Citizen AV3 Series Instruction Manual
  1. Manuals
  2. Brands
  3. Citizen Manuals
  4. Watch
  5. AV3 Series
  6. Instruction manual
Citizen AV3 Series Instruction Manual

Citizen AV3 Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV3 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Citizen AV3 Series

Summary of Contents for Citizen AV3 Series

  • Page 3: Table Of Contents

    Table of contents Thank you for your purchase of this Citizen watch. Before using the watch, read this instruction manual carefully to ensure correct use. Component identification ..Troubleshooting ....

  • Page 4: Component Identification

    Comoponent identification Upper left button Upper right ( C ) button ( B ) Crown Lower right button ( A )
  • Page 5 1 Chronograph second hand 6 Moon phase indicator 2 Hour hand 7 Minute hand 3 Chronograph hour hand 8 Chronograph minute hand 4 Second hand 9 Date indication 5 24 hour hand p Tachymeter The illustrations in this instruction manual may differ from the actual appearance of your watch.
  • Page 6 How to read the moon phase indicator The moon phase shows us the number of days since a new moon. This indication is shown between “0” and “29.5” (the number of days it takes for the moon to complete its cycle). The moon phase indication on this watch should be used as an approximate representation only.
  • Page 7 How to use the screw down crown and screw down push button Some models feature a screw down crown and/or screw down push button. Locking the crown and/or button prevents accidental operation. These must be unlocked prior to using certain features of your watch such as setting the time or date. Unlock Lock Push the crown in to...

  • Page 8: Adjusting The Time

    Adjusting the time Pull the crown out to position 2 when the Crown position second hand indicates “0.” 0 1 2 Adjust the time by rotating the crown. • The 24-hour, hour and date movement are linked with Crown the minute hand. The date advances only and does not move in a backwards fashion.

  • Page 9: Adjusting The Date

    Adjusting the date Pull the crown out to position 1. Crown position Adjust the date by rotating the crown 0 1 2 counterclockwise. • The date will advance only. If you pass the desired date, Crown continue to rotate the crown until the desired date is shown again.

  • Page 10: Adjusting The Moon Phase

    Adjusting the moon phase The moon phase is shown between “0” and “29.5. ” • Before commencing, be sure to check the current moon phase (days since a new moon) through your local newspaper, internet, or other source. Ensure that the crown is in position 0. Crown position 0 1 2 Adjust the moon phase indicator by pressing...
  • Page 11 • The moon phase indicator operates independently of other hands and/or features of this watch. • The moon phase indicator will not align perfectly with the “guide mark. ” See page • To confirm and/or correct the reference (0) position of the moon phase indicator, please refer to pages of this instruction.
  • Page 12 Notes on the moon phase Approximate guide mark Days of the moon 29.5 phase New moon First Full moon Second New moon quarter quarter (7.5) (22.5)
  • Page 13 • The moon phase indication on this watch should be used as an approximate representation only. It is not intended to provide an exact depiction of the moon as it appears in the sky.

  • Page 14: Adjusting The Reference (0) Position Of The Moon Phase Indicator

    Adjusting the reference (0) position of the moon phase indicator Adjust the reference (0) position of the moon phase indicator. • Be sure to reset the chronograph to “0” as shown on page 15 of this instruction prior adjusting the reference (0) position of the moon phase indicator. Pull the crown out to position 2.
  • Page 15 Adjust the moon phase indicator to the correct reference (0) position by pressing and releasing the upper left button ( C ). • Each time you press and release the upper left button ( C ), the moon phase indicator advances the Correct reference (0) equivalent of approximately 7 hours.

  • Page 16: Using The Chronograph

    Using the chronograph • Ensure that the crown is in position 0. Press and release the upper right button ( B ) to start timing. • The button clicks. Press and release the upper right button ( B ) to stop timing. •...
  • Page 17 To reset the chronograph Pressing and releasing the lower right button ( A ) after stopping the chronograph by pressing and releasing the upper right button ( B ). • You must reset the chronograph after timing for using other functions.

  • Page 18: Using The Tachymeter

    Using the tachymeter The tachymeter easily brings you the average speed by recording a lap time to go one kilometer. • You can measure the approximate average speed from 60 km/h up to 400 km/h. • The illustrations in this instruction manual may differ from the actual appearance of your watch.
  • Page 19 Upper right button ( B ) Lower right button ( A ) Tachymeter...
  • Page 20 To measure an average speed Read the value on the tachymeter after recording a lap time. • Ensure that the crown is in position 0. Press and release the upper right button ( B ) to start timing. The chronograph second hand starts timing. Stop timing at the point one kilometer away from the starting point by pressing and releasing the upper right button ( B ).

