Notice for Use
Thank for choosing iSmoka products! Please read this manual carefully before use
to ensure that your usage is correct. If you require additional information or have
questions about the product or its use, please consult your local iSmoka agent, or
visit our website at www.ismoka.com.
Product Introduction
With all the parts detachable, Magoo has been added more flexible features,
whose liquid volume and air inflow are adjustable. Seeing from the individual
window of liquid level, the liquid volume is more intuitive. What's more,
customers can choose pluggable mouthpieces according to their own favors.
From this product, people can also enjoy the fun of DIY, as customers can
replace the heating coil (single and dual) and entire atomizer head by
themselves. In addition, the scalable positive pole contact can better adapt and
protect the battery contacts.
Product Parameter
Length: 71.7mm
Diameter: 23mm
Components
1* Mouthpiece Cover
1* Tube Cover
1* Mouthpiece
1* Metal Tube
1* Clear Tube
1* Atomizer Head (Part A, Part B)
1* Atomizer Base
Atomizer Base
How to assemble
Firstly, screw the atomizer head onto the atomizer base; secondly, screw the
mouthpiece to the atomizer head; thirdly, screw on the atomizer tube, then the tube
cover; at last, the mouthpiece cover.
1
Atomizer Base
How to replace the heating coil
Single heating coil: first, wrap the heating coil on the middle of the delivery
string for several laps with both ends left enough length to reach the bottom of
the atomizer head A. Then wrap the ends on the atomizer head part A,
separately nipped by the plastic ring and the silicon ring, which are the positive
and negative conversion. Finally, put the delivery string into the matching slots
and screw the atomizer part B on.
Delivery String
Heating Filament
Part A
Part B
Atomizer Head
Metal Tube
2
Atomizer Head
23mm
Clear Tube
Mouthpiece
Mouthpiece
Metal Tube
Heating Filament
Plastic Ring
Magoo
User Manual
71.7mm
Mouthpiece Cover
Tube Cover
3
4
Tube Cover
Clear Tube
Mouthpiece Cover
Delivery String
Heating Filament
5
Silicon Ring
