Dynamix DW-Phone S User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D
y
n
D
y
n
D
W
-
P
D
W
-
P
U
s
e
r
M
U
s
e
r
a
m
i
x
a
m
i
x
h
o
n
e
/
h
o
n
e
/
a
n
u
a
l
M
a
n
u
a
l
S
S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW-Phone S and is the answer not in the manual?

Questions and answers

Related Manuals for Dynamix DW-Phone S

Summary of Contents for Dynamix DW-Phone S

  • Page 2: Table Of Contents

    Chapter 1 Overview of the Dynamix DW-Phone/S 3 1. Hardware Overview ....................4 1.Front View and Keypad function ................4 2.Back View ......................7 3.Specification of connector ..................7 2. Software Features and Specification ................9 Chapter 2 Configuring the SIP-Phone through LCD Phone menus 1.
  • Page 3 13. [sip] command ......................44 14. [security] command ....................45 15. [voice] command ....................46 16. [tos] command ......................47 17. [rom] command....................... 48 20. [passwd] command....................49 Chapter 5 Upgrading Software on the SIP-Phone 51 1.From LCD Phone Menu..................... 51 2.

  • Page 4: Chapter 1 Overview Of The Dynamix Dw-Phone/S

    When external power is down, it can be a Plain Old Telephone set (POTs). It provides internal high-quality speakerphone, programmable keys and feature buttons. Dynamix DW-Phone/S also embedded with a dot matrix of two lines 24 characters LCD, which can display date and time, calling party name, calling party number, and digits dialed...

  • Page 5: Hardware Overview

    Note: (**): May be not available right now, please contact with your distributor. 1. Hardware Overview 1.Front View and Keypad function ♦ LCD: 2 lines, 24 character Dot Matrix display. ♦ C: Jump out current LCD menu. ♦ : Move to previous selection or clear previous data. ♦...
  • Page 6 according to phone book data from 1-10 (please refer to LCD configuration-3.Phone Book; Advanced Configurations via Telnet- 10.[pbook] command, or Web Configuration-Phone Book chapter. ♦ Number 1 –10, * and #: The function is as the same as the general phone set. Corresponding list of keypad and symbol: “1”...
  • Page 7 ♦ MESSAGE and its indicated LED light: When having missed incoming calls, the MESSAGE LED will be flashing. User can check the information of missed calls by pressing the MESSAGE button. (**) ♦ TRANSFER: 1. Transfer a call to the third site. When A and B are in communication, A wants to transfer this call to C, A can press TRANSFER button, now B will hear hold tone, and A will hear dial tone, then A can press phone number of C, after C picks up, A can talk with C, after A hangs up, B and C can be connected.

  • Page 8: Back View

    2.Back View ♦ DC 9V: DC 9V power input outlet ♦ LAN: RJ-45 connector, connected directly to the Hub through the straight CAT-5 cable. ♦ PC: RJ-45 connector, connected directly to the PC through the straight CAT-5 cable ♦ Line: RJ-11 connector, connected directly to the PSTN analog line. Note: There are two LED indicated lights: LINK/ACT and 10/100 for LAN port and PC port.
  • Page 9 RJ11connector...

  • Page 10: Software Features And Specification

    2. Software Features and Specification Application: ISP/ITSP (Internet Telephony Service Provider) IP-PBX with office telephony services Multi-nation enterprise communication SOHO Telephony Calling Features Call Hold Call Transfer Call Forward (**) 10 sets last number Redial Ten configurable speed dials Network Supported Fixed IP Dynamic Host Configuration Protocol (DHCP) PPPoE connection (When PPPoE disconnect, SIP-Phone can automatically...
  • Page 11 Provisioning and Configuration SIP (RFC3261) compliance LCD configuration password protection (**) Provide Proxy Mode or Peer-to-Peer Mode (Non Proxy Server needed) selection Ring tone, Speaker and Handset volume adjustable Dial path selection (PSTN or IP mode) (**) Support DNS server inquiry Management Features: Software Upgrade: TFTP/FTP download Three easy ways for system configuration...

  • Page 12: Chapter 2 Configuring The Sip-Phone Through Lcd Phone Menus

    Chapter 2 Configuring the SIP-Phone through LCD Phone menus Note: 1. After any configuration is made for the SIP-Phone, user has to do Reboot in the selection 7 “Reboot”. 2. We suggest user to set IP address via LCD menu 5 2.3.4.5 first, then go to chapter 3 to do other detail configurations via web browser.
  • Page 13 Please notice that user must plug PSTN line in RJ-11 port when SIP-Phone is in PSTN mode. (**) IP-Phone PSTN 10:10:10 AM 6. Press to enter configuration mode then press OK button to enter sub menus; press C can jump out current menu to previous level. Call List (**) Forward Type Phone Book...