  • Page 21: Recharging Your Watch

    Recharging your watch This watch has a rechargeable cell which is charged by exposing the dial to light such as direct sunlight or fluorescent lamps. For optimal performance: • Expose the watch with the dial towards direct sunlight for several hours at least once a month.
  • Page 22 When the watch reaches a low charge state—insufficient charge warning function When the power reserve becomes low, the second hand moves once every two seconds—This is the insufficient charge warning function. Charge the watch by exposing the dial to light. •...
  • Page 23 Charging time by environment Below are the approximate times needed for charging when exposing the watch dial to light continuously. Please use this table as a reference only. Charging time to start Illuminance (Lx) Charging time to work for Environment working normally when the one day rechargeable cell is empty...

  • Page 24: Troubleshooting

    Troubleshooting If you have a problem with your watch, check the table below. Symptoms Remedies Page The hands do not work properly. The second hand moves This indicates a low charge state. Fully charge your watch. once every two seconds. Push the crown in to position 0.
  • Page 25 Charge the watch by exposing it to direct sunlight The watch does not for five or six hours. function, even after fully Though the trouble is not solved after charging, contact your nearest Authorized Citizen Service charging and setting. Center.
  • Page 26 Resetting the watch The watch may not work properly if it is affected by static electricity or shock. • Be sure to charge the watch fully before resetting. Crown position • Reset the chronograph before resetting the watch. See page 15. •...
  • Page 27 Pull the crown out to position 2. Press and hold the upper left button ( C ) and the lower right button ( A ) simultaneously. The moon phase indicator moves slightly indicating the watch has been reset. Be sure to adjust the reference (0) position if needed as shown on pages 12 and 13. Adjust the reference (0) position of the moon phase indicator correctly.

  • Page 28: Precautions

    Precautions Warnings Handling the rechargeable cell • Do not remove the rechargeable cell. If it is removed, keep the rechargeable cell out of the reach of children to prevent ingestion. • If the rechargeable cell is swallowed, consult a doctor and seek medical treatment.
  • Page 29 Cautions About charging • Excessively high temperature when charging the watch may cause discoloration and deformation of the components, and result in malfunction of the movement. • Do not charge the watch at a high temperature (about 50˚C/122˚F or higher). Example: –...
  • Page 30 To avoid injury • DO NOT wear the watch where the temperature becomes extremely high—such as in a sauna. The watch may become hot and burn the skin. To avoid malfunction • DO NOT use the watch where the temperature is lower or higher than the operating temperature specified in this manual.
  • Page 31 • DO NOT apply any strong shock, for example, by dropping it onto a hard floor. • Avoid using the watch where it may be exposed to chemicals or corrosive gases. If solvents, such as thinners or benzine, or substances containing such solvents come in contact with the watch, discoloration, melting, cracking, etc.
  • Page 32 Warnings on water-resistance performance • Water-resistance for daily use: This type of watch is resistant to minor exposure to water such as accidental splashing. For example, you may wear the watch while washing your face; however, it is not designed to be used underwater. •...
  • Page 33 Examples of use Minor Moderate Marine exposure exposure to sports (skin to water water (washing, diving) (washing face, kitchen work, rain, etc.) swimming, Indication Names Specifications etc.) (Case or back) WATER WATER Water resistant RESIST(ANT) or RESIST(ANT) for daily use no indication WR 50 or WATER...
  • Page 34 • If water has penetrated the watch, or if the inside of the glass is fogged up and does not become clear in a day, take the watch to your dealer or Citizen Service Center for repair. Leaving the watch in such a state will rust the internal parts and cause malfunction.
  • Page 35 Keep your watch clean • Keep your watch clean to prevent rust or dirt building up as this may stain your clothes, damage the watch or appear as black residue on your wrist. Depending on use, occasional cleaning of the exterior of your watch may be necessary.

  • Page 36: Maintenance

    Your watch needs an inspection once every two or three years for safety and longer usage. To keep your watch water-resistant, the gaskets and other components need to be replaced regularly. Other parts need to be inspected and replaced if necessary. Always ask for genuine Citizen parts upon replacement.

  • Page 37: Information

    Information Luminous dials and hands The paint on the dial and hands helps you with reading the time in a dark place. The luminous paint stores light (daylight or artificial light) and glows in a dark place. It is free from any radioactive substance or any other material harmful to a human body or environment.

  • Page 38: Specifications

    Specifications Movement caliber E27* Type Analog solar-powered watch number Within ±15 seconds per month when worn at normal operation Timekeeping temperatures (+5˚C/41˚F and +35˚C/95˚F) accuracy −10˚C/14˚F to +60˚C/140˚F Operating temperature range Time: Hours, minutes, seconds, 24-hours Display functions Calendar: Date (not perpetual) Moon phase •...
  • Page 39 • Solar power function Additional • Overcharging prevention function functions • Insufficient charge warning function (two-second interval movement) • Chronograph (up to 12-hours in 0.2 second increments) • Checking/correcting reference (0) position Specifications are subject to change without prior notice.
