Installation Guide
for CSUN PV Module
China Sunergy (Nanjing) Co., Ltd
NO.123，Focheng West Road，Jiangning Economic & Technical development Zone，
Nanjing, China, 211100
Tel: +86-25-5276 6728/5809 6530
E-mail: customer_service@chinasunergy.com
Web：http://www.chinasunergy.com
IEC
Installation Guide
For CSUN PV Module
Version IEC100721
To be a leading company of the renewable category of the world
Advertisement
Table of Contents
Related Manuals for CSUN CSUN295-72M
Summary of Contents for CSUN CSUN295-72M
- Page 1 Installation Guide for CSUN PV Module China Sunergy (Nanjing) Co., Ltd NO.123，Focheng West Road，Jiangning Economic & Technical development Zone， Nanjing, China, 211100 Tel: +86-25-5276 6728/5809 6530 E-mail: customer_service@chinasunergy.com Web：http://www.chinasunergy.com Installation Guide For CSUN PV Module Version IEC100721 To be a leading company of the renewable category of the world...
-
Page 2: Table Of Contents
Contents 1、Purpose of this guide ⑴General ⑵Safety precaution for installing a solar photovoltaic system 2、Product Identification 3、Installation and Operation ⑴Selecting the location ⑵Selecting the proper support frame ⑶Roof mount ⑷Pole mount ⑸Grounding ⑹General installation 4、Wiring and Connection 5、Maintenance and Care 6、Appendix Technique Parameters (Type/Size/ Dimension Drawing /I-V Curves) -
Page 3: Purpose Of This Guide
Installing solar photovoltaic systems may require specialized skills and knowledge. Installation should be performed only by qualified persons. Each module comes with a permanently attached junction box. CSUN can provide customers with fitted cables for ease of installation if desired. Installers should assume the risk of all injury that might occur during installation, including, without limitation, the risk of electric shock. -
Page 4: ⑵Safety Precaution For Installing A Solar Photovoltaic System
N. N is the number of parallel modules .N= Conductor current/Isc, at standard condition, AM1.5, temperature 25℃. We suggest that every series CSUN module string should be fused prior to be connected with other strings. Please refer to the applicable regional and local codes for additional fuse requirements. -
Page 5: Product Identification
Do not wear metallic rings, watchbands, ear, nose, lip rings or other metallic devices while installing or troubleshooting photovoltaic systems. Use only insulated tools that are approved for working on electrical installations. Abide with the safety regulations for all other components used in the system, including wiring and cables, connectors, charging regulators, inverters, storage batteries and rechargeable batteries, etc. -
Page 6: ⑴Selecting The Location
“CSUN” is the short name for China Sunergy (Nanjing) Co., Ltd. The 5th digit refers to the cell manufacturer, ABC used to represent. And the 6th digit refers to the modules manufacturer address, ABC used to represent. The 7th digit refers to the modules production month. ABC used to represent. -
Page 7: ⑵Selecting The Proper Support Frame
According to the design of our installation manual, Final customers could adopt the screw installation method to make the frame supporting. Put the modules on the frame and put on the screws and then combine them firmly after put on all the gaskets. -
Page 8: ⑶Roof Mount
assure the lowest portion of the module is placed high enough so that it is not shaded by plants or trees or damaged by sand and stone driven by wind. (3)Roof mount When installing a module on a roof or building, ensure that it is securely fastened and cannot fall as a result of wind or snow loads. -
Page 9: ⑹General Installation
All module frames and mounting racks must be properly grounded in accordance with the appropriate respective national electrical code. Proper grounding is achieved by connecting the module frame(s) and structural members contiguously one to another using a suitable grounding conductor. The grounding conductor or strap may be copper, copper alloy, or other material acceptable for use as an electrical conductor per respective National Electrical Codes. -
Page 10: Wiring And Connection
Do not lift the module by grasping the module’s junction box or electrical leads. Do not stand or step on module. Do not drop module or allow objects to fall on module. Do not set the module down on any hard surface. To avoid glass breakage, do not place any heavy objects on the module. -
Page 11: Appendix
P156×156 1640×990×50 230W 225W 220W 205W 200W 195W CSUN195-72M M125×125 1580×808×35 190W 185W Specifications of CSUN 295-72M Monocrystalline solar module CSUN Type CSUN 305-72M CSUN 300-72M CSUN 295-72M CSUN 290-72M 285-72M Electrical typical data Pmpp [W] Voc [V] 44.9 44.8 44.6... - Page 12 Isc [A] 8.87 8.80 8.73 8.67 8.60 Vmpp [V] 36.2 36.1 35.9 35.8 35.7 Impp [A] 8.43 8.32 8.22 8.11 7.99 Practical module efficiency 17.73% 17.44% 17.15% 16.86% 16.57% Module efficiency 15.75% 15.49% 15.23% 14.98% 14.72% Maximum system voltage [V] 1000 Voltage temperature coefficient -0.307%/K...
