Summary of Contents for Dixon Automatic Tool SKD-BN7030L
- Page 1 OPERATION AND MAINTENANCE MANUAL SKD-BN7030L SKD-BN7030P DC-TYPE Non-Carbon-Brush Electric Screwdrivers DIXON AUTOMATIC TOOL, INC. www.dixonlighttools.com DIXON AUTOMATIC TOOL, INC. - 2300 23 AVENUE - ROCKFORD, IL 61104 PHONE (815) 226-3000 FAX (815) 226-0180 EMAIL: CUSTSERV@DIXONAUTOMATIC.COM...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. -
Page 4: Do Not Operate This Tool Without Protective Earth Connected
4) Power tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use power tool if switch does not turn it on or off. -
Page 5: Grounding Instructions
Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. The Green (or Green and Yellow)conductor in the Power Cord is the grounding wire. -
Page 6: Description Of Operation
CAUTION ● Do not drop or abuse the tool. ● Whenever a tool is not being used, position the Power Switch to the “OFF” position and unplug the power cord. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by fingertip, and it will be unlocked. -
Page 7: Do Not Attempt To Repair This Electric Screw Driver
CAUTION 1. The use of other than genuine KILEWS replacement parts may Result in decreased tool performance and increased maintenance, and may invalidate all warranties. 2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3. -
Page 8: Specifications
Specifications MODEL SKD-BN7030L SKD-BN7030P Input voltage(DC) Input voltage(DC) Power Consumption (kgf.cm) 10-30 10-30 Torque (Lbf.in) 8.67-26.02 8.67-26.02 (N.m) 0.98-2.94 0.98-2.94 Repeatable Torque Accuracy (%) Repeatable Torque Accuracy (%) Torque Adjustment Torque Adjustment 1200 1200 Unloaded Rotation Speed (R.p.m) )±10% Machine 2.6~4.0... -
Page 9: Torque Adjustment Operation
Torque Adjustment Operation To adjust the torque on these screwdrivers, proceed as follows: 1. Determine the torque output of the tool by checking a tightened Fastener with a torque wrench. 2. Increase or decrease the torque by rotating the Spring Adjusting Ring. Rotating the Ring clockwise to a higher number on the torque Scale increase torque output while rotating the Ring counterclockwise to a lower number decreases the torque output.
