  • Page 1 User’s installation and operation Manual Page 1...

  • Page 2: Important Safeguards And Warnings

    Welcome Thank you for purchasing our DVR! This manual is designed to be a reference tool for the installation and operation of your system. Here you can find information about this series DVR features and functions, as well as a detailed menu tree.

  • Page 3: Table Of Contents

    Directory 1 Production Introduction..........................4 1.1 Product overview ........................... 4 1.2 Main functions ..........................4 2 Open-package check and cable connections..................6 2.1 Open-package check........................6 2.2 Hard disk installation ..........................6 2.3 Front panel............................. 7 2.4 Rear panel ............................. 8 2.5 Audio and video input and output connections ................
  • Page 4 4.3.4 Alarm input ........................39 4.3.5 Alarm output ........................40 4.3.6 Abnormal ....................错误！未定义书签。 4.4 System............................37 4.4.1 General..........................38 4.4.2 Encode ..........................39 4.4.3 Network ..........................40 4.4.4 NetSevice .......................... 41 4.4.5 GUI Display ........................49 4.4.6 PTZ/RS485........................50 4.4.7 RS232..........................

  • Page 5: Production Introduction

    1 Production Introduction 1.1 Product overview The series DVR is designed specially for security and defence field which is an outstanding digital surveillance product. It introduces embedded LINUX operating system which is more stable. It introduces standard H.264mp video compressed format and G.711A audio compressed format which insures the high quality image, low error coding ratio and single frame playing.
  • Page 6 individual real-time video recording as well as searching, playback, network surveillance, recording check, downloading and so on multi-playback mode zoom at arbitrary region Net operating through net tele-surveillance in the real time tele-PTZ control tele-recording check and real-time playback Alarm linkage multi-route relay alarm output which is convenient for the alarm linkage and light control at the spot protecting circuits at the alarm input and output interface which protects the main machine from damage Communication interface...

  • Page 7: Open-Package Check And Cable Connections

    2 Open-package check and cable connections 2.1 Open-package check When you receive the DVR, please check first . First, please check whether there is any visible damage to the package appearance. The protective materials used for the package of the DVR can protect most accidental clashes during transportation. Then, please open the box and get rid off the plastic protective materials.

  • Page 8: Front Panel

    ④ ⑤ ⑥ fix the screw of hard disk connect the data wire connect the power wire ⑦ ⑧ cover the machine fix the co 2.3 Front panel (1) IR remoter receiver (2) Power indicator light (3) Alarm indicator light (4)HDD indicator light (5) Record indicator light (6) Network indicator light (7) Status indicator light (8) Running Indicator (9) Back to main menu...

  • Page 9: Rear Panel

    2.4 Rear panel (1) Video input (2) port for outer device （3）SD card port （4）USB （5）Network （6）VGA （7）port for outer device （8）DC power port （9）Switch （10）HDMI port （11）BNC video output （12）Audio input （13）Audio output 2.5 Audio and video input and output connections 2.5.1 Video input connections The video input port is BNC connector plug.

  • Page 10: Video Output Connections And Options

    welding and oxidation. 2.5.2 Video output connections and options The video output is divided into PAL/NTSC BNC(1.0V ,75Ω) and VGA output(selective configuration). When replace the monitor by the computer display, there are some issues to notice. 1、Do not stay in the turn-on state for a long time. 2、Keep the computer display normal working by demagnetizing regularly.

  • Page 11: Alarm Input And Output Connections

    2.6 Alarm input and output connections １、Alarm input A. Alarm input is grounding alarm input. B. Alarm input demand is the grounding voltage signal. C. When the alarm is connected with two DVRs or connected with DVR and other equipments, it should be isolated by relay.

  • Page 12: Alarm Input Port Specification

    (1) alarm input 1,2,3,4 (2) grounding (3) RS232 (4) RS485 (5) alarm input 5,6,7,8 (6) grounding (7) alarm output parameter meaning (2) & (6) grounding Alarm output interface(constant open type) RS232 port 485communication interface which is connected with the recording control equipments such as the decoder 2.6.1 Alarm input port specification 8 channels alarm input.

