Summary of Contents for inDESIGN BM8 Series
-
Page 2: Front Panel
CONTENTS INTRODUCTION INTRODUCTION The inDESIGN BM 8 is a high quality mixer for commercial and industrial audio applications. IMPORTANT SAFETY The BM 8 features 8 Mic/line inputs plus 2 stereo inputs. INSTRUCTIONS Microphone input 1 features a mute so that a Microphone... - Page 3 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. To prevent injury please refer to these instructions for electrical and safety information before installing or operating the apparatus. 6. This apparatus must not be exposed to dripping or splashing liquid. No object filled with liquid, such as a vase, should be placed on the apparatus.
- Page 4 FRONT PANEL 1. Power Switch: Turns mains power on and off. The round LED light surrounding the Master Volume control indicates the unit is on/off. 2. Level Indicator: To set for optimum working level normal signal should be kept under the 0dB. The red +3dB will illuminate when signal is excessive.
- Page 5 REAR PANEL 7. Mains Socket: The unit is connected to the mains circuit with a standard IEC type power lead. This socket contains a rated slow blow fuse. **NOTE: Only use a fuse equal to the marked rating 8. Tone Generator Connections: There are four alarm triggers; CHIME; ALERT; BELL; EVAC. These are connected via the rear panel Phoenix connector.
- Page 7 SPECIFICATIONS SPECIFICATION Mic Inputs Connectors (Mic/Line) Euro Block / RCA Impedance (Mic/Line) 1kΩ / 13.6kΩ Gain (Mic/Line) 20dB to 50dB / 0dB to 20dB Max Input Level (Mic/Line) -28dBu / +10dBu Frequency Response 20Hz – 20kHz -86dBu THD+N 0.3% (20Hz – 20kHz, +4dBu) Phantom Power Tone Frequency/Control Range 100Hz / 10kHz...
