GPS Receiver System
GSR2600
T p l l j b
Operations Manual
Part Number 750-1-0093 Rev 1

Advertisement

Table of Contents
loading

Related Manuals for Sokkia GSR2600

Summary of Contents for Sokkia GSR2600

  • Page 1 GPS Receiver System GSR2600 T p l l j b Operations Manual Part Number 750-1-0093 Rev 1...
  • Page 2 United States of America (“U.S.A.”) and/or the jurisdic- tion in which you are located. Trademark Notice POINT Sokkia is a trademark of Sokkia, Co. Ltd. GSR2600 is a trademark of , Inc. All other product and brand names are trademarks or registered trademarks of their respective holders.

  • Page 3: Table Of Contents

    Setting Up at the Office .......... 7 Setting Up in the Field..........8 Chapter 3 General Components GSR2600 Front View..........10 GSR2600 Back View ..........11 Data Card Access Door ........12 3.3.1 Data card ............. 12 GPS Antenna............15 Battery Pack ............16 3.5.1 Battery pack LEDs........
  • Page 4 STATUS > Home ........... 44 6.2.1 Occupy ............47 6.2.2 Battery ............48 6.2.3 System ............49 6.2.4 Space ............51 6.2.5 Contrast ............52 GPS DATA > Home ..........52 6.3.1 Lat ..............53 6.3.2 Lon..............54 6.3.3 Hgt..............55 6.3.4 Vel..............55 GSR2600...
  • Page 5 6.7.1 Number ............74 6.7.2 Name............74 6.7.3 Edit Hgt ............74 6.7.4 Antenna ............74 6.7.5 Execute............74 CFG COM > Home ..........75 6.8.1 COM1............76 6.8.2 C1 IMode ............. 78 6.8.3 COM2............79 6.8.4 C2 IMode ............. 79 GSR2600...
  • Page 6 7.2.1 Using receiver configurations ....83 7.2.2 Using the POWERUP configuration ..84 Data File Naming ..........85 Data Storage Requirements ......... 87 Data Logging Interruption........87 Resetting the Receiver........... 87 Appendix A GSR2600 Specifications Appendix B Glossary Index GSR2600...
  • Page 7 Occupation Status ............47 Battery Status ..............48 System Status ..............49 Space Status............... 51 GPS Satellite Messages ............ 56 Interface Modes ..............78 Powerup Configuration Settings ........85 Auto-Generated File Name Convention....... 86 8 MB Data Card Logging Capacity........ 87 GSR2600...
  • Page 8 Figures GSR2600 Front View ..........10 GSR2600 Back View ..........11 Access Door ..............12 SK-600 Antenna ............... 15 Battery Pack Attached to Receiver ........ 16 Battery Pack LEDs ............17 Insert Batteries ..............18 Battery Pack Front Clamps ..........18 Battery Pack Side Clamps ..........

  • Page 9: Chapter 1 Introduction

    Sokkia GSR2600 GPS receiver and its functions. The GSR2600 is a high-performance GPS receiver for use in both RTK and post-processing applications. This receiver is capable of receiving and tracking up to 12 GPS satellites on L1 and L2 channels, has fast data update rates, and integrates memory (Compact Flash Card) for data logging.

  • Page 10: Ports And Icons

    Chapter 1 Introduction Ports and Icons The following icons are located on the front or rear panel of the GSR2600 receiver. The icons identify the: Icon Description Rear Panel Power port COM1 Data collector communications port COM2 Radio communications port...

  • Page 11: Features

    Field upgradeable software Where to Find Information This manual provides sufficient information to enable you to effectively use the GSR2600. In addition to this manual, several other forms of documentation serve as supporting documents. • GSR2600 Advanced Reference Materials. Located on the Complete Product CD.

  • Page 12: Obtaining Technical Assistance

    Firmware version number • Concise description of the problem Technical support for this product is available from the distributor where you purchased it. You also may contact one of the Sokkia subsidiaries listed below. Europe Australia Sokkia B.V. Sokkia Pty. Ltd.

