  • Page 1 DYNAMIX DW-Phone/H User’s Manual...

  • Page 2: Table Of Contents

    Chapter 1 Introduction ........................3 Product Description........................4 1.Features and Specification ....................4 2.Appearance.........................6 Chapter 2 Operating Procedure – LCD Display Configuration ..........9 1.Initialize IP PHONE ........................9 2.LCD Configuration ......................... 11 Chapter 3 Advanced Configurations via Telnet................17 1. [help] command........................17 2. [quit] command........................18 3.
  • Page 3 Download Procedure ......................55 1.LCD Panel Control ......................55 2.Remote Control: Telnet ....................55 3.Web Management......................57...

  • Page 4: Chapter 1 Introduction

    Chapter 1 Introduction The IP PHONE is a full-featured IP-based telephone system, which provides VoIP service on LAN or any IP based environment. By using IP environment for voice communication, company or individual can save lots of expenses and make data and voice network converged.

  • Page 5: Product Description

    Product Description 1.Features and Specification Basic Features: ITU-T H.323 v3 compliance DTMF detection/generation TFTP/FTP software download Remote configuration/reset via Telnet LED indication for system status Speaker, Hold ,Mute , Message , PSTN Network Interface : - Switch Hub inside, providing 2 RJ-45 sockets for 10/100Base-T connection - 1 RJ-11 socket for PSTN connection Microsoft Net Meeting v3.0 compatible SNTP (Simple Network Time Protocol)
  • Page 6 LCD: 2 lines, 24 character Dot Matrix display. Indicator messages of HOLD, MUTE, PSTN, Directed Line 1~10. Display current date and time. Display of call duration. Audio features: Codec -- G.711 a/µlaw, G.723.1 (6.3Kbps),G.729, G.729a VAD (Voice Activity Detection), CNG (Comfort Noise Generate) G.168/165-compliant adaptive echo cancellation Dynamic Jitter Buffer Bad Frame Interpolation...

  • Page 7: Appearance

    2.Appearance 1.Front View and Keypad function ♦ C: Cancel and Clear ♦ : Move to left /previous and right/next . ♦ OK: Press OK to confirm the modification. ♦ Direct Line (DL) Button 1 – 10: User press DL button to do speed dial according to phone book data 1-10 (please refer to LCD configuration-Phone Address Book or Advanced Configurations via Telnet-[pbook] command ).
  • Page 8 “W” ; “X” ; “Y” ; “Z” ; “9” “-“ ; “?” ; “*” “0” “_” ; “@” ; “#” ♦ MUTE: Mute the voice of MIC and let others can’t hear from user in communication. ♦ PSTN: Press PSTN to switch IP PHONE as PSTN or IP Phone Mode. In PSTN mode, “PSTN”...
  • Page 9 only in IP Phone mode. 2.Back View ♦ DC 9V: DC 9V power input outlet ♦ LAN: RJ-45 connector, connected directly to the Hub through the straight CAT-5 cable. ♦ PC: RJ-45 connector, connected directly to the PC through the straight CAT-5 cable ♦...

  • Page 10: Chapter 2 Operating Procedure - Lcd Display Configuration

    1 RJ11connector RJ11 connector is for connecting IP PHONE with PSTN. RJ11connector Chapter 2 Operating Procedure – LCD Display Configuration 1.Initialize IP PHONE 1. When power on the IP PHONE, the LCD screen shows as below. IP-Phone Board Start Booting 2.
  • Page 11 PHONE is in GateKeeper Mode, and when IP PHONE is connected to SNTP server, on LCD will show current time from SNTP server. 5. After pressing the PSTN button, the GK word will be replaced by PSTN. Then IP PHONEis in PSTN Mode. Please notice that in PSTN mode user must plug PSTN line in RJ-11 port.

