- Page 2 Welcome to use MBot Cube 3D Printer Please check all the accessories one by one in the package, any missing or damage, Please contact sales representative within 7days of receiving the MBot cube kit. Have any problem during assembling or other query contact us at...
- Page 3 前 panel 抵挡板 Bottom dam-board...
- Page 4 打印板 玻璃制品 Build plate...
- Page 5 tray Brass barrel 黄铜柱 Washer...
-
Page 6: Tool Box
工具包 Tool box 注意： 检查主板上的驱动小班， 必须和图示上的位置一致， 单打印头插4块， 分别为X、Y、Z、A。 Attention: Make sure the stepper motor drivers chips are in the right position. Note: Only 4 stepper motor drivers chip for single head 3d printer. Control button planel cable Control button panel protector Cable wrap... - Page 7 A6 I6 Assemble all the electronics components and C1 stick to the correct position. G2 m3x8mm G3 m3x12mm G4 m3x16mm G7 m3x30mm G9 m3 G12 m3 C5 m3x7x20mm 6PCS 4PCS 1PCS 4PCS 9PCS 4PCS 4PCS...
- Page 8 Y Axis Assembly 注意： 按键(i3)安装时，注意插口在下方。 Attention: G3 m3x12mm G15 m3 Keep the cable connector socket of control 4PCS button pannel (i3) downside when assembling. 6PCS...
- Page 9 X轴限位开关 X-axis limit switch 背面 back 正面 front G12 m3 G3 m3x12mm G5 m3x20mm 6PCS 2PCS 8PCS...
- Page 10 注意： 电机先不要坚固。 Attention: Don’ t fasten screw on the motor too tight. G3 m3x12mm G7 m3x30mm G9 m3 G12 m3 3x7x12 3x7x20 2PCS 4PCS 2PCS 4PCS 2PCS 4PCS...
- Page 11 G8 2 G10 3 G14 3 G11 3 m5x35mm 0 m5 3PCS 3PCS...
- Page 12 Z Axis and Build platlorm Assembly Insert (F7) the build platlorm into threaded Z axis rod and ratare the threaded rod anti-clockwise untill build platlorm reach bottom. 注意： 组装好后，拧紧最下面一圈螺丝。 Attention: Inter lock and screw tightly all the pannels to each other.
- Page 13 注意： F2 Y轴光杆插入后，安装固定挡板，如图步骤2。 Note: Remeber to insert F2 to get the pannels fixed.
- Page 14 注意： 同步轮F6紧固后，确保 同步轴F1不会左右晃动。 Attention: Make sure F1 is tightened firmly after F6 is fastened Left Right...
- Page 15 panel...
- Page 16 注意： 紧固Y轴电机（螺丝切勿拧紧，会导致电机轴承摩擦到侧板； 检查X轴总成是否与顶板平行，如不平行，固定机器后用手扳平行即可。 Attention： FastenY-axis stepper motor. But don’ t tighten the screw very tight, avoiding friction between the stepper motor bearing and side pannel. Make sure the X-axis assembly parallel to cover pannel.
- Page 17 9、X轴电机线 X-axis motor drive cable 10、Y轴电机线 Y-axis motor drive cable 11、Z轴电机线 Z-axis motor drive cable 12、右机头电机线 Right extruder motor drive cable 13、左机头电机线 Left extruder motor drive cable 编号说明：Instructions 14、X轴限位开关 X-axis limit switch 1、主板 Motherboard 15、Y轴限位开关 Y-axis limit switch 2、电源 Power 16、Z轴限位开关...
- Page 18 命令识别及调校 命令识别（以下仅注明需要用到的命令操作） 主菜单： Utilities Print from SD : 从SD卡打印 Filament loading : 退料/进 料 Preheat : 预热 Preheat settings : 预热设置 Utilities : 设置 Level Build Plate : 水平调整 Home Axes : 原点归位 Filament Odometer : 用料统计 Exit menu : 退出 机器调校Calibration before printing 第一步：检查Z轴上下走动是否流畅。...
- Page 19 http://www.mbot3d.cn 购买与技术服务电话：400 004 1266 0571-88021266 Add：杭州市高新区(滨江)建业路511号华业大厦14楼 邮编：310052 http://www.mbot3d.com www.magicfirm.com Tel: 400 004 1266 +86 571 8802 1266 ( UTC+8 9:30-18:00 work time) 14th Floor，Block A,Huaye Building,511 Jian Ye Road,Binjiang District,310052,Hangzhou...