  • Page 13: Notes, Cautions, And Warnings

    Introduction Chapter 1 Notes, Cautions, and Warnings Notes, Cautions, and Warnings stress important information regarding the installation, configuration, and operation of the GSR2600 receiver. Note Note: Notes outline important information of a general nature. Caution CAUTION Cautions inform of possible sources of difficulty or situations that may cause damage to the product.

  • Page 14: Gsr2600 Usage Cautions

    Do not eject the data card while the GSR2600 is logging data, or you may lose part of, or your entire, data file.

  • Page 15: Chapter 2 Quick Start System Setup

    GSR2600 in the field or office. CAUTION See Section 1.6, GSR2600 Usage Cautions, on Page 6 for a list of items you should be aware of as you set up and use the GSR2600. Setting Up at the Office In a typical GSR2600 office setup, the PC is connected to the receiver’s COM1 port, and a 12 V power supply is...

  • Page 16: Setting Up In The Field

    GSR2600 to the PC (For example, Spectrum Survey). Setting Up in the Field The following explains how to typically set up your GSR2600 to collect static or kinematic data in the field. These steps assume that schedule and logging parameters have already been loaded to the GSR2600, and that an optional handheld data collector is not being used.
  • Page 17 Insert a CompactFlash card into the GSR2600. Connect a power source (For example, battery) to the GSR2600’s PWR port. Press the power button to turn on the GSR2600. If available, the GSR2600 will begin logging according to the stored configuration.

  • Page 18: General Components

    Chapter 3 General Components The following sections introduce the general GSR2600 physical components. GSR2600 Front View The following is an illustration of the GSR2600 main features located on the front of the receiver. Figure 1: GSR2600 Front View Description Description...

  • Page 19: Gsr2600 Back View

    General Components Chapter 3 GSR2600 Back View The following is an illustration of the GSR2600 main features located on the back of the receiver. Figure 2: GSR2600 Back View Description Description COM2 Port (radio Power Port communications) COM1 Port (handheld...

  • Page 20: Data Card Access Door

    Data can be stored on a 3.3 V or 5 V-compliant CompactFlash data card, which can be accessed, exchanged, and replaced when needed. The GSR2600 can store data to the card automatically, according to pre-configured parameters, without any user intervention. In applications when continuous user interaction is required, a data collector can be used with the GSR2600.
  • Page 21 General Components Chapter 3 You can swap data cards while the GSR2600 is on, providing that data logging is not in progress. If the card is accidently removed while data is logging, (or if you experience a power interruption or similar disruptive event), the GSR2600 may lose several seconds, up to a maximum of one minute, of data.
  • Page 22 If you are unsure if the data card is actually logging data, look at the top right corner of the display in the LCD screen. If the word “LOGGING” is flashing, then data is currently being recorded. For more information, see Section 5.5, LCD Front Panel, Page 37. GSR2600...

  • Page 23: Gps Antenna

    For more information on cables, see Section 3.6.3.1, Antenna cables, Page 27. WARNING The performance specifications of the GSR2600 are guaranteed only when the receiver is used with a Sokkia model SK-600 antenna. For complete specifications on this antenna, refer to your product CD for the L1/L2 GPSAntenna Model SK-600 Antenna Quick Start, Part Number 790-0-0064.

  • Page 24: Battery Pack

    LED flashing red), the two non-active batteries can be replaced without disrupting operation. If you install three batteries, the GSR2600 will choose the first battery installed as its power source. If that battery becomes exhausted (for example, the battery drains), the GSR2600 will switch to the next available battery without any interruption in logging activities.

  • Page 25: Battery Pack Leds

    Figure 6: Battery Pack LEDs For the LEDs to work, the battery pack must be fully connected to a GSR2600 that is turned on. For more information, see Section 3.5.3, Connecting the battery pack, Page 20. For easy identification, each battery compartment (when the battery pack is open) lays directly above its associated LED.