  • Page 12: Lcd Configuration

    2.LCD Configuration User can set the following 10 configurations manually by operating the commands displayed on LCD. Note: Any configurations that have made for the IP PHONE, user has to do Reboot in the selection 1→5 “Reboot”. 1. System Configuration (mandatory, protected by password) Please Enter Password: User must key in password to enter this menu, selections under this command are all important ones, which can only be configured by administrators.
  • Page 13 User has to offer one available GateKeeper server IP Address and set this IP Address on the IP PHONE keypad. (7) Second GateKeeper IP PHONE provide alternative GateKeeper feature, if IP PHONE can’t register to Main GateKeeper for 10 times, it will try to register to the Second GateKeeper.
  • Page 14 security token feature, IP PHONE has to set a RRQ/ARQ authentication token password, which is provided by GateKeeper manager. IP PHONE can’t work normally with this GateKeeper unless Token Password is set. (12) GRQ Option To set auto discovery function OFF or ON. If this function is enabled and IP address of GateKeeper is set as 255.255.255.255, IP PHONE will multicast to search a GateKeeper on network with configured GateKeeper ID(please refer to (12)Gatekeeper ID);...
  • Page 15 (5) Start Download Press OK to start download new application rom file. After download is finished, IP PHONE will automatically reboot. (6) Firmware Version Show versions of all rom files and hardware. Note: 1.Download via LCD command can only upgrade new application rom file. 2.If IP PHONE fails to upgrade via LCD menu, IP PHONE will automatically reboot.
  • Page 16 (7) Line Number 7 (8) Line Number 8 (9) Line Number 9 (10) Line Number 10 Note: User can set six zero “000000” on LCD to disable this number and the number after this one. Ex. Line Number 1-5 are configured, if user set Line 3 as “000000”, Line number 3-5 will be disabled.
  • Page 17 (2).Deactivate : choose under which situation to deactivate forward function. After selection, please press OK , then user can see LINE NUMBER of the endpoint which is already configured to forward to, now press OK again. Note: The number that user prepares to forward to is E.164 number which is registered on the GateKeeper.

  • Page 18: Chapter 3 Advanced Configurations Via Telnet

    Chapter 3 Advanced Configurations via Telnet After initializing the IP PHONE IP Address setting (please refer to LCD Configuration: 1.Connect Configuration), user can enter into configuration mode via telnet. There are 18 commands listed below. Note: 1.After user enter IP PHONE configuration via telnet, please use login : ”root”, password : ”press enter”...

  • Page 19: Quit] Command

    2. [quit] command Type quit/exit/close will logout IP PHONE and Telnet Program. 3. [reboot] command After typing commit command, type reboot to restart the IP PHONE . Sometimes after user type reboot, on terminal screen will display :"Data modified, commit to flash rom?", which means IP PHONE will record call history or not.(ex. REDIAL , outgoing and incoming call data) 4.

  • Page 20: Ifaddr] Command

    6. [ifaddr] command Configure and display the IP PHONE IP information. 1. -ip, -mask, -gate: Set IP PHONE IP Address, subnet mask and default gateway respectively. 2. -dhcp: When DHCP function enables (ifaddr –dhcp 1), IP PHONE will automatically search DHCP server after execute the commit and reboot command. Note: After IP PHONE catch a dynamic IP address form DHCP server, user can see this IP address on LCD connect configuration.

  • Page 21: Time] Command

    7. [time] command When sntp server is established as well as the sntp function of IP PHONE is enabled, type time command should show the current time what is retrieved from the assigned sntp server. Note: Please refer to the Chapter 4.6 [ifaddr] command to configure sntp server..

  • Page 22: Pbook] Command

    9. [pbook] command The command is for Peer-to-Peer Mode use only. Therefore, VoIP products such as IP PHONE that support Peer-to-Peer Mode are also available to be addressed on the IP PHONE phone book. 1.-print: display phone book data. User can print all data in phone book by command (pbook –print).

  • Page 23: Ddns] Command

    10.[ddns] command This function is for Dynamic Domain Name Server service. Once user register to one DDNS server, he can specify domain name for the IP PHONE. When IP PHONE reboot, it will automatically update it’s IP address to DDNS server. In this way, even IP PHONE is using dynamic IP address, other endpoint can locate this IP PHONE by it’s domain name.

  • Page 24: Pppoe] Command

    PHONE will update DDNS data immediately. (ddns –force “IP address of IP PHONE”) Note: 1. For now we only support DDNS server as www.dyndns.org and www.3322.org. 2. User must register to DDNS server first, and specify user name and password in ddns -id and ddns –passwd.

  • Page 25: Sysconf] Command

    12.[sysconf] command This command displays the system information and configuration. 1. -print: display system overall information and configuration. 2. -plan: It is for setting dial numbering plan. While e164 number is three digits, the plan should be set as 3 or 0. The plan 0 is for any positive digits use. Note: Before change to Peer-to-Peer mode from GK mode, please remember to set dial plan as 0, or it may works not normally in P2P mode.

  • Page 26: H323] Command

    13. [h323] command 1. –print: display H.323 stack information and configuration. 2. –mode: configure IP PHONE as GateKeeper or Peer-to-Peer Mode. Usage:h323 –mode 0/1(0 for GateKeeper mode ,1 for Peer-to-Peer mode) 3. –gk: set Main GateKeeper IP address(h323 –gk “xxx.xxx.xxx.xxx”) or URL address( Domain Name Server must be configured.
  • Page 27 third number as “x”, from third to fifth number will be disabled at the mean time. (ex. h323 –e164-2 x) 9. –alias: identify ID for the IP PHONE to register to the GateKeeper (h323 –alias “X”)..The default alias is related to MAC address of IP PHONE, so each IP PHONE has different alias.