  • Page 13: Alarm Output Port Relay Parameters

    2.6.3 Alarm output port relay parameters Type：JRC-27F Interface material silver rating Rating switch capacity 30VDC 2A, 125VAC maximal switch power 125VA 160W (resistance load) maximal switch voltage 250VAC, 220VDC maximal switch current isolation Homo-polarity 1000VAC 1minute Inhomo-polarity 1000VAC 1 minute Interface and winding 1000VAC 1 minute Surge voltage...

  • Page 14: Basic Operation

    3 Basic operation Note: The button in gray display indicates nonsupport. 3.1 Turn on Plug the power supply and turn on the power supply switch. Power supply indicator light shining indicates turning on the video recorder. After the startup you will hear a beep. The default setting of video output is multiple-window output mode.

  • Page 15: System Login

    will lose. 3.3 System Login When the DVR boots up, the user must login and the system provides the corresponding functions with the user purview. There are three user settings. The names are admin, guest and default and these names have no password. Admin is the super user purview; guest and default’s permissions are preview and video playback.

  • Page 16: Desktop Shortcut Menu

    3.5 Desktop shortcut menu In preview mode you can right click mouse to get a desktop shortcut menu. The menu includes: main menu, record mode, playback, PTZ control, High Speed PTZ, Alarm Output, color Setting, Output adjust, Logout, view mode shift . Shortcut under Hybrid mode Shortcut menu under full digital mode Picture 3.2 Shortcut Menu...

  • Page 17: Playback

    3.5.2 Playback There are two methods for you to play the video files in the hard disk. 1、 In the desktop shortcut menu. 2、 Main menu>Record->Playback Note: The hard disk that saves the video files must be set as read-write or read-only state.(4.5.1) Picture 3.4 video playback 1.

  • Page 18: Record Mode

    Round play Full screen Stop Picture 3.5 Playback control key Note: play under frame by frame, the playback status should be paused firstly. 【Operation tips】show function of the key that cursor placed. Special functions： button. The Accurate playback：Input time (h/m/s) in the time column and then click play system can operate accurate playback according to the searching time.

  • Page 19: Alarm Output

    【Stop】Click the stop button and the according channel stops recording no matter the channel in any state. 3.5.4 Alarm output Please check current channel status: “○” means it is not in alarming status, “●” means it is in alarming status. You can use desktop shortcut menu or click [main menu]>...
  • Page 20 Picture 3.10 PTZ setup 【Speed】Set the PTZ rotation range. Default range: 1 ~ 8. 【Zoom】Click button to adjust the zoom multiple of the camera. 【Focus】Click button to adjust the focus of the camera . 【Iris】Click button to adjust the iris of the camera. 【Direction control】Control the PTZ rotation.
  • Page 21 preset position corresponds. Clear Preset：Input preset points, click Remove button, remove the preset。 Preset point input blank Preset button Picture 3.11 Preset Settings 2）Preset Point Calls In Picture 3.10, click Page Shift button, enter PTZ control interface as shown in Picture 3.12. In the input blank, write the preset points, then click Preset button, PTZ turn to the corresponding preset point.
  • Page 22 Step 2: click Cruise buttons, the write proper value into the Cruise Line and Preset Points blank， then click Add Preset Points button, complete setting (also can add and delete cruise line which has been set up) Step 3: repeat step1 and step2 , until set out all the preset designated cruise lines。 Remove Preset：Please input preset value in the blank, click Remove Preset button, then remove the preset points.
  • Page 23 Scan value blank Scan Button Picture 3.14 Scan Setup 2）Scan Calls In Picture 3.10, click Page Shift button, then enter PTZ control menu as shown in Picture 3.12. Please input the number of scan in the value blank , then click Scan button，PTZ begins to work on the scan line .
  • Page 24 2）Boundary Scan Calls In Picture 3.10, click Page Shift button, then enter PTZ control menu as shown in Picture 3.12. Please input the number of scan in the value blank , then click Scan button，PTZ begins to work on the scan line . Click Stop button to stop. 5、Horizontal Rotating Click Horizontally Rotating button, PTZ begins to rotate horizontally (relative to the original position of the camera).

