- Page 1 Published Manual Number/ECN: H000000044/2000493N • Publishing System: TPAS • Access date: 1/30/01 • Document ECN's: Latest Available Kit Instruction— KWACSD001R PELLERIN MILNOR CORPORATION POST OFFICE BOX 400, KENNER, LOUISIANA 70063-0400, U.S.A.
-
Page 2: Please Read
“Troubleshooting” chapter or section. See the table of contents. Trademarks of Pellerin Milnor Corporation The following, some of which may be used in this manual, are trademarks of Pellerin Milnor Corporation: ®... - Page 5 W hat To Do First, If the Sprinkler Actuates Ë likely event of a fire in the basket and ensuing sprinkler actuation, the three wire relay drops out, the basket stops rotating and the unload door releases. The sprinkler system (FIGURE 1) must be manually reset and the machine checked for obvious and hidden damages before being returned to service.
- Page 6 R emoving Goods Ê Ë A t the Control Panel Master switch ON. WAITING FOR LOAD Display= ****************** Move the Dryer Load Allowed switch (FIGURE 3) to NO. This tells the shuttle not to deliver a new load of goods to the dryer. (Although this switch is duplicated on the function switch panel next to the unload door, it is possible for the shuttle to send a new load to the dryer immediately, before an operator could reach the panel).
- Page 7 After the power up sequence, the display shows Accesses the Manual Menu. Selects TEST SPRINKLER MENU. Ë For Quick Return to Run Mode from SPRINKLER TEST MENU Display returns to Display returns to Enables the sprinkler funtion. Commands sprinkler ON, operator signal...
- Page 8 T esting Sprinkler Manual Operation See FIGURE 2 during these procedures. Test sprinkler by manually running any drycode that calls for heat, then pulling the manual trip handle. Before beginning, turn OFF water valve. This prevents water from flooding the machine during this test.
- Page 9 Momentarily turn ON water valve, and confirm that water flows from the sprinkler openings in basket. Reset the sprinkler reset handle to reset the system. Turn ON water valve.
