WARRANTY STATEMENT
During the applicable warranty period, any Total Protection Solutions
device which fails due to defect in materials, workmanship, or any electrical anomaly,
including lightning, shall be repaired or replaced at Joslyn's discretion.
Prior to shipment of any suspect or known defective product to Joslyn a Return Material
Authorization (RMA) number must be obtained. An official Joslyn RMA number and shipping
instructions can be obtained from the distributor where the product was originally pur-
chased. Distributors can obtain the official Joslyn RMA number by contacting the Joslyn
Customer Service Department at 800-647-1911. Products arriving at Joslyn without an
official RMA number will not be accepted and will be returned freight collect to the original
point of shipment.
Products being returned with an official Joslyn RMA number should be shipped by prepaid
freight to the nominated point of return as shown on the RMA documentation.
The Company shall have no liability under this warranty for problems or defects directly or
indirectly caused by misuse of the Product, alteration of the Product (including removal of
any warning labels), accidents, improper installation, application, operation or improper
repair of the Product.
THIS WARRANTY REPRESENTS THE ENTIRE WARRANTY OF THE COMPANY. ALL OTHER
WARRANTIES EXPRESS OR IMPLIED, ORAL OR WRITTEN, INCLUDING, BUT NOT LIMIT-
ED TO, THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE HEREBY DISCLAIMED.
THE LIABILITY OF THE COMPANY, AT ITS SOLE OPTION, UNDER THIS WARRANTY IS
EXPRESSLY LIMITED TO THE REPLACEMENT OR REPAIR OF THE DEFECTIVE PART
THEREOF. IN NO EVENT SHALL THE COMPANY BE LIABLE OR RESPONSIBLE FOR SPE-
CIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND OR CHARACTER, NOR
SHALL ITS LIABILITY EVER EXCEED THE PURCHASE PRICE PAID TO JOSLYN FOR SUCH
DEFECTIVE PRODUCT.
This warranty is not transferable and may only be enforced by the original purchaser. Claims
under this warranty must be submitted to Joslyn within thirty (30) days of discovery of any
suspected product defect.
10 YEAR
10 YEAR
™
PANELTRACK
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
surge protector
™
5900 Eastport Boulevard Richmond, VA 23231-4453 USA
TEL: 800.647.1911 FAX: 804.236.4047 www.joslynsurge.com
PN: MNL1020-PKD
Total Protection
Solutions
PanelTrack
PKD Protector Series:
TK-PK025D-24VDC
30VDC max, 25VAC max, 1ø, 2 Wire + Ground
TK-PK025D-48VDC
60VDC max, 45VAC max, 1ø, 2 Wire + Ground
TK-PK025D-90VDC
90VDC max, 65VAC max, 1ø, 2 Wire + Ground
TK-PK025D-125VDC
150VDC max, 110VAC max, 1ø, 2 Wire + Ground
TK-PK040D-48VDC-LA*
65VDC max, 1ø, 2 Wire + Ground
TK-PK040D-125VDC-LA*
200VDC max, 1ø, 2 Wire + Ground
* Intended for DC applications only
All units come with 18 inches of #14 AWG leads.
™
PANELTRACK
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
PanelTr r ack
TM
Surge
Protective
Device
Installation
Operation and
Maintenance
Manual
®
