Summary of Contents for Milnor KLWRACLR01
- Page 3 MTA pins, an empty four pin MTA connector and mounting hardware for the accelerometer and balance board. Technicians installing this kit must be able to read Milnor wiring diagrams, thread a harness through conduit, and make electrical connections.
- Page 4 Figure 1: Mounting Accelerometer, 36030F8 Figure 3: Positioning Balance Board Prior to Installation Figure 2: Accelerometer Mounted On Bracket, 36030F8 Figure 4: Terminal TBA...
- Page 5 Figure 5: Processor Board Electrical Box Processor board 3. Remove side panels on side opposite soil side door. 4. Position the accelerometer mounting bracket inside of the shell front on the side opposite the soil side door as shown in Figure 1. Make sure bracket is level. 5.
- Page 6 a. Plug MTA 82 into the MTA 82 connector on the balance board, remove the wire tray covers, then connect the four individual wires from the connector to the TBA terminal strip as follows: • Connect the blue/white wire from MTA 82 - pin 4 to TBA #7 (ground). •...
- Page 7 33. Verify that voltage is 2.5 VDC. Adjust voltage by turning the screw at the back of the accelerometer. — End of BIIFSP01 —...
