Summary of Contents for VHT LEAD 20
- Page 1 LEAD 20 20W Tube-Driven Amplifier User Manual VC-20...
- Page 2 Table of Contents Table of Contents..........3 Product Safety Information......4 Panel Functions..........5 Technical Specifications......... 9...
-
Page 3: Product Safety Information
Product Safety Information Panel Functions (Please refer to Fig. 1 and Fig. 2 for details.) WARNING! Please read ALL Safety & Operating Instruction BEFORE using this product. A. THE FRONT PANEL CAUTION: To avoid the risk of fire or electric shock, please do not expose this product to rain or moisture. Dangerous high voltages are present inside the enclosure. -
Page 4: The Rear Panel
5. Overdrive Level: Adjusts the volume level of Overdrive Channel. B. THE REAR PANEL 6. Bass: Adjusts the low frequency level. Turn this knob clockwise to boost the bass sound, counter clockwise to cut the bass sound accordingly. Center position (straight up) provides no cut or boost. 7. -
Page 5: Technical Specifications
18. Serial/Parellel FX: Allows you to select the desired type of effects loop, parallel or serial. Name/Model VHT 20W Tube-Driven Amplifier / LEAD 20 19. FX Return: This jack is used to receive signal from an external effects or signal processing devices. - Page 6 Notes Notes...
-
Page 7: Limited Warranty Information
Limited Warranty Information This amplifier is warranted, to the original Purchaser, to be free from defects in material and workmanship for a period of one (1) year, excluding the Tubes, which are warranted for ninety (90) days, from the original date of purchase. The manufacturer shall, at its option, either repair or replace the defective product if the product is returned to the original place of purchase.