  • Page 26: Inserting And Removing Batteries

    To access the battery compartments, open the battery pack by releasing the two clamps holding the compartment closed. Figure 8: Battery Pack Front Clamps Orient the battery flat side down with the connector end facing the rear of the battery compartment. GSR2600...
  • Page 27 Apply pressure to the top of the battery with your fingers. Push the battery away from the compartment connectors. When the battery is no longer seated in the compartment, lift it out of the battery pack. Close the battery pack and re-attach the front clamps. GSR2600...

  • Page 28: Connecting The Battery Pack

    Ensure the battery pack power cable and latches are extended out. Place the GSR2600 on top of the battery pack and aligned so that the back of the receiver’s front bumper touches the front edge of the battery pack.

  • Page 29: Connect Side Clamps

    General Components Chapter 3 Lift the hook of each clamp into the groove on the side of the GSR2600 and press down on their handles to lock them in place. Figure 11: Connect Side Clamps Connect the battery pack power cable to the PWR port on the GSR2600.

  • Page 30: Ports And Cables

    Chapter 3 General Components Ports and Cables As shown in Figure 2, GSR2600 Back View, Page 11, the rear end-cap has four labeled ports: COM2, COM1, PWR, and GPS. Each GSR2600 cable connector is keyed to ensure that the cable can be inserted only one way to prevent damage to both the GSR2600 and the cables.

  • Page 31: Communication Ports

    Data is being transmitted on the port Data is being received and transmitted simultaneously Red and Green on the port For communication to occur, the GSR2600 COM port configuration must match that of the external device’s. The GSR2600’s default port settings are: RS232C •...
  • Page 32 If this happens, reduce the load and allow the unit to automatically reset its protection circuitry. For further information on the signals or connector pin-outs for the serial ports or cables, see your GSR2600 Advance Reference Materials. GSR2600...

  • Page 33: Power Port (Pwr)

    • Provides automatic reset circuit protection WARNING Do not supply the GSR2600 with an input voltage that is outside the allowable range (+6 V to +18 V DC). 3.6.2.1 Power cables The following power cables can be used with the GSR2600: Camcorder Power Cable.

  • Page 34: Gps Port

    Further cable information can be obtained from the GSR2600 Advanced Reference Materials. For a listing of the voltage levels that the GSR2600 switches from one source to the other, or at which the GSR2600 shuts off, see Appendix A, GSR2600 Specifications. 3.6.3...

  • Page 35: General Cable

    If your application requires a longer cable, contact your dealer for information on additional cable lengths. The performance specifications of the GSR2600 are guaranteed only when it is used with supplied RF cables. Note: The cable should be connected to the antenna and GSR2600 before power is supplied.

  • Page 36: Chapter 4 Basic Operations

    Start System Setup. CAUTION See Section 1.6, GSR2600 Usage Cautions, on Page 6 for a list of items and conditions that you should be aware of as you use the GSR2600. In this chapter, all discussions about the GSR2600 being...

  • Page 37: Scheduled Session

    If either happens, the GSR2600 will automatically turn back on. Scheduled Session The GSR2600 can be set up to run schedules at specific time, and even to turn off between schedules to conserve battery power. These options are configured using the SETTINGS >...

  • Page 38: Power Consumption

    Note: Exceptional conditions may delay the acquisition of satellites beyond the start of the logging session. It is important to remember that as long as the GSR2600 is connected to batteries, the GSR2600 is drawing power. When left unused, the GSR2600 will drain the batteries completely after five to ten days.

  • Page 39: Insufficient Power

    CAUTION The GSR2600 may also become inactive if the external power input is greater than the power specified. See Section 1.6, GSR2600 Usage Cautions, on Page 6 for more information.

  • Page 40: When Using Data Collectors

    Receivers are intended to be used as kinematic or static, but not both at one time. You should run configurations and schedules only on the GSR2600 when it is being used as a static receiver (base station). If you need to enter any data on the base station receiver, do so in the office, using Planning software, before you go into the field.