- Page 13 The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C. performance deviation of Pmpp: -/+ 3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: -/+ 10%. certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703. Specifications of CSUN 275-72P Polycrystalline solar module CSUN CSUN...
- Page 14 Isc [A] 8.75 8.67 8.58 8.48 8.40 8.31 Vmpp [V] 35.6 35.4 35.3 35.2 35.0 34.9 Impp [A] 8.15 8.05 7.94 7.82 7.72 7.60 Practical module efficiency 16.55% 16.27% 15.98% 15.70% 15.41% 15.12% Module efficiency 14.98% 14.72% 14.46% 14.20% 13.94% 13.68% Maximum system voltage [V] 1000...
- Page 15 The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C. performance deviation of Pmpp: -/+ 3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: -/+ 10%. certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703. Specifications of CSUN 245-60M Monocrystalline solar module CSUN CSUN...
- Page 16 Isc [A] 8.93 8.86 8.78 8.69 8.62 8.54 Vmpp [V] 30.3 30.2 30.1 30.0 29.8 29.6 Impp [A] 8.58 8.45 8.31 8.17 8.06 7.94 Practical module efficiency 18.14% 17.79% 17.44% 17.09% 16.74% 16.39% Module efficiency 16.02% 15.71% 15.40% 15.09% 14.78% 14.47% Maximum system voltage 1000...
- Page 17 The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C. performance deviation of Pmpp: -/+ 3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: -/+ 10%. certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703. Specifications of CSUN 230-60P Polycrystalline solar module CSUN CSUN...
- Page 18 Practical module efficiency 16.78% 16.44% 16.10% 15.75% 15.41% 15.07% Module efficiency 15.09% 14.78% 14.47% 14.17% 13.86% 13.55% Maximum system voltage [V] 1000 Voltage temperature coefficient -0.292%/K Current temperature coefficient +0.045%/K Power temperature coefficient -0.408%/K Series fuse rating [A] Cells 6×10 pieces polycrystalline solar cells series strings (156mm×156mm) Junction box with 6 bypass diodes Cable...
- Page 19 The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C. performance deviation of Pmpp: -/+ 3%. performance deviation of Voc[V],Isc[A],Vmpp [V] and Impp [A]: -/+ 10%. certified in accordance with IEC 61215, IEC 61730-1/2 and UL 1703. Specifications of CSUN 195-72M Monocrystalline solar module CSUN CSUN...
- Page 20 Impp [A] 5.40 5.32 5.28 5.21 5.17 Practical module efficiency 18.39% 17.94% 17.49% 17.05% 16.60% Module efficiency 16.06% 15.67% 15.27% 14.88% 14.49% Maximum system voltage [V] 1000 Voltage temperature coefficient -0.307%/K Current temperature coefficient +0.039%/K Power temperature coefficient -0.423%/K Series fuse rating [A] Cells 6×12 pieces monocrystalline solar cells series strings (125mm×125mm) Junction box...
- Page 21 Note:mm(inch) × × 10.8(0.43) × × 35(1.38) 9（0.35） FRONT VIEW BACK VIEW 808(31.8) 758(29.83) Note: I-V Curves 1000W/m AM 1.5,1000W/ m 800W/m 600W/m 400W/m 200W/m Voltage/V Voltage/V The electrical data relates to standard test conditions [STC]: 1,000 W/m²; AM 1,5; 25°C. performance deviation of Pmpp: -/+ 3%.
