- Page 1 0-4-0 Dockside Freight Set 0-4-0 Dockside Freight Set Operation Manual Thank you for purchasing this RailKing product. PLEASE READ BEFORE USE AND SAVE...
-
Page 2: Table Of Contents
Unplug the transformer from the electrical wall outlet when not in use. Do not use this transformer for other than its intended purpose. Transformer Ratings: Input: 120 VAC 60 Hz Only Output: 18VAC, 3A 54VA RailKing 0-4-0 Dockside Freight Set... -
Page 3: Set Up Checklist
Cotton Swab or Rag Light Household Oil and Bearing Grease You can obtain replacement parts and replacement instructions from the M.T.H. Parts Department e-mail: parts@mth-railking.com phone: 410-381-2580 mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532 RailKing 0-4-0 Dockside Freight Set... -
Page 4: Getting Started
Also functions as a binding post. Red Harness Wire/Plug Black Harness Red Harness Black Harness Wire/Plug Wire/Plug Wire/Plug RailKing 0-4-0 Dockside Freight Set... -
Page 5: Lubricating The Engine
Coupling the Engine and Cars STEP STEP STEP Incorrect Place the engine and cars Push cars together Position on the track. to couple. Open couplers by pressing down on plunger. Position armiture for proper operation RailKing 0-4-0 Dockside Freight Set... -
Page 6: Basic Operation
OFF position. The engine will not change direction (including going into neutral) until you flip the switch back to ON to return the engine to its normal condition, even if the engine is kept without power for extended periods of time. RailKing 0-4-0 Dockside Freight Set... -
Page 7: Maintenance
M.T.H. Maintenance Kit. STEP Open the gear box. Unscrew the three Reassemble in reverse order. screws on the plate located in front of the motor and lift the motor. RailKing 0-4-0 Dockside Freight Set... -
Page 8: Cleaning The Wheels, Tires And Track
10-15 drops of smoke fluid or turn the smoke unit off. When storing the unit for long periods of time, you may want to add about 15 drops of fluid to prevent the wick from drying out. RailKing 0-4-0 Dockside Freight Set... -
Page 9: Locomotive Light Bulb Replacement
Lower the chassis from the shell, taking care not to pull the wires out. STEP Replace a Bayonet Bulb by turning and pulling up, pulling the bulb from its socket. Bayonet Bulb (Part #CI-0000015) RailKing 0-4-0 Dockside Freight Set... -
Page 10: Railware Interactive Cd Rom
*If you are running Windows 95, 98 or NT choose the folder 32 BIT. Run the file AR32E301.EXE and follow the directions it provides. If you have problems you cannot resolve by using these directions, contact custserv@mth- railking.com or call 410-381-2580 for further help. RailKing 0-4-0 Dockside Freight Set... -
Page 11: Troubleshooting
I can't get the engine to run after I The engine may be locked into the neutral power up the transformer. position. Follow the procedure in the “Lock into a Direction” section on page 6 to unlock the engine’s direction. RailKing 0-4-0 Dockside Freight Set... -
Page 12: Compatibility
Gauge track system, including the RealTrax included with this set or traditional tubular track. It is also compatible with most standard AC transformers, including the hobby transformer packaged with your set Transformer Compatibility and Wiring Chart RailKing 0-4-0 Dockside Freight Set... -
Page 13: Exploded View Parts
20.) Motor mount ( black ) BI-0000034 21.) Screw ( yellow Zink ) IA-0000089 ( M2.5x6.0mm )( roundhead w/ lock washer ) 22.) Screw IA-0000058 ( M2x4.0mm )( roundhead ) 23.) Switch ( small ) BB-0000009 RailKing 0-4-0 Dockside Freight Set... - Page 14 ( pick-up )( bottom )( flat )( square ) 41.) Pick-up BD-0000048 ( 8.0x11.0mm roller )( 28.0mm long ) 42.) Pick-up BD-0000050 ( 8.0x11.0mm roller )( 24.0mm long ) 43.) Bracket ( black )( metal ) IH-0000209 (14.0x42.7x0.5mm)(2.0x21.0mm notch on one side) RailKing 0-4-0 Dockside Freight Set...
- Page 15 Dockside 0-4-0 Engine Parts RailKing 0-4-0 Dockside Freight Set...
-
Page 16: Service And Warranty Information
Service & Warranty Information How to Get Service Under the Terms of the Limited One-Year Warranty For warranty repair, follow the instructions below to obtain warranty service. First, e-mail, write, call or fax an Authorized M.T.H. Service Center in your area or M.T .H. Electric Trains to obtain Repair Authorization. -