  • Page 41: Chapter 5 Display Panel Operations

    The following sections explain how to operate the display panel. Power Button The GSR2600 power button is used for turning the GSR2600 on or off. As well, the power button will enable you to delete all files on your data card, or reset the receiver back to factory settings.
  • Page 42 • Hold button for 1 second and release to turn on the GSR2600. • To indicate that the GSR2600 is on, the LCD will first display a Sokkia screen, Turn on followed by the message Starting up. After initialization, the GSR2600 will beep...

  • Page 43: Audible Annunciator

    Release the button to delete all the files on the installed data card. Audible Annunciator The GSR2600 is equipped with an audible annunciator that issues a series of beeping noises to alert you to the system status and to warn of errors.

  • Page 44: Escape Button

    Press the <Esc> button to go backwards through menu items in the LCD. With continued pressing, you will eventually return back to the top of the menu where you started. For more information, see Section 6.1.1, Navigating the menus, Page 42. GSR2600...

  • Page 45: Enter Button And Navigation Arrows

    LCD Front Panel The LCD screen, located on the front of the display panel, shows a menu for you to communicate with the GSR2600. This section explains the LCD interface, but for information on how to use the menu layout and screens, see Chapter 6, LCD Display.
  • Page 46 For example, if the receiver is logging data to a file, and it is also in a site occupation, the logging indicator will flash Logging followed by Site. GSR2600...

  • Page 47: Logging Status

    SING Single point position SINGLE DGPS Pseudorange differential PSRDIFF solution * Information on GPS Position Type is for advanced users that wish to interpret logs output by the OEM4 card. For more information, see the OEM4 Command Description Manual. GSR2600...

  • Page 48: Navigation Aids

    The arrow indicators in the navigation aids field are used to help you navigate the menu system (also known as navigation mode), and to guide you when editing fields (also known as edit mode). For more information see Figure 15, LCD Interface, Page 37. GSR2600...
  • Page 49 ç ê è ç ê è é ê é ê è ç é é ê é ê GSR2600...

  • Page 50: Chapter 6 Lcd Display

    6.1.1 Navigating the menus The arrow keys on the GSR2600’s front panel enable you to move back and forth through the menus and screens. As a shortcut, at any point while navigating the menu layout, you can press <Esc> to exit your current screen and move to the previous screen, the menu screen, or to the main status information menu.
  • Page 51 To better understand this concept, the following illustrations show the results of pressing the <Esc> button from four levels into the menu system. Current position After pressing <Esc> one time After pressing <Esc> two times After pressing <Esc> three times GSR2600...

  • Page 52: Editing Screen Information

    If you press this key, the fields original value will remain. STATUS > Home After the GSR2600 turns on and acquires satellites, the LCD displays the STATUS menu, on by default, the Home screen. The STATUS > Home screen displays the current system time, as well as a message about the system’s status.
  • Page 53 LCD Display Chapter 6 Circles ....If two blinking circles display on the screen, then the GSR2600 has a system message (either error or notice) to display. Note: To view all the system messages, see Section 6.2.3, System, Page 49. By using the down arrow key, you can see the following...
  • Page 54 Current GPS latitude • Current GPS longitude • Current GPS height • Current occupation status • Battery status • Disk free space on the CompactFlash card Each screen will be displayed for 5 seconds before automatically switching to the next screen. GSR2600...

  • Page 55: Occupy

    10Km processing a 10 Km baseline Sufficient data collected for post 15Km processing a 15 Km baseline Sufficient data collected for post 20Km processing a 20 Km baseline Sufficient data collected for post 30Km processing a 30 Km baseline GSR2600...

  • Page 56: Battery

    9 V, the Battery menu will display the voltage for the power input, and will place <> around the active power input. For example, if the GSR2600 is being powered by 13.7 V, the Battery menu will display the voltage as <A> 13.7 V.

  • Page 57: System

    In other words, once you arrive at this menu, the GSR2600 will automatically scroll through all the messages it is currently reporting. The following table shows all the status messages that can be...
  • Page 58 Expected battery life low warning (both internal INT POWER WARNING batteries combined) Battery failure (both internal batteries INT POWER FAIL combined) TEMPERATURE WARN Controller high-temperature warning TEMPERATURE FAIL Controller temperature fail NVM FAILURE Controller NVM fail PC CARD ERROR PCCard error GSR2600...