  • Page 25: Color Setting

    3.5.6 Color setting Set the selective image parameters (current channel for single window display and cursor place for multi-window display). You can use the desktop shortcut menu and enter the interface. The image parameters include: tonality, brightness, contrast, saturation. You can set different parameters at different time sections.

  • Page 26: Logout

    3.5.8 Logout Logout, shut down the system or reboot up. You can use the desktop shortcut menu or enter [main menu]. Picture 3.20 Logout/Shutdown/Reboot the system 【logout】Quit the menu. Offer password next entrance. 【shut down】Quit the system. Turn off the power supply. When press the shut down button, there is schedule hint.

  • Page 27: Main Menu

    4 Main menu 4.1 Main menu navigation Main menu Sub menu Function Config Set the recording configuration, recording type, recording time section playback Set recording search, recording play, video file storage Record Set screen capture period, type ,etc. Storage Note: Only hybrid mode have this function backup Detect backup device, format device, back the selective files Set motion detect alarm channel, sensitivity, area, linkage parameters:...
  • Page 28 main (assistant) coding parameter: code mode, resolving ability, Encode frame rate, code stream control, image quality type, code stream value, configuration frame between value, video/audio enable, Note: only hybrid mode with encode settings. Network Set basic network parameters, DHCP and DNS parameters, network configuration high speed download NetService...

  • Page 29: Record

    Adjust upside, downside, nearside, starboard distance, black margin Output adjust vertical & horizontal (Note: Only hybrid mode with black margin vertical & horizontal) Automatic Set automatic reboot system and automatic deleting files. maintenance Resume setup state: common setup, code setup, recording setup, alarm Restore setup, network setup, network service, preview playback, serial port setup, user management...
  • Page 30 Picture 4.1 Record Config 【Channel】Choose the corresponding channel number to set the channel. Choose the all option to set the entire channels. 【Redundancy】 Choose the redundancy function option to implement the file double backup function. Double backup is writing the video files in two hard disks. When you do the double backup, make sure that there are two hard disks installed.

  • Page 31: Snapshot Storage

    file type is “M”. Alarm:Trigger the external alarm signal in the set time section. When above alarm is set as opening recording, the “detection recording” state is on. The video file type is “A”. Note：Refer to chapter 4.3 to set corresponding alarm function. 4.2.2 Snapshot Storage When device set as Hybrid mode, there will be snapshot storage function in record, while only analog channel have this snapshot storage function.

  • Page 32: Playback

    【Period】Set normal record period,it only startup Snapshot Storage at set period. 【Type】Three types:regular,detect and alarm 【Record type】Three types:regular,detect and alarm Regular: snapshot at set period Detect:snapshot at set period when motion detect,video blind and video loss which are preset for snapshot enable. Alarm:snapshot at set period when alarm in which is preset for snapshot enable.

  • Page 33: Alarm

    Picture 4.4 File Backup Remove：Clear the file information. Add：Show the file information satisfying the set file attributes. Start/pause：Click the play button to start the backup and click the pause button to stop the backup. Note：During backup you can exit the page layout to carry out other functions. [Imprinting] click imprinting, will copy the record of related channel 【Erase】Choose the file to delete and click erasure to delete the file.
  • Page 34 Picture 4.4 Hybrid mode(4+2) Motion Detect Full digital mode Motion Detect 【Channel】Choose the set motion detect channel. 【Enable】■ means that the motion detect function is on. 【Sensitivity】Choose in the six options according to the sensitivity. 【Region】Click [set] to enter the set area. The area is divided into PAL22X18. Red block means the motion detect defensive area.
  • Page 35 Picture 4.5 Region 【Period】Trigger the motion detect signal in the set time section. You can set according to week or set uniformly. Each day is divided into four time sections.■ means the set valid. Picture 4.6 set the time section 【Interval】Only one alarm signal is turned on even there are several motion detect signals in the set interval.
  • Page 36 【Tour】■ means that the selective channel is single window alternate patrol preview. The interval is set in the [Main Menu]>[System] > [Tour]. 【Snapshot】Choose record channels, when alarm happens, system triggers related channels for snapshot signal. Note: For Snapshot activation, please go to set period, detect and alarm enable at Main Menu-> Record->Record configure, *Snapshot is only at motion detect under hybrid mode, snapshot shows only analog channel.

