Redcat Racing XTXB Instruction Manual page 10

Off-road Monster Truck&Buggy
07125-RadioTray 07126-Adjust Bushes
(centre)
1P
07130-Front Lower Sus.
07129-Centre Diff.Mount
Arm Holder (B)
2P
07134-Front Upper Sus.
07133-Front/ Rear Lower Sus.
Arm Pins 6*90 Arm Pins 6*60
4P
07137-Front Lower Sus. 07138-Rear Lower Sus.
Arm Pins 5*47.8 Arm Pins 5*62.8
2P
07141-Buffer Aluminium
07142-Buffer Post
Mount
1P
07145-Diff.Joint Cups 07146-Centre Dogbone
Joint Cup
2P
17
&short course Common Parts-
07127-Streeing Mount (L/R) 07128-Roll Cage
6P
2P
07131-Rear Lower Sus. 07132-Front Lower Sus.
Arm Holder (C) Arm Holder (A)
2P 1P
07135-Gear Mount 07136-Wheel Mount
2P 1P
07139-Front Stabilizer bar 07140-Rear Stabilizer bar
1P
2P
07144-Universal Drive Joint
07143-Rear wheel Axle
New length:128mm
Old length:130mm
2P 2P
07147-Diff. Gear(30T) 07148-Diff. Gear(11T) steel
steel
1P 1P
1P
2 Off-road Monster Truck&Buggy
07149-Engine Fix Post(AL.) 07150-Streeing Ball
3P
1P
07153-Shock Upper Ball
(AL.)
4P
1P
07157-Center Front Dogbones
length:152mm
2P
2P
07060-Body post
1P For truck only 1P
07364-Wheels Complete
(L/R)
For short course
2P
only 2P
07180-Front Lower Sus.Arm
Pins(screw thread) 5*50.5
2P 2P
&short course
(AL.) 07151-Front Sus.Arm Ball
Length:13mm (AL.) Length:12mm
4P
07155-Wheels Complete
07154-High IntensityWing
For buggy only
1P For buggy only
07158-Center Rear Dogbones 07159-Bearing
length:162mm:
2P
07061-Front Bumper 07362-Front Bumper
For truck only
For short course
only
1P
07065-Wheels Complete (L/R) 07166
For truck only
2P
07181-Rear Lower Sus.Arm
81013-Body Clips
Pins(screw thread) 5*66
2P
Common Parts- 3
07152-Shock lower Ball (AL.)
Length:10mm
4P
4P
07156-Rear Dogbones
New length:133mm
Old length:131mm
2P 2P
19*10*5 85763-Bearing 16*8*5
8P
4P
07363-Rear Bumper
For short course
only
1P
1P 1P 1P
07179-Adjust Bushes
(side)
1P 6P
26001-Engine
( 26CC PRO)
6P 1P
18