  • Page 59: Space

    The card has at least 60% of its memory free The card has at least 40% of its memory free The card has at least 20% of its memory free The card has less than 20% of its memory free. Replace the disk now. GSR2600...

  • Page 60: Contrast

    Chapter 6 LCD Display Note: When the card runs out of space, the GSR2600 will also send out double beeps to notify you that the card is full. 6.2.5 Contrast To change the contrast of the LCD, follow these steps: Press <Ent>...

  • Page 61: Lat

    LCD Display Chapter 6 From the GPS DATA menu, use the arrow keys to move down through the menu items. 6.3.1 This menu displays the current calculated GPS latitude. GSR2600...

  • Page 62: Lon

    This menu displays the standard deviation for the current calculated GPS latitude. To access this menu, make sure you are currently on the GPSDATA > Lat screen, and then press the right arrow on the GSR2600’s display panel. 6.3.2 This menu displays the current calculated GPS longitude. 6.3.2.1...

  • Page 63: Hgt

    GPS height. To access this menu, make sure you are currently on the GPSDATA > Hgt screen, and then press the right arrow on the GSR2600’s display panel. 6.3.4 This menu shows the horizontal speed over ground, in metres per second.

  • Page 64: Sat

    To view information on each satellite, make sure you are currently on the GPSDATA > Sat screen, and then press the right arrow on the GSR2600’s display panel. Each time you press the arrow, another satellite’s information will display. The Sat menu displays information in the following three fields: S......PRN number of the satellite...

  • Page 65: Dops

    DOPS The DOPS1 and DOPS2 menus display various dilution of precision values. To access the DOPS2 menu, make sure you are currently on the GPSDATA > DOPS1 screen, and then press the right arrow on the GSR2600’s display panel. GSR2600...

  • Page 66: Corr Age

    This menu displays the differential corrections’ lag time. The Corr Age menu will display "NO DIFFERENTIAL" if no differential corrections are being received. CFG RCVR > Home The configure receiver menus are used to control the data logging configuration of the system. GSR2600...
  • Page 67 Refer to your Planning Reference Manual for more information on configurations and schedules. From the CFG RCVR menu, use the arrow keys and <Ent> button to move down through the following screens: GSR2600...

  • Page 68: Run Cfg

    This screen is actually a series of screens that display all of the configurations currently stored on the receiver. To stop a configuration, follow these steps: Using the left and right arrow keys, navigate to the configuration name you want to stop. GSR2600...

  • Page 69: Sched

    Sched This menu displays the current state of the scheduler. When the scheduler is disabled, the GSR2600 will not run schedules. To set the GSR2600 so that it will run schedules, follow these steps: Press <Ent>. Use the up and down arrow keys to set the scheduler to ENABLED.

  • Page 70: Schedule

    Chapter 6 LCD Display Note: There are times when the GSR2600 may override the state of the scheduler, such as when the receiver is first turned on. At this time, if there is no powerup group present, the receiver will enable the scheduler even if you disabled it previously.
  • Page 71 Schedule starts at 18:00 and stops at 20:00 every Monday and Wednesday. START: 0700 STOP: 1800 Schedule starts at 07:00 and stops at 18:00 every day. START: m0205 STOP: f1215 Schedule starts at 02:05 on Monday and stops at 12:15 on Friday. GSR2600...

  • Page 72: Cutoff

    This menu shows the elevation cut-off angle for tracked satellites. When you set a cutoff angle, all satellites that fall below the angle will be ignored by the GSR2600 when determining position. The Cutoff screen enables you to change the elevation cutoff value by following these steps: Press the <Ent>...

  • Page 73: Files > Home

    The FILES menu enables you to view information regarding a specific file. As well, you can delete a single file, or all files, from the removable disk. From the FILES menu, use the arrow keys and <Ent> button to move down through the following screens: GSR2600...

