REDCAT-RACING
1/8 BRUSHLESS DESERT TRUCK
MODEL :AFTERSHOCK 8E THREE DIFF
Product Size:
Length:504mm
Width:305mm
Height:165mm
Wheelbase:325mm
Tires size:117*44mm
Ground clearance:33mm
Motor:RC 540 KV:2230
ESC:EZRUN-80A
Instruction Manual
Highlights:
4 Wheel Drive System
Ready Assemble Ready to Run
High Performance RC 540 KV: 2230 Type Brushless Motor, More Power!
Brushless ESC EZRUN-80A
3200 Mah 2x7.4V 20C Li-Po battery
Assembled Chassis(3mm 6061 T6 Aluminum)
Full Function Control
Colored Coil Spring Damped Suspension System
Waterproof and Dustproof Sealed Gearbox
Fast and Easy Assembly and Disassembly of Receiver and Battery Cover
Quality Differential with Four Bevel Gears
Precise Sealed Ball Bearing for the Whole Model
Aluminum Alloy Drive shafts
The fastest and best brushless EP buggy in China!
SAFETY PRECAUTIONS
!
This radio controlled racing car is not a toy!
This high-performance R/C model is recommended for ages 14 and older.
First-time builders should seek the advice of experienced modellers before
commencing assembly.
Take enough safety precautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
www.redcatracing.com
Advertisement
Related Manuals for Redcat Racing AFTERSHOCK 8E THREE DIFF
Summary of Contents for Redcat Racing AFTERSHOCK 8E THREE DIFF
-
Page 1: Safety Precautions
REDCAT-RACING 1/8 BRUSHLESS DESERT TRUCK MODEL :AFTERSHOCK 8E THREE DIFF Product Size: Length:504mm Width:305mm Height:165mm Wheelbase:325mm Tires size:117*44mm Ground clearance:33mm Motor:RC 540 KV:2230 ESC:EZRUN-80A Instruction Manual Highlights: 4 Wheel Drive System Ready Assemble Ready to Run High Performance RC 540 KV: 2230 Type Brushless Motor, More Power! Brushless ESC EZRUN-80A 3200 Mah 2x7.4V 20C Li-Po battery... - Page 7 BS903-003 Shock absorber unit(plastic) 2pcs BS903-010 Suspension arm BS903-008 Upper susp.Arm BS903-007 Body pin 1.5 mount 2pcs BS903-005 Shock tower 2set uint(alum.) 2pcs 6pcs BS903-016 Ball bearing BS903-011 Upper susp.arm BS903-018 Fr.lower susp. BS903-017 C Hub mount-Fr/Rr arm-Lf/Rr w/screw BS903-019 Transverse driver shaft set 2pcs BS903-025 Suspension BS903-026 Front damper...
- Page 8 BS903-092 Washer BS903-091 Washer BS903-094 Double way BS903-089 Pin φ2*10mm BS903-095 Grub screw φ5.2*φ10*0.2 12pcs φ4.2*φ8*0.2 12pcs ball end 6pcs 12pcs M4*4mm 6pcs BS903-106 M3*9.5mm Screw BS903-109 Diff.outdrive BS903-107 Antenna mount BS903-098 Diff.gearbox pin 12pcs BS903-097 Diff.gearbox A/Pin(2*10) 3pcs bulkhead-upper/lower BS903-111 BS903-110 Diff.outdrive BS901-066 M3 locknut 5pcs...
- Page 9 BS803-019 BS803-020 BS803-021 BS803-018 Wire mount BS803-022 Motor mount Centre diff.Unit Centre diff mount Centre Diff Cover BS803-023 Motor gear BS803-025 BS803-024 Brushless BS803-027 Driving/Driven 15T/M3 Grub screw BS803-026 Diff. Unit Diff.gearbox unit motor KV:2230 Gear, Diff.Gear/Bevel gears BS803-028 7.4V/20C B7055W Brushless ESC 80A BS904-003 Bumper 2pcs LiPo battery...
- Page 12 Redcat Racing http://www.redcatracing.com PRINTED IN CHINA NOT RESPONSIBLE FOR TYPOGRAPHICAL ERRORS...
