Automatic Industrial Cordless Brushless
Power Torque Screwdrivers Series
OPERATION AND MAINTENANCE MANUAL
SKC-PTA-B120
SKC-PTA-B90
SKC-PTA-B50F
CAUTION!!
SKC-PTA-B120/B90 SERIES IS ADVANCEMENT IN HIGH TORQUE MOTORS DESIGN.
TO BE MORE SAFTY, ASSEMBLE THE AUXILIARY HANDLE BEFORE OPERATION.
DIXON AUTOMATIC TOOL, INC.
www.dixonlighttools.com
SKC-PTA-B60
SKC-PTA-B35
SKC-PTA-B35F
Y2F111A-E-004
Advertisement
Table of Contents
Related Manuals for Dixon Automatic Tool SKC-PTA-B60
Summary of Contents for Dixon Automatic Tool SKC-PTA-B60
- Page 1 Power Torque Screwdrivers Series OPERATION AND MAINTENANCE MANUAL SKC-PTA-B60 SKC-PTA-B35 SKC-PTA-B35F SKC-PTA-B120 SKC-PTA-B90 SKC-PTA-B50F CAUTION!! SKC-PTA-B120/B90 SERIES IS ADVANCEMENT IN HIGH TORQUE MOTORS DESIGN. TO BE MORE SAFTY, ASSEMBLE THE AUXILIARY HANDLE BEFORE OPERATION. DIXON AUTOMATIC TOOL, INC. www.dixonlighttools.com Y2F111A-E-004...
-
Page 2: Icon Instructions
Before you use the Cordless Screwdriver for the first time, it is essential to read and understand the manual completely (including the spare parts view). The term “Cordless Screwdriver” in all of the warning listed below refers to your main operated appliance. Icon Instructions 1.Read instruction manual. - Page 3 Warning Read all instructions and make sure the appearance of the device has no damage before you use it. Failure to follow all instructions listed below may result in electric shock fire and/or serious injury. 1. Keep the working area nice and clean. 1.1 Mess and dark areas may cause of accidents.
-
Page 4: Function Of Cordless Protection
16. To prevent parts in gearbox from damage, replace the grease at least once for every year. 17. It is necessary for the operators to read and follow up all the operating instructions in this manual. KILEWS is not responsible for any personal injury that might cause of disobeying the safety advices. -
Page 5: Insert Battery Steps
2.1 Below illustration is showing the process of correct install & disassemble the rechargeable battery. The beep sound comes along with a flash while the screwdriver is supplied genuine battery installation. It could be operated once the battery has been identified. 2.2 Too slow to install the battery may cause error identification so the beep sound and flash would be continuing. -
Page 6: Function / Operating Introduction
Function / Operating Introduction (10) (11) Function Name Table Description Description Trigger Switch S waist hook Forward/Reverse Lever Indication light LED Light Torque Adjustment Ring Bit Sleeve (10) Speed adjustment Torque Fixing Ring (11) Wrist strap hole Driver Hook Hole... -
Page 7: Manual / Function
Manual / Function 1. Full auto shut-off screwdriver: It stops automatically when the screw has been tightened up and reached the set-up torque level. The device will not cause damage of task since no continue running after screws are tightened. (1) Trigger switch: The LED lights on when the trigger switch has been pressed about one-third down, and then the screwdriver starts functioning when the switch trigger has been pressed half way down;... - Page 8 (5) Torque Fixing Ring/Coupler: 1).Torque Fixing Ring: To prevent torque to be adjusted, fixed upside-underside housing and clutch. 2).Coupler: Fixed upside-underside housing and clutch. Torque Fixing Ring COUPLER (6) Driver Hook: It is convenient that the production lines are able to have spring balancers work together with the tools to be more efficiently.
-
Page 9: Other Cautions
(10) Hi/Lo Switch: When the rotating speed needs to be changed, set up the switch to Hi for the fastest rotation, and set up the switch to Lo for slowest rotation. It's possible that the uncompleted shut-off occurs when the switch is setup to Lo and the presetting torque is more than 50% of torque range. Please refer to the following table. -
Page 10: Description Of Battery And Charger
13. SKC-PTA-B60/35/35F are tested by our torque meter KTM-CSH. 14. Kilews cordless screwdriver torque output is generated by clutch machnisam, and it is applicable to ISO 6789. -
Page 11: Specifications
Specifications MODEL PTA-B120 PTA-B90 PTA-B50F PTA-B60 PTA-B35 PTA-B35F INPUT VOLTAGE(DC) DC 18V TORQUE (N.m) 6~12 1~3.5 1~3.5 Torque accuracy (%) Torque accuracy (%) Torque adjustment Torque adjustment 1000 2200 1000 1000 2000 Unloaded Speed n0 (r/min)±10% 1400 1300 Machine ≤6 Screw size (mm) 5.0~6.0 4.0~5.0...