  • Page 37: Video Blind

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.3.2 Video Blind When the video image is influenced by the environment such as bad brightness or reaching the set sensitivy parameter, the camera mask function is turned on and the linkage function is turned on. *Same as motion detect function, video blind is different between Hybrid mode &...

  • Page 38: Video Loss

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.3.3 Video Loss When the equipment can not obtain the channel video signal, the video loss alarm is turned on and the linkage function is turned on. *Same as motion detect function, video loss is different between Hybrid mode & Full digital mode: Digital channel: not only to enable video loss function at local side, but also to enable the remote device that was connected.

  • Page 39: Alarm Input

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Note: "Advanced" button is the same as right click. 4.3.4 Alarm input When the equipment obtains the external alarm signal, the alarm function is turned on. *Alarm input is the same between hybrid mode & full digital mode, function enable, when it was set normal, only need to connect alarm sensor at alarm input port on local side, the alarm information is occurring, and will link to related setting functions at the same time Alarm input under hybrid mode(4+2)

  • Page 40: Alarm Output

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.3.5 Alarm output Refer to chapter 3.5.4. 4.3.6 Abnormal Analysing and inspecting current software and hardware of the device: When some abnormal events happen,the device will make a relative answer such as show message and buzzer. Picture 4.12 Abnormal 【Event Type】...

  • Page 41: System

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.4.1 General Picture 4.13 General setup 【System time】Set the system data and time. 【Date format】Choose the data format: YMD, MDY, DMY. 【Date Separator】Choose list separator of the data format. 【Time Format】Choose time format: 24-hour or 12-hour.

  • Page 42: Encode

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.14 DST (week) Picture 4.15 DST (date) 4.4.2 Encode setup There is Encode settings at hybrid mode only, encode settings is for analog channel only. Set the video/audio code parameter: video file, remote monitoring and so on. Set every main stream parameter in the left part, and set the extra stream parameter in the right part.

  • Page 43: Network

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.16 Encode setup 【Channel】Choose the channel number. 【Compression】Standard H.264 main profile. 【Resolution】Resolution type:D1/ HD1/CIF / QCIF. 【Frame Rate】P:1 frame/s~25 frame/s; N: 1 frame/s~30 frame/s 【Bit Rate Type】You can choose limited code stream or variable code stream. When you choose the variable code stream there are six image quality options.

  • Page 44: Netsevice

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Net Card】You can choose cable network card or wireless network card. 【DHCP Enable】Obtain IP address automatically(not suggested) Note：DHCP server is preinstalled. 【IP address】Set the IP address. Default: 192.168.1.10. 【Subnet mask】Set the subnet mask code.
  • Page 45 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【PPPoE setup】 Picture4.19 PPPOE Input the user name and password that ISP（Internet service provider）provides. After saving it reboot up your system. Then the DVR will build a network connection based on PPPoE. The IP address will change into dynamic IP address after above operation is well done.
  • Page 46 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Update Period:The same with the NTP server check interval. Default: 10minutes. 【EMAIL setup】 If the alarm is turned on or the alarm linkage photos are taken, send an email about the alarm information and the photos to appointed address.
  • Page 47 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. are supportive in the list. You can delete the set IP address by √ in the options. Note： When the same IP address is in the white and black list at the same time, the black list precedence is higher.
  • Page 48 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【FTP setup】FTP is available only when alarm happens,or alarm activates record and snapshot,it will upload related record and snapshot pictures to FTP server. Picture 4.24 FTP setup 【Enable】Click Enable,then all settings will be available 【Server IP】...
  • Page 49 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. [Type] choose "DNS" [Enable]: ■ means it is chosen [Sever IP]: IP address of DDNS server [Port]: Port No. of device, related DDNS server listen port [User name] the user name that device can log in DDNS server [Password] the password related to the user name.
  • Page 50 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Server IP】IP address of Alarm Server； 【Port】Device Port No.设备的端口号； 【Alarm Report】Tick it means to report alarm information to server. 【Log Report】Tick it, means to report log to server. 【Wireless Config】...
  • Page 51 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.26 Mobile Monitor Setup 【Enable】 Select it to make sure abnormal function workable 【Port】 It’s a port of mobile monitoring which you need to make a router mapping of if want to visit it by mobile 【UPNP】UPNP protocol can auto port forwarding on router,make sure UPNP is running on router before use it.