  • Page 74: File Information

    On the FILES > Name screen, you can use the up and down arrows to see that file’s information. 6.5.1.1 Size This screen displays the size of the file in bytes. Note: The FILES > Size menu is not updated for files that are still open and logging data. GSR2600...
  • Page 75 Use the up and down arrows to change the delete status to Yes. Press <Ent>. You will be asked if you are sure that you want to delete the file. Press <Ent> to continue with the deletion, or <Esc> to abort. GSR2600...

  • Page 76: Del All Files

    You will be asked if you are sure that you want to delete the file. Press <Ent> to continue with the deletion, or <Esc> to abort. When you choose to delete all files, the GSR2600 will close any open data files, and then delete the files from the disk. SETTINGS > Home...

  • Page 77: Contrast

    From the SETTINGS menu, use the arrow keys and <Ent> button to move down through the following screens: 6.6.1 Contrast This menu displays the screen’s current contrast value. You can modify the contrast of the screen using the <Ent> key. For instructions see Section 6.2.5, Contrast, Page 52. GSR2600...

  • Page 78: Sleep

    For more information on the sleep mode and the automatic scheduler, see Chapter 4, Basic Operations. 6.6.3 RTKReset This menu enables you to reset the RTK filter, forcing the system to restart the ambiguity resolution calculations. GSR2600...

  • Page 79: Freset

    Chg Model This menu enables you to switch between models that are present on the receiver. To change the firmware model of your receiver, follow these steps: Press <Ent>. Use the up and down arrow keys to select the model. GSR2600...

  • Page 80: Gps Ser

    This menu displays the version associated with both the software for data collection and the user interface. CFG SITE > Home Use the CFG SITE menu to configure and set site information, as well as to enter or leave sites. GSR2600...
  • Page 81 Cfg Site and configurations The various CFG SITE menu values can be changed without your intervention when a configuration is started, but these changes will not be updated in the CFG SITE menus. GSR2600...

  • Page 82: Number

    Use this screen to configure the antenna height for the site. 6.7.4 Antenna Use this screen to configure the site’s antenna type. 6.7.5 Execute Use this screen to apply to the site the information you set up in the Number, Name, Edit Hgt, and Antenna screens. GSR2600...

  • Page 83: Cfg Com > Home

    Use this menu to configure the receiver’s communication ports, which may be used to communicate with a hand controller, or to a radio for providing differential corrections. From the CFG COM menu, use the arrow keys and <Ent> button to move down through the following screens: GSR2600...

  • Page 84: Com1

    Data Bits, Parity Description and Stop Bits 8NONE1 8 data bits, no parity, 1 stop bit 8EVEN1 8 data bits, even parity, 1 stop bit 8ODD1 8 data bits, odd parity, 1 stop bit GSR2600...
  • Page 85 Use the right and left arrow keys to position the change line under the field you want to modify. Use the up and down keys to change the field to a new value. Press <Ent> to change to the new setting or <Esc> to leave the original settings. GSR2600...

  • Page 86: C1 Imode

    The port accepts/generates CMR corrections The following example shows a possible setup for COM1. Example: CMR RTCM Receive Interface This port will accept only Mode CMR format data Transmit Interface This port will only transmit RTCM Mode RTCM format data GSR2600...

  • Page 87: Com2

    COM2. See Section 6.8.2, C1 IMode, Page 78. 6.8.5 The description of this screen is analogous to that for COM1 with the exception that the settings apply to the AUXCOM communications port. See Section 6.8.1, COM1, Page 76. GSR2600...

  • Page 88: Chapter 7 Collecting Data

    PC for post-processing and adjustment using Sokkia’s Spectrum Survey Suite software package. The GSR2600 records raw data in the form of logs, which are written to the data file on a periodic basis. Sokkia’s software interprets these logs and the data that they contain.

  • Page 89: Scheduled Data Collection

    You can schedule your GSR2600 to collect data repetitively (For example, every day from 15:00 to 17:00), or customized (For example, tomorrow from 10:00 to 11:00 and the day after from 17:00 to 18:00).

  • Page 90: Handheld Data Collection

    When you connect the data collector to the receiver, a communication link is established and the handheld controls the behavior of the receiver. If you turned on the GSR2600 by pressing its power button, the POWERUP configuration (if it exists) will run until the data collector takes control of the receiver.