  • Page 14: Lcd Menu Configuration

    2. LCD Menu Configuration User can set the following configurations by LCD keypad. Note: 1. Press TRANSFER before input data can switch characters to be capital or lowercase. 2. Press SPEED before input data can switch input mode as character mode or IP mode;...
  • Page 15 Deactivate No Response Forward function. (3) Unconditional It is included the above two types. Whether the SIP-Phone is in which status, calls will be automatically forwarded to the assigned phone number. A. Activate Enter a forwarded phone number to activate Unconditional Forward function.
  • Page 16 (1) Mode: Display current network connection mode of SIP-Phone to be Static (Fixed IP), DHCP, or PPPoE. (2) IP, Mask, Gateway: display current IP information. Network Mode Set network mode of SIP-Phone to be Static (Fixed IP), DHCP, or PPPoE. IP address Set IP address of SIP-Phone.
  • Page 17 Behind IP-Sharing (1) If SIP-Phone is behind IP sharing or NAT device, on IP sharing must enable “DMZ” function or set “Virtual Server” to open ports (UDP port: 5060 and 16384). (2) User must enter public IP address of IP sharing. 6.
  • Page 18 Set Line Number of SIP-Phone to register to Proxy Server. C. Password Set User Password of SIP-Phone to register to Proxy Server. This configuration is not necessary, if Proxy server doesn’t request client to set password, user only has to set User Name the same as Line Number.

  • Page 19: Chapter 3 Configuring The Sip-Phone Through Web Pages

    Chapter 3 Configuring the SIP-Phone through Web Pages The HTTPD web management interface provides user an easier way to configure rather than command line method through TELNET. The configuration function and steps are similar with the way through command line. Please refer to the chapter 4- Configuring the SIP-Phone through Telnet command lines for more detail information.

  • Page 20: Step 1. Browse The Ip Address Predefined Via Keypad

    Step 1. Browse the IP Address predefined via Keypad Please enter IP address (user have to set via LCD menu first) of SIP-Phone in web browser. If user failed to set IP address via LCD menu, the default IP address of SIP-Phone is 10.1.1.3, user can try to connect to SIP-Phone via this default IP via web interface.

  • Page 21: Step 2. Input The Login Name And Password

    Step 2. Input the login name and password Login name: root / administrator Password (The same with TELNET): Null (just press confirm, no need to key in password in default value) Note: User can set password later in 8.PASSWORD via web interface.

  • Page 22: Step 3. Enter The Web Interface Main Screen

    Step 3. Enter the web interface main screen After enter login name and password, user can see web interface main screen as below. Step 4. Start to configure Most important items are Network Interface, Information, and Phone Book (in Peer-to-Peer mode).

  • Page 23: Network Interface

    1. Network Interface Please refer to chapter 4.7 [ifaddr] command. IP Address: Set IP Address of SIP-Phone Subnet Mask: Set the Subnet Mask of SIP-Phone Default routing gateway: Set Default routing gateway of SIP-Phone Get IP Mode: User has to set SIP-Phone to use which network mode. 1.
  • Page 25 SNTP: Enable / Disable the Simple Network Time Protocol function SNTP Server Address: Set SNTP Server Address When SNTP server is available, enable SIP-Phone SNTP function to point to SNTP server IP address so that SIP-Phone can get correct current time. GMT: Set time zone for SNTP Server time User can set different time zone according to the location of SIP-Phone.

  • Page 26: Sip Information

    2. SIP Information Please refer to chapter 4.13 [SIP] command Run Mode: Select SIP-Phone to work under Peer-to-Peer mode or Proxy mode. Proxy IP Address: Set Proxy IP Address or URL address (Domain Name Server must be configured. Please refer to Network Interface). Outbound Proxy: Set IP Address or URL address (Domain Name Server must be configured.
  • Page 27 as Account Name @”IP address of Proxy”, if user set prefix as abc, SIP-Phone will set out as abc123@”IP address of Proxy”. This function is for special proxy server. Line Number: identify one number for the SIP-Phone to register to the Proxy. Line Account: set user name of SIP-Phone for registering.

