- Page 1 Optical wireless gaming headset instruction manual Item name : 2.4G optical wireless gaming headset Model : HW-933M A、For PS3 console...
- Page 2 B、Product & accessories : A、Headset ------------------------1PCS B、Transmitter---------------------1PCS C、Detachable Microphone----------1PCS D、Micro USB-USB Short cable -----1PCS E、Micro USB-USB Long cable -----1PCS F、Optical cable------------------1PCS ： C , Connection ports function Transmitter 1、Optical port 2、MICRO USB port 3、Working indicating light（Flashing during pairing , solid blue light paired in use , solid red light while mic muted ）...
- Page 3 Headset 1. Working indicator light 2. Background sound VOL 3. Chat sound VOL 4. 3.5mm microphone interface 5. 3.5mm XBOX interface 6. Power ON/OFF switch 7. USB recharging port 8. Recharging indicator light 9. Vibration strength D、 Connection method ： 1、First of all , connect Micro USB-USB long cable to DC 5V charging adaptor USB port to charge headset for around 5 hours, red light on during charging and off after fully charge .
- Page 4 2、Connect PS3 optical port with Transmitter optical port using Optical cable （ protection cover must be removed ) ；Using Micro USB short cable to connect PS3 USB port with Transmitter USB port as below ： 3、 Detail connection diagram ：...
- Page 5 E、PS3 console setting : 1、After power on PS3 console , select setting and choose Accessory Settings 2、Select Audio Device Settings 3、Set Input Device and Output Device to 2.4G Wireless headset , at this moment , you can set the microphone level and test the sound level when you wear the headset , you can set mic level from 1 to 5...
- Page 6 4、Back to setting screen , select Sound Settings 5、Select Audio Output Settings...
- Page 7 6、Select Optical Digital 7、 Remove √ticks of “Dolby Digital 5.1ch” and “DTS 5.1ch” and press Enter to confirm ；...
- Page 8 8、Set Audio Multi-Outpot on F、Operation method ： 1、Connect transmitter and PS3 console USB port using the short USB cable ,light flashing . 2、Long press power button for 3 seconds to power on the headset , the headset should auto pair with the transmitter and solid blue light light up , if the headset light keep flashing , please pair them once again .
- Page 9 light keep fast flashing , then the light on transmitter and headset will become solid blue. 4、Default setting for mute is off ( chat on ), if you want to mute your chat voice , please press the mute button once and transmitter light will become red 5、Volume adjusting switch allow you to adjust the game background and chat volume .
- Page 10 Settings--System--Console settings--Audio-- ①Digital Output -- DigitalStereo(don’t choose Dolby Digital 5.1 or Dolby Digital with WMA Pro), ②Sound Effects--Enable Sound Effents，③Ratings Collection Sound ---Turn On No mic sound 1. Plug in microphone for headset 2、Use short USB cable for audio transmission 3、Setting should be : Settings-Accessory Settings-Audio Device Settings-Input Device and Output Device - Select all options: 2.4G Wireless headset-OK-Enter...