  • Page 91: Defining Data To Be Collected

    You can define what type of information should be collected during a data collection session by using tools available in the Sokkia Planning software to create configurations for the GSR2600. The following sections give an overview of using configurations. For more information, refer to your Planning Reference Manual.

  • Page 92: Using The Powerup Configuration

    7.2.2 Using the POWERUP configuration The GSR2600 receiver initially operates on a default configuration called POWERUP (for more information on configurations, see Section 7.2, Defining Data to be Collected, Page 83, or refer to your Planning Reference Manual).

  • Page 93: Data File Naming

    RTK base if the radio/modem is present. By including all necessary logs for either configuration into the one POWERUP group, you will not have to change the default logs if your GSR2600 is switched between static and RTK base. Data File Naming...

  • Page 94: Auto-Generated File Name Convention

    When scheduling a single data collection event, you can provide a name for the data file in advance. If you are scheduling a series of events, you must allow the GSR2600 to generate names automatically. All files have a *.pdc extension, and must consist of one to eight characters.

  • Page 95: Data Storage Requirements

    Average # of Satellites Epoc Rate Data Logging Interruption If you press the power button to turn off the GSR2600 while it is logging data, the GSR2600 will save any open data files before turning off. Resetting the Receiver A POWERUP configuration (refer to your Planning Reference Manual for more information) is provided for default data collection.
  • Page 96 For more information on audio features, see Section 5.2, Audible Annunciator, Page 35. WARNING Holding the power button for approximately 20 seconds will erase all data off the data card. For more information, see Section 5.1, Power Button, Page GSR2600...

  • Page 97: Specifications

    Vibration (Random Profile) The GSR2600 can acquire and track satellites while undergoing vibration levels as shown below. It assumes that C/No > 45 dB-Hz and that the GSR2600 is in high-dynamics mode. Assuming appropriate mounting, the GSR2600 conforms to random vibration templates for RTCA/DO-160C, Section 8.6.2 (Curve C template), MIL-STD-202F, Test Condition I (Letter A nominal template), and ASAE EP455, Section 5.15.1 nominal template.
  • Page 98 Current Power Management If the GSR2600 is connected to a battery pack, it begins using the first battery installed. When this voltage drops below 6.5 V DC, the battery is unusable, and the GSR2600 will switch to the next available battery. Once battery reserves are depleted, the GSR2600 shuts itself off.

  • Page 99: Gsr2600 Specifications

    GSR2600 Specifications Appendix A GSR2600 SPECIFICATIONS Static Accuracy Horizontal: 5mm + 1ppm * D Carrier Phase Vertical: 10mm + 1ppm * D Post-Processed Occupation: 4SVs, 30sec rate, >1h Rapid-Static Horizontal: 5mm + 1ppm * D Vertical: 10mm + 1ppm * D Occupation: 5SVs, 15sec rate, >20min...
  • Page 100 Complies with the radiated and conducted emission limits for a Class B digital device, for both CISPR 22 and Part 15 of the FCC rules. For full details see GSR2600 FCC and CE Notice on Page 2. a. Accuracy depends on number of satellites visible, obstructions, satellite geometry (DOP), occupation time, multipath effects, atmospheric conditions, baseline length, survey procedures, and data quality.