  • Page 28: System Configuration

    3. System Configuration Please refer to chapter 4.12 [sysconf] command Keypad DTMF Type: set DTMF type. User can select DTMF type SIP-Phone transmits. RFC2833 Payload Type: change RFC2833 Payload type. This is for special request from the other site, if RFC2833 payload type of 2 sites are different, it may cause some problem of connection.

  • Page 29: Pppoe Configure

    4. PPPoE Configure Please refer to chapter 4.11[pppoe] command User Name: Set PPPoE authentication User Name. Password: Set PPPoE authentication password. Reboot After Remote Host Disconnection: Enable/Disable auto reboot after PPPoE disconnection If user enables this function, after PPPoE being disconnected, SIP-Phone will automatically reboot to re-connect, and after reboot, if SIP-Phone still can’t get contact with server, SIP-Phone will keep trying to connect.

  • Page 30: Voice Setting

    5. Voice Setting Please refer to chapter 4.15 [voice] command Codec Priority: set codecs priority in order. Please notice that user can set from 1 to 5 codecs as their need. For example, user can only set first priority as G.723.1, and set the others as x, that means only G.723.1 is available.

  • Page 31: Phone Book

    6. Phone Book Please refer to chapter 4.10 [pbook] command Add Data: User can specify 20 sets of phone book via web interface. Please input index, Name, IP Address and E.164 number of the destination device. Delete Date: User can delete any configured phone book data by index.

  • Page 32: Dscp Configure

    7. DSCP Configure Please refer to chapter 4.16 [tos] command Set Signal or RTP Packet DSCP value: Assured Forwarding (AF) PHB: Select Delay priority and Drop Precedence Expedited Forwarding (EF) PHB: Select TOS value as EF Default: Select TOS value as 0 User Assign Special DSCP Code: User can set other unspecified value here.
  • Page 33 DROP Precedence Class #1 Class #2 Class #3 Class #4 Low Drop Precedence (AF11) (AF21) (AF31) (AF41) 001010 010010 011010 100010 Medium Drop Precedence (AF12) (AF22) (AF32) (AF42) 001100 010100 011100 100100 (AF13) (AF23) (AF33) (AF43) High Drop Precedence 001110 010110 011110 100110...

  • Page 34: Password

    8. Password Please refer to chapter 4.18 [password] command Change: First select login name as root or administrator, then enter current password, new password and confirm new password again to set new password. Abort: Press abort will clean all inputs.

  • Page 35: Rom Configuration

    9. Rom Configuration Please refer to chapter 4.17 [rom] command FTP/TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Login: Set FTP login name and password Target File Type: Select which sector of SIP-Phone to upgrade Note:...

  • Page 36: Flash Clean

    10. Flash Clean Press CLEAN will clean all configurations of SIP-Phone and reset to factory default value. Note: User must re-configure all commands all over again (except Network Configure) once execute this function,...

  • Page 37: Commit Data

    11. Commit Data Press COMMIT to save all configurations. Please remember to commit data before reboot SIP-Phone.

  • Page 38: Reboot System

    12. Reboot System Press reboot will reset SIP-Phone. Note: To execute reboot via web browser, SIP-Phone will automatically save all data before reboot. To execute reboot via TELNET command, please remember to do Commit Data before Reboot System.

  • Page 39: Chapter 4 Configuring The Sip-Phone Through Telnet Command Lines

    Chapter 4 Configuring the SIP-Phone through Telnet command lines After setting the IP Address of SIP-Phone and reboot, (please refer to LCD Menu: 5-3.4.5), user can enter into Telnet command lines. Note: 1. After user enter SIP-Phone configuration via telnet, please use login: ”root”, password: null, press enter to enter command lines.

  • Page 40: Quit] Command

    2. [quit] command Type quit/exit/close will logout SIP-Phone and Telnet Program. 3. [debug] command This command is for engineers to debug system of SIP-Phone. User can add debug flag via command debug –add “debug flags”, and then start debug function via command debug –open.

  • Page 41: Commit] Command

    6. [commit] command Save any changes after configuring the SIP-Phone. 7. [ifaddr] command Configure and display the SIP-Phone IP information. 1. –print: print out all current configurations of ifaddr command. 2. -ip, -mask, -gate: Set SIP-Phone IP Address, subnet mask and default gateway respectively.