  • Page 28: Voice] Command

    Note: 1.Items from 9-20 are for advanced user only. 2.In Peer-to-Peer mode, h323 –print will only display e164, alias, mode, RTP port, and allocated port range. 3.In P2P mode, please dial “#” after press IP address (ex.10.1.1.1 please dial 10*1*1*1#) or e.164 of Phone book (Please refer to chapter 3.9 Pbook command).

  • Page 29: Rbtone] Command

    4. -volume: There are three types can be adjustable, voice volume, input gain and DTMF volume. 5. -nscng: enable or disable sound compression and comfort noise generation. It is only for codec G.723.1. (0 for off ,1 for on) 6. -echo: echo canceller can be made to each specified port. The default value is on to 6 ports.

  • Page 30: Tos] Command

    15. [tos] command TOS/DiffServ (DS) priority function can discriminate the Differentiated Service Codepoint (DSCP) of the DS field in the IP packet header, and map each Codepoint to a corresponding egress traffic priority. As per the definition in RFC2474, the DS field is Type-of-Service (TOS) octet in IPv4.

  • Page 31: Tone] Command

    Signalling Packet: DSCP Code: 10 <====== Configure control signal DSCP code Media Packet: DSCP Code: 10 <====== Configure RTP (voice) DSCP code usr/config$ Or, the ToS function can be configured via Web Browser selection by entering the above DSCP Decimal Code. This command is for setting IP packet TOS values to determine IP Packets priority on network.

  • Page 32: Support] Command

    increase the volume. 17. [support] command 1.-print : display current SUPPORT values configurations. 2.-fstart: enable or disable fast start (support –fstart 0/1 , 0 for disable and 1 for enable.) Note: When fast start function is enabled, if user wants to send DTMF message after connection, IP PHONE will send out Q.931 message.

  • Page 33: Bureau] Command

    18. [bureau] command Type bureau can display commands below. 1. -print: display bureau line information and configuration. 2. -hold: set hold tone generation on or off. If other terminals support H.450 hold function, and execute hold function when connecting with IP PHONE , user will hear hold tone from IP PHONE .

  • Page 34: Passwd] Command

    server is 192.168.4.. rom –app –s 192.168.1.1 –f lp.100(If –server is specified , can just type rom –app –f lp.100) Command rom –print can show current version installed in IP PHONE . 20.[passwd] command For security protection, user has to input the password before entering application user/config mode.
  • Page 35 system. 1. –set: set password of “root” users or “administrator” users. (password –set root/administrator “password”) 2.–clean: clean up password restored before, and user can login :”root/adminstrator”, password:”press enter”. User who requests authorization to execute all configuration commands needs to login with “root”.

  • Page 36: Chapter 4 Web Configuration

    Chapter 4 Web Configuration The initial version for HTTPD web management interface provides user to configure easily rather than command operating method through RS-232 / TELNET. The configuration function and step is similar with the way through command line. Basically this version is not the finalized version for web interface.

  • Page 37: Step 1. Browse The Ip Address Predefined Via Keypad Or Telnet

    Step 1. Browse the IP Address predefined via Keypad or TELNET Step 2. Input the login name and password Login name: root / administrator Password: None (just press Enter in default value)

  • Page 38: Step 3. The Web Interface Main Screen

    Step 3. The web interface main screen Step 4. Start configure Most of all commands displayed in console / telnet are transfer to web interface. The most important commands are Network Interface, H323 Information, Commit Data Reboot System. The method is as the same as command mode.

  • Page 39: Network Configure

    1.Network Configure Please refer to chapter 3.6 [ifaddr] command. DHCP: Enable / Disable to DHCP mode IP Address: Set IP Address Subnet Mask: Set the Subnet Mask Default gateway: Set Default routing gateway Domain Name Server: Set Domain Name Server IP address SNTP: Enable / Disable the Simple Network Time Protocol SNTP Server Address:...
  • Page 40 to input any values. If behind the dynamic WAN IP Address situation please configure as GK mode and select special Gatekeeper, please refer to your vendor.

  • Page 41: H323 Configure

    2. H323 Configure Please refer to chapter 3 [h323] command Mode: Select GK mode or Peer-to-Peer mode Gatekeeper IP Address: Set Gatekeeper IP Address Gatekeeper IP: Set Redundancy Gatekeeper IP Address Gatekeeper Id: Set GateKeeper ID Gatekeeper Discovery: Enable/Disable GRQ function Registered E.164 Number-01: Set 1 phone number...
  • Page 42 Registered E.164 Number-09: Set 9 phone number Registered E.164 Number-10: Set 10 phone number Registered H.323 ID: Set Registered Alias as H323 ID Token Password: Set Token password for H.235 security or LCD menu use. User can clean this password via web configuration, so that will be no need to enter any password when entering LCD menu.