  • Page 101: Appendix B Glossary

    True North (0 degrees) typically, and a chosen point. Baseline - The three-dimensional vector distance between a pair of stations for which simultaneous GPS data has been collected and processed with differential techniques. The most accurate GPS result. GSR2600...
  • Page 102 GPS receivers within the same general geographic area. Differential positioning - Determines the relative coordinates using two or more receivers that are simultaneously tracking the same satellites. Dynamic differential positioning is a real-time calibration technique achieved by sending corrections to the GSR2600...
  • Page 103 This is related to GDOP. It describes the NDOP (North Dilution effects of geometry on the northern of Precision) component of positioning accuracy. Doppler - The change in frequency of sound, light or other wave caused by movement of its source relative to the observer. GSR2600...
  • Page 104 GPS receivers. Available as "broadcast ephemeris" or as post-processed "precise ephemeris." Epoch - Same as measurement time epoch. The local time at which a GPSCard takes a measurement. For example, 15 seconds, 30 seconds. GSR2600...
  • Page 105 Geoidal Separation (or Geoidal Height) - The height difference between the ellipsoidal height and orthometric height at a given point on the earth’s surface. Worded differently, it is the separation between the geoid surface and the ellipsoid surface at a given point on the earth’s surface. GSR2600...
  • Page 106 HI - Height of Instrument IODE - Issue of Data (Ephemeris) Iono-free Carrier Phase Observation - A linear combination of L1 and L2 carrier phase measurements which provides an estimate of the carrier phase observation on one frequency with GSR2600...
  • Page 107 (C/A) code, as well as encrypted P-code, and navigation, messages used by commercial GPS receivers. L2 - A secondary GPS carrier, containing only encrypted P-code, used primarily to calculate signal delays caused by the ionosphere. The L2 frequency is 1227.60 MHz. GSR2600...
  • Page 108 Obstruction - Physical feature that blocks the satellite direct line of site from the point of observation. GPS signals are very weak. They can be blocked from reaching the GPS antenna by objects between the antenna and the satellites. Classic examples of obstructions are trees and buildings. GSR2600...
  • Page 109 Pseudolite - An Earth-based transmitter designed to mimic a satellite. May be used to transmit differential corrections. Pseudorange - The calculated range from the GPS receiver to the satellite determined by taking the difference between the measured satellite transmit time and the receiver time of GSR2600...
  • Page 110 Root-Mean-Square (RMS) - A statistical measure of the scatter of computed positions about a "best fit" position solution. RMS can be applied to any random variable. Rover - The GPS receiver that moves from site to site during a kinematics GPS survey. GSR2600...
  • Page 111 Standard Positioning Service (SPS) - A positioning service made available by the United States Department of Defense which will be available to all GPS civilian users on a continuous, worldwide basis (typically using C/A Code). GSR2600...
  • Page 112 Earth in a local region. GPS uses the center of the WGS84 ellipsoid as the center of the GPS ECEF reference frame. GSR2600...

  • Page 113: Index

    Office 7 Storage requirements 87 Cables Data collection method Antenna 27 Handheld 82 Communications 23 Manual 80 General 27 Scheduled 81 Power 25 DC power supply 25 Camcorder power cable 25 Differential corrections 58 COM port default settings 23 GSR2600...
  • Page 114 PC data cable 24 Display 42 PDL radio cables 24 Front panel 37 Ports Menu functions 37 Communications 23 Logging capacity 87 GPS 26 Power 25 Power Button 33 Manual data collection 80 Cables 25 Memory status 51 Consumption 30 GSR2600...
  • Page 115 Lat 53 Lon 54 Lon Std 54 Name 74 Number 74 Occupy 47 RTKReset 70 Run Cfg 60 Sat 56 Sched 61 Schedule 62 Size 66 Sleep 70 Space 51 Stop Cfg 60 SW Ver 72 System 49 Vel 55 GSR2600...
  • Page 116 Contents SDR data cables 24 Setup Field 8 Office 7 SK-600 Antenna 15 Sleep 28 Subsidiaries 4 Support, customer 4 System status Audio messages 35 Screen messages 49 Storage limits 51 Technical assistance 4 Usage cautions 6 GSR2600...
  • Page 118 SOKKIA PTY. LTD. Rydalmere Metro Centre, Unit 29, 38-46 South St., Rydalmere, NSW 2116 Australia Phone +61 2 9638 2400 Fax +61-2-9638-3933 Web http://www.sokkia.com.au SOKKIA B.V. Businesspark De Vaart, Damsluisweg 1, 1332 EA Almere, P.O. Box 1292, 1300 BG Almere, The Netherlands Phone +31-36-53.22.880 Fax +31-36-53.26.241 Web http://www.sokkia.nl...
