QA6ADP QA Conversion
Thank you for buying the Mitsubishi general-purpose programmable
logic controller MELSEC-Q Series
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
© 2007 MITSUBISHI ELECTRIC CORPORATION
Adapter Module
User's Manual
MODEL
MODEL
CODE
IB(NA)-0800402-B(0803)MEE
QA6ADP
QA6ADP-U-JE
13JY50
Advertisement
Table of Contents
Related Manuals for Mitsubishi QA6ADP
Summary of Contents for Mitsubishi QA6ADP
- Page 1 QA6ADP QA Conversion Thank you for buying the Mitsubishi general-purpose programmable logic controller MELSEC-Q Series Prior to use, please read both this manual and detailed manual thoroughly and familiarize yourself with the product. © 2007 MITSUBISHI ELECTRIC CORPORATION Adapter Module User’s Manual...
- Page 2 Revisions * The manual number is noted at the lower right of the top cover. Print Date *Manual Number Aug., 2007 IB(NA)-0800402-A First printing Mar., 2008 IB(NA)-0800402-B This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses.
-
Page 3: Table Of Contents
Part Names ...9 Extension Stage Number Setting...10 5. IMPLEMENTATION AND INSTALLATION...11 Mounting/Removal of QA6ADP ...11 Connection/Disconnection of Extension Cable ...13 6. PRECAUTION FOR USING QA6ADP...16 Current Consumption of QA6ADP ...16 Voltage Drop of Extension Cable...17 7. EXTERNAL DIMENSIONS...18 GENERIC TERMS AND ABBREVIATIONS Unless otherwise specified, this manual uses the following generic terms and abbreviations to explain the QA conversion adapter module. -
Page 4: Overview
POINT • The QA6ADP is CE-compliant. To meet the EMC directive, the extension base unit and module to be used in combination with the QA6ADP should be CE-compliant. • When using a control line or communication cable, keep it away from the main circuit or power line 100mm or more. -
Page 5: System Configuration
The QA6ADP cannot be used in combination with the QA1S6 B. (3) The number of slots of the QA6ADP+A5 B/A6 B is always displayed in 8 slots, regardless of the number of slots of the extension base unit to be used in combination with the QA6ADP. -
Page 6: Configuration Device List
Extension base unit (Power supply module mounting type) (2) Module mountable on the extension base unit where the QA6ADP is mounted The following shows modules that can be mounted on the extension base unit where the QA6ADP is mounted. - Page 7 Make sure that the following condition is satisfied when A series AC input module is used. A series AC input module is mounted on the QA6 B or QA6ADP+A6 B. A series AC input module is mounted on the QA6ADP+A5 B. However, A series compatible extension base unit, QA6 B or QA6ADP+A6 B, exists in the system.
-
Page 8: Specifications
3. SPECIFICATIONS 3.1 General Specifications This section describes general specifications of the QA6ADP. Item Operating ambient temperature Storage ambient temperature Operating ambient humidity Storage ambient humidity Conforming Vibration resistance JIS B 3502, IEC 61131-2 Under Shock resistance Operation ambiance Operating... -
Page 9: Performance Specifications
Weight Adapter mounting screw (M3) torque Board fixing screw torque *1: The external dimensions show values in a status where the QA6ADP is mounted on the extension base unit. Specifications 110 mA 130 mm (5.11 inch) (H) 74 (2.91 inch) mm (D) 0.2 kg... -
Page 10: Part Names And Setting
4. PART NAMES AND SETTING 4.1 Part Names This section describes part names of the QA6ADP. Name Extension cable connector Stage number setting connector Adapter module mounting screw (M3 screw) Adapter module mounting bracket Mounting bracket fixing screw Base side stage... -
Page 11: Extension Stage Number Setting
If the stage number setting of the QA6ADP and that of the extension base unit is different, the two or more settings are made to one stage, the same stage number is duplicated, or no setting is made to the number of stages, incorrect input or incorrect output will occur. -
Page 12: Implementation And Installation
5. LOADING AND INSTALLATION 5.1 Mounting/Removal of QA6ADP (1) Mounting of the QA6ADP The following shows procedures for mounting the QA6ADP on the extension base unit. Disconnect the A series extension cable from the extension base unit. Remove a base cover from the extension base unit. - Page 13 (2) Removal of the QA6ADP The following shows procedures for removing the QA6ADP from the extension base unit. Disconnect an extension cable form the QA6ADP. Remove the adapter module mounting screws of the QA6ADP at two parts (top and bottom).
-
Page 14: Connection/Disconnection Of Extension Cable
QC100B POINT When connecting the base unit of the previous stage and the QA6ADP with an extension cable, be sure to connect the OUT side connector of the base unit of the previous stage and the IN side connector of the QA6ADP. - Page 15 • To connect an extension cable to the QA6ADP, remove a sticker on the IN side connector. QA6ADP • To connect an extension cable to the OUT side connector of the QA6ADP, remove the portion (lid) under the characters "OUT" by tools such as a flathead screwdriver (5.5 75, 6 100).
- Page 16 • Hold the connector part of an extension cable when connecting the extension cable to the QA6ADP. QA6ADP • Make sure to tighten fixing screws of the extension cable connector after connecting the extension cable. (Tightening torque: 0.20 N m)
-
Page 17: Precaution For Using Qa6Adp
Current consumption of CPU and I/O of main base unit *1 The quantity of the QA6ADP includes the QA6ADP when the A6 B is used. The following shows the concept of the current consumption of the power supply module mounted on the main base unit. -
Page 18: Voltage Drop Of Extension Cable
4.90VDC. Therefore, the voltage of the IN side connector of the QA6ADP+A5 B/A6 B in the final stage is 4.75VDC or more only when the sum (V) of voltage drop is 0.15V or less. -
Page 19: External Dimensions
7. COMPATIBLE MODELS LIST This chapter describes external dimensions of the QA6ADP. QA6ADP QA conversion adapter module Handle 74 (2.91) Power supply module, Extension cable A series extension base unit that you have already had 2 6-M4 screw (for mounting module) POWER 73.5 (2.89) - Page 20 Warranty Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
