Summary of Contents for Monoprice 612790
-
Page 2: Safety Warnings And Guidelines
If you have any problem with your order, please give us an opportunity to make it right. You can contact a Monoprice Customer Service representative through the Live Chat link on our website www.monoprice.com during normal business hours (Mon-Fri: 5am-7pm PT, Sat-Sun:... -
Page 3: Package Contents
PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. 1x Outdoor rated PAR stage light 1x User's manual... -
Page 4: Menu Modes
MENU MODES Menu Display Value Range Function 001 ~ 256 DMX channel selection Hot or SLu Hot or SLu Host (Master) or Slave mode □ 01 ~ 32 The total number of follow mode devices* ‑ 01 ~ 32 Follow mode ID** 00 ~ 8 Strobe follow mode color selections E.01... - Page 5 STROBE FOLLOW MODE EXAMPLE □ ‑ As an example of setting the values, let's assume that you have four lights that □ ‑ you want to strobe in sequence. Set the lights to use the following values: □ ‑ Light # Value Value □...
-
Page 6: Dmx Control
DMX CONTROL Channel DMX Values Control Function 000 ~ 255 General dimming (0 ~ 100%) 000 ~ 255 Red dimming (0 ~ 100%) 000 ~ 255 Green dimming (0 ~ 100%) 000 ~ 255 Blue dimming (0 ~ 100%) 000 ~ 255 White dimming (0 ~ 100%) No strobe 001 ~ 255... - Page 7 Note: The last device in any DMX chain must be terminated using a DMX Terminator. You can purchase a DMX terminator (PID 601600) from Monoprice or you can make a DMX terminator using a standard XLR male plug (PID 601651) by soldering a 120 ohm (1/4 watt) resistor between pins 2 and 3.
-
Page 8: Troubleshooting
Check to ensure the light is in DMX mode (001 ~ 255). Check to ensure the DMX controller is operating properly. If you experience other problems with this light and cannot solve them on your own, please contact Monoprice Technical Support for assistance. -
Page 9: Technical Support
TECHNICAL SUPPORT Monoprice is pleased to provide free, live, online technical support to assist you with any questions you may have about installation, setup, troubleshooting or product recommendations. If you ever need assistance with your new product, please come online to talk to one of our friendly and knowledgeable Tech Support Associates. -
Page 10: Regulatory Compliance
Modifying the equipment without Monoprice’s authorization may result in the equipment no longer complying with FCC requirements for Class A digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense.
