366: Code 93 Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET CODE 93 LABEL ID 5-356 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 367: Code 93 Length Control

    Code 93 Enable Code 93 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 93. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 368: Code 93 Length 1

    The selectable range for this option is 01 to 50. Pad all single digit numbers with a leading zero to yield a two-digit entry (01-50). 4. Complete the programming sequence by scanning the SWITCH bar code. SET CODE 93 LENGTH 1 5-358 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 369: Code 93 Length 2

    Code 93 Enable Code 93 Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 93 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.

  • Page 370: Code 93 Correlation

    Complete the programming sequence by scanning the SWITCH bar code. CODE 93 CORRELATION = DISABLE CODE 93 CORRELATION = ENABLE 5-360 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 371: Code 93 Stitching

    Code 93 Enable Code 93 Stitching Enables/disables stitching for Code 93 labels. When parts of a Code 93 bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 372: Code 93 Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. CODE 93 MINIMUM READS = 1 CODE 93 MINIMUM READS = 2 5-362 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 373 Code 93 Enable Code 93 Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. CODE 93 MINIMUM READS = 3 CODE 93 MINIMUM READS = 4 5-363 Product Reference Guide...

  • Page 374: Msi/Plessey Enable

    3. Complete the programming sequence by scanning the SWITCH bar code. MSI/PLESSEY = DISABLE MSI/PLESSEY = ENABLE 5-364 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 375: Msi/Plessey Check Character Calculation

    MSI/Plessey Enable MSI/Plessey Check Character Calculation Enables/disables calculation and verification of optional MSI/Plessey check characters. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a bar code are treated as data characters. NOTE To set this feature: 1.

  • Page 376: Msi/Plessey Number Of Check Characters

    3. Complete the programming sequence by scanning the SWITCH bar code. MSI/PLESSEY NUMBER OF CHECK CHARACTERS = 1 MSI/PLESSEY NUMBER OF CHECK CHARACTERS = 2 5-366 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 377: Msi/Plessey Check Character Transmission

    MSI/Plessey Enable MSI/Plessey Check Character Transmission Enables/disables transmission of optional MSI/Plessey check characters. This feature applies only when MSI/Plessey Check Character Calculation is enabled. NOTE To set this feature: 1. Scan the SWITCH bar code. 2. Scan either the enable or disable bar code below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 378: Msi/Plessey Label Id

    ‘4’, ‘1’, ‘4’, and ‘2’ must be scanned. The selectable range for this option is any hex value from 00 to FF. 4. Complete the programming sequence by scanning the SWITCH bar code. SET MSI/PLESSEY LABEL ID 5-368 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 379: Msi/Plessey Length Control

    MSI/Plessey Enable MSI/Plessey Length Control This feature specifies whether variable-length or fixed-length decoding will be set for MSI/Plessey. To set this feature: 1. Scan the SWITCH bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.

  • Page 380: Msi/Plessey Length 1

    The selectable range for this option is 04 to 16. Pad all single digit numbers with a leading zero to yield a two-digit entry (04-16). 4. Complete the programming sequence by scanning the SWITCH bar code. SET MSI/PLESSEY LENGTH 1 5-370 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 381: Msi/Plessey Length 2

    MSI/Plessey Enable MSI/Plessey Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode (see Code 93 Length Control) Length includes the barcode’s check and data characters. To set this feature: 1.

  • Page 382: Msi/Plessey Correlation

    Complete the programming sequence by scanning the SWITCH bar code. MSI/PLESSEY CORRELATION = DISABLE MSI/PLESSEY CORRELATION = ENABLE 5-372 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 383: Msi/Plessey Stitching

    MSI/Plessey Enable MSI/Plessey Stitching Enables/disables stitching for MSI/Plessey labels. When parts of an MSI/ Plessey bar code are presented to the scanner with this feature enabled, the bar code parts will be assembled by the scanner’s software, and the data will be decoded if all bar code proofing requirements are met.

  • Page 384: Msi/Plessey Minimum Reads

    Complete the programming sequence by scanning the SWITCH bar code. MSI/PLESSEY MINIMUM READS = 1 MSI/PLESSEY MINIMUM READS = 2 5-374 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 385 MSI/Plessey Enable MSI/Plessey Minimum Reads — continued Remember to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. MSI/PLESSEY MINIMUM READS = 3 MSI/PLESSEY MINIMUM READS = 4 5-375 Product Reference Guide...
  • Page 386 NOTES 5-376 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 387 Figure A-1 The descriptions following identify the use or function of each compo- nent. Figure A-1. Scanner Controls and Indicators Speaker Model 2200VS Scan Window Volume/Tone Indicator Push Button LED plus...