  • Page 52: Gui Display

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Search】 search SSID of wireless LAN 【Enable】 Select it to enable the function 【SSID】 SSID name 【Password】 password of WIFI 【IP Address】 IP address of WIFI 【Subnet Mask】 Subnet mask of WIFI 【Gateway】...
  • Page 53 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. GUI display of Hybrid Mode GUI display of Full digital mode Picture 4.28 GUI Display 【Channel Title】Click the channel name modify button and enter the channel name menu. Modify the channel name.
  • Page 54 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. the nine-window preview status. 【Transparency】Choose the background image transparency. The range is 128~255. 【Resolution】set display resolution. 【Channel】Choose the set code output channel number. 【Region Cover】 means the selective state. Click the cover area button and enter the corresponding channel window.

  • Page 55: Rs232

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Parity】Include odd check, even check, sign check, blank check. Default: void. *When system set as full digital channel, it will show RS485 device only 【Protocol】Choose protocol of related brand model(Example：DaHua)； 【Address】Set related address, default is 1；...

  • Page 56: Tour

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Serial Port Function】Common serial port is used to debug and update program or set up specific serial port. 【Baud rate】Choose the corresponding baud rate length. 【Data bits】Include 5-8 options. 【Stop bits】Include 2 options.
  • Page 57 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Digital Channels： 【Channel】select channel title； 【Enable】Open digital channel, tick enable, then can do related settings； 【Time Synchronization】Tick it means the time of this channel and device is the same. 【Connection Mode】can be singe connect or multi-ink, multi-link modes can connect to several devices, device will be tour displayed one by one, tour interval can be set, no less then 10s;...
  • Page 58 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Add】click add will come out below page to add new device： 【Configur Name】device is with default config title, user can revise it as you like； 【Device Type】3 types: IPC、DVR、HVR，user can choose as what you like, default is IPC； 【Protocol】Default is TCP 【Remote channel】User can input remote channel title from the device that you want to connect remotely；...
  • Page 59 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. When a channel is added with device and it is online, you will see as below: Channel status interface under full digital mode (One of the channel without device) Remark: when This Resolution is over Max Resolution, when preview it, will show a red X, as Page 59...

  • Page 60: Advanced

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. beow: Under all digital channel mode, Max resolution of channel 3 is D1, if it was connected to a device with resolution over D1 ( such as 960H), you will see below pic: Channel Mode：...

  • Page 61: Account

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture4.32 HDD Manage 4.5.2 Account Manage the user purview. Note：1. The character length is 8 bytes at most for the following user and user team name. The blank ahead or behind the character string is invalid.The middle blank in the character string is valid.
  • Page 62 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 【Modify User】Modify the existed user attribute. 【Modify Group】Modify the existed team attribute. 【Modify Password】Modify the user password. You can set 1-6 bit password. The blank ahead or behind the char string is invalid. The middle blank in the char string is valid. Note：The user who possess the user control purview can modify his/her own or other users password Picture 4.34 Modify Password...
  • Page 63 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.35 add user 【Add Group】Add a user team and set the purview. There are 36 different purviews: shut down the equipment, real time surveillance, playback, recording setup, video file backup and so on. Picture 4.36 Add Group 【Delete User】Delete the current user.

  • Page 64: Online User

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.37 Delete Group 4.5.3 Online User Look up the network user information in the local DVR. You can choose the network user and cut the connection. Then the user is locked until next boot-strap. Picture 4.38 Online User 4.5.4 TV adjust Refer to chapter 3.5.7 .

  • Page 65: Auto Maintain

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.5.5 Auto Maintain The user can set the auto reboot time and auto file deleting time limit. Picture 4.39 Auto maintain 4.5.6 Restore The system restore to the default setup. You can choose the items according to the menu. Picture 4.40 Restore Page 65...

