User Manual DCT08D00893BE
Industrial Monitor
8" Color LCD
Code No.: CL0883BR
Part Number: DCT08D00893BE
REV: A0
0600883705

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCT08D00893BE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Canvys DCT08D00893BE

Summary of Contents for Canvys DCT08D00893BE

  • Page 1 User Manual DCT08D00893BE Industrial Monitor 8” Color LCD Code No.: CL0883BR Part Number: DCT08D00893BE REV: A0 0600883705...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SAFETY SYMBOLS & PRECAUTIONS ............3 1.1. Safety Symbols ................3 1.2. Pprecautions.................. 3 2. INTRODUCTION ..................6 2.1. Features ..................6 2.2. Package Contents ................6 3. CABLE CONNECTION ................7 3.1. Before Connecting ................. 7 3.2.

  • Page 3: Safety Symbols & Precautions

    1. SAFETY SYMBOLS & PRECAUTIONS 1.1. Safety Symbols This manual uses the safety symbols below. They denote critical information. Please read them carefully. WARNING Failure to abide by the information in a WARNING may result in serious injury and can be life threatening. CAUTION Failure to abide by the information in a CAUTION may result in moderate injury and/or property or product damage.
  • Page 4 To avoid danger of suffocation, keep the plastic packing bags away from babies and children. Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock.
  • Page 5 CAUTION Handle with care when carrying the unit. Disconnect the power cord and signal cables and remove the optional unit. Moving the unit with the cord or the option attached is dangerous. It may result in injury. When handling the unit, grip the bottom of the unit firmly with both hands ensuring the panel faces outward before lifting.

  • Page 6: Introduction

    2. INTRODUCTION Thank you very much for choosing this monitor. 2.1. Features - VGA analog input - DVI digital input compliant - Resolutions up to 800×600 - Power management system conforms to VESA DPMS standard. - Supports DDC1/2B for Plug & Play compatibility. - Advanced On Screen Display (OSD) control for picture quality adjustment 2.2.

  • Page 7: Cable Connection

    3. CABLE CONNECTION 3.1. Before Connecting Before connecting your monitor to the computer, change the display screen settings (Resolution and frequency) in accordance with the charts below. Note: - The lower display modes like 640x 480, automatically enlarge to the maximum display mode (800x600), and some lines of the characters may become fuzzy.

  • Page 8: Installing The Driver Software

    Signal Cable Connector of Computer D-sub Signal Cable D-Sub 15pin 3. Connect end of the touchscreen USB cable to the rear side of the computer and the other end to the monitor. Plug the power cord into the power connector on the rear of the monitor. Then, plug the other end of the cord into a power outlet.

  • Page 9: Adjustment

    If Windows 98, Windows Me or Windows 2000 does not start the Add New Hardware Wizard. NOTE: For Windows 2000 you must have administrator access rights to install the driver. 1. Put the CD into CD_ROM. 2. Choose the icon of TOUCHSCREEN driver. 3.

  • Page 10: Osd Menu Adjustments And Settings

    3. Exiting the OSD MENU - To return to the main menu, select the <Return> icon and press the MENU button. - To exit the OSD menu, select <Exit> icon . 5.2 OSD MENU Adjustments and Settings The following table shows all adjustment and setting menus. Main Menu Sub Menu Reference...
  • Page 11 2. Adjust by using <Image Setting> menu in the OSD Menu. (1) Vertical bars appear on the screen → Use the <Clock> adjustment. Select the <Clock> and eliminate the vertical bars by using the UP and Down of the Control buttons.

  • Page 12: Troubleshooting

    6. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact a dealer. Problems Points to check with Possible Solutions 1. No picture Check that the power cord is correctly connected. If the Indicator status: Off problem persists, turn off the monitor power for a few minutes, then turn it back on and try again.

  • Page 13: Cleaning

    7. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. Note: Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel.

  • Page 14: Specification

    8. SPECIFICATION 8.1 Touchmonitor Specification Display characteristics Size: 8.4″ active display Native resolution: 800 x600 Pixel pitch: 0.213 mm Viewing angle: 120°(H)/100°(V) Brightness: 250 cd/m2 Typ. Contrast ratio: 400:1Typ. Response time: 30 ms Typ. External connections DVI Signal DVI-D Analog Video Input: 15 pin D-sub Touchscreen Interface: 8.2 D-Sub 15pin Connector...

  • Page 15: Guarantee Exclusion

    - burn-in on the LCD panel caused by permanent display and spots forming on the LCD panel 10.Vendor: Europe: Headquarter (North America): Canvys Canvys A Division of Richardson Electronics GmbH A Division of Richardson Electronics GmbH Raiffeisenstraße 5 40W267 Keslinger Road...