  • Page 388: Volume/Tone Push Button

    Only system support personnel should perform a reset. Resets Scanner a. By standard default, this function is normally disabled to prevent accidental activation by users. b. Users should not perform scanner resets except under the direction of trained systems support person- nel. A-378 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 389: Green Led Indicator

    Green LED Indicator The green LED indicates scanner status as shown in the table below. Table A-2. Green LED Indications DURATION COMMENT INDICATION Scanner (Green) LED on steady and Scanner Active The scanner is ready for operation. Scanning is immediately available. (Normal Mode) Good Read Scanner (Green) LED - bright flash...
  • Page 390 NOTES A-380 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 391: Appendix B. Cable Information

    Appendix B Cable Information Introduction The following pages contain pinout information, enabling you to create an auxilary port cable for use in interconnecting the scanner to an external handheld scanner. General Specifications Wire Requirements • Cable length should not exceed 15 feet. •...

  • Page 392: External Handheld Input

    No Connection - Reserved RTS out Request To Send (output) RxD in Receive Data (Input) TxD out Transmit Data (output) ~EAS_GOOD READ Special use Good Read +5V out (500mA max) +5V out Signal Ground SPKR OUT Speaker Out B-382 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 393: Appendix C Keypad

    Appendix C Keypad Use the bar codes in this section to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 394 Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. C-384 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 395 Use the bar codes in this section to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 396 Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. C-386 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 397 Use the bar codes in this section to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 398 Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. C-388 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 399 Use the bar codes in this section to enter numbers and characters as you would select digits/characters from a keypad. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
  • Page 400 Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan. C-390 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 401: Appendix D Host Commands

    Appendix D Host Commands Accepting Commands from an RS-232 Scanner Host The scanner responds to the following RS-232 commands: COMMAND ASCII COMMENT Enable Scanner 0x45 Disable Scanner 0x44 Reset Scanner 0x52 Not On File Indication 0x46 Long series of beeps Beep Good Read Tone 0x42 Beeps if Good Read Beep is enabled...
  • Page 402 NOTES D-392 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 403: Appendix E. Handheld Data Format Requirements

    Appendix E Handheld Data Format Requirements This appendix provides application notes to describe the general format of data that can be accepted by the scanner through the auxilliary port as transmitted from a handheld scanner. Handheld Data Format Requirements General •...

  • Page 404: Datalogic Handheld Data Format Requirements

    Check digit must be included in label data and is assumed to be cor- rect. • Supplemental data is appended to base label. • Prefix must be an ASCII character 'A' - total length including prefix must be 15. • Example: 'A06099201118712'. E-394 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 405 UPC-A with 5-Digit Supplemental • System number must be included in label data • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII character 'A' - total length including prefix must be 18 •...
  • Page 406 15 (code 128 Supplemental codes are variable length having a minimum of 2 data characters). • Characters immediately following base label must be of the form '8100', '8101' or '8102'. • Example: 'E099887508101000951'. E-396 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 407 EAN-8 • Check digit must be included in label data and is assumed to be cor- rect • Prefix must be an ASCII characters 'FF' - total length including pre- fix must be 10 • Example: 'FF00210126' EAN-8 with 2-Digit Supplemental •...
  • Page 408 20 (code 128 Supplemental codes are variable length having a minimum of 2 data characters) • Characters immediately following base label must be of the form '8100', '8101' or '8102' • Example: 'F11012345678918100000951' E-398 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 409 Code 39 • Check character must be included in label data. • Label length including start, stop and check characters and exclud- ing prefix character must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type.

  • Page 410: Standard 2 Of

    Start stop character sets must be of the form ABCD/ABCD and must be included in the label. • Example: '%s$99.95s' (the lower case ‘s’ at each end of the example is a placeholder for the start stop character set). E-400 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 411 Code 128 • Prefix must be an ASCII character '#'. • Label length excluding prefix character must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. • Function characters may be transmitted as a hexadecimal value 8x. Where x correlates to function characters 1 thru 4 as follows: •...

  • Page 412: Aim Formats

    AIM does not specify UPC-E as a separate symbology using this transmission format - labels will be transmitted as EAN-13. • Example: ']E00000000998875'. EAN-13 • Check digit must be included in label data and is assumed to be cor- rect. E-402 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 413: Digit Supplemental

    • Prefix must be ASCII characters ']E0'- total length including prefix must be 16. • Example: ']E01101234567891'. EAN-8 • Check digit must be included in label data and is assumed to be cor- rect. • Prefix must be ASCII characters ']E4' - total length including prefix must be 11.
  • Page 414 5-digit addon portion of the label must have a prefix of ]E2. Examples: addon portion is highlighted data is underlined. UPC-A 5-Digit addon ']E00060992011187]E212345' UPC-E 5-Digit addon ']E00000000998875]E212345' EAN-8 5-Digit addon ']E400210126]E212345' EAN-13 5-Digit addon ']E01101234567891]E212345' UPC-A ]E3006099201118712345 UPC-E ]E3000000099887512345 EAN-13 ]E3110123456789112345 E-404 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 415 Code 39 • Check character must be included in label data. • Label length including start, stop and check characters and exclud- ing prefix characters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type.

