- Page 1 GETTING STARTED GUIDE SXPro GPS SXPro GNSS SXPro RTK...
- Page 2 SXPro Series Quick Start Guide 1. Appearance External antenna GPS Antenna connector Earpiece Camera Lock Screw Touch panel Battery Function Keys Camera Key Power Key DATA port Reset Microphone Back Front 2. Operating Instructions • Charging Battery charger: Insert the Li-ion battery into the battery charger to charge. b) DC adapter + charging cable: a charging cable for connection between device and DC adapter.
-
Page 3: Installing And Removing The Battery
Counter clockwise rotation Turning lock Installing and removing the battery • Turning the collector on/off Make sure the battery has enough power, or connect the receiver to your PC with a USB cable. b) Press power button for 3～5 seconds to turn on (until the boot screen appears)/ turn off. Note: if the receiver is down, press the reset button in the bottom of the receiver to reset it. - Page 4 GNSSViewer Quick Start • a) Copy GNSSViewer into SXPro. b) Run it, and select the GNSS board, GPSPORT, BaudRate as the picture below. c) Click OK.
- Page 5 d) Click ‘Setup’-> Ntrip Client e) Click Setup. f) Setup parameters of IP, Port, Account and password as following picture. Click ‘OK’ indicated by the red circle. Notes: please use the local parameters.
- Page 6 g) Select ‘Update Source Table’ and click start. h) Select proper mount point and click ‘Start’ again. i) Click ‘Return’ to the main interface.
- Page 7 • Camera Select ‘Start->Picture & Video’，select ‘Camera’ or camera icon to take photos. b) Press camera key to take photos. Click screen and select ‘OK’ to exit. • User Serial Port User serial port is COM1. Transfer data between SXPRO and other devices by a specialized cable named DB9 9PIN Fischer Cable.
- Page 8 • Auto power off (*actually backlight off, the device does not support auto power off *) Select ‘Start-> Settings-> System-> Power-> Advanced’, set the power off time in different conditions. Backlight will be off according to the settings • Remove programs Select ‘Start->...
-
Page 9: Usb Data Cables
WiFi safety Turn WiFi off in areas where WiFi use is prohibited or when it may cause interference or danger, such as in airplanes while flying. Care and maintenance SXPro is an electronic product and should be treated with care, to reduce the risk of fire, electronic shock, or product damage take the following precautions: •...