  • Page 42: Time] Command

    Note: Some Proxy servers support endpoint behind NAT function, in this case SIP-Phone doesn’t have to enable IP sharing function, please contact with your Proxy Server vendor. 8. –upnp: enable/disable UPnP function. If the IP sharing or NAT device supports UPnP, user can enable UPnP function so that SIP-Phone will automatically connect with NAT device without configuration in SIP Phone and NAT device.

  • Page 43: Pbook] Command

    10. [pbook] command This command is functional both in Proxy mode and Peer-to-Peer mode. In proxy mode, use speed dial or 10 DL button will dial out e.164 number in phone book. In the other hand, in peer-to-peer mode, SIP-Phone will dial out IP address. 1.

  • Page 44: Pppoe] Command

    11. [pppoe] command 1. -print: display all current configurations and information. 2. –id: to set PPPoE authentication user name. 3. –pwd: to set PPPoE authentication password. 4. –reboot: Choose enable or disable this function. If user enables this function, after PPPoE disconnected, SIP-Phone will automatically reboot to re-connect, and after reboot, if SIP-Phone still can’t connect with server, SIP-Phone will keep trying to connect.

  • Page 45: Sysconf] Command

    12. [sysconf] command 1. -print: display all current configurations. 2. -idtime: set the duration(in second) of two pressed digits in dial mode as timed out. If after the duration user hasn’t pressed next number, SIP-Phone will dial out all number pressed. 3.

  • Page 46: Security] Command

    “line number”). Note: In proxy mode please remember to set user account information under security command. 8. –pbsearch: enable/disable phone book search function under Proxy Mode. If user enabled this function, SIP-Phone will search dialed number in phone book to see if there is any matched table before send to Proxy server, and if there is a matched data in phone book, SIP-Phone will make call to related IP address.

  • Page 47: Voice] Command

    15. [voice] command The voice command is associated with the voice codec setting information. 1. -print: display voice codec information and configuration. 2. -send: three voice packet size can be configured as 20 ms, 40 ms or 60 ms.(only 30 and 60 ms for G..723.1) 3.

  • Page 48: Tos] Command

    16. [tos] command TOS/DiffServ (DS) priority function can discriminate the Differentiated Service Code Point (DSCP) of the DS field in the IP packet header, and map each Code Point to a corresponding egress traffic priority. As per the definition in RFC2474, the DS field is Type-of-Service (TOS) octet in IPv4.

  • Page 49: Rom] Command

    011110 ====> 30 (Decimal System) 100110 ====> 38 (Decimal System) 000000 ====> 0 (Decimal System) 1. -print : display all current configurations. 2. –rtptype: set DSCP value of signaling packets from 0 to 63 3. –siptype: set DSCP value of RTP packets from 0 to 63 Note: 1.

  • Page 50: Passwd] Command

    7. –ftp: specify user name and password for FTP download method. For example: User prepares to upgrade the latest app rom file – siplp201.100, the TFTP server is 192.168.4.1.1. rom –app –s 192.168.1.1 –f siplp201.100 Command rom –print can show current version installed in SIP-Phone. 20.
  • Page 51 with “root”. If a user login with “administrator”, two commands are not functional: 1. password –set root: set password of login : “root”. 2. passwd –clean: clean up password restored before, and user can login :”root/administrator”, password: ”press enter”.

  • Page 52: Chapter 5 Upgrading Software On The Sip-Phone

    Chapter 5 Upgrading Software on the SIP-Phone SIP-Phone supports three methods to upgrade the new version. All methods are necessary to prepare the TFTP or FTP program on the host PC as TFTP/FTP server. After installing TFTP/FTP program on one PC and connecting to network, SIP-Phone is ready to be upgraded.

  • Page 53: Web Management

    2. Web Management Please refer to chapter 4.18 [rom] command FTP/TFTP Server IP Address: Set TFTP server IP address Target File name: Set file name prepared to upgrade Method: Select download method as TFTP or FTP FTP Login: Set FTP login name and password Target File Type: Select which sector of SIP-Phone to upgrade Note:...

  • Page 54: Remote Control: Telnet

    3. Remote Control: Telnet Please refer to chapter 4.17 [rom] command 1. -print: show all current configurations and version information. 2. -app,-boot, -dsptest, -dspcore, -dspapp,: upgrade main boot code, main application code, DSP testing code, DSP kernel code, DSP application code, Ring Back Tone PCM file and Hold Tone .
  • Page 55 Command rom –print can show current version installed in SIP-Phone.
