- Page 1 Eternal Lighting CUBEecho™ IP65 HEX User Manual CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 2 Example: Full Red (255) will go about 17 hours Full Green (255) will go about 14 hours Full Blue (255) will go about 13 hours Full White (255) will go about 14 hours CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 3 Custom Color - R, G, B, W, A, UV (0-255) Shnd Color, Auto, Fade SLnd Master/Slave Mode UE 1.0 Run Time Hours and Total Life Hours btcc Battery Percentage Indicator IR Sensor (On/Off) UIrE Wireless Receiver (On/Off) CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 4 How to use the XT-Mitter PRO 3.0 with your lights: To operate the XT-Mitter PRO 3.0, you must connect the XT-Mitter Pro 3.0 with a DMX cable to a DMX Controller. CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 5 To use the IR Remote Plus control on the CUBEecho™ IP65 HEX, first ENABLE the IR located in the MENU selection. Also, turn the fixture into a MASTER. To control the fixture you must aim the remote at the infrared sensor located on the top of the fixture by the LEDs. CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 6 0-255 BLUE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright) 0-255 WHITE dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright) 0-255 AMBER dimmer (0-1 Off, 2-255 Dimmer from Dim to Bright) CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 7 Auto (0-10 Off, 11-255 Auto Change Color Snap through the preset colors) 0-255 Auto Slow to Fast (0-255) 0-255 R, G, B,W STROBE from slow to fast (0-15 Off, 16-255 Strobe Slow to Fast) Not Used CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 8 186-207 Orange as RED/Amber mixed, 208-255 Color Snap Red to Green to Blue to White to Amber) 0-255 Auto Speed Slow to Fast (0-255) CH10 0-255 R, G, B,W, A STROBE from slow to fast (0-255) CH11 Not Used CUBEecho™ IP65 HEX Eternal Lighting November 2015...
- Page 9 CH11 0-255 Auto/Fade Speed Slow to Fast (0-255) CH12 0-255 R, G, B,W, A STROBE from slow to fast (0-255) CH13 Not Used For more information, please contact Support by email at support@eternallighting.com CUBEecho™ IP65 HEX Eternal Lighting November 2015...