  • Page 416: Databar Omnidirectional

    • Prefix must be ASCII characters ']I0', ']I1' or ']I2' (other prefixes specify different check character properties which are not sup- ported). • Example: ']I10123456789'. E-406 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 417 Standard 2 of 5 • Check character must be included in label data. • Label length including check characters and excluding prefix charac- ters must meet requirements imposed by the main scanner's fixed or variable label length control for this symbology type. •...
  • Page 418 NOTES E-408 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 419: Appendix F. Keyboard Function Key Mappings

    Appendix F Keyboard Function Key Mappings Keyboard Model Cross Reference summarizes the keyboard models, their defined protocol, scancode set, and some Table F-410 unique features. The remaining tables in this chapter provide the function key maps associated with each of the scancode sets. F-409 Product Reference Guide...
  • Page 420 Wedge G AT/PS2 Scan Set 3 (122-key keyboard) IBM 3xxx Terminals Wedge H AT/PS2 Scan Set 3 (102-key keyboard) PS55 5530T with Japanese Wedge I AT/PS2 JAPANESE DOS (TDOS) NEC 9801 Wedge J NEC 9801 9801 F-410 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 421 Keyboard Model Cross Reference Table F-2. Scanset 1 Function Key Map ASCII ASCII code Scancode (hex) ALT right Make E0h 38h ALT right Break E0h B8h ALT left Make ALT left Break CTRL left Make CTRL left Break CTRL right Make E0h 1Dh CTRL right Break E0h 9Dh...
  • Page 422 7Dh + E0 PAGE DOWN (inner keypad) 7Ah + E0 HOME (inner keypad) 6Ch + E0 LEFT arrow (inner keypad) 6Bh + E0 DOWN arrow (inner keypad) 72h + E0 UP arrow (inner keypad) 75h + E0 F-412 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 423 Keyboard Model Cross Reference Table F-4 Scanset 3, 102-Key Function Key Map ASCII (hex) ASCII code Scancode ALT right Make ALT right Break F0h 39h ALT left Make ALT left Break F0h 19h CTRL left Make CTRL left Break F0h 11h CTRL right Make CTRL right Break F0h 58h...
  • Page 424 0Dh + S CR (FIELD EXIT) Make only 5Ah F0h 5Ah CR (FIELD EXIT) Make/Break INSERT (inner keypad) FIELD + FIELD - HOME (inner keypad) LEFT arrow (inner keypad) DOWN arrow (inner keypad) UP arrow (inner keypad) F-414 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 425 Keyboard Model Cross Reference Table F-6. Japanese DOS Function Key Map ASCII value ASCII code Scancode ALT right Make ALT right Break ALT left Make ALT left Break CTRL left Make CTRL left Break CTRL right Make CTRL right Break TAB right RIGHT arrow (inner keypad) TAB left...
  • Page 426 RIGHT arrow (inner keypad) TAB left 0Fh + S DELETE INSERT (inner keypad) KATAKANA LOCK ON (Make) KATAKANA LOCK OFF (Break) HOME (inner keypad) LEFT arrow (inner keypad) DOWN arrow (inner keypad) UP arrow (inner keypad) F-416 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 427 Keyboard Model Cross Reference Table F-8. USB Keyboard Function Key Usage Map ASCII Key Value Usage Name ALT right Make ALT right Break GUI right Make GUI right Break CTRL right Make CTRL right Break TAB right RIGHT arrow (inner keypad) TAB left Enter (right keypad) INSERT (inner keypad)
  • Page 428 NOTES F-418 Magellan 2200VS/2200VS and 2300HS/2300HS...
  • Page 429 Keyboard Model Cross Reference NOTES F-419 Product Reference Guide...
  • Page 430 NOTES F-420 Magellan 2200VS/2200VS and 2300HS/2300HS...

  • Page 431: Ascii Character Set

    ASCII Character Set The table on this page shows a set of ASCII characters and their corresponding Hex Values. The Hex Values in this table are needed for setting symbology specific label identifiers, as well as enabling custom prefix and suffix characters. ASCII ASCII ASCII...
  • Page 432 Australia Japan Datalogic Scanning Pty Ltd Datalogic Scanning KK Telephone: [61] (2) 9870 3200 Telephone: 81 (0)3 3491 6761 australia.scanning@datalogic.com japan.scanning@datalogic.com France and Benelux Latin America Datalogic Scanning SAS Datalogic Scanning, Inc Telephone: [33].01.64.86.71.00 Telephone: (305) 591-3222 france.scanning@datalogic.com latinamerica.scanning@datalogic.com Germany Singapore Datalogic Scanning GmbH Datalogic Scanning Singapore PTE LTD...

This manual is also suitable for:

2300hs

Table of Contents
