Shenzhen SX-MX48IR-70 Quick Start Manual

Hdmi matrix 4x4group (hdmi&hdbaset)
Hide thumbs

Advertisement

Quick Links

Download this manual
HDMI Matrix
4x4Group(HDMI&HDBaseT)
SX-MX48IR-70
Features
•Incorporates HD Base-T technology.
•Any Four Sources to Any Four Displays,Each port supports HDMI or DVI inputs.
•The four outputs are all include one HDMI-A output port and one HDBT output port,
They can output simultaneously.
•Support high definition resolutions 1080p, 1080i, 720p and other standard video formats.
•Extends HDMI up to 228 feet (70 meters) using one CAT5e (or better) cable
•Supports high bit-rate audio formats (Dolby True-HD / DTS Master Audio)
•Switching modes: panel buttons, IR system , RS232 and Ethernet.
•IR system could control the sources from the sinks or control the sinks from sources
•HDCP compliant.
•Support 3D.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SX-MX48IR-70 and is the answer not in the manual?

Questions and answers

Related Manuals for Shenzhen SX-MX48IR-70

Summary of Contents for Shenzhen SX-MX48IR-70

  • Page 1 HDMI Matrix 4x4Group(HDMI&HDBaseT) SX-MX48IR-70 Features •Incorporates HD Base-T technology. •Any Four Sources to Any Four Displays,Each port supports HDMI or DVI inputs. •The four outputs are all include one HDMI-A output port and one HDBT output port, They can output simultaneously.
  • Page 2 TABLE OF CONTENTS Package Contents Dimensional drawing Speci cations Panel Descriptions Connecting and Operating Typical Application Maintenance Product Service Warranty Packing contents 1) Main Unit: 4x4 HDMI Matrix 2) Power supply DC 12V 3A 3) Remote Controller 4) IR-RX cable x 5PCS 5) IR-TX cable x 4PCS 5) M3x5 Screw x 6PCS 6) Operating Instructions...
  • Page 3 -5 to +35 C(+23 to +95 F) 5 to 90%RH (No Condensation) 225MHz/6.75Gbps Up to 1080p@60Hz@36 b/pixels, support 3D HDMI receptacle RJ45 Power DC receptacle IR Extender 1080P 228FT/70m over single CAT5E/6 cable 110-240V/ 12VDC power supply 20Watts Cold-Rolled (Cold Rolled) Steel W442.5xH170xT44.5mm 2450g Use CAT5e&CAT6 cabling(stranded and solid core types.
  • Page 4 Front Panel Four groups LEDs for each output port IR windows Power ON/OFF Assembly ear Rear Panel IR-TX IR-RX 3 4 5 Ethernet port RS232 port DIP Switch Power input IR extender control Output port (HDMI and HDBaseT ) HDMI input ports IR-TX ports IR-RX ports Connecting and operating...

  • Page 5: Front Panel Control

    Operation 1. Front panel control The HDMI matrix front panel control for switching inputs to the various outputs. There are four groups of LEDs for each output port. The LED lit on the position means that the output port selects this input as its source. 2.
  • Page 6 This function can be disabled or enabled. Enable the function: press the output2 selection button and the output4 selection button at the same time for about 3 seconds. After all the output1 LEDs and the output2 LEDs flash once, the function is enabled. Disable the function: press the output2 selection button and output4 selection button at the same time for about 3 seconds.
  • Page 7 Control the sources from the sinks Step1 : Connect the HDMI input sources to the Matrix. Step2: Connect 4pcs IR TX cables to the IR-TX sockets on the matrix, connect 4pcs IR RX cables to the IR RX sockets on the receivers. Step3 :affix the IR emitter to the IR window of the HDMI source which connected to the related input port .
  • Page 8 2.1 Receive Window The “receive window” will show the message received from matrix. When you click the Control Buttons (see step 4) or send Control Command (see 2.3) to matrix, it will send out the message about “operation results” as right windows: 2.2 Status Button Click this button to read the status of Matrix.
  • Page 9 3 The Com Status 3.1 connect state. Connect state shows the com open or not. If it is open, the state is green. Otherwise, the state is red. 3.2 com select. Select which com you will use. Connect button. The word on this button will change when the connection state changes. If the word is “Disconnect”, then click this button, the com will be closed.
  • Page 10 C. select the device and press “web browser” to enter the web control window. D. enter the password “0000000000” E.WEB control.
  • Page 11 Switch for EDID setting. (Factory default setting: DIP in ‘010’ mode, EDID are all 1080p and stereo.) Position ID Function copy HDMI Sink's EDID to its current selection of input port (note1) 1080P 3D stereo (note2) 1080p stereo (Using Embedded EDID) (note3) 1080i stereo (Using Embedded EDID) (note4) 1080p5.1(Using Embedded EDID) (note5) 1080p 7.1(Using Embedded EDID) (note6)
  • Page 12 Examples for EDID setting: How to reset EDID to factory default setting? Because the default EDID is 1080p and stereo. So just set DIP to ‘010’ and power on the matrix, all the EDID for input ports will be set to 1080p and stereo. After reset the EDID data, the DIP switches can be set to ‘000’...
  • Page 13 Below is the diagram for the some usage examples. Blue-ray player HDMI matrix (Support 1080p (Support 1080p (Support 1080i 7.1 Audio) stereo audio) stereo audio) DIP:000 Video:1080i Video:1080i Video:1080i Auto Mix Audio:Stereo Audio:Stereo Audio:Stereo DIP:001 Video:1080P Video:1080P Video/Audio: Copy AVR’S EDID Audio: Audio:7.1 Unsupported...
  • Page 14 HDMI cable Cat5e cable IR cable Blue-ray player Xbox Sink remote HDMI matrix Receiver Receiver Receiver Receiver Matrix remote Source remote Source remote Source remote...
  • Page 15 RS-232 and Telnet Commands (The symbol "_ " in the belowing command means : Press the space key ) command feedback description cir_09\r\n Output 1 select input 1 cir_1D\r\n Output 1 select input 2 cir_1F\r\n Output 1 select input 3 cir_0D\r\n Output 1 select input 4 cir_17\r\n...
