PRIMARY UNDER-HOOD FUSE BOX
Table Of Contents
No. Amps.
120 A
1
−
2 1
− −
2 2
− −
30 A
2 3
−
2 4 40 A
−
40 A
2 5
−
2 6 40 A
−
2 7 40 A
−
2 8
− −
3 1 60 A
−
3 2 40 A
−
3 3 60 A
−
50 A
3 4
−
: Canadian model
＊
Circuits Protected
Main fuse
Not Used
Not Used
Not Used
Rear Blower Motor
ABS VSA
Trailer Main
Power Seats, Driver's
Position Memory System,
Subwoofer
Front Heated Seat, TPMS,
Moonroof, Driver's Lumber
Support
Not Used
Fog Lights, Front Blower
Motor
Headlights, Daytime
Running Lights
Cooling Fan, Condenser Fan,
MG Clutch, Headlight
Washer
＊
Ignition Switch Main

Fuse Locations

No. Amps. Circuits Protected
50 A Power Window
3 5
−
3 6 60 A SH-AWD , Power Tailgate
®
−
Open/Closer, Rear ACC
Socket, Cargo Area Light,
Rear Defroster
3 7 30 A ECU (PCM)
−
3 8 Not Used
− −
4 40 A Audio, Door Lock, Interior
Lights
5 Not Used
−
6 Not Used
−
7 30 A Active Damper Control Unit
8 30 A Audio Amplifier
7.5 A Rear Entertainment System
9
10 15 A Hazard
15 A Horn, Stop
11
12 20 A ABS VSA
20 A Trailer (Brake)
13
14 20 A Rear Heated Seat
20 A A/C Inverter
15