  • Page 43: System Configure

    3. System Configure Please refer to chapter 3 [sysconf] command Keypad Type: Select different DTMF Keypad Type (For Advanced User) Dial Plan: Set DTMF digit limitation (0 is for any digits) Call Alive: Enable the function to check connection (Both side must support) Inter Digit Time: Set the DTMF inter digit time (second) Digit Type of End of Dialing:...

  • Page 44: Pppoe Configure

    4. PPPoE Configure Please refer to chapter 3 [pppoe] command Device: Enable/Disable PPPoE function User Name: Set PPPoE Connection User Name Password: Set PPPoE Connection password Reboot After Remote Host Disconnection: Enable/Disable auto reboot after PPPoE disconnection Other items: After PPPoE connection established, related information will be displayed...

  • Page 45: Ddns Configure

    5. DDNS Configure Status: to enable/disable DDNS function Server: to choose one DDNS server, on which user has already registered. (Now only one DDNS server is available---www.dyndns.org) Localhost Name: to set the registered Domain Name of IP PHONE User ID: to set login ID of registered account to log in DDNS server User Password: set password of registered account to log in DDNS server...

  • Page 46: Voice Configure

    6. Voice Configure (For Advanced User) Please refer to chapter 3 [voice] command Codec Priority: It got wrong order with “Frame Size”. Select the packet size in sending process. (For Advanced User) Sending Packet Size: Select the Codec Priority. (For Advanced User) G.723 Silence Suppression: Enable / Disable (For Advanced User)
  • Page 47 7. Tone Configure (For Advanced User) Please refer to chapter 3 [tone] command Busy Tone Reorder Tone Ring Tone 1 Ring Tone 2 Dial Tone Set the above tone Frequency, Level and On/Off time...

  • Page 48: Bureau Configure

    8. Bureau Configure Please refer to chapter 3 [bureau] command Hold Tone Generation (using PCM file): Enable/Disable hold tone generation...

  • Page 49: Support Functions

    9. Support Functions (Both side must support) Please refer to chapter 3 [support] command Fast Start: Enable to do Fast Start H.245 Tunneling: Enable to open H.245 Tunneling H.245 Separate Channel: Enable/Disable open H.245 channel after fast start connection...

  • Page 50: Dscp Configure

    10. DSCP Configure Please refer to chapter 3 [tos] command Set Signal or RTP Packet DSCP value: Assured Forwarding (AF) PHB: Select Delay priority and Drop Precedence Expedited Forwarding (EF) PHB: Select TOS value as EF Default: Select TOS value as 0 User Assign Special DSCP Code: User can set other unspecified value here.
  • Page 51 11. Phone Book (For Peer-to-Peer mode only) Please refer to chapter 3 [pbook] command User can specify 20 sets of phone book via web interface. Input the Name, IP Address and E.164 No. of the destination device.
  • Page 52 12. Password Please refer to chapter 3 [password] command First select login name as root or administrator, then enter current password , new password and confirm new password again.

  • Page 53: Firmware Upgrade

    13. Firmware Upgrade Please refer to chapter 3 [rom] command TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Server IP Address: Set FTP server IP address FTP Login: Set FTP login name and password...

  • Page 54: System Command

    14. System Command Press CLEAN will clean all configurations of IP PHONE and reset to factory default value. Please be noted: Once execute this function, user must re-configure all commands all over again. Press reboot will reset IP PHONE.
  • Page 55 15. Version Information Display current version list.

  • Page 56: Chapter 5 Upgrade The Ip Phone

    Chapter 5 Upgrade the IP PHONE IP PHONE supports three methods to upgrade the new version. all methods are necessary to prepare the TFTP program on the host PC as TFTP server. After installing TFTP program on one PC and connecting to network, IP PHONE is ready to be upgraded. 1.
  • Page 57 1. -print: show versions of all rom files. 2. -app,-boot, -dsptest, -dspcore, -dspapp, -rbpcm and -htpcm: upgrade main boot code, main application code, DSP testing code, DSP kernel code, DSP application code, Ring Back Tone PCM file and Hold Tone . 3.

  • Page 58: Web Management

    3.Web Management Please refer to chapter 3 [rom] command TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Server IP Address: Set FTP server IP address FTP Login: Set FTP login name and password Target File Type:...