  • Page 66: Upgrade

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.5.7 Upgrade Upgrade Picture 4.41 【 Upgrade】choose USB interface. 【Upgrade file】choose the file which needs upgraded. 4.5.8 Device Info Provide device interface info like audio in, alarm in/out to be conveniently used for user. Picture 4.42 Device Info.

  • Page 67: Bps

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.43 HDD Info Clue:○ means that the hard disk is normal. X means that the hard disk is broken-down.- means that there is no hard disk. If the user need to change the damaged hard disk, you must shut down the DVR and take up all the damaged hard disks,then install a new one.

  • Page 68: Log

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 4.6.3 LOG Look up system log according to the set mode. Log information include: system operation, configuration operation, data management, alarm affair, recording operation, user management, file management and so on. Set the time section to look up and click the look up button.

  • Page 69: Shut Down System

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Picture 4.46 Version 4.7 Shut down system Refer to chapter 3.5.8. Page 69...

  • Page 70: Faq And Maintenance

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. 5 FAQ and maintenance 5.1 FAQ If the problems are not listed, please contact the local service or call the HQ service. We are willing to offer the service. 1、...
  • Page 71 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Possible reasons are as followed: The program is not matched. Please update the program. The image brightness is all 0. Please restore the default setup. There is no video input signal or the signal is too weak. The channel protection or the screen protection is set.
  • Page 72 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. It is not an active tone arm. It is not an active sound box. The audio lines are damaged. The hardware of the DVR is damaged. 9、 There is audio signal in the surveillance window but mo audio signal in the playback state.
  • Page 73 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. The sensitivity is too low. Limited by some hardware edition. 13、 I can not login via web or CMS. Possible reasons are as followed: The system is windows 98 or win me. We recommend updating to windows 2000sp4 or higher Version or installing the software for low edition.
  • Page 74 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. The data is too much. Please stop recording and backup. The data exceeds the backup storage. The backup equipment is not compatible. The backup equipment is damaged. 17、 The keyboard can not control the DVR.
  • Page 75 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Possible reasons are as followed: Front vidicon quality is bad. The lens is too dirty. The vidicon is in backlighting installation. The hard disk capability is not enough. The hard disk is damaged.

  • Page 76: Maintenance

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Possible reasons are as followed: 1 HDD manage without partition for snapshot. 2 Partition for snapshot is 0 3 The snapshot function is not enable on record-> storage of related channel. 27、...
  • Page 77 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. DVR from static or inductive electricity. Do not pull out the video signal line or RS-232 port or RS-485 port with the power on. Do not use the TV in the local video output port(VOUT) of DVR. It will damage the video output circuit easily.

  • Page 78: Appendix 1.Remote Controller Operation

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Appendix 1.Remote controller operation Serial Name Function number Multi-window Same function as Multi-window button in the front button panel Numeric button Code input/number input/channel switch 【Esc】 Same function as【Esc】button in the front panel Direction button Same function as direction button in the front panel Record control...

  • Page 79: Appendix 2.Mouse Operation

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Appendix 2.Mouse operation *Take right hand as an example The mouse in USB connection is supported. Operation Function Double click one item in the file list to playback the video Double click the playback video to zoom in or out the Double left click...

  • Page 80: Appendix 3.Hard Disk Capability Calculation

    Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Appendix 3.Hard disk capability calculation Make sure the hard disk installed to the DVR for the first time. Pay attention to the IDE hard disk lines connection. 1、 Hard disk capability There is no limit for recording machine.
  • Page 81 Generated by Foxit PDF Creator © Foxit Software http://www.foxitsoftware.com For evaluation only. Video Preview Monitor:D1, VGA:High Definition, HDMI(optional) Playback 1080P/720P/960H/D1/HD1/CIF/QCIF Analog + digital: 4*D1+2*D1 2*D1+4*D1 Only Digital: Hybrid Input 6*D1 1*720P+ 3*D1 2*720P 4*960H 1*1080P Zones:64(8*8)detection zones,Sensitivity:1-6(6 is highest) Motion Detect Trigger recording,PTZ movement,tour,alarm,e-mail,snapshot &...
